AMBJN7Wireless USB Adapter

NextG High Power USB WiFi Adapter This manual walks though the steps of setting up the NextG High Power USB WiFi Adapter from quick start followed by detailed explanation of what each parameter does. Instruction Manual Instruction Manual DN-WLAN-028 Page 2 Copyright© by Datacom Network Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this Company .This company makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove defective following their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software. Further, this company reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes. The software and specifications are subject to change without notice. All rights reserved including all brand and product names mentioned in this manual are trademarks and/or registered trademarks of their respective holders Linux Open Source Code Certain products include software code developed by third parties, software code is subject to the GNU General Public License ("GPL") or GNU Lesser General Public License ("LGPL"). Please see the GNU (www.gnu.org) and LPGL(www.gnu.org) Websites to view the terms of each license. The GPL Code and LGPL Code used in products are distributed without any warranty and are subject to the copyrights of their authors. For details, see the GPL Code and LGPL Code licenses. Instruction Manual DN-WLAN-028 Page 3 Table of Contents 2. QUICK START ......................................................................................................................................... 4 2.1 INSTALLATION AND DEVICE CONNECTION ................................................................................................. 4 1. SCANNING THE WIFI SIGNAL – A QUICK GUIDE ................................................................... 5 1.1 RALINK WIRELESS UTILITY (RAUI) OR WINDOWS ZERO CONFIGURATION (WZC) .. 5 1.2 WORKING WITH WZC ................................................................................................................................ 5 1.2.1 Configuration of NIC by using WZC ........................................................................................ 6 1.3 WORKING WITH RAUI .............................................................................................................................. 10 2. ADVANCED RAUI FEATURES ....................................................................................................... 12 2.1 PROFILE ..................................................................................................................................................... 12 2.1.1 Example to Add a PROFILE ...................................................................................................... 13 2.2 NETWORK ................................................................................................................................................... 17 2.2.1 Network – General ..................................................................................................................... 18 2.2.2 Network – WPS ............................................................................................................................ 19 2.2.3 Network – CCX (Cisco Compatible Extensions) ............................................................. 20 2.2.4 Network – 802.11n ................................................................................................................... 20 2.3 ADVANCED .............................................................................................................................................. 21 2.4 STATISTICS .............................................................................................................................................. 22 2.4.1 Transmit Statistics ..................................................................................................................... 22 2.4.2 Receive Statistics ........................................................................................................................ 23 2.5 WWM ........................................................................................................................................................ 23 2.6 WPS ........................................................................................................................................................... 25 2.7 CCX (CISCO COMPATIBLE EXTENSIONS) ............................................................................................... 27 2.8 RADIO ON/OFF ......................................................................................................................................... 27 Instruction Manual DN-WLAN-028 Page 4 2. Quick Start 2.1 Installation and Device Connection Install the CD-ROM software driver before you plug in the USB adapter to you PC or laptop computer. This avoids the USB adapter being recognized by another existing WiFi software driver which might not be fully compatible with the original software driver. Before making any device and cable connection to the computer, you have to install the CD software driver and utility from fresh. Insert the CD-ROM into the CD/DVD drive of your computer. …

Text truncated - open the document above for the full version.

BearExtender Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for ( FCC ID: AMBJN7 ) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Date: 2013/7/28 Name: Roland Saekow Title: Co-founder Tel: 3523729902 Company: BearExtender

Differences Description We BearExtender state: Product name: Wireless USB Adapter Model: JN7, NWC2, NW200, NW610, NW614, NWA2, NWB2, NW617, NW618, NWD2 All model’s the function, software and electric circuit are the same , only with a product color and model named different. Signatory Signature Date: 2013/7/28 Name: Roland Saekow Title: Co-founder Tel: 3523729902 Company: BearExtender

BearExtender SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 BearExtender SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013/7/28 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, BearExtender hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： Wireless USB Adapter Model Name： JN7, NWC2, NW200, NW610, NW614, NWA2, NWB2, NW617, NW618, NWD2 Trade name: BearExtender FCC ID： AMBJN7 We affirm that between SIEMIC and __ BearExtender __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Date: 2013/7/28 Name: Roland Saekow Title: Co-founder Tel: 3523729902 Company: BearExtender

BearExtender SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 BearExtender SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 2013/7/28 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: AMBJN7 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Date: 2013/7/28 Name: Roland Saekow Title: Co-founder Tel: 3523729902 Company: BearExtender

Full View Top View Bottom View Rear View Left View Right View Front View EUT View

Label: Label Location FCC ID: AMBJN7 BearExtender Model No.: JN7 Product name: Wireless USB Adapter This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Top View Top View Bottom View Antenna

FCC ID: AMBJN7 RF EXPOSURE TEST FCC ID: AMBJN7 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation17  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: AMBJN7 Maximum measured transmitter power. 802.11B frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2412 9.31 8.53 2437 9.25 8.41 2462 9.28 8.47 802.11G frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2412 8.43 6.97 2437 8.38 6.89 2462 8.41 6.93 802.11N20 frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2412 8.21 6.62 2437 8.15 6.53 2462 8.17 6.56 FCC ID: AMBJN7 802.11N 40M frequency range Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2412 7.04 5.06 2437 6.98 4.99 2462 7.01 5.02 The max.output power E.I.R.P is 9.31dBm=8.53mW, Frequency is 2.412GHz So (8.53/5)* √2.412=2.6494≤ 3.0 Note: √2.412 =1.553 Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID: AMBJN7 Product： Wireless USB Adapter Trade Name： BearExtender Model Name： JN7 Serial Model： NWC2, NW200, NW610, NW614, NWA2, NWB2, NW617, NW618, NWD2 Report No.： BZT13071814-1ER Prepared for BearExtender 1406 Henry Street, Berkeley, California, 94709, USA Prepared by BZT Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. BZT Testing Technology Co., Ltd Page 2 of 75 Report No.: BZT13071814-1ER TEST RESULT CERTIFICATION Applicant’s name ................. : BearExtender Address ................................. : 1406 Henry Street, Berkeley, California, 94709, USA Manufacture's Name ............ : HK YUNLINK TECHNOLOGY LTD Address ................................. : A9 Building, Longwangmiao Industrial Zone, Baishixia East,Fuyong Town, Baoan, Shenzhen Guangdong Province China Product description Product name............................ : Wireless USB Adapter Model and/or type reference : JN7 Serial Model .............................. : NWC2, NW200, NW610, NW614, NWA2, NWB2, NW617, NW618, NWD2 DIFF ........................................... : All model’s the function, software and electric circuit are the same , only with a product color and model named different. Test sample model: JN7 Standards ............................. : FCC Part15.247 Test procedure ............................... : ANSI C63.4-2003 This device described above has been tested by BZT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BZT, this document may be altered or revised by BZT, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 18 July. 2013 ~26 July. 2013 Date of Issue .......................................... : 27 July. 2013 Test Result.............................................. : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) BZT Testing Technology Co., Ltd Page 3 of 75 Report No.: BZT13071814-1ER Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 36 4 . POWER SPECTRAL DENSITY TEST 52 4.1 APPLIED PROCEDURES / LIMIT 52 4.1.1 TEST PROCEDURE 52 4.1.2 DEVIATION FROM STANDARD 52 4.1.3 TEST SETUP 52 4.1.4 EUT OPERATION CONDITIONS 52 4.1.5 TEST RESULTS 53 5 . BANDWIDTH TEST 62 5.1 APPLIED PROCEDURES / LIMIT 62 BZT Testing Technology Co., Ltd Page 4 of 75 Report No.: BZT13071814-1ER Table of Contents Page 5.1.1 TEST PROCEDURE 62 5.1.2 DEVIATION FROM STANDARD 62 5.1.3 TEST SETUP 62 5.1.4 EUT OPERATION CONDITIONS 62 5.1.5 TEST RESULTS 63 6 . PEAK OUTPUT POWER TEST 71 6.1 APPLIED PROCEDURES / LIMIT 71 6.1.1 TEST PROCEDURE 71 6.1.2 DEVIATION FROM STANDARD 71 6.1.3 TEST SETUP 71 6.1.4 EUT OPERATION CONDITIONS 71 6.1.5 TEST RESULTS 72 7 . ANTENNA REQUIREMENT 73 7.1 STANDARD REQUIREMENT 73 7.2 EUT ANTENNA 73 8 . EUT TEST PHOTO 74 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS BZT Testing Technology Co., Ltd Page 5 of 75 Report No.: BZT13071814-1ER 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report BZT Testing Technology Co., Ltd Page 6 of 75 Report No.: BZT13071814-1ER 1.1 TEST FACILITY BZT Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.: 701733 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% BZT Testing Technology Co., Ltd Page 7 of 75 Report No.: BZT13071814-1ER 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Wireless USB Adapter Trade Name BearExtender Model Name JN7 Serial Model NWC2, NW200, NW610, NW614, NWA2, NWB2, NW617, NW618, NWD2 Model Difference All model’s the function, software and electric circuit are the same , only with a product color and model named different. Test sample model: JN7 Product Description The EUT is a Wireless USB Adapter Operation Frequency: 802.11b/g/n 20:2412~2462 MHz 802.11n 40: 2422~2452MHz Modulation Type: CCK/OFDM/DBPSK/DA…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup in Chamber Conducted Emission Test Setup in Chamber
