ALH37323110VHF / FM HANDHELD TRANSCEIVER

KENWOOD CORPORATION TK-2180-K, TK-2180-K2 FCC ID:ALH37323110 IC:282D-37323110 TK-3180-K, TK-3180-K3 FCC ID:ALH37333110 INSTRUCTION MANUAL TK-2180/TK-3180 THANK YOU! We are grateful you chose KENWOOD for your land mobile radio applications. We believe this easy-to-use transceiver will provide dependable communications to keep personnel operating at peak efficiency. KENWOOD transceivers incorporate the latest in advanced technology. As a result, we feel strongly that you will be pleased with the quality and features of this product. NOTICES TO THE USER WARNING: ‹ GOVERNMENT LAW PROHIBITS THE OPERATION OF UNLICENSED RADIO TRANSMITTERS WITHIN THE TERRITORIES UNDER GOVERNMENT CONTROL. ‹ ILLEGAL OPERATION IS PUNISHABLE BY FINE OR IMPRISONMENT OR BOTH. ‹ REFER SERVICE TO QUALIFIED TECHNICIANS ONLY. ‹ DO NOT OPERATE YOUR TRANSCEIVER IN EXPLOSIVE ATMOSPHERES (GASES, DUST, FUMES, ETC.). ‹ TURN OFF YOUR TRANSCEIVER WHILE TAKING ON FUEL, OR WHILE PARKED IN GASOLINE SERVICE STATIONS. SAFETY: It is important that the operator is aware of and understands hazards common to the operation of any transceiver. WARNING: EXPLOSIVE ATMOSPHERES (GASES, DUST, FUMES, etc.) Turn off your transceiver while taking on fuel, or while parked in gasoline service stations. One or more of the following statements may be applicable: FCC WARNING This equipment generates or uses radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY THE FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can generate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer for technical assistance. KENWOOD CORPORATION TK-2180-K, TK-2180-K2 FCC ID:ALH37323110 IC:282D-37323110 TK-3180-K, TK-3180-K3 FCC ID:ALH37333110 ATTENTION (U.S.A. Only): The RBRC Recycle seal found on KENWOOD nickel-cadmium (Ni-Cd) battery packs indicates KENWOOD’s voluntary participation in an industry program to collect and recycle Ni-Cd batteries after their operating life has expired. The RBRC program is an alternative to disposing Ni-Cd batteries with your regular refuse or in municipal waste streams, which is illegal in some areas. For information on Ni-Cd battery recycling in your area, call (toll free) 1-800-8-BATTERY (1-800-822-8837). KENWOOD’s involvement in this program is part of our commitment to preserve our environment and conserve our natural resources. UNPACKING AND CHECKING EQUIPMENT Note: The following unpacking instructions are for use by your KENWOOD dealer, an authorized KENWOOD service facility, or the factory. Carefully unpack the transceiver. We recommend that you identify the items listed in the following table before discarding the packing material. If any items are missing or have been damaged during shipment, file a claim with the carrier immediately. § Accessories Quantity Item Part Number K Instruction Manual B62 -1759 - *0 1 Belt Clip J29 - 0710 -*5 1 Screw N30 - 3008 - 60 2 Cap B09 - 0625 - *3 1 Screw N08 - 0548 - *4 1 KENWOOD CORPORATION TK-2180-K, TK-2180-K2 FCC ID:ALH37323110 IC:282D-37323110 TK-3180-K, TK-3180-K3 FCC ID:ALH37333110 Installing/ Removing the Optional Battery Pack PREPARATION The battery pack is not charged at the factory; charge it before use. CAUTION: ‹ DO NOT RECHARGE THE BATTERY PACK IF IT IS ALREADY FULLY CHARGED. DOING SO MAY CAUSE HE LIFE OF THE BATTERY PACK TO SHORTEN OR THE BATTERY PACK MAY BE DAMAGED. ‹ AFTER RECHARGING THE BATTERY PACK, DISCONNECT IT FROM THE CHARGER. IF THE CHARGER POWER IS RESET (TURNED ON AFTER BEING TURNED OFF), RECHARGING WILL START AGAIN AND THE BATTERY PACK WILL BECOME OVERCHARGED. ‹ DO NOT SHORT THE BATTERY TERMINALS OR DISPOSE OF THE BATTERY BY FIRE. ‹ NEVER ATTEMPT TO REMOVE THE CASING FROM THE BATTERY PACK. 1 Match the guides of the battery pack with the corresponding grooves on the upper rear of the transceiver, then firmly press the battery pack t 2 Flip the safety catch into place to prevent accidentally pressing the release latch and removing the battery. 3 To remove the battery pack, lift the safety catch, press the release latch,then pull the battery pack away from the transceiver. KENWOOD CORPORATION TK-2180-K, TK-2180-K2 FCC ID:ALH37323110 IC:282D-37323110 TK-3180-K, TK-3180-K3 FCC ID:ALH37333110 Installing the Antenna Screw the antenna into the connector on the top of the transceiver by holding the antenna at its base and turning it clockwise until secure. Installing the Belt Clip If necessary, attach the belt clip using the two supplied 3 x 6 mm screws. Notes: If the belt clip is not installed, its mounting location may get hot during continuous transmission or when left sitting in a hot environment. KENWOOD CORPORATION TK-2180-K, TK-2180-K2 FCC ID:ALH37323110 IC:282D-37323110 TK-3180-K, TK-3180-K3 FCC ID:ALH37333110 Installing the Cap over the Speaker/Microphone Jacks If you are not using an optional KMC-25 …

Text truncated - open the document above for the full version.

TK-2180-K FCC ID:ALH37323110 IC:282D-37323110 TK-2180-K2 FCC ID:ALH37323110 IC:282D-37323110

TK-2180-K, TK-2180-K2 FCC ID:ALH37323110 IC:282D-37323110 TXRX Component Side View TXRX Foil Side View TK-2180-K, TK-2180-K2 FCC ID:ALH37323110 IC:282D-37323110 Display Component Side View Display Foil Side View

FCC ID: ALH37323110 Transmitter Certification of FCC ID: ALH37323110 Models: TK-2180-K and TK-2180-K2 to Federal Communications Commission Rule Parts 22, 74, 90, 90.210, Confidentiality Date of report: May 3, 2004 On the Behalf of the Applicant: Kenwood USA Corporation At the Request of: P.O. JB-F-006 Kenwood USA Corporation Communications Division 3975 Johns Creek Court, Suite 300 Suwanee, GA 30024 Attention of: Joel E. Berger, Research & Development [email protected] (678) 474-4722; FAX: -4731 Supervised by: Morton Flom, P. Eng. MFA p0430004, d0450002 FCC ID: ALH37323110 List of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: Kenwood USA Corporation FCC ID: ALH37323110 By Applicant: 1. Letter of Authorization x 2. Confidentiality Request: 0.457 And 0.459 x 3. Part 90.203(e) & (g) Attestation x 4. Identification Drawings, 2.1033(c)(11) x Label x Location of Label x Compliance Statement x Location of Compliance Statement 5. Photographs, 2.1033(c)(12) x 6. Documentation: 2.1033(c) (3) User Manual x (9) Tune Up Info x (10) Schematic Diagram x (10) Circuit Description x Block Diagram x Active Devices x By M.F.A. Inc.: A. Testimonial & Statement of Certification MFA p0430004, d0450002 FCC ID: ALH37323110 The Applicant has been cautioned as to the following: 15.21 Information to the User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. MFA p0430004, d0450002 FCC ID: ALH37323110 Table of Contents Rule Description Page . Test Report 1 2.1033(c) General Information Required 2 2.1033(c)(14) Rule Summary 6 . Standard Test Conditions and Engineering Practices 7 2.1046(a) Carrier Output Power (Conducted) 8 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 10 2.1046(a) ERP Carrier Power (Radiated) 29 2.1053(a) Field Strength of Spurious Radiation 30 90.214 Transient Frequency Behavior 34 2.1047(a) Audio Low Pass Filter (Voice Input) 40 2.1047(a) Audio Frequency Response 43 2.1047(b) Modulation Limiting 45 2.1055(a)(1) Frequency Stability (Temperature Variation) 48 2.1055(b)(1) Frequency Stability (Voltage Variation) 51 2.202(g) Necessary Bandwidth and Emission Bandwidth 52 MFA p0430004, d0450002 FCC ID: ALH37323110 Page Number 1 of 52. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0450002 d) Client: Kenwood USA Corporation Communications Division 3975 Johns Creek Court, Suite 300 Suwanee, GA 30024 e) Identification: TK-2180-K and TK-2180-K2 FCC ID: ALH37323110 EUT Description: VHF / FM Transceiver f) EUT Condition: Not required unless specified in individual tests. g) Report Date: May 3, 2004 EUT Received: March 9, 2004 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. MFA p0430004, d0450002 FCC ID: ALH37323110 Page Number 2 of 52. List of General Information Required for Certification In Accordance with FCC Rules and Regulations, Volume II, Part 2 and to 22, 74, 90, 90.210, Confidentiality Sub-part 2.1033 (c)(1): Name and Address of Applicant: Kenwood USA Corporation Communications Division 3975 Johns Creek Court, Suite 300 Suwanee, GA 30024 Manufacturer: Kenwood Electronics Technologies PTE Ltd. 1 Ang Mo Kio Street 63 Singapore 569110 (c)(2): FCC ID: ALH37323110 Model Numbers: TK-2180-K and TK-2180-K2 (c)(3): Instruction Manual(s): Please see attached exhibits (c)(4): Type of Emission: 16K0F3E, 11K0F3E (c)(5): Frequency Range, MHz: 136 to 174 (c)(6): Power Rating, Watts: 5 Switchable x Variable N/A FCC Grant Note: BE – The output power is continuously variable from the value listed in the entry to 15%-20% of the value listed. (c)(7): Maximum Power Rating, Watts: 300 DUT Results: Passes x Fails MFA p0430004, d0450002 FCC ID: ALH37323110 Page Number 3 of 52. Information for Push-To-Talk Devices Type and number of antenna to be used for this device: Whip antenna series Maximum antenna gain for antenna indicated above: 0dBi nominal Can this device sustain continuous operation with respect to its hardware capabilities and…

Text truncated - open the document above for the full version.
