ANOCORN1SHRIBM ThinkPad T30 Series

Part Number: XXPXXXX Wireless Regulatory Notice for ThinkPad T30 Series This notice is a supplementary document of the “ThinkPad ® T30 Series Service and Troubleshooting Guide.” The ThinkPad T30 Series computer complies with the radio frequency and safety standards of any country or region in which it has been approved for wireless use. You are requested to install and use your ThinkPad computer in strict accordance with the instructions as described hereafter. Before you use the ThinkPad T30 Series computer, please read this document. © Copyright IBM Corp. 20021 USA — Federal Communications Commission (FCC) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.this device must accept any interference received, including interference that may cause undesired operation. i) Installation of the integrated wireless modules The integrated wireless modules (Wireless LAN Mini-PCI Card and Bluetooth card) are preinstalled by IBM ® , and you are not permitted to install nor replace the integrated modules by yourself. If your integrated Wireless LAN Mini-PCI Card or Bluetooth card requires replacement via the proper step shown in“Chapter 3. Getting help and service from IBM”of the ThinkPad T30 Series Service and Troubleshooting Guide, IBM will request you to send your computer with the card(s) to IBM so that IBM will repair it. ii) The FCC RF Safety Requirement The radiated output power of Wireless LAN Mini-PCI Card and Bluetooth card are far below the FCC radio frequency exposure limits. Nevertheless, the ThinkPad T30 Series computer shall be used in such a manner that the potential for human contact during normal operation is minimized as follows: Multiple Transmitters model If you find the FCC ID "ANOCORN1TASUHOP"or"ANOCORN1SHR"on the label at the bottom side of your ThinkPad computer, your computer is approved as a Multiple Transmitters device that is permitted to use the integrated Wireless LAN Mini-PCI Card and Bluetooth card with two or more wireless option PC Cards in the PC Card slot simultaneously. Please make sure of the following conditions on use of option wireless cards. Use of Wireless options Please make sure of the following when you use a Bluetooth option or wireless option PC Card in your ThinkPad computer. 1.Visit the IBM site atwww.ibm.com/pc/qtechinfo/MIGR-39377.htmland confirm the updated list of RF option devices that have been approved to cooperate with the integrated wireless feature. 2.When you use any other RF option device that is not listed on the IBM site, all other wireless features including the integrated transmitter in your ThinkPad computer are required to be turned off. 3.Users are requested to follow the RF Safety instructions on wireless option devices that are included in the RF option device’s user’s manual. 2 CAUTION: To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm (8 inches) must be maintained between the antenna for the integrated Wireless LAN Mini-PCI Card built in to the screen section and all persons. The Bluetooth antenna is located in the left edge portion of keyboard. Transmitted energy from the Bluetooth device is very low compared to other RF devices. Therefore a 20 cm separation from the Bluetooth antenna is not required. FCC ID: ANOCORN1TASUHOP 3 FCC ID: ANOCORN1SHR Note:The Thinkpad of FCC ID: ANOCORN1SHR implements transmission diversity function. The function does not emit radio frequencies simultaneously from both antennas. One of the antennas is selected automatically or manually (by users) to have good quality of radiocommunication. iii) Interference Statement An improper installation or unauthorized use may cause harmful interference to radio communications. Also any tampering of the internal antenna will void the FCC certification and your warranty. Refer to the“Appendix D. Notices, Electronic emission notices”of the ThinkPad T30 Series Service and Troubleshooting Guide for more detail. 4 Canada—Industry Canada (IC) Certification number The term“IC”before the equipment certification number only signifies that the Industry Canada technical specifications were met. The certification number“IC: 349E-CORN1BDC”on the label at the bottom of the computer is for the integrated Bluetooth module. The number for the integrated wireless LAN Mini-PCI Card is affixed on the Card installed in the Mini-PCI Card slot, as shown below. Attention:You can install or remove the wireless LAN Mini-PCI Card by yourself. If you install a wireless LAN Mini-PCI Card that is not authorized for the ThinkPad T30 Series computer, the computer does not start, but only displays an error message and emits beeps. Low Power License-Exempt Radiocommunication Devices (RSS-210) Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Numéro d’homologation signifie Le terme«IC»avant le numéro d’homologation signifie seulement que les normes d’Industrie Canada ontétérespectées. Le numéro d’homologation IC: 349E-CORN1BDC qui figure sur l’étiquette apposée sous l’ordinateur concerne le module Bluetooth intégré.Lenuméro d’homologation pour la carte mini-PCI pour réseau local sans fil est collésur la carte installée dans l’emplacement correspondant, comme indiquédans la figure précédente. 5 Attention: Vous pouvez installer ou retirer la carte mini-PCI pour réseau local sans fil vous-même. Si vous avez installéune carte de ce type qui n’est pas homologuée pour l’ordinateur ThinkPad T30 Series, l’ordinateur ne démarrera pas ; un mes…

Text truncated - open the document above for the full version.

ThinkPad ® T30Series ServiceandTroubleshootingGuide
 Note Before using this information and the product it supports, be sure to read the general information under Appendix A, “Important safety instructions” on page 39, Appendix B, “Wireless related information” on page 45, Appendix C, “Warranty information” on page 47, and Appendix D, “Notices” on page 61. DANGER vTo avoid electric shock hazard, connect and disconnect cables appropriately when installing, moving or opening the covers of this product or attached devices. Use the power cord with a properly grounded outlet. vDo not leave the base of your computer in contact with your lap or any part of your body for an extended period when the computer is functioning or when the battery is charging. Your computer dissipates some heat during normal operation. This heat is a function of the level of system activity and battery charge level. Extended contact with your body, even through clothing, could cause discomfort or, eventually, a skin burn. vTo reduce the risk of electric shock, do not use your computer in or near water. vTo avoid electric shock, do not use your computer with the telephone cable connection during an electrical storm. Do not connect the cable to or disconnect it from the telephone outlet on the wall during an electrical storm. vStore packing materials safely out of the reach of children to prevent the risk of suffocation from plastic bags. vThe battery pack contains a small amount of harmful substances. There is danger of an explosion if the battery pack is incorrectly replaced, exposed to fire or water, short-circuited or disassembled. Keep the battery pack away from children and do not put it in trash that is disposed of in landfills. vTo reduce the risk of fire, use only No. 26 AWG or thicker telephone cable. vThe fluorescent lamp in the LCD contains mercury. Do not put it in trash that is disposed of in landfills. Rough handling or dropping the computer can cause the LCD to break and the internal fluid to get into your eyes or on your hands. Immediately wash the affected areas with water. If symptoms persist, seek medical care. vDo not disassemble the optical storage drive unit, as this might result in hazardous radiation exposure. vAvoid direct eye exposure with the laser beam contained in some drives. First Edition (June 2002) The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with local law: INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION′′AS IS′′WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you. This information could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time without notice. IBM may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you. © Copyright International Business Machines Corporation 2002. All rights reserved. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp. Important Wireless Regulatory Notice for Users The ThinkPad T30 Series computer complies with the radio frequency and safety standards of any country or region in which it has been approved for wireless use. You are requested to install and use your ThinkPad computer in strict accordance with the local RF regulations. Before you use the ThinkPad T30 Series computer, please find and read“Wireless Regulatory Notice for ThinkPad T30 Series,”the notice that supplements this Service and Troubleshooting Guide. The notice is included in the package with this publication. © Copyright IBM Corp. 2002iii ivThinkPad ® T30 Series Service and Troubleshooting Guide Finding information with Access ThinkPad Find answers to questions about your computer and view IBM Web sites by pressing the ThinkPad button to open Access ThinkPad, your on-board computer help center. © Copyright IBM Corp. 2002v Take a tour of your ThinkPad computer and learn how to get started, customize your computer, add memory, protect data, recover applications and data files, upgrade, and solve problems. Once you are familiar with the hardware features of your computer, click the Tools and Tips tab to get the most out of those features, like Wireless Networking, Maximizing your battery life, and even personalizing Access ThinkPad. Click Access Helpto open a comprehensive help system that offers information such as how to change or upgrade the memory in your computer. Visit these IBM Web sites to join an interactive community of ThinkPad users, download new backgrounds, purchase accessories, or get online support. Keyword Search provides a quick way to search information in Access Help. Click System Information to view information about your system, such as model number, serial number, and hard disk capacity. viThinkPad ® T30 Series Service and Troubleshooting Guide Some of the topics in your help system contain brief video clips that show you how to perform certain tasks, such as replacing your battery, inserting a PC Card, or upgrading your memory. Use the controls shown to play, pause, and rewind the video clip. Finding information with Access ThinkPadvii viiiThinkPad ® T30 Series Service and Troubleshooting Guide Contents Important Wireless Regulatory Notice for Users..............iii Finding information with Access ThinkPadv Chapter 1. Overview of your new ThinkPad computer.............1 Your ThinkPad at a glance.......2 Feature…

Text truncated - open the document above for the full version.

FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Attestation Statements regarding the FCC 15.247 for Bluetooth Daughter Card Registergerichth registered in:Vorstandh Board of Directors:7 layers AG, Borsigstrasse 11 Ratingen HRB 3264Dr. Wolfgang Dahm40880 Ratingen, Germany AufsichtsratsvorsitzendehDr. Hans-Jürgen MeckelburgPhone: +49 (0) 2102 749 0 Chairman of the Supervisory Board:Fax: +49 (0) 2102 749 350 Dr. Sabine Grobeckerwww.7layers.com Annex Additional declaration part according FCC 15.247 for Bluetooth devices Version: 2000-01-11 (Annex - Additional declaration part according FCC 15.247 for Bluetooth devices) Page 2 of 5 pages 1 Output power and channel separation of a Bluetooth device in the different operating modes: The different operating modes (data-mode, acquisition-mode) of a Bluetooth device don’t influence the output power and the channel spacing. There is only one transmitter which is driven by identical input parameters concerning these two parameters. Only a different hopping sequence will be used. For this reason the check of these RF parameters in one op-mode is sufficient. 2 Frequency range of a Bluetooth device: Hereby we declare that the maximum frequency of this device is: 2402 – 2480 MHz. This is according the Bluetooth Core Specification V 1.0B (+ critical errata) for devices which will be operated in the USA. This was checked during the Bluetooth Qualification tests (Test Case: TRM/CA/04-E). Other frequency ranges ( e.g. for Spain, France, Japan) which are allowed according the Core Specification are not supported by this device. 3 Co-ordination of the hopping sequence in data mode to avoid simultaneous occupancy by multiple transmitters: Bluetooth units which want to communicate with other units must be organised in a structure called piconet. This piconet consist of max. 8 Bluetooth units. One unit is the master the other seven are the slaves. The master co-ordinates frequency occupation in this piconet for all units. As the master hop sequence is derived from it’s BD address which is unique for every Bluetooth device, additional masters intending to establish new piconets will always use different hop sequences. 4 Example of a hopping sequence in data mode: Example of a 79 hopping sequence in data mode: 40, 21, 44, 23, 42, 53, 46, 55, 48, 33, 52, 35, 50, 65, 54, 67, 56, 37, 60, 39, 58, 69, 62, 71, 64, 25, 68, 27, 66, 57, 70, 59, 72, 29, 76, 31, 74, 61, 78, 63, 01, 41, 05, 43, 03, 73, 07, 75, 09, 45, 13, 47, 11, 77, 15, 00, 64, 49, 66, 53, 68, 02, 70, 06, 01, 51, 03, 55, 05, 04 (Annex - Additional declaration part according FCC 15.247 for Bluetooth devices) Page 3 of 5 pages 5 Equally average use of frequencies in data mode and behaviour for short transmissions: The generation of the hopping sequence in connection mode depends essentially on two input values: 1. LAP/UAP of the master of the connection 2. Internal master clock The LAP (lower address part) are the 24 LSB’s of the 48 BD_ADDRESS. The BD_ADDRESS is an unambiguous number of every Bluetooth unit. The UAP (upper address part) are the 24 MSB’s of the 48 BD_ADDRESS. The internal clock of a Bluetooth unit is derived from a free running clock which is never adjusted and is never turned off. For synchronisation with other units only offset are used. It has no relation to the time of the day. Its resolution is at least half the RX/TX slot length of 312.5 μs. The clock has a cycle of about one day (23h30). In most case it is implemented as 28 bit counter. For the deriving of the hopping sequence the entire LAP (24 bits), 4 LSB’s (4 bits) (Input 1) and the 27 MSB’s of the clock (Input 2) are used. With this input values different mathematical procedures (permutations, additions, XOR- operations) are performed to generate the sequence. This will be done at the beginning of every new transmission. Regarding short transmissions the Bluetooth system has the following behaviour: The first connection between the two devices is established, a hopping sequence was generated. For transmitting the wanted data the complete hopping sequence was not used. The connection ended. The second connection will be established. A new hopping sequence is generated. Due to the fact that the Bluetooth clock has a different value, because the period between the two transmission is longer (and it cannot be shorter) than the minimum resolution of the clock (312.5 μs). The hopping sequence will always differ from the first one. 6 Receiver input bandwidth and behaviour for repeated single or multiple packets: The input bandwidth of the receiver is 1 MHz. In every connection one Bluetooth device is the master and the other one is the slave. The master determines the hopping sequence (see chapter 5). The slave follows this sequence. Both devices shift between RX and TX time slot according to the clock of the master. Additionally the type of connection (e.g. single or multislot packet) is set up at the beginning of the connection. The master adapts its hopping frequency and its TX/RX timing according to the packet type of the connection. Also the slave of the connection will use these settings. Repeating of a packet has no influence on the hopping sequence. The hopping sequence generated by the master of the connection will be followed in any case. That means, a repeated packet will not be send on the same frequency, it is send on the next frequency of the hopping sequence. (Annex - Additional declaration part according FCC 15.247 for Bluetooth devices) Page 4 of 5 pages 7 Dwell time in data mode The dwell time of 0.3797s within a 30 second period in data mode is independent from the packet type (packet length). The calculation for a 30 second period is a follows: Dwell time = time slot length * hop rate / number of hopping channels *30s Example for a DH1 packet (with a maximum length of one time slot) Dwell time = 625 μs * 1600 1/s / 79 * 30s = 0.3797s (in a 30s period) For multislot packet the hopping is reduced accordi…

Text truncated - open the document above for the full version.

IBM Japan Ltd. 1623-14, Shimotsuruma, Yamato Kanagawa 242-8502, Japan June 10, 2002 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315, USA Subject: Request for FCC Certification of Part 15, Subpart C Dear sir : Please find enclosed an IBM’s application document for the FCC Part 15, Subpart C certification. - FCC ID : ANOCORN1SHR - Applying equipment name : ThinkPad T30 Series -Device type : 2400-2483.5MHz Spread Spectrum, Direct Sequence and Frequency Hopping (Bluetooth) system The applying product is a full size laptop PC integrating IEEE802.11b Wireless LAN Mini- PCI card and Bluetooth Standard adapter. The PC system unit, the built_in antennas and integrated Bluetooth card are the same as the previous model of “ThinkPad T30 Series” (FCC ID : ANOCORN1TASUHOP) granted on April/22/2002. The integrated IEEE802.11b Wireless LAN card is replaced with a new module. If any further information is required concerning this application, please contact us. Sincerely, Akihisa Sakurai Manager, EMC Engineering Yamato Laboratory, IBM Japan Ltd.

IBM Japan Ltd. 1623-14, Shimotsuruma, Yamato Kanagawa 242-8502, Japan June 10, 2002 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315, USA Subject: Confidentiality Request for FCC Certification of Part 15, Subpart C Dear sir : Please find enclosed an IBM’s application for the FCC Part 15, Subpart C certification : - FCC ID : ANOCORN1SHR - Applying equipment name : ThinkPad T30 Series Pursuant to 47 CFR section 0.457(d) and 0.459, we hereby request the confidentiality for the following exhibits. - Schematic Diagrams of the integrated Bluetooth module - Block Diagrams of the integrated Bluetooth module And as per the confidentiality request of Cisco Systems, Inc., the schematics, detailed block diagrams, detailed theories of operation, and parts list of the applying wireless card should be held in confidence. Please refer the attached authorization letter by Cisco Systems, Inc. Sincerely, Akihisa Sakurai Manager, EMC Engineering Yamato Laboratory, IBM Japan Ltd.

Cisco Systems, Inc. 320 Springside Drive Akron, Ohio 44333 Phone: 330 664-7900 Fax: 330-664-7922 http://www.cisco.com Phone: (330) 664-7362 Fax: (330) 664-7301 E-Mail: [email protected] June 11, 2002 Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: FCC ID: ANOCORN1SHR To Whom It May Concern: The following information is to be held confidential pursuant to 47 CFR Part 0 §0.457 and Section 552(b)(4) of the Freedom of Information Act, because the information provided is proprietary and contains trade secrets. If made public, the information might be used to the disadvantage of the Cisco Systems, Inc. in the market place. This information is to be withheld from the applicant, IBM, as well. Block Diagram Schematic Diagrams Technical Description Bill of Materials (Parts List) Best Regards, Jim Nicholson EMC Compliance Engineer

FCC ID: ANOCORN1SHR Document Number: FCC-19-0196-0 IBM Japan Ltd. 1623-14, Shimotsuruma, Yamato-shi Kanagawa-ken 242-8502, Japan August 1, 2002 To whom this may concern OET Requested Information FCC ID : ANOCORN1SHR Applicant : International Business Machines Corporation Correspondence Reference Number : 23516 731 Confirmation Number : EA519925 Original Requested Date : July 31, 2002 Subject 1) Can all optional transmitters transmit simultaneously? If no, how is that prevented? If yes, please submit MPE estimation for 2.4 GHz and 5.2 GHz simultaneous. Answer 1) The 2.4GHz PCMCIA option cards transmit simultaneously with the applying device, but the 5.2GHz PCMCIA option card was withdrawn from the application due to the insufficient RF exposure evaluation. Please see the revised exhibit “RF_Exposure_update.pdf” submitted on July/25/2002. Subject 2) Please submit webpage snapshot listing all optional transmitters. Answer 2) The Web page is included in the revised exhibit on July/25/2002. Subject 3) How does this notebook series (slot location and distance to edges, proximity to shielding/metallic structures) compare to laptop used in 5.2 GHz SAR test, and does that SAR test support compliance in the present host? Answer 3) We withdrew the co_location with the 5.2GHz option, so this question is no longer applicable. Subject 4) Source-based time-averaging applies only to fixed transmitters or mobile and portable for occupational use. Please revise RF exposure exhibit accordingly. Subject 5) "Web guidance" for co-located conditions is pending for TCB approval purposes when SAR routine evaluation is needed, and does not apply for this application. Please revise RF exposure exhibit accordingly. Answer 4, 5) Please refer the revised exhibit on July/25/2002. Subject 6) We do not understand the statement: "When the antenna separation from a person's body is closer than 2.5 cm, the near field estimation (i.e. the source- based time- averaging) is not proper method for the RF exposure evaluation. So 5 mW should be considered as the criteria of SAR evaluation for the co-location of transmitters." We think you mean "MPE estimation," not near-field. We think you may intend to apply Suppl C Footnote 14. Please clarify and revise RF exposure exhibit accordingly. Note that if Bluetooth and 5.2 GHz LAN antennas are close together, simultaneous SAR evalution could be needed. Answer 6) The “Web guidance” introduced two evaluation routs for the co-location of standalone transmitters. One is “2% of the source- based time-averaged conducted and radiated output power levels of the dominant transmitter” and the other is “5 mW”. The distance between the PC slot and lap is approximately 1.5cm for all applying PC models, so I thought the former method is not applicable due to near-field. FCC ID: ANOCORN1SHR Document Number: FCC-19-0196-0 Anyway we withdrew the 5.2GHz option and revised the RF Exposure evaluation exhibit. We eliminated the “Web guidance” and made a reference to only Suppl C Footnote 14. Please see the revised exhibit on July/25/2002. Subject 7) Please explain how the system uses a BIOS lock or other method, in order to prevent a user from installing unauthorized transmitter modules. Answer 7) The BIOS lock mechanism was basically developed for the customer installation of a mini-PCI type transmitter. But the transmitter modules (both integrated WLAN and Bluetooth) of this applying equipment(ANOCORN1SHR) are preinstalled by IBM. Also a broken card will be replaced by IBM ourselves. Therefore there is no phase where an unauthorized transmitter module is installed by a customer in this PC model. Please refer the submittal exhibit “RF_Safety_Info.pdf”. We guide the customers as follows. Subject 8) Page 5 of the DSS test report indicates 32 mW(15dBm) and does not agree with page 19 (100 mW). Please correct. Verify output power. Answer 8) This was a careless miss. The correct specification of the applying transmitter is 20dBm, so we would like to submit an additional page for the replacement in the next page since we can’t revise the test report’s date. Sincerely, August 01, 2002 Toshiya Murota, Staff Engineer, EMC Engineering, Yamato Laboratory, IBM Japan Ltd. (page 2) i) Installation of the integrated wireless modules The integrated wireless modules (Wireless LAN Mini-PCI Card and Bluetooth card) are preinstalled by IBM, and you are not permitted to install nor replace the integrated modules by yourself. If your integrated Wireless LAN Mini-PCI Card or Bluetooth card requires replacement via the proper step shown in “Chapter 3. Getting help and service from IBM” of the ThinkPad T30 Series Service and Troubleshooting Guide, IBM will request you to send your computer with the card(s) to IBM so that IBM will repair it. FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by S. Fujio - 5 - C. OPERATION MODE OF EUT All tests were performed using the “Venus MPI 350 Software”. Three kinds of modulation are used for transmission with appropriate bit rates: Table C-1 Transmit mode (TX) Rated output power (conducted) [dBm] Operation Frequency [GHz] Bit rate 2MbpsBit rate 5.5MbpsBit rate 11Mbps Test performed* 2.412 (Ch. 1)+20+20+20X 2.417 (Ch. 2)+20+20+20 2.422 (Ch. 3)+20+20+20 2.427 (Ch. 4)+20+20+20 2.432 (Ch. 5)+20+20+20 2.437 (Ch. 6)+20+20+20X 2.442 (Ch. 7)+20+20+20 2.447 (Ch. 8)+20+20+20 2.452 (Ch. 9)+20+20+20 2.457 (Ch. 10)+20+20+20 2.462 (Ch. 11)+20+20+20X * Full testing with bit rate 11Mbps only Table C-2 Receive mode (RX) Operation Frequency [GHz]Test performed 2.412 (Ch. 1) 2.417 (Ch. 2) 2.422 (Ch. 3) 2.427 (Ch. 4) 2.432 (Ch. 5) 2.437 (Ch. 6)X 2.442 (Ch. 7) 2.447 (Ch. 8) 2.452 (Ch. 9) 2.457 (Ch. 10) 2.462 (Ch. 11)

FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 1/2 External Photos FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 2/2 Rear side view

FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 1/1 Product Labeling Bottom view, Front side

FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 1/9 Internal Photos Bottom view Locations of wireless cards FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 2/9 IEEE802.11b Wireless LAN Mini-PCI card by Cisco Systems Inc. Bluetooth Daughter card by TDK Systems Europe Ltd. Bottom view, front side Main antenna cable Auxiliary antenna cable Bluetooth antenna cable FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 3/9 IEEE802.11b Wireless LAN Mini-PCI Adapter (Top side) FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 4/9 IEEE802.11b Wireless LAN Mini-PCI Adapter (Back side) Shielded back side FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 5/9 Bluetooth Daughter Card (Top side) FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 6/9 Bluetooth Daughter Card (Back side) Antenna terminal FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 7/9 Antenna Locations IEEE802.11b Wireless LAN Left antenna Inverted-F type IEEE802.11b Wireless LAN Right antenna Inverted-F type Bluetooth Antenna (Tx/Rx) (Inverted-F type Antenna) FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 8/9 IEEE802.11b Wireless LAN Antenna (Inverted F type Antenna and Cable) Left antenna (Tx/Rx switch) : IBM P/N: 46L4819 Cable : coax 560 mm Right antenna (Rx only) : IBM P/N: 46L4818 Cable : coax 800 mm FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 9/9 Bluetooth Antenna (Inverted F type Antenna and Cable) Tx/Rx switch : IBM P/N: 46L4932 Cable : coax 125 mm

FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 1/5 RF Exposure 1. Antenna Gains of applying transmitters Figure A: Main Antenna Gain of IEEE802.11b Wireless LAN Adapter Figure B: Auxiliary Antenna Gain of IEEE802.11b Wireless LAN Adapter FCC Test Report FCC ID: ANOCORN1SHR Document Number: FCC 19-0196-0 Prepared by T. Murota 2/5 Figure C: Antenna Gain of Bluetooth Daughter Crad 2. RF Exposure evaluation of Cisco Aironet Wireless 802.11b As shown in the following photos, the WLAN’s antenna positions of IBM ThinkPad T30 Series are located at the top of display (LCD) bezel for both the main and auxiliary antennas. The separation distances between the antennas and the human body are 20cm or more. Therefore the equipment of this configuration can be categorized as a mobile device by FCC CFR 47 Section 2.1091. The highest conducted peak output power of the Test Report is 93.3mW(19.7dBm) and the maximum antenna gain is 0.53dBi. (See the previous Figure A.) The separation distance between the antenna and the human body is 20c…
