AMPL71ALCD Monitor

Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method for encouraging the adaptation of goods and services to the environment. The main problem, as far as computers and other electronics equipment are concerned, is that environmentally harmful substances are used both in the products and during their manufacture. Since it is not so far possible to satisfactorily recycle the majority of electronics equipment, most of these potentially damaging substances sooner or later enter nature. There are also other characteristics of a computer, such as energy consumption levels, that are important from the viewpoints of both the work (internal) and natural (external) environments. Since all methods of electricity generation have a negative effect on the environment (e.g. acidic and climate-influencing emissions, radioactive waste), it is vital to save energy. Electronics equipment in offices is often left running continuously and thereby consumes a lot of energy. What does labelling involve? This product meets the requirements for the TCO'99 scheme, which provides for international and environmental labelling of personal Page1-2 stands for TCO’99 model only. Please see back label for model distinction. computers. The labelling scheme was developed as a joint effort by the TCO (The Swedish Confederation of Professional Employees), Svenska Naturskyddsforeningen (The Swedish Society for Nature Conservation) and Statens Energimyndighet (The Swedish National Energy Administration). Approval requirements cover a wide range of issues: environment, ergonomics, usability, emission of electric and magnetic fields, energy consumption and electrical and fire safety. The environmental demands impose restrictions on the presence and use of heavy metals, brominated and chlorinated flame retardants, CFCs (freons) and chlorinated solvents, among other things. The product must be prepared for recycling and the manufacturer is obliged to have an environmental policy which must be adhered to in each country where the company implements its operational policy. The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for the user. Labelled products must meet strict environmental demands, for example, in respect of the reduction of electric and magnetic fields, physical and visual ergonomics and good usability. On the Back page of this folder, you will find a brief summary of the environmental requirements met by this product. The complete environmental criteria document may be ordered from: TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): [email protected] Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs. Both the flame retardants containing bromine or chloride and the PCBs are suspected of giving rise to severe health effects, including reproductive damage in fish-eating birds and mammals, due to the bio-accumulative * processes. Flame retardants have been found in human blood and researchers fear that disturbances in foetus development may occur. The relevant TCO'99 demand requires that plastic components weighing more than 25 grams must not contain flame retardants with organically bound bromine or chlorine. Flame retardants are allowed in the printed circuit boards since no substitutes are available. Cadmium Cadmium is present in rechargeable batteries and in the colour- generating layers of certain computer displays. Cadmium damages the nervous system and is toxic in high doses. The relevant TCO'99 * Bio-accumulative is defined as substances which accumulate within living organisms requirement states that batteries, the color-generating layers of display screens and the electrical or electronics components must not contain any cadmium. Mercury Mercury is sometimes found in batteries, relays and switches. It damages the nervous system and is toxic in high doses. The relevant TCO'99 requirement states that batteries may not contain any mercury. It also demands that mercury is not present in any of the electrical or electronics components associated with the labelled unit. CFCs (freons) The relevant TCO'99 requirement states that neither CFCs nor HCFCs may be used during the manufacture and assembly of the product. CFCs (freons) are sometimes used for washing printed circuit boards. CFCs break down ozone and thereby damage the ozone layer in the stratosphere, causing increased reception on earth of ultraviolet light with e.g. increased risks of skin cancer (malignant melanoma) as a consequence. Lead ** Lead can be found in picture tubes, display screens, solders and capacitors. Lead damages the nervous system and in higher doses, causes lead poisoning. The relevant TCO ́99 requirement permits the inclusion of lead since no replacement has yet been developed. ** Lead, Cadmium and Mercury are heavy metals which are Bio- accumulative. Operation Instructions Thank you for pu…

Text truncated - open the document above for the full version.

(Photo 1) FCC ID: AMPL71A (Photo 2) FCC ID: AMPL71A (Photo 3) FCC ID: AMPL71A (Photo 22) FCC ID: AMPL71A (Photo 23) FCC ID: AMPL71A

120 37 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: AMPL71A Date of Mfg.: Serial No: As an ENERGY STAR R Partner, JEAN CO., LTD. has determined that this product meets the ENERGY STAR R guidelines for energy efficiency. This device complies with the LOW EMISSIONS requirements of MPR 1990: 8 (MPRII) . MODEL NAME:JT178A3 Type No.: L71A Rating: 12Vdc 3.5A 89.10.251:1 JT178A3 NEUTRAL Set Label mm 2055132001 1 X E137379 LISTED 6K28 UL1950 JEAN CO. LTD. 7F,2, Rei Kuang Road, Nei Hu, TAIPEI, TAIWAN Made in Taiwan

(Fig. 1) FCC ID: AMPL71A FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

(Photo 4) FCC ID: AMPL71A (Photo 5) FCC ID: AMPL71A 2 (Photo 6) FCC ID: AMPL71A 4 (Photo 7) FCC ID: AMPL71A (Photo 8) FCC ID: AMPL71A 3 (Photo 9) FCC ID: AMPL71A (Photo 10) FCC ID: AMPL71A (Photo 11) FCC ID: AMPL71A 5 (Photo 12) FCC ID: AMPL71A (Photo 13) FCC ID: AMPL71A

(Photo 14) FCC ID: AMPL71A (Photo 15) FCC ID: AMPL71A (Photo 16) FCC ID: AMPL71A (Photo 17) FCC ID: AMPL71A (Photo 18) FCC ID: AMPL71A (Photo 19) FCC ID: AMPL71A (Photo 20) FCC ID: AMPL71A (Photo 21) FCC ID: AMPL71A 1 6 (Photo 24) FCC ID: AMPL71A (Photo 25) FCC ID: AMPL71A (Photo 26) FCC ID: AMPL71A

ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 1 FCC ID: AMPL71A EMC TEST REPORT REPORT NO.: F89100209B MODEL NO.: JT178A DATE OF TEST: Dec. 6, 2000 DATE OF RECEIPT: Nov. 15, 2000 PREPARED FOR: JEAN CO., LTD. ADDRESS : 7F, 2, REI KUANG ROAD, NEI HU, TAIPEI, TAIWAN, R.O.C. PREPARED BY:ADVANCE DATA TECHNOLOGY CORPORATION 11F, NO.1, SEC.4, NAN-KING EAST RD., TAIPEI, TAIWAN, R.O.C. This test report consists of 25 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of our laboratory. It should not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. government. The test result in the report only applies to the tested sample. Accredited Laboratory ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 2 FCC ID: AMPL71A TABLE OF CONTENTS 1.CERTIFICATION..................................................................................................................3 2.GENERAL INFORMATION..................................................................................................4 2.1GENERAL DESCRIPTION OF EUT.....................................................................4 2.2DESCRIPTION OF SUPPORT UNITS..................................................................5 2.3TEST METHODOLOGY AND CONFIGURATION.............................................5 3.TEST INSTRUMENTS..........................................................................................................6 3.1TEST INSTRUMENTS (EMISSION)....................................................................6 3.2LIMITS OF CONDUCTED AND RADIATED EMISSION...................................7 4.TEST RESULTS (EMISSION)............................................................................................8 4.1RADIO DISTURBANCE.......................................................................................8 4.2EUT OPERATION CONDITION...........................................................................8 4.3TEST DATA OF CONDUCTED EMISSION (A)..................................................9 4.4TEST DATA OF CONDUCTED EMISSION (B)................................................11 4.5TEST DATA OF CONDUCTED EMISSION (C)................................................13 4.6TEST DATA OF RADIATED EMISSION (A)....................................................16 4.7TEST DATA OF RADIATED EMISSION (B)....................................................18 4.8TEST DATA OF RADIATED EMISSION (C)....................................................20 5.PHOTOGRAPHS OF THE TEST CONFIGURATION WITH MINIMUM MARGIN......22 6.APPENDIX - INFORMATION OF THE TESTING LABORATORY.................................26 ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 3 FCC ID: AMPL71A 1. CERTIFICATION Issue Date: Dec. 20, 2000 Reference No.: 89111502 Product:17” LCD MONITOR Trade Name:JEAN Model No.:JT178A Applicant:JEAN CO., LTD. Standard:FCC Part 15, Subpart B, Class B CISPR 22: 1997, Class B ANSI C63.4-1992 We hereby certify that one sample of the designation has been tested in our facility on Dec. 6, 2000. The test record, data evaluation and Equipment Under Test (EUT) configurations represent herein are true and accurate representation of the measurements of the sample's EMC characteristics under the conditions herein specified. The test results show that the EUT as described in this report is in compliance with the Class B limits of conducted and radiated emission of applicable standards. ADVANCE DATA TECHNOLOGY CORPORATION Accredited Laboratory ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 4 FCC ID: AMPL71A 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product:17” LCD MONITOR Model No.:JT178A Power Supply Type:Switching (from Power Adapter) Power Cord:Nonshielded 3-pin (1.5 m) Data Cable:Shielded (1.8 m) Note: The EUT is a 17” LCD MONITOR with resolution up to 1280 x 1024. The EUT has three kinds of signal output mode: 1. DVI mode 2. D-SUB mode 3. S-Video mode All the above modes were tested, and its data recorded in this report accordingly. The EUT was tested using ViewSonic power adapter, model: API-208- 98010. It has input rating: 100-240V, 1.5A, 50-60Hz and output rating: 12V, 3.6A. There is a ferrite core on the DC output cable of the power adapter. There are two ferrite cores on the video cable outside the monitor. For more detailed features description, please refer to Manufacturer’s Specification or User's Manual. ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 5 FCC ID: AMPL71A 2.2 DESCRIPTION OF SUPPORT UNITS The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories are used to form representative test configuration during the tests. No.ProductBrandModel No.Serial No.FCC ID 1 PERSONAL COMPUTER NTIPI I-333TP201102 FCC DoC APPROVED 2PS/2 KEYBOARDFORWARDFDA-104GAFDKB8110111F4ZDA-104G 3MOUSELOGITECHM-S43LZE00703197DZL211106 4MODEMACEEX1414980020569IFAXDM1414 5PRINTERHP2225C+3123S97230DSI6XU2225 6SPEAKERJAZZJ-008J797411NA 7 VIDEO CASSETTE RECORDER MITSUBIS HI HS-U775017552M BGBHS-U795 No.Signal cable description 1NA 21.5 m foil shielded wire, terminated with PS/2 connector via metallic frame, w/o core. 31.5 m foil shielded wire, terminated with PS2 connector via drain wire, w/o core. 41.2 m braid shielded wire, terminated with DB25 and DB9 connector via metallic frame, w/o core. 51.2m braid shielded wire, terminated with DB25 and Centronics connector via metallic frame, w/o core. 61.1 m wrapped shielded wire, terminated via drain wire, with 3.5 mm phone plug, w/o core. 7NA Note: 1. All power cords of the above support units are non shielded (1.8m). 2. An audio cable (1.7m) was connected between EUT and support unit 1. 3.An AV cable (1.5m) was connected between the AV terminal port of EUT and Support unit 7. 4…

Text truncated - open the document above for the full version.

ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 22 FCC ID: AMPL71A 5. PHOTOGRAPHS OF THE TEST CONFIGURATION WITH MINIMUM MARGIN CONDUCTED EMISSION TEST (MODE 1, 2) ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 23 FCC ID: AMPL71A (MODE 3) ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 24 FCC ID: AMPL71A RADIATED EMISSION TEST (MODE 1, 2) ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89100209B Page 25 FCC ID: AMPL71A (MODE 3)
