AFJ332200UHF Amateur Transceiver

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: MODIFICATION OF THIS DEVICE TO RECEIVE CEL- LULAR RADIOTELEPHONE SERVICE SIGNALS IS PROHIBITED UNDER FCC RULES AND FEDERAL LAW. INSTRUCTION MANUAL New2001 ID-31A UHF TRANSCEIVER ID-31E UHF TRANSCEIVER The photo shows the ID-31E version. i New2001New2001 FOREWORD Thank you for purchasing this fine Icom product. The ID-31A or ID-31E u h f t r a n s c e i v e r is designed and build with Icom’s superior technology and craftsmanship combining traditional analog technologies with the new digital technology, Digital Smart Technologies for Amateur Radio (D-STAR), for a bal- anced package. With proper care, this product should provide you with years of trouble-free operation. We thank you for making your ID-31A or ID-31E your radio of choice, and hope you agree with Icom’s philosophy of “tech- nology first.” Many hours or research and development went into the design of your ID-31A or ID-31E. FEATURES ❍ DV mode (Digital voice + Low-speed data communication) operation-ready – Text message and call sign exchange – Transmit position data ❍ DR (D-STAR Repeater) mode and repeater list allow you to easily operate using a D- STAR repeater ❍ GPS receiver installed ❍ GPS Logger function allows you to check your route as you move ❍ Waterproof construction (IPX7*) * Only when the supplied battery pack, antenna and jack cover are attached. ❍ microSD card slot Spurious signals may be received in the DV mode near the following frequencies. These are made in the internal circuit and does not indicate a transceiver malfunction. 430.080 MHz, 442.370 MHz For Canada: This device complies with RSS-310 of Industry Canada. Operation is subject to the condition that this device does not cause harmful interference. Cet appareil est conforme au CNR-310 d’Industrie Canada. Son exploitation est autorisée sous réserve que l’appareil ne cause pas de brouillage préjudiciable. New2001 ii FCC INFORMATION • FOR CLASS B UNINTENTIONAL RADIATORS: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal- lation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that inter- ference will not occur in a particular installation. If this equip- ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the inter- ference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and re- ceiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. EXPLICIT DEFINITIONS WORDDEFINITION R DANGER! Personal death, serious injury or an ex- plosion may occur. R WARNING! Personal injury, fire hazard or electric shock may occur. CAUTION Equipment damage may occur. NOTE Recommended for optimum use. No risk of personal injury, fire or electric shock. IMPORTANT READ ALL INSTRUCTIONS carefully and completely before using the transceiver. SAVE THIS INSTRUCTION MANUAL— This instruction manual contains important operating instructions for the ID-31A/ID-31E. CAUTION: Changes or modifications to this device, not expressly approved by Icom Inc., could void your authority to operate this device under FCC regulations. iii New2001New2001 R DANGER! NEVER short the terminals of the bat- tery pack. R DANGER! NEVER Use and charge only specified Icom battery packs with Icom radios or Icom chargers. Only Icom battery packs are tested and approved for use with Icom radios or charged with Icom chargers. Using third-party or counterfeit battery packs or chargers may cause smoke, fire, or cause the battery to burst. R WARNING RF EXPOSURE! This device emits Radio Frequency (RF) energy. Caution should be observed when operating this device. If you have any questions regard- ing RF exposure and safety standards please refer to the Federal Communications Commission Office of Engineering and Technology’s report on Evaluating Compliance with FCC Guidelines for Human Radio Frequency Electromagnetic Fields (OET Bulletin 65) R WARNING! NEVER hold the transceiver so that the antenna is very close to, or touching exposed parts of the body, especially the face or eyes, while transmitting. The transceiver will perform best if the microphone is 5 to 10 cm (2 to 4 inches) away from the lips and the transceiver is verti- cal. R WARNING! NEVER operate the transceiver with an earphone, headphones or other audio accessories at high volume levels. Hearing experts advise against continuous high volume operation. If you experience a ringing in your ears, reduce the volume level or discontinue use. R WARNING! NEVER operate the transceiver while driving a vehicle. Safe driving requires your full attention— anything less may result in an accident. R WARNING! NEVER connect the transceiver to a power source of more than 16 V DC or use reverse polarity. This could cause a fire or damage the transceiver. R WARNING! NEVER operate or touch the trans- ceiver with wet hands. This may result in an electric shock or may damage the transceiver. CAUTION: MAKE SURE the flexible antenna and battery pack are securely attached to the transceiver, and that the antenna and battery pack are dry before attachment. Exposing the inside of the transceiver to water will r…

Text truncated - open the document above for the full version.

UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NvLap Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] November 23, 2011 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Certification Testing in Accordance with FCC CFR 47, Part 15, Subpart B - Scanning Receivers Applicant: ICOM Incorporated Product: UHF Transceiver Model: ID-31A FCC ID: AFJ332200 Dear Sir/Madam: As appointed agent for ICOM Incorporated, we submit the application for certification of the above product. Please review all files uploaded to your electronic filing site. If you have any queries, please do not hesitate to contact us: Yours truly, Dharmajit Solanki Dharmajit Solanki Authorized Agent

UHF Transceiver Model No.: ID-31A FCC ID: AFJ332200 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku Osaka, Japan, 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Part 15, Subpart B, Scanning Receivers UltraTech's File No.: ICOM-285Q_FCC15.121 This Test report is Issued under the Authority of Tri M. Luu, BASc Vice President of Engineering UltraTech Group of Labs Date: November 23, 2011 Report Prepared by: Dharmajit Solanki Issued Date: November 23, 2011 Tested by: Wei Wu Test Dates: Oct. 31 to Nov. 9, 2011  The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected.  This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] FCC Korea KCC-RRL 91038 1309 46390-2049 NvLap Lab Code 200093-0 SL2-IN-E-1119R CA2049 FCC Part 15, Subpart B, Section 15.121 Contents i UHF Transceiver, M/N: ID-31A FCC ID: AFJ332200 ULTRATECH GROUP OF LABS File #: ICOM-285Q_FCC15.121 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 November 23, 2011 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ......................................................................................................................................... 1 1.1. SCOPE......................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) .................................................................................................................. 1 1.3. NORMATIVE REFERENCES ................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .............................................................................................................. 2 2.1. CLIENT INFORMATION .......................................................................................................................................... 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ............................................................................................ 2 2.3. EUT’S TECHNICAL SPECIFICATIONS ................................................................................................................. 3 2.4. LIST OF EUT’S PORTS............................................................................................................................................. 3 2.5. ANCILLARY EQUIPMENT ...................................................................................................................................... 3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 4 3.1. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS............................................. 4 EXHIBIT 4. SUMMARY OF TEST RESULTS ............................................................................................................... 5 4.1. LOCATION OF TESTS.............................................................................................................................................. 5 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ............................................................. 5 4.3. MODIFICATIONS REQUIRED FOR COMPLIANCE............................................................................................. 5 EXHIBIT 5. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS............................... 6 5.1. TEST PROCEDURES................................................................................................................................................. 6 5.2. MEASUREMENT UNCERTAINTIES ...................................................................................................................... 6 5.3. MEASUREMENT EQUIPMENT USED ................................................................................................................... 6 5.4. POWER LINE CONDUCTED EMISSIONS [§ 15.107(A)] ...................................................................................... 7 5.5. RECEIVER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§15.111(A)] ........... 12 5.6. SPURIOUS/HARMONIC RADIATED EMISSIONS FROM RECEIVER AND CLASS B UNINTENTIONAL RADIATORS (DIGITAL DEVICES) [§ 15.109(A)] ............................................................................................... 16 5.7. REQUIREMENTS FOR SCANNING RECEIVERS [§ 15.121].............................................................................. 19 5.8. SCANNING RECEIVERS CELLULAR BAND REJECTION [§ 15.121(B)] ........................................................ 22 EXHIBIT 6. TEST EQUIPMENTS LIST ....................................................................................................................... 24 EXHIBIT 7. MEASUREMENT UNCERTAINTY.........................................................................................................25 7.1. LINE CONDUCTED EMISSION MEASUREMENT UNCERTAINTY ................................................................ 25 7.2. RADIATED EMISSION MEASUREMENT UNCERTAINTY .............................................................................. 25 FCC Part 15, Subpart B, Section 15.121 Page 1 UHF Transceiver, M/N: ID-31A FCC ID: AFJ332200 ULTRATECH GROUP OF LABS File #: ICOM-285Q_FCC15.121 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 November 23, 2011 Tel. #: 9…

Text truncated - open the document above for the full version.

ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated UHF Transceiver, Model ID-31A FCC ID: AFJ332200, IC: 202D-332200 A1 - 1 AC Power-line Conducted Emission ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated UHF Transceiver, Model ID-31A FCC ID: AFJ332200, IC: 202D-332200 A1 - 2 AC Power-line Conducted Emission ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated UHF Transceiver, Model ID-31A FCC ID: AFJ332200, IC: 202D-332200 A1 - 3 DC Power-line Conducted Emission ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated UHF Transceiver, Model ID-31A FCC ID: AFJ332200, IC: 202D-332200 A1 - 4 Radiated Emission at 3m Distance ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated UHF Transceiver, Model ID-31A FCC ID: AFJ332200, IC: 202D-332200 A1 - 5 Radiated Emission at 3m Distance ANNEX 1 – TEST SETUP PHOTOS Icom Incorporated UHF Transceiver, Model ID-31A FCC ID: AFJ332200, IC: 202D-332200 A1 - 6 Radiated Emission at 3m Distance
