AFJ397410VHF Marine Transceiver

VHF MARINE TRANSCEIVERS INSTRUCTION MANUALINSTRUCTION MANUAL i Thank you for choosing this Icom product. This product is designed and built with Icom’ s state of the art technology and craftsmanship. With proper care, this product should provide you with years of trouble-free operation. IMPORTANT READ ALL INSTRUCTIONS carefully and completely before using the transceiver. SAVE THIS INSTRUCTION MANUAL — This instruction manual contains important operating instructions for the IC-M330, IC-M330E, IC-M330G, IC-M330GE. This instruction manual includes some functions which are usable only when they are preset by your dealer. Ask your dealer for details. EXPLICIT DEFINITIONS WORDDEFINITION WARNING! shock may occur. CAUTION Equipment damage may occur. NOTE If disregarded, inconvenience only. No risk Icom is not responsible for the destruction, damage to, or performance of any Icom or non-Icom equipment, if the malfunction is because of: • disasters, disturbances, riots, war, or radioactive contamination. • The use of Icom transceivers with any equipment that is not manufactured or approved by Icom. FEATURES Easy user interface The transceiver is equipped with a screen for easy readability and easy-to-use user interface. Dualwatch and Tri-watch functions Convenient functions that enable you to monitor the Distress channel (Ch 16) while receiving on another channel of your choice (Dualwatch), or while receiving on another channel of your choice, and the Call channel (Tri-watch). * May not be usable, depending on the transceiver version. DSC function The transceiver has the DSC functions for distress alert transmission and reception, as well as the general DSC calls such as Individual calls, All ships calls, Group calls, and so on. ii IN CASE OF EMERGENCY If your vessel requires assistance, contact other vessels and the Coast Guard by sending a distress call on Channel 16. USING CHANNEL 16 DISTRESS CALL PROCEDURE 1. “MAYDAY MAYDAY MAYDAY.” 2. “THIS IS ...............” (name of vessel). 3. Say your call sign or other indication of the vessel (AND your 9 digit DSC ID, if you have one). 4. “LOCATED AT ...............” (your position). 5. State the nature of the distress and assistance required. 6. Give any other information which might facilitate the rescue. Or, transmit your Distress call using Digital Selective Calling (DSC) on Channel 70. USING DIGITAL SELECTIVE CALLING (Ch 70) DISTRESS CALL PROCEDURE 1. While lifting up the key cover, hold down [DISTRESS] for 3 seconds until you hear 3 short beeps and then one long beep. 2. Wait for an acknowledgment on Channel 70 from a coast station. • After the acknowledgement is received, Channel 16 is automatically selected. 3. Hold down [PTT], then transmit the appropriate information as listed to the left. Key cover iii RADIO OPERATION WARNING Icom requires the radio operator to meet the FCC Requirements for Radio Frequency Exposure. An omnidirectional antenna with gain not greater than 9 dBi must be mounted a minimum of 5 meters (measured from the lowest point of the antenna) vertically above the main deck and all possible personnel. This is the minimum safe separation distance estimated to meet all RF exposure compliance requirements. This 5 meter distance is based on the FCC Safe Maximum Permissible Exposure (MPE) distance of 3 meters added to the height of an adult (2 meters) and is appropriate for all vessels. For watercraft without suitable structures, the antenna must be mounted so as to maintain a minimum of 1 meter vertically between the antenna, (measured from the lowest point of the antenna), to the heads of all persons AND all persons must stay outside of the 3 meter MPE radius. Do not transmit with radio and antenna when persons are within the MPE radius of the antenna, unless such persons (such as driver metallic barrier. The MPE Radius is the minimum distance from the antenna axis that person should maintain in order to avoid RF exposure higher than the allowable MPE level set by FCC. FAILURE TO OBSERVE THESE LIMITS MAY ALLOW THOSE WITHIN THE MPE RADIUS TO EXPERIENCE RF RADIATION ABSORPTION WHICH EXCEEDS THE FCC MAXIMUM PERMISSIBLE EXPOSURE (MPE) LIMIT. IT IS THE RESPONSIBILITY OF THE RADIO OPERATOR TO ENSURE THAT THE MAXIMUM PERMISSIBLE EXPOSURE LIMITS ARE OBSERVED AT ALL TIMES DURING RADIO TRANSMISSION. THE RADIO OPERATOR IS TO ENSURE THAT NO BYSTANDERS COME WITHIN THE RADIUS OF THE MAXIMUM PERMISSIBLE EXPOSURE LIMITS. Determining MPE Radius THE MAXIMUM PERMISSIBLE EXPOSURE (MPE) RADIUS HAS BEEN ESTIMATED TO BE A RADIUS OF ABOUT 3M PER OET BULLETIN 65 OF THE FCC. THIS ESTIMATE IS MADE ASSUMING THE MAXIMUM POWER OF THE RADIO AND ANTENNAS WITH A MAXIMUM GAIN OF 9 dBi ARE USED FOR A SHIP MOUNTED SYSTEM. iv AVERTISSEMENT POUR LES OPÉRATEURS RADIO Icom exige que l'opérateur radio se conforme aux exigences de la FCC en matière d'exposition aux radiofréquences. Une antenne omnidirectionnelle à une distance minimale de 5 mètres (mesurée depuis le point le plus bas de l'antenne) verticalement au-dessus du pont principal et de tout le personnel qui peut s'y trouver. Il s'agit de la distance de sécurité minimale prévue pour satisfaire aux exigences de conformité en matière d'exposition aux RF. Cette distance de 5 mètres est établie en fonction de l'exposition maximale admissible sécuritaire de 3 mètres établie par la FCC, à laquelle on ajoute la hauteur d'un adulte (2 mètres); cette distance convient pour tous les navires. Dans le cas des embarcations sans structure convenable, l'antenne mètre verticalement entre cette antenne (mesurée depuis son point le plus bas) et la tête de toute personne présente; toutes les personnes présentes doivent se tenir à l'extérieur d'un rayon d'exposition maximale admissible de 3 mètres. Ne pas émettre à l'aide de la radio et de l'antenne lorsque des personnes se trouvent à l'intérieur du rayon d'exposition maximale admissible de cette antenne, à moins que ces personnes (comme le conducteur ou l'opérateur radio) ne soi…

Text truncated - open the document above for the full version.

29 DSC OPERATION 7 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Sending a Test call channels and safety calling channels. When you cannot avoid testing on a distress or safety channel, you should indicate that these are test calls. 1. Push . • The “Other DSC” screen is displayed. You can also display the “Other DSC” screen by selecting the “Other DSC” item on the Menu screen. 2. Select “Test,” and then push [ENT]. •The Test call is selected, and returns to the “OTHER DSC” screen. 3. Select “Address,” and then push [ENT]. • The “ADDRESS” screen is displayed. 4. Select a station to send the Test call to. You can also select “Manual Input” to manually enter the calling station. 5. Push to send the Test call. • “Transmitting Test Call” is displayed. If Channel 70 is busy, the transceiver stands by until the channel becomes clear. 6. When you receive an •An alarm sounds. •The screen to the right is displayed. 7. Push to turn OFF the alarm. • displayed. 8. Push . • “Terminate the procedure. Are you sure?” is displayed. 9. Push to return to the operating screen. 30 7 DSC OPERATION Sending a Test Acknowledgement calling station . If the function is set to “Manual,” do 1. After a Test call is being received, push to turn OFF the alarm. 2. Push . • 3. Push . • 4. Push • “Transmitting Test ACK” is displayed. Sending a Position Request call/Polling Request call You can send a Position Request call or Polling request call to a station, depending on the presetting. (Example: Sending a Position Request call) 5. Push . •A confirmation screen is displayed. 6. Push to return to the operating screen. 1. Push . • The “OTHER DSC” screen is displayed. You can also display the “OTHER DSC” screen by selecting the “Other DSC” item on the Menu screen. 2. Select “Type,” and then push [ENT]. •The 3. Select “Position,” and then push [ENT]. •The message type is selected, and returns to the “OTHER DSC” screen. When you send a Polling Request call, select “Polling.” 4. Select “Address,” and then push [ENT]. • The “ADDRESS” screen is displayed. 5. Select a target to send a Position Request call to, and the push [ENT]. You can also select “Manual Input” to manually enter the target ID. 31 DSC OPERATION 7 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Sending a Position Reply call is received. If the Auto ACK function is set to “Auto,” the station. 1. While a Position Request call is being received, push to turn OFF the alarm. 2. Push . • displayed. 3. Push to send an “Able to to send an “Unable to Comply” you can manually enter the position and time in “Position” item on this screen. See “Entering the position and time” on page 20 for details. 4. Push to send the Position Reply call. 6. Push to send the Position Request call. • “Transmitting Position Request” is displayed, and then the assigned channel is automatically selected. If Channel 70 is busy, the transceiver stands by until the channel becomes clear. 7. •An alarm sounds. •The screen to the right is displayed. 8. Push to turn OFF the alarm. 9. Push . •The received information is displayed. 10. 11. Push , and then to return to the operating screen. 5. Push , and then to return to the operating screen. 32 7 DSC OPERATION Receiving DSC calls (Distress) The transceiver receives Distress calls, Distress When you receive a call, an emergency alarm sounds. When a Distress call is received: •The emergency alarm sounds until you turn it OFF. • “RCVD DISTRESS” is displayed. 1. Push to turn OFF the alarm. 2. (Ignore): •Returns to the operating screen. • The call is saved in the DSC Log. • “” blinks continuously until you display the call message. (Pause): is not displayed if the “CH Auto SW” item is set to “Manual.” • automatically selected. •Select • The call is saved in the DSC Log. (Accept): • Accepts the call. •Channel 16 is automatically selected. • Monitor Channel 16 as a coast station may require assistance. • After Channel 16 is selected, you can select your EXIT HIST Displays the “DISTRESS HISTORY” screen. INFO NOTE: 33 DSC OPERATION 7 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Receiving DSC calls (other) •Individual call (p. 33) •Individual Acknowledgement call (p. 26) •Group call (p. 34) •All Ships call (p. 35) •Position Request call (p. 36) •Test call (p. 37) •Test Acknowledgement call (p. 38) The receivable call types may differ, depending on the version or presetting. Receiving an Individual call When an Individual call is received: •The alarm sounds. • “RCVD INDIVIDUAL” is displayed. 1. Push to turn OFF the alarm. 2. (Ignore) •Ignores the call and returns to the operating screen. • The call is saved in the DSC Log. • “” blinks continuously until you display the call message. (Accept) • Accepts the call. • The assigned channel is automatically selected. • The call is saved in the DSC Log. • displayed. • (Able to comply) • •The assigned channel is automatically selected. • After sending, [RESEND] to resend. • The call is saved in the DSC Log. NOTE default. (Able to Comply): (Unable to Comply): you cannot communicate. (Propose New CH): but on another channel. Assign 34 7 DSC OPERATION Receiving a Group call When a Group call is received: •The alarm sounds for 2 minutes. • 1. Push to turn OFF the alarm. The channel that is assigned by the caller is automatically selected after 10 seconds by default. 2. (Ignore): •Ignores the call and returns to the operating screen. • The call is saved in the DSC Log. • “” blinks continuously until you display the call message. (Pause): is not displayed if the “CH Auto SW” item is set to “Manual.” • automatically selected. •Select • The call is saved in the DSC Log. (Accept): • Accepts the call. •The assigned channel is selected. • The call is saved in the DSC Log. operating screen. 35 DSC OPERATION 7 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 (Accept) • Accepts the call. •The assigned channel is selected. • The call is saved in the DSC Log. operating screen. Receiving an All Ships call When an All Ships call is received: •The alarm sounds. • “RCVD AL…

Text truncated - open the document above for the full version.

For USA Only Supplier’s Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier: Trade Name : ICOM Model Name: : IC-M330 Responsible party: Company name : Icom America Inc. Address : 12421 Willows Road NE Kirkland, WA 98034 U.S. Contact Information: 800-USA-ICOM (800-872-4266) Monday - Friday 7AM to 5PM PST FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

For USA Only Supplier’s Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier: Trade Name : ICOM Model Name: : IC-M330G Responsible party: Company name : Icom America Inc. Address : 12421 Willows Road NE Kirkland, WA 98034 U.S. Contact Information: 800-USA-ICOM (800-872-4266) Monday - Friday 7AM to 5PM PST FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

March 9, 2021 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 80 (Marine in 156.025-157.425 MHz Band) - Non-Broadcast Radio Transceivers. Applicant: ICOM Incorporated Product: VHF Marine Transceiver Model: IC-M330 AND IC-M330G FCC ID: AFJ397410 Dear Sir/Madam: As appointed agent for ICOM Incorporated, we submit the application for FCC certification of the above product. Kindly review all required documents uploaded to your E-Filing Site. If you have any queries, please do not hesitate to contact us. Yours truly, Santhosh Fernandez Santhosh Fernandez Authorized Agent FCC TCB & ISED CB APEC TEL #CA0001 1309 CA 0001/2049 AT-1945 SL2-IN-E-1119R Korea KCC-RRL CA0001 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

Serial Number Sticker IC-M330 (Black version) IC-M330 (White version) IC-M330G (Black version) IC-M330G (White version) Serial Number Sticker

FCC Parts 2, 80, RSS-182 Page 46 of 80 VHF Marine Transceiver, Model: IC-M330 AND IC-M330G FCC ID: AFJ397410 ULTRATECH GROUP OF LABS File #: 21ICOM-536_F80RSS182 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 March 2, 2021 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.8.2. Method of Measurements Calculation Method of RF Safety Distance : 22 44r EIRP r PG S      Where, P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power. S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm S EIRP S PG r     44 FCC radio frequency exposure limits may be exceeded at distances closer than r cm from the antenna of this device. Evaluation of RF Exposure Compliance Requirements Maximum RF Power conducted, P conducted[W]: 25 Maximum Antenna Gain, G[dBi]: 9 Maximum EIRP, PEIRP[W]: 198.6 User-based time-average for PTT 50% FCC MPE Limit for Occupational/Controlled Exposure, Scontrolled[mW/cm2]: 1.0 ISED MPE Limit for Occupational/Controlled Exposure, Scontrolled[mW/cm2]: 0.6455ƒ0.5 0.81 Min Calculated RF Safety Distance for Occupational/Controlled Exposure,r safety_controlled[cm]: FCC 89 Min Calculated RF Safety Distance for Occupational/Controlled Exposure, r safety_controlled[m]: ISED 0.99 FCC MPE Limit for General Population/Un-controlled Exposure, SUNcontrolled[mW/cm2]: 0.2 ISED MPE Limit for General Population/Un-controlled Exposure, SUNcontrolled[mW/cm2]: 0.1291 Min Calculated RF Safety Distance for General Population/Un-controlled Exposure Exposure,r safety_uncontrolled[cm]: FCC 199 Min Calculated RF Safety Distance for General Population/Un-controlled Exposure Exposure, r safety_uncontrolled[m]: ISED 2.48 MPE distance: FCC Requirement=2m, ISED Requirement=2.5m User manual specified distance (MPE Radius) =300cm Calculated power density S for this distance=0.0878 mW/Cm 2 (0.88 W/m 2 )

VHF Marine Transceiver Model No (s).: IC-M330 AND IC-M330G FCC ID: AFJ397410 IC:202D-397410 Applicant: ICOM Incorporated 1-1-32, Kamiminami, Hirano-ku, Osaka Japan 547-0003 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Part 2, Part 80 (Marine in 156.025-157.425Hz) Industry Canada RSS-182, Issue 5 Maritime Radio Transmitters and Receivers in the Band 156-162.5 MHz UltraTech's File No.: 21ICOM-536_F80RSS182 This Test report is Issued under the Authority of Tri M. Luu Vice President of Engineering UltraTech Group of Labs Date: March 2, 2021 Report Prepared by: Santhosh Fernandez Issued Date: March 2, 2021 Tested by: Nimisha Desai Test Dates: Feb 22- Mar 2, 2021  The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected.  This report must not be used by the client to claim product endorsement by any agency of the US Government.  This test report shall not be reproduced, except in full, without a written approval from UltraTech. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] Korea KCC-RRA APEC TEL #CA0001 1309 CA 0001/2049 AT-1945 SL2-IN-E- 1119R CA0001 FCC Parts 2, 80, RSS-182 Contents i VHF Marine Transceiver, Model: IC-M330 AND IC-M330G FCC ID: AFJ397410 ULTRATECH GROUP OF LABS File #: 21ICOM-536_F80RSS182 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 March 2, 2021 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ......................................................................................................................................... 1 1.1. SCOPE ......................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................... 1 1.3. NORMATIVE REFERENCES ................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .............................................................................................................. 2 2.1. CLIENT INFORMATION .......................................................................................................................................... 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION .............................................................................................. 2 2.3. EUT’S TECHNICAL SPECIFICATIONS .................................................................................................................. 3 2.4. LIST OF EUT’S PORTS ............................................................................................................................................. 3 2.5. ANCILLARY EQUIPMENT ...................................................................................................................................... 3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 4 3.1. CLIMATE TEST CONDITIONS ................................................................................................................................ 4 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS .............................................. 4 3.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ......................................... 4 3.4. DEVIATION OF STANDARD TEST PROCEDURES .............................................................................................. 4 EXHIBIT 4. SUMMARY OF TEST RESULTS ............................................................................................................... 5 4.1. LOCATION OF TESTS .............................................................................................................................................. 5 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ............................................................... 5 EXHIBIT 5. TEST DATA ................................................................................................................................................... 6 5.1. RF POWER OUTPUT [§§ 2.1046 & 80.215] [RSS-182, SECTION 7.5] ................................................................. 6 5.2. MODULATION CHARACTERISTICS & AUDIO FREQUENCY RESPONSE [§§ 2.1047(A) & 80.213(E)] .......... 8 5.3. MODULATION LIMITING [§ 80.213 & § 2.1047(B)] ............................................................................................. 11 5.4. EMISSION MASK [§§2.1049, 80.205 & 80.211] [RSS-182, SECTIONS 7.3, 7.9.1 & 7.9.2] ............................. 14 5.5. TRANSMITTER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§80.211(F)(3)] [RSS-182, SECTION 7.9] .................................................................................................................................................. 30 5.6. TRANSMITTER SPURIOUS/HARMONIC RADIATED EMISSIONS [§ 80.211(F)(3)] [RSS-182, SECTION 7.9] 42 5.7. FREQUECNY STABILITY [§§ 2.1055 & 80.209] [RSS-182, SECTION 7.4] ...................................................... 43 5.8. RF EXPOSURE REQUIREMENTS [§§ 1.1310 & 2.1091] [RSS GEN SEC 5.6 & RSS-102] .................................... 45 5.9. SUPPRESSION OF INTERFERENCE ABOARD SHIPS [§ FCC 80.217] .............................................................. 47 5.10. RECEIVER SPURIOUS EMISSIONS (RADIATED) [RSS-182 § 7.11, RSS-GEN §§ 7.3] .................................. 58 5.11. POWERLINE CONDUCTED E…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF MARINE TRANSCEIVER M/N: IC-M330G FCC ID: AFJ397410, IC: 202D-397410 Tx Radiated Emission Test Setup ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF MARINE TRANSCEIVER M/N: IC-M330G FCC ID: AFJ397410, IC: 202D-397410 ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF MARINE TRANSCEIVER M/N: IC-M330G FCC ID: AFJ397410, IC: 202D-397410 ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF MARINE TRANSCEIVER M/N: IC-M330G FCC ID: AFJ397410, IC: 202D-397410 Powerline Conducted Emissions ANNEX 1 - TEST SETUP PHOTOGRAPHS ICOM Incorporated VHF MARINE TRANSCEIVER M/N: IC-M330G FCC ID: AFJ397410, IC: 202D-397410
