FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota User’s Manual The attachment is a summary related to the FCC and IC regulations. Please refer the page 6 and 7 for this application. Part Number: 92P1335 Regulatory Notice for ThinkPad ® X30 Series This notice is a supplementary document of theThinkPad X30 Series Service and Troubleshooting Guide. Please read this document before you use the ThinkPad X30 Series computer. The ThinkPad X30 Series computer complies with the radio frequency and safety standards of any country or region in which it has been approved for wireless use. You are requested to install and use your ThinkPad computer in strict accordance with the instructions as described hereafter. Réglementation concernant les ordinateurs ThinkPad X30 Series Le présent document complète le manuelThinkPad X30 Series- Guide de maintenance et d’identification des incidents. Avant d’utiliser votre ordinateur ThinkPad X30, veuillez lire ce document. L’ordinateur ThinkPad X30 series est conforme aux normes de radiofréquence et de sécurité en vigueur dans les pays ou régions où son utilisation sans fil a été acceptée. L’ordinateur doit être installé et utilisé conformément aux instructions fournies ci-après. Hinweis zu Einheiten für den ThinkPad X30 Dieser Hinweis ergänzt die Informationen im HandbuchThinkPad X30 - Service und Fehlerbehebung. Lesen Sie unbedingt die entsprechenden Informationen in diesem Dokument, bevor Sie den ThinkPad X30 verwenden. Der ThinkPad X30 erfüllt die Funkfrequenz- und Sicherheitsstandards der Länder und Regionen, in denen er für die Verwendung als drahtlose Einheit zugelassen ist. Der ThinkPad X30 muss exakt wie nachfolgend beschrieben installiert und verwendet werden. © Copyright IBM Corp. 20031 USA — Federal Communications Commission (FCC) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.this device must accept any interference received, including interference that may cause undesired operation. I. Permanent integrated wireless module vIBM Dual-Band 11a/b Wi-Fi Wireless Mini PCI Adapter i) Installation of the integrated wireless module IBM Dual-Band 11a/b Wi-Fi Wireless Mini PCI Adapter is preinstalled by IBM, and is not removable by users. If your card requires replacement via the proper step shown in “Chapter 3. Getting help and service from IBM” of theThinkPad X30 Series Service and Troubleshooting Guide, IBM will request you to send your computer with the card(s) to IBM so that IBM will repair it. ii) The FCC RF safety requirement The radiated output power of wireless LAN Mini-PCI Card and Bluetooth card is far below the FCC radio frequency exposure limits. Nevertheless, the ThinkPad X30 Series computer shall be used in such a manner that the potential for human contact during normal operation is minimized as follows: Use of wireless options If you find the FCC ID “ANO20020304T2L” on the label at the bottom side of your ThinkPad computer, your computer is approved as a multiple transmitters device that is permitted to use the integrated wireless LAN Mini-PCI Card and the Bluetooth card with one or more wireless option PC Cards in the PC Card slot simultaneously. Please make sure of the following when you use the Bluetooth option or the wireless option PC Card in your ThinkPad computer. 1. Visit the IBM site atwww.ibm.com/pc/qtechinfo/MIGR-44156.htmland confirm the updated list of RF option devices that have been approved to cooperate with the integrated wireless feature. 2. When you use any other RF option device that is not listed on the IBM site, all other wireless features including the integrated transmitter in your ThinkPad computer are required to be turned off. 6 3. Users are requested to follow the RF Safety instructions on wireless option devices that are included in the RF option device’s user’s manual. Caution: To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm (8 inches) must be maintained between the antenna for the integrated Wireless LAN Mini-PCI Card built in to the screen section and all persons. FCC ID: ANO20020304T2L Note:IBM Dual-Band 11a/b Wi-Fi Wireless Mini PCI Adapter implements transmission diversity function. The function does not emit radio frequencies simultaneously from both antennas. One of the antennas is selected automatically or manually (by users) to have good quality of radiocommunication. iii) Radio Frequency interference requirements vThis device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. vHigh power radar are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. 7 vAn improper installation or unauthorized use may cause harmful interference to radio communications. Also any tampering of the internal antenna will void the FCC certification and your warranty. Refer to the“Appendix D. Notices, Electronic emission notices” of theThinkPad X30 Series Service and Troubleshooting Guidefor more detail. II. User installable wireless modules vMini-PCI Cards - Cisco Aironet Wireless 802.11b - Intel ® PRO/Wireless LAN 2100 3B Mini PCI Adapter vCommunication Daughter Card (CDC) - IBM Integrated Bluetooth with 56K Modem i) FCC ID of wireless modules There is no FCC ID for Mini-PCI Cards shown on the enclosure of your ThinkPad computer. Instead you will find an indicator pointing the location of the FCC ID at the bottom side of your ThinkPad computer as shown below in the figure i-1). Also the location of the FCC ID’s indicator for CDC is shown by the figure i-2). The FCC IDs are affixed on each approved module installed…

Text truncated - open the document above for the full version.

FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 IBM Japan Ltd. 1623-14, Shimotsuruma, Yamato Kanagawa 242-8502, Japan January 15, 2003 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 Subject: Request for FCC Certification of Part 15, Subpart E Dear Sir : Please find enclosed an IBM’s application document for the FCC Part 15, Subpart E certification. - FCC ID : ANO20020304T2L - Applying equipment name : ThinkPad X30 Series -Device type : 5180M-5320MHz U-NII device (Composite application with a separated Subpart C, DTS device) The applying product is a standard size laptop PC integrating IEEE802.11a/b combo Wireless LAN Mini-PCI adapter. The built-in transmitter module is entirely the same as the one of previous application (ANO20020300D3L). A new FCC ID is assigned with a new host antenna system. If any further information is required concerning this application, please contact us. Sincerely, Akihisa Sakurai Manager, EMC Engineering Yamato Laboratory, IBM Japan Ltd.

FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC-19-0212-0 Yellow Sheet: No. EM732 Application Document for FCC Part 15, Subpart E (UNII Devices) Document Number: FCC 19-0212-0 Product Name: ThinkPad X30 Series (Machine type: 2672, 2673) FCC ID: ANO20020304T2L January 14, 2003 EMC Staff Engineer Toshiya Murota Signature: IBM Japan, Ltd. EMC Engineering LAB-S59 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan Phone: +81-46-215-6574 Fax: +81-46-273-7420 E-Mail: [email protected] Portable Product Director Masaki Kobayashi Signature: IBM Japan, Ltd. Portable Product LAB-R16 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan Phone: +81-46-215-3889 EMC Engineering Manager / NVLAP signatory Akihisa Sakurai Signature: IBM Japan, Ltd. EMC Engineering LAB-S59 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan Phone: +81-46-215-2613 Fax: +81-46-273-7420 E-Mail: [email protected] Portable Systems Director Arimasa Naitoh Signature: IBM Japan, Ltd. Portable Systems LAB-R11 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan Phone: +81-46-215-6110 FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC-19-0212-0 Prepared by T. Murota 2/3 Outline of Submission 1. Objective This is a Certification Compliance Report for FCC Part 15 subpart E, U-NII device. - The applying equipment : ThinkPad X30 Series - FCC ID : ANO20020304T2L The device is composite equipment with the same FCC ID of Part 15 subpart C, DTS device. 2. Installation of the applying transmitter The built-in wireless LAN module is preinstalled by IBM. According the FCC Part 15.407(d), a tamperproof structure is employed so that the applying wireless module is not able to be removed nor plugged in by users. Since users can not access to the card, IBM or a responsible party will replace a broken card with a spare part. Refer to “Circuitry Description” document, and page 6 of User’s Manual. 3. Product Description The applying equipment is a compact size laptop computer integrating IEEE 802.11a & b combo Wireless LAN function inside. The wireless module consists of an OEM card (Philips Components, Model No: PH11107-X, 802.11 Combo Mini-PCI WLAN Card) and built-in antennas (Inverted F-figure Dual bands antennas × 2). The specifications of the applying wireless LAN card and the built-in antennas are as follows. Specification of Wireless-LAN feature IBM product name of wireless Card IBM Dual-Band 11a/b Wi-Fi ® Wireless Mini PCI Adapter Carrier Frequencies 5180MHz ~ 5320MHz Antenna gain Maximum peak 1.42 dBi (in the above band) Conducted transmission power Maximum 17 dBm Inverted F-figure type dual band antenna Antenna type Main antenna : P/N: 08K4083 Auxiliary antenna : P/N: 08K4084 Antenna cable type And length Main antenna : coax 394 mm Auxiliary antenna : coax 534 mm FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC-19-0212-0 Prepared by T. Murota 3/3 4. Mounting structure of Wireless LAN card and Antenna The two inverted F-figure type antennas are built in the left and right side of LCD. Those diversity antennas are not used simultaneously. One of the antennas is selected automatically or manually to have a good quality of radio communication. The selected antenna performs transmission or receiving in half duplex alternatively. Antenna Cables Bracket The bracket is fixed with a special screw so that the wireless module is not removed. Main Antenna Auxiliary Antenna without Bracket Mini-PCI Wireless adapter

FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 IBM Japan Ltd. 1623-14, Shimotsuruma, Yamato Kanagawa 242-8502, Japan January 15, 2003 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 Subject: Confidentiality Request for FCC Certification of Part 15, Subpart E Dear Sir : Please find enclosed an IBM’s application for the FCC Part 15, Subpart E certification. - FCC ID : ANO20020304T2L - Applying equipment name: ThinkPad X30 Series - Device type: 5180M-5320MHz, U-NII device Pursuant to 47 CFR section 0.457(d) and 0.459, we hereby request confidentiality for the schematics, detailed block diagrams, detailed theories of operation, and parts list. The subjected files are as follows. - Confidential_Schematic_Diagrams.pdf - Confidential_Block_Diagrams.pdf - Confidential_Circuitry_Description.pdf (including BIOS lock logic) - Confidential_Parts_List.pdf Sincerely, Akihisa Sakurai Manager, EMC Engineering Yamato Laboratory, IBM Japan Ltd.

FCC ID: ANO20020304T2L Document Number: FCC 19-0212-1 Prepared by T. Murota. 1/2 IBM Japan Ltd. 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan To whom this may concern February 13, 2003 OET Requested Information FCC ID : ANO 20020304T2L Applicant : International Business Machines Corporation Correspondence Reference Number: 230207TE.ANO Confirmation Number: TC3013 Original Requested Date : February 07, 2003 Subject 1) Please clarify the frequency of operation of the transmitter. Theusers manual provided (pages 7, 13) shows 5.15-5.25, 5.25-5.35, and 5.65-5.85 GHz operation. Please revise users manual or send supporting test data, as appropriate. Answer 1) Those frequency bands are not the specifications of the applying transmitter, but the ones of MSS or High Power radars. The notice of indoor use in 5.15-5.25GHz band is mandated by the CFR47 Part 15.407(e), and the other notice about the interference with High Power radars in 5.25-5.35G Hz or 5.65-5.85GHz band is voluntary. Therefore the manual revision may not be required. Subject 2) Please clarify the user installed wireless module option antenna installation procedure stated on page 8-9 of the users manual. Please provide how the antenna will be installed or selected by the user and provide antenna installation to satisfy RF exposure compliance. Answer 2)The users manual of the host device (IBM ThinkPad X30 Series) introduces 4 kinds of transmitters. The page 8-9 are showing different transmitters which are to be certified separately from this application. Please refer to page 6-7 for the applying ANO200204T2L. The FCC ID and installation method is described clearly in those pages. Also please refer to “Outline of Submission” exhibit. The applying transmitter is pre-installed by IBM, so the latter question is not applicable for the device. Subject 3) Please explain if this device meets the integral antenna requirement specified in Section 5.407(d) of the FCC Rules. Answer 3) The antennas are furnished in the LCD section fixedly and the applying transmitter is built-in the keyboard section with a tamperproof screw so that users can not remove it. Therefore the device meets the requirement. Please refer to the “Outline of Submission” and “Circuitry Description” exhibits. Subject 4) Please clarify the RF Exposure (MPE) exhibit shown on the Power Table page 5/6 (Center Freq. 5.15 - 5.35 GHz) which shows operational frequencies outside the requested frequency band of operation. Answer 4) The measurement was performed with the full allocated frequency band of UNII devices (i.e. 5150M-5350MHz) to cover the whole intentional emission BW (i.e. 26dB BW). As shown by the plots of the next page, the highest peak antenna gain was found at 5350MHz for the main (left) antenna and declines its value gradually from high to low frequency. In other hand, the peak gain for the Auxiliary (Right) antenna was found at 5150MHz, then declines from low to high frequency. Thus the peak antenna gain in the operation band never exceed 1.42 dBi for the left antenna, nor 0.19 dBi for the right antenna. So we would declare those values as the maximum FCC ID: ANO20020304T2L Document Number: FCC 19-0212-1 Prepared by T. Murota. 2/2 antenna gains. Plots of the antenna gain (left antenna) Plots of the antenna gain (Right antenna) Subject 5) Please confirm if this UNII device will be installed by IBM only or installed by the user. Answer 5) The UNII device is pre-installed by IBM only. Please refer to the “Outline of Submission” exhibit, or page 6 of users manual. Subject 6) Please send the FCC/OET correspondence pertaining to the subject device. Each filing must stand on its own with all the required exhibits/documents. Answer 6) Yes, we will send each correspondence to each subject device with each separate exhibit. This is the answer for the Subpart E portion of FCC ID: ANO20020304T2L. (Document #: FCC 19-0212) Sincerely, February 13, 2003 Toshiya Murota, Staff Engineer, EMC R&D Engineering, Yamato Laboratory, IBM Japan Ltd.

FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 1/2 External Photos IBM ThinkPad X30 Series, Front View IBM ThinkPad X30 Series, Side View FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 2/2 IBM ThinkPad X30 Series, Side View IBM ThinkPad X30 Series, Rear View

FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 1/2 Product Labeling Bottom view Front Side FCC ID FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 2/2 Label for a different model of the applying equipment (ThinkPad X30 Series) The model (X30) supports the applying transmitter and a built-in type Bluetooth LMA module which is to be certified separately with FCC ID: ANO20020100MTN. Bottom view Front Side

FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 1/5 Internal Photos Main Antenna Auxiliary Antenna without Bracket Antenna Cables Bracket The bracket is fixed with a special screw so that the wireless module is not removed. FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 2/5 IBM Dual-Band 11a/b Wi-Fi Wireless Mini PCI adapter Shielded Top Side Unshielded Top Side Auxiliary Antenna Port Main Antenna Port Antenna Terminals FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 3/5 Shielded Back Side Unshielded Back Side FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 4/5 Antenna Locations Auxiliary antenna Dual Band Inverted-F type P/N: 08K4084 Main antenna Dual Band Inverted-F type P/N: 08K4083 FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 5/5 Antennas (Dual-Band Inverted F type Antenna and Cable) Main Antenna (Left) Manufacturer: Nissei Electric Ltd. Parts Number: 08K4083 Dual Band Inverted-F type antenna Cable : coax 394 mm Auxiliary Antenna (Right) Manufacturer: Nissei Electric Ltd. Parts Number: 08K4084 Dual Band Inverted-F type antenna Cable : coax 534 mm

FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 1/6 RF Exposure 1. RF Exposure evaluation for the applying transmitter As shown in the following photo, both main and auxiliary WLAN antennas of the applying laptop PC, IBM ThinkPad X30 Series, are located at the upper part of the display (LCD) bezel. The separation distances between the antennas and the human body are 20cm or more. Therefore the laptop PC can be categorized as a mobile device by FCC CFR 47 Section 2.1091. [MPE on 5.2GHz band] The highest conducted peak output power of the Test Report is 56.2mW (17.5dBm) and the maximum antenna gain is 1.42 dBi (See page 4 of this exhibit.). Therefore the peak radiated output power(EIRP) is calculated as follows. EIRP = P + G = 17.5 dBm + 1.42 dBi = 18.92 dBm (77.98 mW) Then, the maximum power density at 20cm distance is calculated as : S = EIRP/(4 % R 2 % o) = 0.0155 mW/cm 2 Since the applying laptop PC’s WLAN transmitter does not function to emit the radio frequency from both diversity antennas simultaneously, the above value is the maximum RF exposure to the persons and is below the MPE limit (1.0 mW/ cm 2 ). Therefore the laptop PC meets the MPE requirements for general Population/Uncontrolled exposure. Antennas are located at the same height The separation distance between the antenna and the human body (lap) is about 21cm . FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 2/6 2. RF Exposure evaluation for Bluetooth transmitters The applying laptop PC (ThinkPad X30 Series) supports three kinds of Bluetooth devices as follows. FCC IDGrantee Name Product Name Granted DateERP in FCC Test Report PI4BT-ULTRA Bluetooth Ultraport Module May/22/20011.4 mW User’s option PI4BT-IBM-PCII TDK Systems Europe Ltd. Blutooth PC Card II August/21/2001 1.0mW Built-in type LMA Transmitter ANO20020100MTNIBM Japan, Ltd. IBM integrated Blutooth with 56K Modem Under inspection with this application 2.5mW Interfaces to connect Wireless options Built-in Bluetooth Antenna USB Main antenna of applying transmitter PCMCIA 20cmm 20cmm FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 3/6 The main and auxiliary antennas of the applying transmitter in the LCD section are assembled apart from each Bluetooth antenna shown in the previous page with 20 cm or more distance. Therefore the RF exposure evaluation for those Bluetooth transmitters is able to be done independently of the applying antennas. In other word, a collocated SAR testing is not required. When a customer operates the applying PC on one’s lap, the sufficient separation distance (minimum 20cm) between the above Bluetooth antennas and the person’s body (lap) can not be maintained. But the footnote of the Section 3 in Supplement C to OET Bulletin 65 states “ 14 .......... If a device, its antenna or other radiating structures are operating at closer than 2.5 cm from a person’s body or in contact with the body, SAR evaluation may be necessary when the output is more than 50 – 100 mW, depending on the device operating configurations and exposure conditions.” The total output power of the three Bluetooth transmitters in the previous table does not exceed 5mW. Therefore these transmitters also satisfy the RF exposure evaluation regarding CFR 47 Part 15.247(b)(4) without a SAR compliance test report, and can operate with the applying transmitter simultaneously. IBM Web site guides to customers about the grant condition related to those collaborating transmitter devices. See page 6 of this exhibit. FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 4/6 Main Antenna Auxiliary Antenna 3. Antenna Gains of applying equipment 3.1 Antenna Specification Transmission Antenna assembly overview DesignatorManufactureAntenna typeCable type and length Gain (dBi) Note 1) 08K4083 Main antenna Nissei Electric Ltd. (Japan) Dual Band Inverted F type Antenna coax 394mm5150-5350MHz 1.42 dBi (peak) 08K4084 Auxiliary antenna Nissei Electric Ltd. (Japan) Dual Band Inverted F type Antenna coax 534mm5150-5350MHz 0.19 dBi (peak) Notes: 1a. Includes all cable losses. 1b. Antenna type should be Omni Directional and have gain of 3.0 dBi or less for IEEE802.11a(5GHz band), regarding the IBM internal specification. 3.2 Radiation characteristic of antennas Radiation characteristic of antenna is measured in regard to the rotation angle x° as shown below. Measuring Apparatus 3m Inverted F Antenna (Main Side) x° Measuring Apparatus 3m x° Inverted F Antenna (Auxiliary Side) FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 5/6 -30 -20 -10 0 10 H V H+V 0º Peak 355º 180º 270° 90° -30 -20 -10 0 10 H V H+V 0º Peak 0º 180º 270° 90° Main antenna Note1) The measurement was performed at 3 frequencies (5150, 5250, 5350MHz). Note2) The maximum antenna gain was found around 355 degree angle from measuring apparatus in vertical polarization at the high frequency (5350MHz). Auxiliary antenna Note1) The measurement was performed at 3 frequencies (5150, 5250, 5350MHz). Note2) The maximum antenna gain was found around 0 degree angle from measuring apparatus in vertical polarization at the low frequency (5150MHz). Hori (dBi) ave.-10.19 Vert (dBi) ave.-2.89 H+V (dBi) ave.-2.15 Peak(dBi) ( V )1.42 Peak Angle ( Xº= )355º Center Frequency5350MHz Hori (dBi) ave.-10.92 Vert (dBi) ave.-3.92 H+V (dBi) ave.-3.13 Peak(dBi) ( V )0.19 Peak Angle ( Xº= )0º Center Frequency5150MHz FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Murota 6/6 4. IBM Web site for user’s guidance concerning the co-located transmitters Note) The contents will be available after the product announcement. http://www.pc.ibm.com/qtechinfo/MIGR-44156.html

FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Emission Test Report Standard: FCC Part 15 Subpart E / IC RSS-210 Document Number : FCC 19-0212-0 Product: IBM ThinkPad X30 Series included IBM Dual-Band 11a/b Wi-Fi ® Wireless Mini PCI Adapter FCC ID: ANO20020304T2L IC: 349E-PH11107E January 9, 2003 Prepared: EMC Staff Engineer Takeshi Asano Signature: IBM Japan, Ltd. EMC Engineering LAB-S59 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242, Japan Phone: +81-46-215-4779 Fax: +81-46-273-7420 E-Mail: [email protected] Reviewed and Checked: EMC Staff Engineer Toshiya Murota Signature: IBM Japan, Ltd. EMC Engineering LAB-S59 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242, Japan Phone: +81-46-215-6574 Fax: +81-46-273-7420 E-Mail: [email protected] Approved: Manager, EMC Engineering Akihisa Sakurai Signature: IBM Japan, Ltd. EMC Engineering LAB-S59 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242, Japan Phone: +81-46-215-2613 Fax: +81-46-273-7420 E-Mail: [email protected] FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 MEASUREMENT / TECHNICAL REPORT – Part 15 Subpart E (Intentional Radiator) IBM ThinkPad X30 Series (Machine type : 2672, 2673) with IBM Dual-Band 11a/b Wi-Fi ® Wireless Mini PCI Adapter FCC ID : ANO20020304T2L January 9, 2003 This report concerns: (check one) Original Grant ̧ Class I change Class II change Equipment type: Wireless LAN device This report shall not be reproduced except in full, without the written permission of this test lab. The measurement results contained in this report relate only to the item which was tested. Measurement procedure used is ANSI C63.4-2000 unless otherwise specified. Other test procedure: The FCC has issued provisional acceptance of this test laboratory for Declaration of Conformity testing per letter dated 1997. APPLICANT ANTI-DRUG ABUSE CERTIFICATION: By checking yes, the applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse of 1988, 21 U.S.C. 853(a), or, in the case of a non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. For the definition of a “party” for these purposes, see 47 CFR 1.2002(b). Yes or No “Report shall not be reproduced except in full, without the written approval of the laboratory” “the report must not be used by the client to claim product endorsement by NVLAP or any agency of the US government” Prepared by: Takeshi Asano IBM Japan Corporation, Yamato EMC Enginnering LAB-S59, 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan Tel: +81-46-215-4779 Fax: +81-46-273-7420 FCC Test Report FCC ID: ANO20020304T2L Document Number: FCC 19-0212-0 Prepared by T. Asano 3/47 - Index - A. GENERAL INFORMATION...................................................................4 B. SUMMARY OF TEST RESULTS................................................................5 C. TEST INSTRUMENTS.........................................................................6 D. OPERATION MODE OF EUT...................................................................8 E. JUSTIFICATION.................................................................................8 F. MEASUREMENT UNCERTAINTY.............................................................9 G. TEMPERATURE AND HUMIDITY.............................................................9 H. RELATED SUBMITTAL(S)/GRANT(S)/NOTES...............................................9 1. BANDWIDTH AT 26 DB BELOW / BANDEDGE................................................10 1.1Test Procedure.....................................................................................................................................................10 1.2Measurement Results........................................................................................................................................10 1.3Trace Data..............................................................................................................................................................11 2. PEAK CONDUCTED TRANSMIT OUTPUT POWER...........................................14 2.1Test Procedure.....................................................................................................................................................14 2.2Measurement Results........................................................................................................................................16 2.3Trace Data..............................................................................................................................................................17 3. PEAK POWER SPECTRAL DENSITY...........................................................20 3.1Test Procedure.....................................................................................................................................................20 3.2Measurement Results........................................................................................................................................20 3.3Trace Data..............................................................................................................................................................21 4. PEAK EXCURSION RATIO......................................................................27 4.1Test Procedure.....................................................................................................................................................27 4.2Measurement Results........................................................................................................................................27 4.3Trace Data............................................................................................…
