ANO12P701ZNotebolok Type PC IBM ThinkPad Series

i Note:Before using this information and the product it supports, be sure to read the general information under “Safety information” on page v, and Appendix A, “Product warranty and notices” on page 55. First Edition (November 2000) The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with local law: INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION "AS IS" WITHOUT ANY WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE LIMITED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimers or express or implied warranties in certain transactions; therefore, this statement may not apply to you. This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements or changes in the products or the programs described in this publication at any time. Requests for technical information about IBM products should be made to your IBM Authorized Dealer or your IBM Marketing Representative.  Copyright International Business Machines Corporation 2000. All rights reserved. Note to US Government Users — Documentation related to restricted rights — Use, duplication, or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with IBM Corp. Contents Safety information . . . . . . . . . . . . . . . . . . . . . . . . . .v Chapter 1. Caring for your ThinkPad computer........ 1 Important tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Be careful about where you work. ................ 2 Be gentle with your computer.................... 2 Carry your computer properly. ................... 2 Handle storage media and drives properly............ 3 Take care in setting passwords................... 3 Other important tips ......................... 3 Cleaning your computer...................... 4 Extending the usefulness of the battery............. 4 Chapter 2. System overview . . . . . . . . . . . . . . . . . . . .7 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 Using your on-board help...................... 12 Starting the BIOS Setup Utility ................... 13 Chapter 3. Protecting your computer ............. 15 Using passwords . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Power-on password . . . . . . . . . . . . . . . . . . . . . . . .16 Screen-saver password . . . . . . . . . . . . . . . . . . . . .16 Hard-disk password . . . . . . . . . . . . . . . . . . . . . . . .17 Windows password . . . . . . . . . . . . . . . . . . . . . . . .17 Setup password . . . . . . . . . . . . . . . . . . . . . . . . . .18 Network password . . . . . . . . . . . . . . . . . . . . . . . . .18 Using locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Chapter 4. Solving computer problems............ 21 Replacing the hard disk drive .................... 22 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Error codes or messages.................... 25 Errors without codes or messages ............... 27 Input problems . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Battery problems . . . . . . . . . . . . . . . . . . . . . . . . .30  Copyright IBM Corporation 2000iii Standby or hibernation problems................ 31 Power switch problem...................... 33 Hard-disk drive problems ..................... 34 CD-ROM or DVD-ROM Problems................ 35 Computer display problems................... 37 Software problems . . . . . . . . . . . . . . . . . . . . . . . .39 Other problems . . . . . . . . . . . . . . . . . . . . . . . . . .40 Testing your computer ........................ 41 Backing up your system....................... 42 Backing up your system configuration............. 42 Backing up your data ....................... 43 Recovering lost or damaged software............. 43 Getting service . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Getting help on the Web ..................... 49 Getting help by fax........................ 50 Calling IBM . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 Recording sheets . . . . . . . . . . . . . . . . . . . . . . . . .53 Appendix A. Product warranty and notices .......... 55 Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66 Processing date data....................... 67 Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . .67 Electronic emission notices................... 68 Telecommunication notice . . . . . . . . . . . . . . . . . . . .70 Notice for Australia ........................ 73 Regions where ThinkPad i Series 1200/1300 has ThinkPad modem integrated . . . . . . . . . . . . . . . . . . . . . . . .73 Notice to New Zealand users of the "Ambit U98.005.C.00 Internal Modem" . . . . . . . . . . . . . . . . . . . . . . . . .74 Notice for European Union countries.............. 75 Radiocommunication notice . . . . . . . . . . . . . . . . . . .76 Notice for Canada ......................... 76 Remarque relative aux communications radio Canada.... 76 Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77 iv Safety information DANGER Electrical current from power, telephone, and communi- cation cables is hazardous. To avoid shock hazard, connect and disconnect cables as shown below when installing, moving, or opening the covers of this product or attached devices. If the 3–pin power cord is provided with this product, it must be used with a properly grounded outlet. To Connect Turn everything OFF. First, attach all cables to devices. Attach the signal cables to the receptacles. Attach the power cord to an outlet. Turn the device ON. To Disconnect Turn everything OFF. First, remove the power cord from t…

Text truncated - open the document above for the full version.

Nederland B.V. WCND Report No. 015127, Rev. A TEST REPORT Subject: Processing Gain For the ORiNOCO IEEE802.11b products Ref.: FCC Rules 47 CFR Part 15, Section 5.247d Report Prepared by: Maarten Visee July 28, 2000 NameSignatureDate Concurrence: 1. Director of Engineering Bruce Tuch August 10, 2000 NameSignatureDate 2. Team Captain Frans Hoekstra August 10, 2000 NameSignatureDate Lucent WCND Confidential Information ©2000 FCC Processing Gain Measurements Results, for the OriNOCO IEEE802.11b products, Report No. 015127, Rev. A. Lucent WCND Confidential ©2000 1 This document describes the Receiver Processing Gain verification measurements performed at the WaveLAN-II PC-Card Type 2, according to Ref.[2]. The Lucent WaveLAN-II PC-Card Type 2 product confirms to the minimum required 10 dB processing gain, as set forth by the FCC for operation in the 2.4 GHz ISM band. 1- Document FCC 97-114, Appendix C, Guidance on Measurements for Direct Sequence Spread Spectrum Systems. 2- Hardware Functional Specification for WaveLAN-II Embedded, High Speed, Doc. No. 011735, Rev. A, Source Organization Lucent Technologies WCND Utrecht. 3-Viterbi, A. J., Principles of Coherent Communications, New York, McGraw-Hill 1966. 4- Proakis, J.G., Digital Communications, New York, McGraw-Hill 1989, page 270. 4.1 Test introduction - FCC requirements: Part of FCC certification for the Lucent WaveLAN IEEE 802.11 High Speed compliant Network Interface Card (NIC) is a processing gain test. This test proves that the receiver of the tested product employs a true spread spectrum device receiver structure, taking full advantage of the direct sequence spread spectrum modulation technique. This test verifies the receiver processing gain to be 10 dB or more for a data rate of 1, 2, 5.5 and 11 Mbit/s, by monitoring the Bit Error Rate (BER) of the product under test for each data rate, while operating under strict defined received signal conditions. Several methods of showing compliance to the rules are possible, from a stepped CW jammer to a continuous sweeping CW interferer. For this test the discrete stepped CW jammer method was chosen, as described in Ref.[1]. Therefore a receiver input signal is applied to the product under test, in the presence of a Continuous Wave (CW) interference source, also referred to as CW jammer. 1.Summary: 2.Conclusion: 3.References: 4.Measurement description: FCC Processing Gain Measurements Results, for the OriNOCO IEEE802.11b products, Report No. 015127, Rev. A. Lucent WCND Confidential ©2000 2 The test takes place at the product Functional Specification (Ref.[2]) specified conditions for BER rate measurements, specifying a BER equal or better than 10^-8 at a receiver input level of -55 dBm. For practical reasons these test are performed at -55 dBm or -53 dBm. This small deviation from the Functional Specification should not cause any deviation from the specified Bit Error Rate, since the received levels are well above the thermal noise. The test criteria for meeting the minimal processing gain is such that it takes the theoretical calculated SNR for the applied modulation technique and specified BER as a reference. From this given SNR the processing gain is subtracted, yielding the CW Jammer to Signal ratio J/S. From Ref. [4], likewise as Ref.[3] consulted in Ref. [1], it is determined that for a BER of 10^-8 the SNR (S/N)o equals: 13 dB @ 1 Mbit/s, 15 dB @ 2 Mbit/s, 15 dB @ 5.5 Mbit/s, 18 dB @ 11 Mbit/s. Thus the J/S ratio for a processing gain of 10 dB that must be met is calculated as: -13 + 10 = -3 dB @ 1 Mbit/s (DBPSK), -15 + 10 = -5 dB @ 2 Mbit/s (DQPSK), -15 + 10 = -5 dB @ 5.5 Mbit/s (CCK), -18 + 10 = -8 dB @ 11 Mbit/s (CCK). Two types of measurement corrections are allowed for as described in Ref.[1]. The first taking into account 2 dB implementation losses, thus increasing the absolute J/S ratio by 2 dB. The second correction allows for deleting the 20% worst- case frequencies in the processing gain test that causes the test at that CW interference to fail. This implies that for the considered 14 MHz wide measurement interval the worst case 57 CW jammer frequencies can be ignored, being those that result in received data errors/missing frames (20% of 14 MHz *(1 MHz/50 KHz) + 1 = (20% * 281) + 1 = 57). FCC Processing Gain Measurements Results, for the OriNOCO IEEE802.11b products, Report No. 015127, Rev. A. Lucent WCND Confidential ©2000 3 4.2 Test sequence: The measurements are performed at a 50 KHz CW jammer raster. For each CW jammer frequency 10^8 bits are transmitted by the reference transmitter, and received by the product under test. For practical reasons 50.000 messages are transmitted. After blanking out frame overhead 1927 bits per frame are monitored. This results in 50.000 * 1927 = 9650000 transmitted bits for a BER test, which is a mere 1.4% less than the targeted 10^8 bits. Though it would be more elegant to show BER compliance for at least say ten times 10^8 transmitted/received bits, the time involved with this grows significantly. Since the CW interferer is stepped in a 50 KHz raster, covering the receiver bandwidth of 14 MHz, it is considered that the BER requirement is sufficiently met since such a multitude of measurements are taken. The total measurement is being performed under computer control, hereafter referred to as controller. It involves the control over the reference transmitter, CW-interference generator, receiver under test and received data error- checker/frame counter. The controller is programmed by a configuration file, that lists the CW jammer frequencies and CW jammer signal levels. The controller program flow chart is given in Annex A, WaveLAN-II FCC Processing Gain Measurements, Controller Flow Chart. The transmitted data pattern is fixed, and known at the receiver. Therefore the error checker compares the known transmitted data sequence with received data sequence. Received data errors and missing received frames information is retrieved by the cont…

Text truncated - open the document above for the full version.

FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 18/30 5. BLOCK DIAGRAM 5.1Block Diagram of the PC system unit Figure 14 Block diagram of ThinkPad i 1300 and ThinkPad 130 FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 19/30 5.2Block Diagram of the Wireless-LAN mini-PCI card Figure 15 Block diagram of the Wireless-LAN mini-PCI card

U\D MIXER VCO PLL D A D A I Q RX/TX SWITCH DIG SIG PROC BANDPASS FILTER LNA/ AGC UP MIXER DOWN MIXER RFCONNECTOR(S) & DIVERSITY SWITCH AUTOMATIC GAIN CONTROL ANTENNA DIVERSITY CONTROL 2.4-2.5GHz 2.05-2.15GHz I Q PLL VCO RX/TX SWITCH RX/TX SWITCH BANDPASS FILTER ref osc and load osc load Amp PFB 352MHz saw D A D A MAC SRAM 128k x 8 32k x 8 70 ns 3.3 V Xtal BANDPASS FILTER 704 MHz 352MHz saw 200nS 3.3 V FLASH ROM H E R M E S T H E S E U S miniPCI bridge bus 1 2 3 22 6 7 8 19 9 10 11 15 14 12 13 18 16 21 20 4 5 17 22MHz 25 26 27 9 Block diagramm Lucent 2.4 GHz WaveLAN

Responses to Non-Conformities (Ref #E00-000537-1) FCC ID: ANO12P701Z Item 1: Please provide a block diagram showing the frequency of all oscillators in the device. Response provided 1/10/2001 - Please see the page 19/30 of TPI1300-Block-Diagram.pdf. I also attach the full size chart. (See attached file: TPI1300-Block-Diagram.pdf) (See attached file: Minipcib.ppt) Item 2: Please provide photo's of both sides of all transceiver boards. Response provided 1/10/2001 - Please see the page 16/30 and 17/30 in the TPI1300-internal-photo.pdf. (See attached file: TPI1300-internal-photo.pdf). Item 3: According to the TCB RF exposure procedure, you should follow requirements in Section F. The RF exposure reflects Section L. This device appears to be mobile. Please correct accordingly. Response provided 1/16/2001 - I understand the FCC's position, so please replace with the attached exhibit following to Section F. Item 4: For each data rate, provide the Chip/symbol rate, the symbol/bit rate and the Chip/bit rate. How does each meet the 10 dB requirement. Response provided 1/10/2001 - The Chip/symbol rate the symbol/bit rate and the Chip/bit rate are described in the page 3/30 in the TPI1300- Operational-Description.pdf. As to the 10dB requirement, please refer to the Annex B(no page number) in the Processing Gain.pdf. (See attached file: Processing Gain.pdf) The items indicated above must be submitted before processing can continue on the referenced application. Failure to provide the requested information within 60 days may result in application dismissal pursuant to Section 2.917(c) and forfeiture of the filing fee pursuant to Section 1.1106. Note: Any corrections or additions to this report can only be made by a further document which meets the requirements of TCB0005 and such a document is to be labeled as a supplement to evaluation report serial number E00-000537.

OET Requested Information Applicant: International Business Machines Corporation Correspondence Reference Number: 2041 731 Confirmation Number: TC99807 Date of Original Email: 05/18/2001 Subject: 1) The original report showed output power data at 17.5 dBm(56mW). You requested 42mW. New data was submitted at 15dBm(31.6mW). What is the correct output power of the device? Answer: The correct Output Power for this device is 15dBm (0.0316 Watts), the Grant has been modified to reflect this. 2) You need to specifically answer the next question which was item#4 of the last inquiry. Do not just resubmit the same processing gain exhibit. " Verify where the Process gain data came from. Was it supplied by the manufacturer? Was the device tested or was the data provided by the manufacturer and is based solely on the baseband processing chip? Answer: The processing Gain was performed by the Manufacturer (Lucent - Netherlands) but was not performed on the Identical unit used in IBM's device. All circuitry is Identical between the two devices, the ONLY difference is the interface to the PC. The devices tested for processing gain interfaced via PCMCIA, and the device in IBM's product uses MiniPCI interface.

FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 10/30 3. EXTERNAL PHOTOS Figure 4: Front View : ThinkPad i Series 1300 / ThinkPad 130 (12 inch LCD) Figure 5: Front View : ThinkPad i Series 1300 / ThinkPad 130 (13 inch LCD) FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 11/30 Figure 6: Rear View : ThinkPad i Series 1300 / ThinkPad 130 (all models) Fugure 7: Rear View : Connector terminals

FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 8/30 2. PRODUCT LABELING Figure 2: Labeing of ThinkPad i Series 1300 rear side bottom view FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 9/30 Figure 3: Labeing of ThinkPad 130 rear side bottom view

FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 12/30 4. INTERNAL PHOTOS 4.1Exterior views of Antennas Figure 8: Exterior views of Slot antenna FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 13/30 Figure 9: Exterior views of Inverted F-figure type antenna FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 14/30 4.2Antenna locations in LCD panel Figure 10: Diversity Antennas mounted in 12 inch LC Inverted F antenna Slot antenna FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 15/30 Figure 11: Diversity Antennas mounted in 13 inch LCD Inverted F antenna Slot antenna FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 16/30 4.3Exterior view of Wireless-LAN card Figure 12: Top side views of IEEE802.11b Wireless-LAN mini-PCI card With metallic shielding covers Without metallic shielding covers FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 17/30 Figure 13: Back side views of IEEE802.11b Wireless-LAN mini-PCI card With metallic shielding covers Without metallic shielding covers

FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 1/30 MEASUREMENT/TECHNICAL REPORT – Part 15 Subpart C (Intentional Radiator) ThinkPad i Series 1300, ThinkPad 130 (1171-5BU/5WF/5WU/7WF/7WU) (1171-5WJ/7WJ) FCC ID : ANO12P701Z November 17, 2000 This report concerns: (check one) Original Grant ̧ Class I change Class II change Equipment type: Wireless LAN device in Computer (computer, printer, modem, etc.) This report shall not be reproduced except in full, without the written permission of this test lab. The measurement results contained in this report relate only to the item which was tested. Measurement procedure used is ANSI C63.4-1992 unless otherwise specified. Other test procedure: The FCC has issued provisional acceptance of this test laboratory for Declaration of Conformity testing per letter dated June 30, 2000. APPLICANT ANTI-DRUG ABUSE CERTIFICATION: By checking yes, the applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse of 1988, 21 U.S.C. 853(a), or, in the case of a non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. For the definition of a “party” for these purposes, see 47 CFR 1.2002(b). Yes or No “Report shall not be reproduced except in full, without the written approval of the laboratory” “the report must not be used by the client to claim product endorsement by NVLAP or any agency of the US government” Prepared by: Toshiya Murota IBM Japan Corporation, Yamato EMC Enginnering LAB-S59, 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan Tel: +81-46-215-6574 Fax: +81-46-273-7420 FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 2/30 MEASUREMENT/TECHNICAL REPORT – PART 15 SUBPART C....................................1 1. OPERATION DESCRIPTION (GENERAL INFORMATION)........................................3 1.1Objective....................................................................................................................................................................3 1.2Product Description.................................................................................................................................................3 1.3Mounting structure of Wireless-LAN card and Antenna...................................................................................4 1.4 Circuitry description of the Wireless-LAN mini-PCI card...............................................................................5 1.5Related Submittal(s)/Grant(s)/Notes.....................................................................................................................7 1.6Compliance Summary.............................................................................................................................................7 1.7Condition of EUT.....................................................................................................................................................7 1.8Dates of Receipt of EUT..........................................................................................................................................7 1.9Dates of Measurements done by test house..........................................................................................................7 1.10EUT Details...............................................................................................................................................................7 2. PRODUCT LABELING .............................................................................8 3. EXTERNAL PHOTOS............................................................................10 4. INTERNAL PHOTOS.............................................................................12 4.1Exterior views of Antennas...................................................................................................................................12 4.2Antenna locations in LCD panel..........................................................................................................................14 4.3Exterior view of Wireless-LAN card...................................................................................................................16 5. BLOCK DIAGRAM.................................................................................18 5.1Block Diagram of the PC system unit.................................................................................................................18 5.2Block Diagram of the Wireless-LAN mini-PCI card........................................................................................19 6. SCHEMATIC DIAGRAMS.........................................................................20 7. USER’S MANUAL..................................................................................21 8. PARTS LIST OF WIRELESS-LAN MINI-PCI CARD..............................................22 9. RF EXPOSURE.....................................................................................28 FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 3/30 1. OPERATION DESCRIPTION (GENERAL INFORMATION) 1.1Objective This is a Certification Compliance Report for FCC Part 15, Subpart C (Intentional Radiator). The names of applying euipment are ThinkPad i Series 1300, and ThinkPad 130. 1.2Product Description The applying equipment is a portable type notebook personal computer integrating IEEE 802.11b Wireless LAN function inside. The wireless module consists of an OEM card(Lucent miniPCI IEEE802.11b Wireless LAN card) and IBM original integrated 2 antennas(inverted F-figure type, and slot type antenna). These models feature as follows; Ta…

Text truncated - open the document above for the full version.

FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 28/30 9. RF EXPOSURE SP(1): The peak conducted output power of the applying equipment is 17.5 dBm (P = 56.2mW). This measurement was performed at the maximum condition with the continuous transmission mode as shown below. So the source-based time-averaging duty factor is considered as 100% duty. FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 29/30 And the peak radiated (EIRP) output power is calculated as follows. P + G = 17.5 dBm + (-1.2 dBi(antenna gain)) = 16.3 dBm (42.7 mW) Therefore this applying equipment is classified as the Transmitter Category V), Part 15 Fixed and Mobile Transmitters, Section F. SP(3): In line with the instruction of Section F, the users notification shown in the next page is delivered to customers associated with the users manual. SP(5): The applying equipment has 11 channels, but it selects one of the available frequencies in the link establishing phase in line with the standard CCA procedure of IEEE802.11b, then starts radiocommunication in a single frequency band. SP(7): The antenna installation instructions and device operating conditions for installers to satisfy RF exposure requirements are presented in the users notification shown in the next page. SP(8): The installation and operating instructions, of which conditions are for satisfying FCC RF exposure compliance, are presented in the users notification shown in the next page. FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 30/30 Exposure to Radio Frequency Energy Part Number : xxxxxxx IMPOTANT NOTE To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm (8 inches) must be maintained between the antenna of this device and all persons. Antenna locations FCC Certification of this device prohibits the use of any other Radio Frequency wireless device in conjunction with your ThinkPad i Series notebook wireless LAN. Do not use any wireless PCMCIA card in your ThinkPad i Series notebook while operating the internal wireless LAN function. Furthermore, any tampering of the internal antenna will void the FCC Certification and your warranty.

FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 28/30 9. RF EXPOSURE SP(1): The peak conducted output power of the applying equipment is 17.5 dBm (P = 56.2mW). This measurement was performed at the maximum condition with the continuous transmission mode as shown below. So the source-based time-averaging duty factor is considered as 100% duty. FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 29/30 And the peak radiated (EIRP) output power is calculated as follows. P + G = 17.5 dBm + (-1.2 dBi(antenna gain)) = 16.3 dBm (42.7 mW) Therefore this applying equipment is classified as the Transmitter Category V), Part 15 Fixed and Mobile Transmitters, Section F. SP(3): In line with the instruction of Section F, the users notification shown in the next page is delivered to customers associated with the users manual. SP(5): The applying equipment has 11 channels, but it selects one of the available frequencies in the link establishing phase in line with the standard CCA procedure of IEEE802.11b, then starts radiocommunication in a single frequency band. SP(7): The antenna installation instructions and device operating conditions for installers to satisfy RF exposure requirements are presented in the users notification shown in the next page. SP(8): The installation and operating instructions, of which conditions are for satisfying FCC RF exposure compliance, are presented in the users notification shown in the next page. FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 Prepared by T. Murota 30/30 Exposure to Radio Frequency Energy Part Number : xxxxxxx IMPOTANT NOTE To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm (8 inches) must be maintained between the antenna of this device and all persons. Antenna locations FCC Certification of this device prohibits the use of any other Radio Frequency wireless device in conjunction with your ThinkPad i Series notebook wireless LAN. Do not use any wireless PCMCIA card in your ThinkPad i Series notebook while operating the internal wireless LAN function. Furthermore, any tampering of the internal antenna will void the FCC Certification and your warranty.

Additional FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 - 1 - IBM Japan Ltd. 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan May 23, 2001 CKC Certification Services 4933 Sierra Pines Dr., Mariposa, CA 95338 Subject: FCC Certification of Part 15, Subpart C Response to E-Mail “Requested Information from the FCC” dated May 19, 2001 FCC ID: ANO12P701Z Dear Sir : The attachment is the update of RF Exposure evaluation to be replaced together with the re- submission of the maximum peak output power measurement. Sincerely, Toshiya Murota EMC Staff Engineer Yamato Laboratory, IBM Japan Ltd. Additional FCC Test Report FCC ID: ANO12P701Z Document Number: FCC-19-0154-0 - 2 - RF Exposre The applying equipment is a standard fullsize laptop computer which is categorized as a mobile device by FCC CFR 47 Section 2.1091. Therefore the separation distance between the antenna and the human body is 20cm or more. SP(1): The peak conducted output power of the applying equipment is 15.0 dBm (P = 31.6mW), and the maximum antenna gain is –1.2dBi. Therefore the peak radiated (EIRP) output power is calculated as follows. EIRP = P + G = 15.0 dBm – 1.2 dBi = 13.8 dBm (24.0 mW) With this result, the maximum power density in 20cm distance is calculated as : S = EIRP/(4 x R 2 x pi) = 0.0048 mW/cm 2 When an operator will use the applying equipment during 3…
