AFJ350000HF Transeiver

2001 NEW HF TRANSCEIVER iF8101 INSTRUCTION MANUAL This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. i 2001 NEW2001 NEW FOREWORD Thank you for purchasing this Icom product. The IC- F8101 h f t r a n s c e i v e r is designed and built with Icom’s state of the art technology and craftsmanship. With proper care, this product should provide you with years of trouble-free operation. We appreciate you making the IC-F8101 your radio of choice, and hope you agree with Icom’s philosophy of “technology first.” Many hours of research and develop- ment went into the design of your IC-F8101. D FEATURES ❍ ALE (Automatic Link Establishment)/Sel- call capability ❍ Digital Signal Processor (DSP) allows flex- ible filter selection ❍ Full-dot matrix LCD for a variety of infor- mation IMPORTANT READ THIS INSTRUCTION MANUAL CAREFULLY before attempting to operate the transceiver. SAVE THIS INSTRUCTION MANUAL. This manual contains important safety and operating in- structions for the IC-F8101. EXPLICIT DEFINITIONS WORDDEFINITION R DANGER! Personal death, serious injury or an explosion may occur. R WARNING! Personal injury, fire hazard or electric shock may occur. CAUTION Equipment damage may occur. NOTE Recommended for optimum use. No risk of personal injury, fire or electric shock. Versions of the IC-F8101 which display the “N33” symbol on the serial number seal, comply with Standard Australia Specification No. AS/NZS 4770: 2000. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries. All other products or brands are registered trademarks or trademarks of their respective holders. FCC INFORMATION FOR CLASS A UNINTENTIONAL RADIATORS: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communica- tions. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. CAUTION: Changes or modifications to this trans- ceiver, not expressly approved by Icom Inc., could void your authority to operate this transceiver under FCC regulations. 2001 NEW ii FOREWORD .............................................................. i IMPORTANT ............................................................... i EXPLICIT DEFINITIONS ............................................ i FCC INFORMATION .................................................. i TABLE OF CONTENTS ..............................................ii SAFETY TRAINING INFORMATION .........................iii INFORMATION EN MATIÈRE DE SÉCURITÉ ..........iv PRECAUTIONS ......................................................... v 1 PANEL DESCRIPTION ..................................... 1–6 Controller (Front panel or HM-192) ■ ................... 1 Rear panel ■ ........................................................ 4 LCD screen ■ ....................................................... 5 2 BASIC OPERATION ....................................... 7–10 Power ON ■ .......................................................... 7 Selecting the display mode ■ ............................... 7 Selecting a channel ■........................................... 8 Setting audio volume ■ ........................................ 8 Squelch function ■ ............................................... 8 Scan function ■ .................................................... 9 Mode selection ■ .................................................. 9 VFO operation ■ ................................................. 10 3 RECEIVE AND TRANSMIT ........................... 11–17 Basic voice transmit/receive ■ ............................ 11 Functions for transmit ■ ..................................... 12 Functions for receive ■ ....................................... 14 4 SELCALL/ALE OPERATION ........................ 18–32 Selcall/ALE ■...................................................... 18 5 MENU SCREEN ............................................ 33–65 Manager Menu ■ ................................................ 33 Main Menu ■ ...................................................... 46 CPU Reset ■ ...................................................... 65 6 CONNECTION AND INSTALLATION ........... 66–79 Supplied accessories ■ ...................................... 66 Connections ■ .................................................... 68 Ground connection ■.......................................... 70 Power source ■ .................................................. 70 Antenna ■........................................................... 71 CFU-F8100 (Optional Cooling Fan) ■ ................ 71 RMK-6 (Optional Separation kit) ■ ..................... 72 HM-192 (Optional Remote control microphone) ■ ........................................................................ 74 Mounting ■ ......................................................... 75 Fuse replacement ■ ........................................... 77 Connector information ■ ..................................... 78 Connector information for OPC-2308 ■ ............. 79 7 SPECIFICATIONS ............................................... 80 8 OPTIONS ............................................................ 81 TABLE OF CONTENTS 1 2 3 4 5 6 7 8 iii 2001 NEW2001 NEW SAFETY TRAINING INFORMATION WARNING Your Icom radio generates RF electromag- netic energy during transmit mode. This radio is designed for and cla…

Text truncated - open the document above for the full version.

UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NVLAP LAB CODE 200093‐0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] June 11, 2013 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Certification under FCC 47 CFR, Parts 2 and 90 - Non- Broadcast Radio Transceivers Operating in the Frequency Band 1.6 - 30 MHz. Applicant: ICOM Incorporated Product: HF Transceiver Model: IC-F8101 FCC ID: AFJ350000 Dear Sir/Madam: As appointed agent for ICOM Incorporated, we submit the application for certification of the above product. Please review all files uploaded to your electronic filing site. If you have any queries, please do not hesitate to contact us. Yours truly, DanHuynh Dan Huynh Authorized Agent

ＩＣ－Ｆ８１０１（ｆｒｏｎｔ ｓｉｄｅ） ＩＣ－Ｆ８１０１（ｒｅａｒ ｓｉｄｅ） ＩＣ－Ｆ８１０１（ｆｒｏｎｔ ｓｉｄｅ） ＩＣ－Ｆ８１０１（ｒｅａｒ ｓｉｄｅ） ＲＭＫ－６（ｆｒｏｎｔ ｓｉｄｅ） ＲＭＫ－６（ｒｅａｒ ｓｉｄｅ） ＲＭＫ－６（ｆｒｏｎｔ ｓｉｄｅ） ＲＭＫ－６（ｒｅａｒ ｓｉｄｅ） ＩＣ－Ｆ８１０１ ＩＣ－Ｆ８１０１

Ｓｅｒｉａｌ Ｓｅａｌ Ｍａｎｕｓｃｒｉｐｔ Ｐｏｓｉｔｉｏｎ Ｒｉｇｈｔ－ｓｉｄｅ Ｖｉｅｗ ＦＣＣ Ｐａｒｔ１５ Ｓｈｅａｌ Ｐｏｓｉｔｉｏｎ Ｌｅｆｔ－ｓｉｄｅ Ｖｉｅｗ ＳＡＲ Ｓｈｅａｌ Ｐｏｓｉｔｉｏｎ Ｔｏｐ Ｖｉｅｗ

ＭＡＩＮ ＵＮＩＴ（ｔｏｐ） ＭＡＩＮ ＵＮＩＴ（ｂｏｔｔｏｍ） ＭＡＩＮ ＵＮＩＴ（ｔｏｐ） ＭＡＩＮ ＵＮＩＴ（ｂｏｔｔｏｍ） ＰＡ ＵＮＩＴ（ｔｏｐ） ＰＡ ＵＮＩＴ（ｂｏｔｔｏｍ） ＰＡ ＵＮＩＴ（ｔｏｐ） ＰＡ ＵＮＩＴ（ｂｏｔｔｏｍ） ＤＳＰ－１ ＵＮＩＴ（ｔｏｐ） ＤＳＰ－１ ＵＮＩＴ（ｂｏｔｔｏｍ） ＤＳＰ－１ ＵＮＩＴ（ｔｏｐ） ＤＳＰ－１ ＵＮＩＴ（ｂｏｔｔｏｍ） ＤＩＳＰＬＡＹ ＵＮＩＴ（ｔｏｐ） ＤＩＳＰＬＡＹ ＵＮＩＴ（ｂｏｔｔｏｍ） ＤＩＳＰＬＡＹ ＵＮＩＴ（ｔｏｐ） ＤＩＳＰＬＡＹ ＵＮＩＴ（ｂｏｔｔｏｍ） ＭＩＣ ＵＮＩＴ（ｔｏｐ） ＭＩＣ ＵＮＩＴ（ｂｏｔｔｏｍ） ＭＩＣ ＵＮＩＴ（ｔｏｐ） ＭＩＣ ＵＮＩＴ（ｂｏｔｔｏｍ） ＤＲＩＶＥＲ ＵＮＩＴ（ｔｏｐ） ＤＲＩＶＥＲ ＵＮＩＴ（ｂｏｔｔｏｍ） ＤＲＩＶＥＲ ＵＮＩＴ（ｔｏｐ） ＤＲＩＶＥＲ ＵＮＩＴ（ｂｏｔｔｏｍ） ＶＡＲＩＳＴＯＲ ＵＮＩＴ（ｔｏｐ） ＶＡＲＩＳＴＯＲ ＵＮＩＴ（ｂｏｔｔｏｍ） ＶＡＲＩＳＴＯＲ ＵＮＩＴ（ｔｏｐ） ＶＡＲＩＳＴＯＲ ＵＮＩＴ（ｂｏｔｔｏｍ） ＤＳＰ－２ ＵＮＩＴ（ｔｏｐ） ＤＳＰ－２ ＵＮＩＴ（ｂｏｔｔｏｍ） ＤＳＰ－２ ＵＮＩＴ（ｔｏｐ） ＤＳＰ－２ ＵＮＩＴ（ｂｏｔｔｏｍ） ＲＭＫ－６ ＦＲＯＮＴ ＵＮＩＴ（ｔｏｐ） ＲＭＫ－６ ＦＲＯＮＴ ＵＮＩＴ（ｂｏｔｔｏｍ） ＲＭＫ－６ ＦＲＯＮＴ ＵＮＩＴ（ｔｏｐ） ＲＭＫ－６ ＦＲＯＮＴ ＵＮＩＴ（ｂｏｔｔｏｍ） ＲＭＫ－６ ＲＥＡＲ ＵＮＩＴ（ｔｏｐ） ＲＭＫ－６ ＲＥＡＲ ＵＮＩＴ（ｂｏｔｔｏｍ） ＲＭＫ－６ ＲＥＡＲ ＵＮＩＴ（ｔｏｐ） ＲＭＫ－６ ＲＥＡＲ ＵＮＩＴ（ｂｏｔｔｏｍ）

FCC Parts 2 and 90, Non-Broadcast Radio Transceivers Page 57 of 64 HF Transceiver, Model IC-F8101 FCC ID: AFJ350000 ULTRATECH GROUP OF LABS File #: ICOM-331F90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 June 11, 2013 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.8. RF EXPOSURE REQUIRMENTS [§§ 1.1310 & 2.1091] The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation. FCC 47 CFR § 1.1310: 5.8.1. Method of Measurements Refer to Sections 1.1310, 2.1091 In order to demonstrate compliance with MPE requirements (see Section 2.1091), the following information is typically needed: (1) Calculation that estimates the minimum separation distance (20 cm or more) between an antenna and persons required to satisfy power density limits defined for free space. (2) Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement (3) Any caution statements and/or warning labels that are necessary in order to comply with the exposure limits (4) Any other RF exposure related issues that may affect MPE compliance FCC Parts 2 and 90, Non-Broadcast Radio Transceivers Page 58 of 64 HF Transceiver, Model IC-F8101 FCC ID: AFJ350000 ULTRATECH GROUP OF LABS File #: ICOM-331F90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 June 11, 2013 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) Calculation Method of RF Safety Distance: 22 44r EIRP r GP S       Where: P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm 5.8.2. RF Evaluation EVALUATION OF RF EXPOSURE COMPLIANCE REQUIREMENTS RF Exposure Requirements Compliance with FCC Rules Minimum calculated separation distance between antenna and persons required: *12.9 cm Manufacturer’ instruction for separation distance between antenna and persons required: 80 cm Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement Antenna installation and device operating instructions shall be provided to installers to maintain and ensure compliance with RF exposure requirements. Caution statements and/or warning labels that are necessary in order to comply with the exposure limits Refer to User’s Manual for RF Exposure Information. Any other RF exposure related issues that may affect MPE compliance None. *The minimum separation distance between the antenna and bodies of users are calculated using the following formula: For General /Un-controlled Exposure operating in 1.6 -30 MHz: S = 180/f 2 = 180 / 1.6 2 = 70.31 mW/cm 2 (worst case) Maximum EIRP = 51.70 + 0 dBi = 51.70 dBm = 147911 mW (worst case) (Minimum Safe Distance, r) = cm S EIRP 9.12 )31.70(4 147911 4      For Occupational/Controlled Exposure operating in 1.6 -30 MHz: S = 100 mW/cm 2 (worst case) Maximum EIRP = 51.70 + 0 dBi = 51.70 dBm = 147911 mW (worst case) (Minimum Safe Distance, r) = cm S EIRP 8.10 )100(4 147911 4     

HF Transceiver Model: IC-F8101 FCC ID: AFJ350000 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku Osaka Japan, 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Parts 2 and 90 UltraTech's File No.: ICOM-331F90 This Test report is Issued under the Authority of Tri M. Luu Vice President of Engineering UltraTech Group of Labs Date: June 11, 2013 Report Prepared by: Dan Huynh Issued Date: June 11, 2013 Tested by: Wei Wu Test Dates: Apr 17 - May 27, 2013  The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected.  This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech Group of Labs 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected] , Email: [email protected] FCC Korea KCC-RRL 91038 1309 46390-2049 NVLAP LAB CODE 200093‐0 SL2-IN-E-1119R CA2049 FCC Parts 2 and 90, Non-Broadcast Radio Transceivers Contents i HF Transceiver, Model IC-F8101 FCC ID: AFJ350000 ULTRATECH GROUP OF LABS File #: ICOM-331F90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 June 11, 2013 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION .................................................................................................................................................... 1 1.1. SCOPE ........................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ........................................................................................................................... 1 1.3. NORMATIVE REFERENCES ......................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .......................................................................................................................... 2 2.1. CLIENT INFORMATION ................................................................................................................................................. 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ...................................................................................................... 2 2.3. EUT’S TECHNICAL SPECIFICATIONS ......................................................................................................................... 3 2.4. LIST OF EUT’S PORTS.................................................................................................................................................. 3 2.5. ANCILLARY EQUIPMENT.............................................................................................................................................. 4 2.6. GENERAL TEST SETUP................................................................................................................................................ 5 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ..................................................... 6 3.1. CLIMATE TEST CONDITIONS....................................................................................................................................... 6 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS.......................................................... 6 EXHIBIT 4. SUMMARY OF TEST RESULTS............................................................................................................................ 7 4.1. LOCATION OF TESTS ................................................................................................................................................... 7 4.2. APPLICABILITY & SUMMARY OF EMISSION TEST RESULTS ................................................................................... 7 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ................................................... 7 EXHIBIT 5. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS ..................................................... 8 5.1. RF POWER OUTPUT [§ 2.1046, 90.205] ....................................................................................................................... 8 5.2. AUDIO FREQUENCY RESPONSE [§ 2.1047(a) & 90.242(b)(8)] ................................................................................. 11 5.3. MODULATION LIMITING [§ 2.1047 (b) & 90.210] ........................................................................................................ 14 5.4. OCCUPIED BANDWIDTH & EMISSION MASK [§ 2.1049, 90.209 & 90.210] .............................................................. 19 5.5. TRANSMITTER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§ 2.1051, 2.1057, 90.210] .......................................................................................................................................................................... 46 5.6. TRANSMITTER SPURIOUS/HARMONIC RADIATED EMISSIONS [§ 2.1053, 2.1057, 90.210].................................. 53 5.7. FREQUENCY STABILITY [§ 2.1055, 90.213]............................................................................................................... 55 5.8. RF EXPOSURE REQUIRMENTS [§§ 1.1310 & 2.1091]............................................................................................... 57 EXHIBIT 6. TEST EQUIPMENT LIST...................................................................................................................................... 59 EXHIBIT 7. MEASUREMENT UNCERTAINTY ...........…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated HF Transceiver, M/N: IC-F8101 FCC ID: AFJ350000 Radiated Emission at 3m, 30 MHz to 1GHz ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated HF Transceiver, M/N: IC-F8101 FCC ID: AFJ350000 Radiated Emission at 3m, Above 1GHz
