ALH35733110VHF/FM HANDHELD TRANSCEIVER

© B62-1796-10 (K) 09 08 07 06 05 04 03 02 01 INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES VHF APCO P25 TRANSCEIVER TRANSCEPTOR APCO P25 VHF TK-5210 i WARNING: EXPLOSIVE ATMOSPHERES (GASES, DUST, FUMES, etc.) Turn off your transceiver while taking on fuel, or while parked in gasoline service stations. ◆GOVERNMENT LAW PROHIBITS THE OPERATION OF UNLICENSED RADIO TRANSMITTERS WITHIN THE TERRITORIES UNDER GOVERNMENT CONTROL. ◆ILLEGAL OPERATION IS PUNISHABLE BY FINE OR IMPRISONMENT OR BOTH. ◆REFER SERVICE TO QUALIFIED TECHNICIANS ONLY. SAFETY: It is important that the operator is aware of and understands hazards common to the operation of any transceiver. THANK YOU We are grateful you chose KENWOOD for your land mobile radio applications. We believe this easy-to-use transceiver will provide dependable communications to keep personnel operating at peak efficiency. KENWOOD transceivers incorporate the latest in advanced technology. As a result, we feel strongly that you will be pleased with the quality and features of this product. NOTICES TO THE USER This device made under license under one or more of the following US Patents: 4,590,473; 4,636,791; 4,716,407; 4,972,460; 5,148,482; 5,185,796; 5,271,017; 5,377,229; 5,502,767. The IMBE™ voice coding Technology embodied in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into a human-readable form. ii One or more of the following statements may be applicable: ATTENTION (U.S.A. Only): The RBRC Recycle seal found on KENWOOD nickel-cadmium (Ni-Cd) battery packs indicates KENWOOD’s voluntary participation in an industry program to collect and recycle Ni-Cd batteries after their operating life has expired. The RBRC program is an alternative to disposing Ni-Cd batteries with your regular refuse or in municipal waste streams, which is illegal in some areas. For information on Ni-Cd battery recycling in your area, call (toll free) 1-800-8-BATTERY (1-800-822-8837). KENWOOD’s involvement in this program is part of our commitment to preserve our environment and conserve our natural resources. FCC WARNING This equipment generates or uses radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY THE FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can generate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer for technical assistance. UNPACKING AND CHECKING EQUIPMENT Note: The following unpacking instructions are for use by your KENWOOD dealer, an authorized KENWOOD service facility, or the factory. Carefully unpack the transceiver. We recommend that you identify the items listed in the following table before discarding the packing material. If any items are missing or have been damaged during shipment, file a claim with the carrier immediately. SUPPLIED ACCESSORIES Item Parts Number Instruction Manual B62-1796-00 1 Pamphlet B59-2390-00 1 Belt Hook J29-0710-05 1 Screw Set N99-2044-05 1 Cap B09-0682-03 1 Appearance TOP No. Name Correspondence Note 1 Power SW/Volume control Type 1/2/3 2 Selector Type 1/2/3 3 Concentric Switch Type 1/2/3 4 Lever Switch Type 1/2/3 5 Orange key Type 1/2/3 1 1 2 4 5 Front No. Name Correspondence Note 1 PF A key Type 2/3 2 PF B key Type 2/3 3 PF C key Type 2/3 4 PF D key Type 2/3 5 12 keypad Type 3 1 2 3 4 5 Type 3 Type 2 Type 1 Side No. Name Correspondence Note 1 Side1 key Type 1/2/3 2 PTT Type 1/2/3 3 Side2 key Type 1/2/3 4 Side3 key Type 1/2/3 1 2 3 4 Left side Right side Key Type1 Type2 Type3 (Power SW/Volume) Power Switch/Volume Power Switch/Volume Power Switch/ Volume (Selector) 16 Position Rotaly SW 16 Position Rotaly SW 16 Position Rotaly SW (Concentric Switch) 3 Position Selector 3 Position Selector 3 Position Selector (Lever Switch) 2 Position Selector 2 Position Selector 2 Position Selector (Orange) Orange Orange Orange (Side 1) Side 1 Side 1 Side 1 (Side 2) Side 2 Side 2 Side 2 (Side 3) Side 3 Side 3 Side 3 (PTT) PTT PTT PTT (A) -- A A (B) -- B B (C) -- C C (D) -- D D (DTMF 12 Key) -- -- DTMF 1.1 LCD(Type2,Type3) Standard Display (2Line) Message Display (3Line) Conventional Trunking PREPARATION INSTALLING/ REMOVING THE (OPTIONAL) BATTERY PACK CAUTION: -DO NOT RECHARGE HE BATTERY PACK IF IT IS ALREADY FULLY CHARGED. DOING SO MAY CAUSE THE LIFE OF THE BATTERY PACK TO SHORTEN OR THE BATTERY PACK MAY BE DAMAGED. -AFTER RECHARGING THE BATTERY PACK, DISCONNECT IT FROM THE CHARGER. IF THE CHARGER POWER IS RESET (TURNED ON AFTER BEING TURNED OFF), RECHARGING WILL START AGAIN AND THE BATTERY PACK WILL BECO…

Text truncated - open the document above for the full version.

5/27/2004 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P.O. Box 358315 Pittsburgh, PA 15251-5315 Attention: Authorization and Evaluation Division Reference: FCC ID: ALH35733110 Model: TK-5210-K, TK-5210-K2, and TK-5210-K3. Dear Sir: Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application, as listed below: Block Diagram Schematic Diagrams Circuit Description Parts List Active Devices Tuning Procedure These materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d)(1)(ii), disclosure of the Application and all accompanying documentation will not be made before the date of Grant for the Application. Sincerely yours, Morton Flom, P. Eng.

TK-5210-K FCC ID: ALH35733110 IC ID: 282D-35733110 Rear View Front View TK-5210-K FCC ID: ALH35733110 IC ID: 282D-35733110 Top View Bottom View TK-5210-K FCC ID: ALH35733110 IC ID: 282D-35733110 Right View Left View TK-5210-K2 FCC ID: ALH35733110 IC ID: 282D-35733110 Rear View Front View TK-5210-K2 FCC ID: ALH35733110 IC ID: 282D-35733110 Top View Bottom View TK-5210-K2 FCC ID: ALH35733110 IC ID: 282D-35733110 Right View Left View TK-5210-K3 FCC ID: ALH35733110 IC ID: 282D-35733110 Rear View Front View TK-5210-K3 FCC ID: ALH35733110 IC ID: 282D-35733110 Top View Bottom View TK-5210-K3 FCC ID: ALH35733110 IC ID: 282D-35733110 Left View Right View

TK-5210-K, TK-5210-K2, TK-5210-K3FCC ID: ALH35733110 / IC:282D-35733110 TK TKTK TK- -- -5210 52105210 5210- -- -K KK K TK-5210-K, TK-5210-K2, TK-5210-K3FCC ID: ALH35733110 / IC:282D-35733110 TK TKTK TK- -- -5210 52105210 5210- -- -K2 K2K2 K2 TK-5210-K, TK-5210-K2, TK-5210-K3FCC ID: ALH35733110 / IC:282D-35733110 TK TKTK TK- -- -5210 52105210 5210- -- -K3 K3K3 K3

TK-5210-K, -K2,-K3 FCC ID: ALH35733110 IC ID: 282D-35733110 TXRX Component Side View TXRX Foil Side View TK-5210-K FCC ID: ALH35733110 IC ID: 282D-35733110 Display Component Side View Display Foil Side View TK-5210-K2,-K3 FCC ID: ALH35733110 IC ID: 282D-35733110 Display Component Side View Display Foil Side View

FCC ID: ALH35733110 Transmitter Certification of FCC ID: ALH35733110 Model: TK-5210-K, TK-5210-K2, TK-5210-K3 to Federal Communications Commission Rule Part(s) 22, 74, 90, 90.210, Confidentiality Date of report: May 21, 2004 On the Behalf of the Applicant: Kenwood USA Corporation At the Request of: P.O. JB-F-006 Kenwood USA Corporation Communications Division 3975 Johns Creek Court, Suite 300 Suwanee, GA 30024 Attention of: Joel E. Berger, Research & Development [email protected] (678) 474-4722; FAX: -4731 Supervised by: Morton Flom, P. Eng. MFA p0440007, d0450043 FCC ID: ALH35733110 List of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: Kenwood USA Corporation FCC ID: ALH35733110 By Applicant: 1. Letter of Authorization x 2. Confidentiality Request: 0.457 And 0.459 x 3. Part 90.203(e) & (g) Attestation x 4. Identification Drawings, 2.1033(c)(11) x Label x Location of Label x Compliance Statement x Location of Compliance Statement 5. Photographs, 2.1033(c)(12) x 6. Documentation: 2.1033(c) (3) User Manual x (9) Tune Up Info x (10) Schematic Diagram x (10) Circuit Description x Block Diagram x Parts List x Active Devices x 7. SAR Attestation x By M.F.A. Inc.: A. Testimonial & Statement of Certification MFA p0440007, d0450043 FCC ID: ALH35733110 The Applicant has been cautioned as to the following: 15.21 Information to the User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. MFA p0440007, d0450043 FCC ID: ALH35733110 Table of Contents Rule Description Page . Test Report 1 2.1033(c)(14) Rule Summary 2 . Standard Test Conditions and Engineering Practices 3 2.1033(c) General Information Required 5 2.1046(a) Carrier Output Power (Conducted) 8 2.1046(a) ERP Carrier Power (Radiated) 10 2.1051 Unwanted Emissions (Transmitter Conducted) 12 2.1053(a) Field Strength of Spurious Radiation 14 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 18 90.214 Transient Frequency Behavior 29 2.1047(a) Audio Low Pass Filter (Voice Input) 35 2.1047(a) Audio Frequency Response 37 2.1047(b) Modulation Limiting 39 2.1055(a)(1) Frequency Stability (Temperature Variation) 42 2.1055(b)(1) Frequency Stability (Voltage Variation) 44 2.202(g) Necessary Bandwidth and Emission Bandwidth 46 MFA p0440007, d0450043 FCC ID: ALH35733110 Page Number 1 of 46. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0450043 d) Client: Kenwood USA Corporation Communications Division 3975 Johns Creek Court, Suite 300 Suwanee, GA 30024 e) Identification: TK-5210-K, TK-5210-K2, TK-5210-K3 FCC ID: ALH35733110 S/N: 40, 41 EUT Description: VHF FM Handheld Transceiver f) EUT Condition: Not required unless specified in individual tests. g) Report Date: May 21, 2004 EUT Received: 2004-Apr-27 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. MFA p0440007, d0450043 FCC ID: ALH35733110 Page Number 2 of 46. Sub-part 2.1033(c)(14) : Test and Measurement Data All tests and measurement data shown were performed in accordance with FCC Rules and Regulations, Volume II; Part 2, Sub-part J, Sections 2.947, 2.1033(c), 2.1041, 2.1046, 2.1047, 2.1079, 2.1051, 2.1053, 2.1055, 2.1057 and the following individual Parts: 21 – Domestic Public Fixed Radio Services x 22 – Public Mobile Services 22 Subpart H - Cellular Radiotelephone Service 22.901(d) - Alternative technologies and auxiliary services 23 – International Fixed Public Radiocommunication services 24 – Personal Communications Services x 74 Subpart H - Low Power Auxiliary Stations 80 – Stations in the Maritime Services 80 Subpart E - General Technical Standards 80 Subpart F - Equipment Authorization for Compulsory Ships 80 Subpart K - Private Coast Stations and Marine Utility Stations 80 Subpart S - Compulsory Radiotelephone Installations for Small Passenger Boats 80 Subpart T - Radiotelephone Installation Required for Vessels on the Great Lakes 80 Subpart U - Radiotelephone Installations Required by the Bridge-to-Bridge Act 80 …
