AFJ360300Wireless Access Point

– 4 – – 1 – A-7168W-2EX-q Printed in Japan © 2014–2015 Icom Inc. 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan CONNECTION GUIDE WIRELESS ACCESS POINT AP-90M Thank you for purchasing this Icom product. The AP-90M w i r e l e s s a c c e s s p o i n t is designed and built with Icom’s IP network technology. It complies with the “IEEE802.11ac” and “IEEE802.11n” standards, and is designed for dual band communications in the 5 GHz and 2.4 GHz bands. Read the “PRECAUTIONS” leaflet first, if you have not done so. Supplied Accessories D • Cushion sheet ............1 • Antenna .....................2 • Mounting bracket set ...1 • Precautions guide • “Setting the interface language and the Time Zone” leaflet • Connection Guide (This guide) Other requirements D • PC • Ground wire • LAN cable • Power adapter ( The adapter type differs, depending on the access point version) About this Connection Guide: This Connection Guide explains the basic operation of the AP-90M. Access our website to download the instruction manual. Icom website http://www.icom.co.jp/world/ NOTE: • Adobe ® Reader ® is required on your PC in order to display the downloaded PDF instruction manual. • If your PC does not have Adobe ® Reader ® , please download it from the Adobe ® website. Step 1 System Requirements Step 2 Panel description About the indicators D * 1 When the LED OFF Mode is set to “Enable,” the light is dimmed, and when set to “Enable (Completely),” the light turns OFF. (Default: Disable) * 2 When there is no wireless device to communicate with the AP-90M, or no wireless communication is performed while the Wireless Unit is enabled, the LED lights orange. The time when the LED turns orange differs, depending on the communication status. * 3 The LED also turns OFF when the same Wireless Mode is set to the internal antenna and the external antenna. Step 6 Changing the administrator’s password To prevent unauthorized access, you must change the password. Enter Click [Management], then [Administrator]. q Fill out each box to change the password. w Click [Apply.] e * Enter the new administrator’s password from now on. NOTE: If you have forgotten your password, you cannot access the AP-90M’s setting screen. When you forgot your password: Hold down the [MODE] button by following the instructions described in the precautions guide. The AP-90M will have to be reset as its default. Click LEDPOWER* 1 LAN WIRELESS 1 (Internal antenna)* 2 WIRELESS 2 (External antenna)* 2 Green LightsON LAN connected (1000BASE-T) More than 1 connection/WPS succeeded Blinks—LAN is communicating (1000BASE-T)WPS is running Red Lights “Accessing the USB flash drive” error —— Blinks“Duplicated IP address” error—WPS failed Orange Lights Accessing the USB flash drive. A firmware update is ready. LAN connected (10BASE-T/ 100BASE-TX) Internal antenna enabled (Wireless unit is not connected) External antenna enabled (Wireless unit is not connected) Blinks Booting. Operating [MODE]. LAN is communicating (10BASE-T/ 100BASE-TX) Wireless operation is standing by for DFS OFFOFFLAN is not connectedInternal antenna disabled* 3 External antenna disabled* 3 AP-90M WIRELESS ACCESS POINT Antenna connector [LAN] [POWER] [WIRELESS 1] [WIRELESS 2] WPS [LAN] port (RJ-45) [USB] port (USB 2.0) DC jack Ground terminal Antenna connector Wi-Fi Protected Setup MODE Back side [WIRELESS 1]: Internal antenna. [WIRELESS 2*]: External antenna. * The “IEEE802.11ac” standard can only be used when the 5 GHz band is selected. Refer to “Resetting to the factory defaults” in the Pre- cautions Guide, for details. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries. Microsoft, Windows and Windows Server are registered trademarks of Microsoft Corporation in the United States and/or other countries. Adobe and Adobe Reader are registered trademarks of Adobe Systems Incorporated in the United States and/or other countries. All other products or brands are registered trademarks or trademarks of their respective holders. Step 7 DFS function and channel auto setting The DFS function automatically avoids radio-frequency interference to Weather radars. The DFS conditions differ, depending on your location. NOTE: Whether or not the DFS function is enabled on a frequency is regulated by the local law, and cannot be disabled by users. • The Wireless Bridging is not activated if a channel is used that requires the DFS function or if automatic channel selection is set. Refer to the PDF instruction manual on the Icom’s website for setting details. • The usable wireless LAN frequencies and channels differ, depending on your location. After setting a channel in the setting screen, restart the ➥ AP-90M. The AP-90M will then search for a weather ra- dar’s signal for approximately 1 minute. While searching for a signal, [WIRELESS 1 or 2] will blink, and access to the AP-90M will be paused. When a weather radar’s signal is detected, the operating channel automatically changes to a different channel to avoid the interference. The DFS function pauses on the new channel, if the chan- ➥ nel does not require the DFS. – 2 –– 3 – Step 4 About the setting screen q Open your web browser, then enter the IP address of the AP-90M into the address bar. *The default IP address is “ //192.168.0.1/.” w Push the [ENTER] key. • The Login Authentication screen will appear. e Enter “admin” (fixed username) and “admin” (default pass- word) in their respective input fields in the Login Authenti- cation window, and then click [OK]. • When accessing the web browser for the first time, setting the time zone is required. See the “Setting the interface language and the Time Zone” leaflet for details. To prevent unauthorized access You must carefully chose your password, and change it occasionally. See page 4 of this connection guide for password setting details. • Choose one that is not easy t…

Text truncated - open the document above for the full version.

Report No.: 1490280R-RFUSP05V00 Page : 1 of 13 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 1490280R-RFUSP05V00 Page : 2 of 13 (3) EUT Photo (4) EUT Photo

FCC ID.: AFJ360300 FCC ID Label

        ! "#   $% $&'  ( ) )* +,-..%%% ) )*.% $&          !"   MODE DC 12V SERIAL NO. Model : AP - 90M MADE IN JAPAN This device complies with Par t 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful inter ference, and (2)this device must accept any interference received, including interference that may cause undesired operation. ́ ` This Class B digital apparatus complies with Canadian ICES - 003. Cet appareil numerique de la classe B est conforme a la norme NMB - 003 du Canada. FCC ID : AFJ360300 IC : 202D - 360300 CAN ICES - 3 ( B ) / NMB - 3 ( B )

Report No. 1490280R-RFUSP05V00 Page: 1 of 3 RF Exposure Evaluation declaration Product Name Wireless Access Point Model No. AP-90M FCC ID AFJ360300 Applicant ICOM Incorporated Address 1-1-32 Kamiminami, Hirano-ku, Osaka, 547-0003, Japan Date of Receipt Sep. 10, 2014 Date of Declaration Jan. 07, 2015 Report No. 1490280R-RFUSP05V00 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No. 1490280R-RFUSP05V00 Page: 2 of 3 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No. 1490280R-RFUSP05V00 Page: 3 of 3 1.3. Test Result of RF Exposure Evaluation Product : Wireless Access Point Test Item : RF Exposure Evaluation Operation Frequency 802.11b/g/n-20MHz:2412-2462MHz , 802.11n-40MHz:2422-2452MHz 802.11a/n-20MHz:5745-5825MHz 802.11n-40MHz:5755-5795MHz 802.11ac-80MHz: 5775MHz 802.11a/n-20MHz: 5180-5320MHz, 5500-5700MHz 802.11n-40MHz: 5190-5310, 5510-5670MHz 802.11ac-20MHz: 5720, 802.11ac-40MHz: 5710 802.11ac-80MHz: 5210-5290MHz, 5530-5690MHz Maximum Conducted output power 23.52dBm for 2.4GHz Internal Antenna 20.82dBm for 2.4GHz External Antenna 22.61dBm for 5GHz Internal Antenna 22.03dBm for 5GHz External Antenna Antenna gain 1.15dBi for 2.4GHz Internal Antenna 3.00dBi for 2.4GHz External Antenna 3.24dBi for 5GHz Internal Antenna 5.00dBi for 5GHz External Antenna 2.4GHz Internal Antenna Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 224.9055 0.058308 Power density is lower than the limit (1 mW/cm2). 2.4GHz External Antenna Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 120.7814 0.047944 Power density is lower than the limit (1 mW/cm2). 5GHz Internal Antenna Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 182.3896 0.076512 Power density is lower than the limit (1 mW/cm2). 5GHz External Antenna Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 159.5879 0.100399 Power density is lower than the limit (1 mW/cm2).

Report No.: 1490280R-RFUSP25V00 Page: 1 of 294 FCC Test Report Product Name Wireless Access Point Model No AP-90M FCC ID. AFJ360300 Applicant ICOM Incorporated Address 1-1-32 Kamiminami, Hirano-ku, Osaka, 547-0003, Japan Date of Receipt Sep. 10, 2014 Issue Date Feb. 04, 2015 Report No. 1490280R-RFUSP25V00 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 1490280R-RFUSP25V00 Page: 2 of 294 Test Report Issue Date: Feb. 04, 2015 Report No.: 1490280R-RFUSP25V00 Product Name Wireless Access Point Applicant ICOM Incorporated Address 1-1-32 Kamiminami, Hirano-ku, Osaka, 547-0003, Japan Manufacturer ICOM Incorporated Model No. AP-90M EUT Rated Voltage AC 100-240V, 50-60Hz EUT Test Voltage AC 120V/60Hz Trade Name ICOM Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2013 ANSI C63.4: 2009, ANSI C63.10: 2009 KDB 558074 D01 DTS Meas Guidance v03r02 Test Result Complied Documented By : ( Senior Adm. Specialist / Joanne Lin ) Tested By : ( Engineer / Jack Hsu ) Approved By : ( Director / Vincent Lin ) Report No.: 1490280R-RFUSP25V00 Page: 3 of 294 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................8 1.3. Tested System Details....................................................................................................................9 1.4. Configuration of Tested System ....................................................................................................9 1.5. EUT Exercise Software .................................................................................................................9 1.6. Test Facility .................................................................................................................................10 2. Conducted Emission.................................................................................................................. 11 2.1. Test Equipment............................................................................................................................11 2.2. Test Setup ....................................................................................................................................11 2.3. Limits ..........................................................................................................................................12 2.4. Test Procedure .............................................................................................................................12 2.5. Uncertainty ..................................................................................................................................12 2.6. Test Result of Conducted Emission.............................................................................................13 3. Maximum Conducted Power....................................................................................................21 3.1. Test Equipment............................................................................................................................21 3.2. Test Setup ....................................................................................................................................21 3.3. Limits ..........................................................................................................................................21 3.4. Test Procedure .............................................................................................................................22 3.5. Uncertainty ..................................................................................................................................22 3.6. Test Result of Maximum Conducted Power................................................................................23 4. Radiated Emission .....................................................................................................................39 4.1. Test Equipment............................................................................................................................39 4.2. Test Setup ....................................................................................................................................40 4.3. Limits ..........................................................................................................................................41 4.4. Test Procedure .............................................................................................................................42 4.5. Uncertainty ..................................................................................................................................42 4.6. Test Result of Radiated Emission................................................................................................43 5. RF Antenna conducted test .......................................................................................................99 5.1. Test Equipment............................................................................................................................99 5.2. Test Setup ....................................................................................................................................99 5.3. Limits ...........…

Text truncated - open the document above for the full version.

Report No.: 1490280R-RFUSP05V00 Page : 1 of 4 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 1490280R-RFUSP05V00 Page : 2 of 4 Front View of Radiated Test Back View of Radiated Test Report No.: 1490280R-RFUSP05V00 Page : 3 of 4 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn) Report No.: 1490280R-RFUSP05V00 Page : 4 of 4 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn)
