AFJ305400VHF Marine Transceiver

INSTRUCTION MANUAL New2001 iM412 VHF MARINE TRANSCEIVER i New2001 FOREWORD Thank you for purchasing this Icom product. The IC-M412 v h f m a r i n e t r a n s c e i v e r is designed and built with Icom’s state of the art technology and craftsmanship. With proper care, this transceiver should provide you with years of trou- ble-free operation. We appreciate you making the IC-M412 your radio of choice, and hope you agree with Icom’s philosophy of “technology first.” Many hours of research and development went into the de- sign of your IC-M412. D FEATURES m Advanced receiver performance m Easy to hear speaker m Built-in DSC meets Class D requirement m Rugged waterproof construction m Favorite channel function m AquaQuake water draining function IMPORTANT READ ALL INSTRUCTIONS carefully and completely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This in- struction manual contains important operating instructions for the IC-M412. EXPLICIT DEFINITIONS WORD DEFINITION R WARNING! CAUTION NOTE Personal injur y, fire hazard or electric shock may occur. Equipment damage may occur. Recommended for optimum use. No risk of personal injury, fire or electric shock. C L E A N T H E T R A N S C E I V E R A N D M I C RO P H O N E THOROUGHLY WITH FRESH WATER after exposure to water including salt water, otherwise, the keys and switches may become inoperable due to salt crystalliza- tion. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incor- porated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries. ii New2001 IN CASE OF EMERGENCY If your vessel requires assistance, contact other vessels and the Coast Guard by sending a Distress call on Channel 16. USING CHANNEL 16 DISTRESS CALL PROCEDURE 1. “MAYDAY MAYDAY MAYDAY.” 2. “THIS IS ...............” (name of vessel) 3. Your call sign or other indication of the vessel (AND 9-digit DSC ID if you have one). 4. “LOCATED AT ...............” (your position) 5. The nature of the distress and assistance required. 6. Any other information which might facilitate the rescue. Or, transmit your Distress call using digital selective calling on Channel 70. USING DIGITAL SELECTIVE CALLING (Ch 70) DISTRESS CALL PROCEDURE 1. While lifting up the key cover, hold down [DISTRESS] for 5 seconds until you hear 5 short beeps change to one long beep. 2. Wait for an acknowledgment on Channel 70 from a coast station. • After the acknowledgement is received, Channel 16 is automatically selected. 3. Hold down [PTT], then transmit the appropr iate information as listed above. NOTE A WARNING STICKER is supplied with the transceiver. To comply with FCC regulations, this sticker must be affixed in such a location as to be readily seen from the operating controls of the radio as in the diagram below. Make sure the chosen location is clean and dry before applying the sticker. (p. 36) EXAMPLE WARNING STICKER iii New2001 RADIO OPERATOR WARNING WARNING Icom requires the radio operator to meet the FCC Requirements for Radio Frequency Exposure. An omnidirectional antenna with gain not greater than 9 dBi must be mounted a minimum of 5 meters (measured from the lowest point of the antenna) vertically above the main deck and all possible personnel. This is the minimum safe separation distance estimated to meet all RF exposure compliance requirements. This 5 meter distance is based on the FCC Safe Maximum Permissible Exposure (MPE) distance of 3 meters added to the height of an adult (2 meters) and is appropriate for all vessels. For watercraft without suitable structures, the antenna must be mounted so as to maintain a minimum of 1 meter vertically between the antenna, (measured from the lowest point of the antenna), to the heads of all persons AND all persons must stay outside of the 3 meter MPE radius. Do not transmit with radio and antenna when persons are within the MPE radius of the antenna, unless such persons (such as driver or radio operator) are shielded from antenna field by a grounded metallic barrier. The MPE Radius is the minimum distance from the antenna axis that person should maintain in order to avoid RF exposure higher than the allowable MPE level set by FCC. FAILURE TO OBSERVE THESE LIMITS MAY ALLOW THOSE WITHIN THE MPE RADIUS TO EXPERIENCE RF RADIATION ABSORPTION WHICH EXCEEDS THE FCC MAXIMUM PERMISSIBLE EXPOSURE (MPE) LIMIT. IT IS THE RESPONSIBILITY OF THE RADIO OPERATOR TO E N S U R E T H AT T H E M A X I M U M P E R M I S S I B L E EXPOSURE LIMITS ARE OBSERVED AT ALL TIMES D U R I N G R A D I O T R A N S M I S S I O N . T H E R A D I O OPERATOR IS TO ENSURE THAT NO BYSTANDERS C O M E W I T H I N T H E R A D I U S O F T H E M A X I M U M PERMISSIBLE EXPOSURE LIMITS. Determining MPE Radius T H E M A X I M U M P E R M I S S I B L E E X P O S U R E ( M P E ) RADIUS HAS BEEN ESTIMATED TO BE A RADIUS OF ABOUT 3M PER OET BULLETIN 65 OF THE FCC. THIS ESTIMATE IS MADE ASSUMING THE MAXIMUM P OW E R O F T H E R A D I O A N D A N T E N N A S W I T H A MAXIMUM GAIN OF 9dBi ARE USED FOR A SHIP MOUNTED SYSTEM. iv New2001 TABLE OF CONTENTS FOREWORD .....................................................................................i IMPORTANT ......................................................................................i EXPLICIT DEFINITIONS ...................................................................i IN CASE OF EMERGENCY .............................................................ii NOTE ................................................................................................ii RADIO OPERATOR WARNING ......................................................iii TABLE OF CONTENTS ...................................................................iv PRECAUTIONS ................................................................................v 1 OPERATING RULES ..................................................................1 2 PANEL DESCRIPTION .....................................…

Text truncated - open the document above for the full version.

September 1, 2010 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 80 (Marine in 156.025-157.425 MHz Band) - Non-Broadcast Radio Transceivers. Applicant: ICOM Incorporated Product: VHF Marine Transceiver Model: IC-M412 FCC ID: AFJ305400 Dear Sir/Madam, As appointed agent for ICOM Incorporated, We would like to submit FCC certification application of the above product. Please find report and application documents uploaded your E-filing site. If you have any queries, please do not hesitate to contact us. Yours truly, xutianlu Steven (Xu Tian) Lu Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] September 1, 2010 Icom America, Inc. 2380 116 th Ave. N.E. Bellevue, Washington 98004 USA Attn.: Mr. Masaaki Takahashi Subject: Certification Testing in accordance with FCC 47 CFR, Parts 2, 80 (Marine in 156.025-157.425 MHz Band) - Non-Broadcast Radio Transceivers. Product: VHF Marine Transceiver Model: IC-M412 Dear Mr. Takahashi, The product sample has been tested in accordance with FCC CFR 47, Parts 2, 80 (Marine in 156.025-157.425 MHz) - Non-Broadcast Radio Transceivers Operating , and the results and observation were recorded in the engineering report, Our File No.: ICOM-238F80 Enclosed you will find copy of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, xutianlu Steven (Xu Tian) Lu Authorized Agent Encl. UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NvLap Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

iii New2001 RADIO OPERATOR WARNING WARNING Icom requires the radio operator to meet the FCC Requirements for Radio Frequency Exposure. An omnidirectional antenna with gain not greater than 9 dBi must be mounted a minimum of 5 meters (measured from the lowest point of the antenna) vertically above the main deck and all possible personnel. This is the minimum safe separation distance estimated to meet all RF exposure compliance requirements. This 5 meter distance is based on the FCC Safe Maximum Permissible Exposure (MPE) distance of 3 meters added to the height of an adult (2 meters) and is appropriate for all vessels. For watercraft without suitable structures, the antenna must be mounted so as to maintain a minimum of 1 meter vertically between the antenna, (measured from the lowest point of the antenna), to the heads of all persons AND all persons must stay outside of the 3 meter MPE radius. Do not transmit with radio and antenna when persons are within the MPE radius of the antenna, unless such persons (such as driver or radio operator) are shielded from antenna field by a grounded metallic barrier. The MPE Radius is the minimum distance from the antenna axis that person should maintain in order to avoid RF exposure higher than the allowable MPE level set by FCC. FAILURE TO OBSERVE THESE LIMITS MAY ALLOW THOSE WITHIN THE MPE RADIUS TO EXPERIENCE RF RADIATION ABSORPTION WHICH EXCEEDS THE FCC MAXIMUM PERMISSIBLE EXPOSURE (MPE) LIMIT. IT IS THE RESPONSIBILITY OF THE RADIO OPERATOR TO E N S U R E T H AT T H E M A X I M U M P E R M I S S I B L E EXPOSURE LIMITS ARE OBSERVED AT ALL TIMES D U R I N G R A D I O T R A N S M I S S I O N . T H E R A D I O OPERATOR IS TO ENSURE THAT NO BYSTANDERS C O M E W I T H I N T H E R A D I U S O F T H E M A X I M U M PERMISSIBLE EXPOSURE LIMITS. Determining MPE Radius T H E M A X I M U M P E R M I S S I B L E E X P O S U R E ( M P E ) RADIUS HAS BEEN ESTIMATED TO BE A RADIUS OF ABOUT 3M PER OET BULLETIN 65 OF THE FCC. THIS ESTIMATE IS MADE ASSUMING THE MAXIMUM P OW E R O F T H E R A D I O A N D A N T E N N A S W I T H A MAXIMUM GAIN OF 9dBi ARE USED FOR A SHIP MOUNTED SYSTEM.

September 1, 2010 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 80 (Marine in 156.025-157.425 MHz Band) - Non-Broadcast Radio Transceivers. Applicant: ICOM Incorporated Product: VHF Marine Transceiver Model: IC-M412 FCC ID: AFJ305400 Dear Sir/Madam, As appointed agent for ICOM Incorporated, We would like to submit FCC certification application of the above product. Please find report and application documents uploaded your E-filing site. If you have any queries, please do not hesitate to contact us. Yours truly, xutianlu Steven (Xu Tian) Lu Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] September 1, 2010 Icom America, Inc. 2380 116 th Ave. N.E. Bellevue, Washington 98004 USA Attn.: Mr. Masaaki Takahashi Subject: Certification Testing in accordance with FCC 47 CFR, Parts 2, 80 (Marine in 156.025-157.425 MHz Band) - Non-Broadcast Radio Transceivers. Product: VHF Marine Transceiver Model: IC-M412 Dear Mr. Takahashi, The product sample has been tested in accordance with FCC CFR 47, Parts 2, 80 (Marine in 156.025-157.425 MHz) - Non-Broadcast Radio Transceivers Operating , and the results and observation were recorded in the engineering report, Our File No.: ICOM-238F80 Enclosed you will find copy of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, xutianlu Steven (Xu Tian) Lu Authorized Agent Encl. UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NvLap Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] VHF Marine Transceiver Model No.: IC-M412 FCC ID: AFJ305400 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku Osaka Japan, 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Part 2, Part 80 (Marine in 156.025-157.425 MHz) UltraTech's File No.: ICOM-238F80 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: September 1, 2010 Report Prepared by: Steven (Xu Tian) Lu Issued Date: September 1, 2010 Tested by: Hung Trinh, Technician Test Dates: August 13, 22~24, 2010 The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] FCC Korea KCC-RRL 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R CA2049 FCC Parts 2, 80 (Marine in 156.025-157.425 MHz), Non-Broadcast Radio Transceivers Contents i VHF Marine Transceiver, Model IC-M412 FCC ID: AFJ305400 ULTRATECH GROUP OF LABS File #: ICOM-238F80 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 September 1, 2010 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ......................................................................................................................................... 1 1.1. SCOPE ......................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................... 1 1.3. NORMATIVE REFERENCES ................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .............................................................................................................. 2 2.1. CLIENT INFORMATION .......................................................................................................................................... 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION .............................................................................................. 2 2.3. EUT’S TECHNICAL SPECIFICATIONS .................................................................................................................. 3 2.4. LIST OF EUT’S PORTS ............................................................................................................................................. 3 2.5. ANCILLARY EQUIPMENT ...................................................................................................................................... 3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 4 3.1. CLIMATE TEST CONDITIONS ................................................................................................................................ 4 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS .............................................. 4 EXHIBIT 4. SUMMARY OF TEST RESULTS ............................................................................................................... 5 4.1. LOCATION OF TESTS ..............................................................................................................................................…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M412 FCC ID: AFJ305400, IC: 202D-305400 Plot #1: Radiated Emission Test Setup ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M412 FCC ID: AFJ305400, IC: 202D-305400 Plot #2: Radiated Emission Test Setup ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M412 FCC ID: AFJ305400, IC: 202D-305400 Plot #2: Radiated Emission Test Setup ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M412 FCC ID: AFJ305400, IC: 202D-305400 Plot #3: Radiated Emission Test Setup ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF Marine Transceiver, M/N: IC-M412 FCC ID: AFJ305400, IC: 202D-305400 Plot #4: Radiated Emission Test Setup
