Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
© B62-2364-00 (K2) 09 08 07 06 05 04 03 02 01 00 NX-410/ NX-411 800MHz DIGITAL TRANSCEIVER 900MHz DIGITAL TRANSCEIVER INSTRUCTION MANUAL ÉMETTEUR-RÉCEPTEUR NUMÉRIQUE 800MHz ÉMETTEUR-RÉCEPTEUR NUMÉRIQUE 900MHz MODE D’EMPLOI TRANSCEPTOR DIGITAL 800MHz TRANSCEPTOR DIGITAL 900MHz MANUAL DE INSTRUCCIONES 800MHz DIGITAL TRANSCEIVER 900MHz DIGITAL TRANSCEIVER NX-410/ NX-411 INSTRUCTION MANUAL ENGLISH Terminal Descriptions Universal connector It is possible to use a resin-based cover for the Universal connector. NO.Name Description ImpedanceI/O 1SSWExt/Int Speaker Switch InputHigh ImpedanceI 2SP+BTL Output + for External Speaker 8 Ω/ 16 Ω O 3SP-BTL Output - for External SpeakerO 4MSW Ext/Int MIC Switch Input High ImpedanceI 5EMC External MIC Input1.8 kΩI 6ME External MIC GND GND- 7PTTExternal PTT InputHigh ImpedanceI 8PFProgramable Function Key Input High ImpedanceI 9OPTMan Down InputHigh ImpedanceI 10EGNDGND- 115V5V power supply output5VO 12TXDSerial Data OutputCMOSO 13RXDSerial Data InputCMOSI 14NCNot used-- Antenna Terminal 50 Ω impedance Battery Terminal The battery terminal uses a spring plate. The negative terminal connects to the chassis ground. The battery is mounted on the rear side of the transceiver using a sliding mounting method. THANK YOU We are grateful you have chosen KENWOOD for your land mobile radio applications. This instruction manual covers only the basic operations of your NEXEDGE portable radio. Ask your dealer for information on any customized features they may have added to your radio. NOTICES TO THE USER ◆ Government law prohibits the operation of unlicensed radio transmitters within the territories under government control. ◆ Illegal operation is punishable by fine and/or imprisonment. ◆ Refer service to qualified technicians only. SAFETY: It is important that the operator is aware of and understands hazards common to the operation of any transceiver. i One or more of the following statements may be applicable: FCC WARNING This equipment generates or uses radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY THE FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can generate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer for technical assistance. ii The RBRC Recycle seal found on KENWOOD lithium-ion (Li-ion) battery packs indicates KENWOOD’s voluntary participation in an industry program to collect and recycle Li-ion batteries after their operating life has expired. The RBRC program is an alternative to disposing Li-ion batteries with your regular refuse or in municipal waste streams, which is illegal in some areas. For information on Li-ion battery recycling in your area, call (toll free) 1-800-8-BATTERY (1-800-822-8837). KENWOOD’s involvement in this program is part of our commitment to preserve our environment and conserve our natural resources. The RBRC Recycle seal found on KENWOOD nickel-cadmium (Ni-Cd) battery packs indicates KENWOOD ’s voluntary participation in an industry program to collect and recycle Ni-Cd batteries after their operating life has expired. The RBRC program is an alternative to disposing Ni-Cd batteries with your regular refuse or in municipal waste streams, which is illegal in some areas. For information on Ni-Cd battery recycling in your area, call (toll free) 1-800-8-BATTERY (1-800-822-8837). KENWOOD ’s involvement in this program is part of our commitment to preserve our environment and conserve our natural resources. The RBRC Recycle seal found on KENWOOD nickel metal hydride (Ni-MH) battery packs indicates KENWOOD ’s voluntary participation in an industry program to collect and recycle Ni-MH batteries after their operating life has expired. The RBRC program is an alternative to disposing Ni-MH batteries with your regular refuse or in municipal waste streams, which is illegal in some areas. For information on Ni-MH battery recycling in your area, call (toll free) 1-800-8-BATTERY (1-800-822-8837). KENWOOD ’s involvement in this program is part of our commitment to preserve our environment and conserve our natural resources. iii PRECAUTIONS • Do not charge the transceiver and battery pack when they are wet. • Ensure that there are no metallic items located between the transceiver and the battery pack. • Do not use options not specified by KENWOOD. • If the die-cast chassis or other transceiver part is damaged, do not touch the damaged parts. • If a headset or headphone is connected to the transceiver, reduce the transceiver volume. Pay attention to the volume level when turning the squelch off. • Do not place the microphone cable around your neck while near machinery that may catch the cable. • Do not place the transceiver on unstable surfaces. • Ensure that the end of the antenna does not touch your eyes. • When the transceiver is used for transmission for man…
Text truncated - open the document above for the full version.
November 1, 2011 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 To Whom It May Concern: This letter will authorize Compliance Testing LLC to act as our Agent in all FCC matters. This appointment is effective until otherwise notified by us. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The Applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely,
October 31, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attn: Reviewing Engineer RE: CONFIDENTIALITY REQUEST FOR MODEL: NX-411-K2, FCC ID: ALH409001. To Whom It May Concern: This letter serves as an official request for permanent confidentiality pursuant to 47 CFR Section 0.459 of the Commission Rules. We have requested that the Block Diagram, Schematic Diagrams, Circuit Description, Parts List, Active Devices and Tuning Procedure required to be submitted with this application be withheld from public review. The documents are company proprietary information that should never get into the possession of our competition. Please contact me if you require any additional information. Sincerely,
NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 Rear View Front View NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 Left View Right View NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 Top View Bottom View
NX-411-K2 FCC ID: ALH409001 IC: 282D-409001
NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 DISPLAY UNIT NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 DISPLAY UNIT NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 DISPLAY UNIT NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 TXRX UNIT NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 TXRX UNIT NX-411-K2 FCC ID: ALH409001 IC: 282D-409001 TXRX UNIT
Applicant: Kenwood USA Corporation FCC ID: ALH409001 IC: 282D-409001 DUT Type: Portable Digital PTT Radio Transceiver DUT Model: NX-411-K2 896-902 / 935-941 MHz 2011 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 60 Date(s) of Evaluation October 06-07, 2011 Test Report Serial No. 092811ALH-T1125-S90P Test Report Revision No. Rev. 1.0 (1st Release) Test Report Issue Date October 20, 2011 Description of Test(s) Specific Absorption Rate RF Exposure Category Occupational (Controlled) Test Lab Certificate No. 2470.01 DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION FCC & IC Name CELLTECH LABS INC. Test Lab Information Address 21-364 Lougheed Road, Kelowna, B.C. V1X 7R8 Canada Test Lab Accreditation(s) A2LA ISO/IEC 17025:2005 (A2LA Test Lab Certificate No. 2470.01) Name KENWOOD USA CORPORATION Applicant Information Address 3970 Johns Creek Court, Suite 100, Suwanee, GA 30024 United States Standard(s) Applied FCC 47 CFR §2.1093 ICHealth Canada Safety Code 6 FCC OET Bulletin 65, Supplement C FCCKDB 447498 D01v04 FCC KDB 643646 D01v01r01 (SAR Test Reduction Considerations for Occ. PTT Radios) IC RSS-102 Issue 4 IEEE1528-2003 Procedure(s) Applied IEC62209-2:2010 FCC Licensed Non-Broadcast Transmitter Held to Face (TNF) - FCC Part 90, 24D Device Classification(s) IC Land Mobile Radio Transmitter/Receiver (27.41-960 MHz) - RSS-119, RSS-134 FCC ID: ALH409001 FCC App. Type TCB New Certification Device Identifier(s) IC: 282D-409001 IC App. Type CB New Certification Date of Sample Receipt September 28, 2011 Date(s) of Evaluation October 06-07, 2011 Device Description Portable 900-Band Push-To-Talk (PTT) Digital Radio Transceiver Device Model(s) NX-411-K2 Test Sample Serial No.00232058 (Identical Prototype) Test Sample Revision No.s Hardware Revision 0 Firmware Revision 0 896-901 MHz (Part 90, RSS-119) 901-902 MHz (Part 24D, RSS-134) DUT Transmit Frequency Range(s) FCC/IC 935-940 MHz (Part 90, RSS-119) 940-941 MHz (Part 24D, RSS-134) Manufacturer’s Rated Output Power 2.5 Watts (Conducted) Manuf. Tolerance Spec. +/- 0 dB 33.98 dBm 2.5 Watts 896.05 MHz Average Conducted RF Output Power Levels Measured 33.98 dBm 2.5 Watts 935.05 MHz Average Conducted Antenna Type(s) Tested Whip Antenna P/N: KRA-38 896-940 MHz Length: 182 mm Li-Ion 7.4V 1700 mAh P/N: KNB-33L Ni-MH 7.2V 2500 mAh P/N: KNB-32N Battery Type(s) Tested Alkaline Battery Case 9 V 6x AA P/N: KBP-6 Body-worn Accessories Tested Belt-Clip (contains metal) P/N: KBH-11 Audio Accessories Tested Speaker-Microphone P/N: KMC-41 Face-held 0.560 W/kg 1g50% PTT duty factor Occupational / Controlled Exp. Max. SAR Level(s) Evaluated Body-worn 1.35 W/kg 1g50% PTT duty factor Occupational / Controlled Exp. FCC/IC Spatial Peak SAR Limit Head/Body 8.0 W/kg 1g50% PTT duty factor Occupational / Controlled Exp. Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada Safety Code 6 for the Occupational / Controlled Exposure environment. The device was tested in accordance with the measurement procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), Industry Canada RSS-102 Issue 4, IEEE Standard 1528-2003 and International Standard IEC 62209-2:2010. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Test Report Approved BySean JohnstonLab ManagerCelltech Labs Inc. Applicant: Kenwood USA Corporation FCC ID: ALH409001 IC: 282D-409001 DUT Type: Portable Digital PTT Radio Transceiver DUT Model: NX-411-K2 896-902 / 935-941 MHz 2011 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 2 of 60 Date(s) of Evaluation October 06-07, 2011 Test Report Serial No. 092811ALH-T1125-S90P Test Report Revision No. Rev. 1.0 (1st Release) Test Report Issue Date October 20, 2011 Description of Test(s) Specific Absorption Rate RF Exposure Category Occupational (Controlled) Test Lab Certificate No. 2470.01 TABLE OF CONTENTS 1.0 INTRODUCTION __________________________________________________________________ 4 2.0 SAR MEASUREMENT SYSTEM ______________________________________________________ 4 3.0 RF CONDUCTED OUTPUT POWER MEASUREMENTS ___________________________________ 5 4.0 FCC POWER THRESHOLDS FOR PTT DEVICES (F< 0.5 GHZ) ____________________________ 5 5.0 NO. OF TEST CHANNELS (N C )_______________________________________________________ 5 6.0 SAR PROBE CALIBRATION & MEASUREMENT FREQUENCIES ___________________________ 6 7.0 MANUFACTURER’S DISCLOSED ACCESSORY LISTING _________________________________ 7 8.0 FLUID DIELECTRIC PARAMETERS___________________________________________________ 8 9.0 TEST REDUCTION PROCEDURES (FCC KDB 643646 D01V01R01) ________________________ 10 10.0 SAR MEASUREMENT SUMMARY __________________________________________________ 11 11.0 SAR SCALING (TUNE-UP TOLERANCE) ____________________________________________ 13 12.0 DETAILS OF SAR EVALUATION ___________________________________________________ 14 13.0 SAR EVALUATION PROCEDURES_________________________________________________ 14 14.0 SYSTEM PERFORMANCE CHECK _________________________________________________ 15 15.0 SIMULATED EQUIVALENT TISSUES _______________________________________________ 16 16.0 SAR…
Text truncated - open the document above for the full version.
Radio FRequency eneRgy SaFety inFoRmation This Kenwood transceiver has been tested and complies with the standards listed below, in regards to Radio Frequency (RF) energy and electromagnetic energy (EME) generated by the transceiver. • FCC RF exposure limits for Occupational Use Only. RF Exposure limits adopted by the FCC are generally based on recommendations from the National Council on Radiation Protection and Measurements, & the American National Standards Institute. • FCC OET Bulletin 65 Edition 97-01 Supplement C • American National Standards Institute (C95.1 – 1992) • American National Standards Institute (C95.3 – 1992) This Kenwood transceiver generates RF EME while transmitting. RF EME (Radio Frequency Electric & Magnetic Energy) has the potential to cause slight thermal, or heating effects to any part of your body less than the recommended distance from this radio transmitter’s antenna. RF energy exposure is determined primarily by the distance to and the power of the transmitting device. In general, RF exposure is minimized when the lowest possible power is used or transmission time is kept to the minimum required for consistent communications, and the greatest distance possible from the antenna to the body is maintained. The transceiver has been designed for and is classified for Occupational Use Only. Occupational/ controlled exposure limits are applicable to situations in which persons are exposed to RF energy as a consequence of their employment, and such persons have been made aware of the potential for exposure and can exercise control over their exposure. This means you can use the transceiver only if you are aware of the potential hazards of operating a transceiver and are familiar in ways to minimize these hazards. This transceiver is not intended for use by the general public in uncontrolled environments. Uncontrolled environment exposure limits are applicable to situations in which the general public may be exposed to RF energy, or in which the persons who are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. The following list provides you with the information required to ensure that you are aware of RF exposure and of how to operate this transceiver so that the FCC RF exposure limitations are not exceeded. • While transmitting (holding the PTT switch or speaking with VOX enabled), always keep the antenna and the radio at least 3 cm (1 3/16 inches) from your body or face, as well as from any bystanders. A LED on the top of the radio shows red when the transmitter is operating in both PTT and VOX modes. • Do not transmit for more than 50% of the total transceiver use time; transmitting over 50% of the total use time may exceed the limits in accordance to the FCC RF exposure requirements. Nominal transceiver operation is 5% transmission time, 5% reception time, and 90% stand-by time. • Use only the specified antenna for this transceiver; this may be either the antenna provided with the transceiver or another antenna authorized by Kenwood . Use only Kenwood authorized accessories (antennas, battery packs, belt clips, Speaker/ Mics or headsets etc.): When worn on the body, always place the radio in a Kenwood recommended clip or carrying case meant for this product. The use of other than recommended or approved body- worn accessories may result in RF exposure levels which exceed the FCC’s occupational/ controlled environment RF exposure limits. To ensure that your exposure to RF EME is within the FCC limits for occupational use, you must observe and adhere to the above points. Electromagnetic Interference Compatibility Electronic devices are susceptible to electromagnetic interference (EMI) if they are not adequately shielded or designed for electromagnetic compatibility. Because this transceiver generates RF energy, it can cause interference to such equipment. • Turn OFF your transceiver where signs are posted to do so. Hospitals and health care facilities use equipment that is sensitive to electromagnetic radiation. • Turn OFF your transceiver while on board an aircraft when so instructed. Use of the transceiver must be in accordance with airline regulations and/or crew instructions. B59-2546-00
p1180017_FCC_Part 24_90_Rev 1.0 Page 1 of 47 Test Report Prepared for: Kenwood USA Corporation Model: NX-411-K2 Description: 900MHz Digital Transceiver To FCC Part 24 and 90 Date of Issue: September 27, 2011 On the behalf of the applicant: Kenwood USA Corporation 3970 Johns Creek Ct Ste 100 Suwanee, GA 30024 Attention of: Joel Berger, Research & Development Ph: (678)474-4722 Fax: (602)489-5896 E-Mail: [email protected] Prepared by Compliance Testing, LLC 3356 N San Marcos Pl, Suite 107 Chandler, AZ 85225-7176 (866) 311-3268 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p1180017 John Erhard Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p1180017_FCC_Part 24_90_Rev 1.0 Page 2 of 47 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 September 27, 2011 John Erhard Original Document p1180017_FCC_Part 24_90_Rev 1.0 Page 3 of 47 Table of Contents Description Page Test Report Revision History 2 Standard Test Conditions and Engineering Practices 7 Test Result Summary 8 Carrier Output Power (Conducted) 9 Conducted Spurious Emissions 10 Field Strength of Spurious Radiation 17 Emission Masks (Occupied Bandwidth) 20 Audio Low Pass Filter (Voice Input) 30 Audio Frequency Response 31 Modulation Limiting 32 Frequency Stability (Temperature Variation) 35 Frequency Stability (Voltage Variation) 39 Receiver Spurious Emissions 43 Necessary Bandwidth Calculation 45 Test Equipment Utilized 47 p1180017_FCC_Part 24_90_Rev 1.0 Page 4 of 47 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless noted in the table below. Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC OATS Reg, #933597 IC Reg. #2044A-1 Non-accredited tests contained in this report: N/A p1180017_FCC_Part 24_90_Rev 1.0 Page 5 of 47 The Applicant has been cautioned as to the following: 15.21: Information to the User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance cold void the user’s authority to operate the equipment. 15.27(a): Special Accessories Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without an additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. p1180017_FCC_Part 24_90_Rev 1.0 Page 6 of 47 Sub-part 2.1033(c)(14): Test and Measurement Data All tests and measurement data shown were performed in accordance with FCC Rules and Regulations, Volume II, Part 2, Sub-part J, Sections 2.947, 2.1033(c), 2.1041, 2.1046, 2.1047, 2.1079, 2.1051, 2.1053, 2.1055, 2.1057, and the following individual Parts: 24 and 90. p1180017_FCC_Part 24_90_Rev 1.0 Page 7 of 47 Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing. In accordance with ANSI/C63.4-2009, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Environmental Conditions Temperature Humidity 21.76 34.45 Measurement results, unless otherwise noted, are worst-case measurements. EUT Description: Model: S/N: Firmware: Software: EUT during Test Conditions: Accessories: None Qty Type Make, Model S/N Description p1180017_FCC_Part 24_90_Rev 1.0 Page 8 of 47 Test Result Summary Specification Test Name Pass, Fail, N/A Comments 2.1046 Carrier Output Power (Conducted) Pass 2.1051 Unwanted Emissions (Transmitter Conducted) Pass 2.1053 Field Strength of Spurious Radiation Pass 90.210 / 24.133 Emission Masks (Occupied Bandwidth) Pass 2.1047 Audio Low Pass Filter (Voice Input) Pass 2.1047 Audio Frequency Response Pass 2.1047 Modulation Limiting Pass 90.213 Frequency Stability (Temperature Variation) Pass 90.213 Frequency Stability (Voltage Variation) Pass p1180017_FCC_Part 24_90_Rev 1.0 Page 9 of 47 Carrier Output Power (Conducted) Name of Test: Carrier Output Power (Conducted) Specification: 2.1046 Engineer: John Erhard …
Text truncated - open the document above for the full version.
Page 1 of 5 Test Setup Photos: Kenwood FCC ID: ALH409001 IC: 282D-409001 AC Conducted AC Conducted Page 2 of 5 Radiated Emissions Radiated Emissions Page 3 of 5 Radiated Emissions Radiated Emissions Page 4 of 5 RF Conducted Radiated Conducted Page 5 of 5 RF Conducted
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 4 | 9 | 935 MHz - 940 MHz | 2.5 W | NOTE 1 | 1 ppm |
