AQZ-MX-9325Multimode data transceiver

PUBLICATION NUMBER: 10515-0152-4300 JUNE 2000 Rev. 02 Air Traffic Control Communications next level solutions MX-9325 TRANSCEIVER INTERMEDIATE MAINTENANCE MANUAL The material contained herein is subject to U.S. export approval. No export or re-export is permitted without written approval from the U.S. Government. LIMITED ONE YEAR WARRANTY HARRIS CORPORATION (RF COMMUNICATIONS DIVISION) FROM HARRIS TO YOU – This warranty is extended to the original buyer and applies to all Harris Corporation, RF Communications Division equipment purchased and employed for the service normally intended, except those products specifically excluded. WHAT WE WILL DO – If your Harris Corporation, RF Communications Division equipment purchased from us for use outside the United States fails in normal use because of a defect in workmanship or materials within one year from the date of shipment, we will repair or replace (at our option) the equipment or part without charge to you, at our factory. If the product was purchased for use in the United States, we will repair or replace (at our option) the equipment or part without charge to you at our Authorized Repair Center or factory. WHAT YOU MUST DO – You must notify us promptly of a defect within one year from date of shipment. Assuming that Harris concurs that the complaint is valid, and is unable to correct the problem without having the equipment shipped to Harris: •Customers with equipment purchased for use outside the United States will be supplied with information for the return of the defective equipment or part to our factory in Rochester, NY, U.S.A., for repair or replacement. You must prepay all transportation, insurance, duty and customs charges. We will pay for return to you of the repaired/replaced equipment or part, C.I.F. destination; you must pay any duty, taxes or customs charges. •Customers with equipment purchased for use in the United States must obtain a Return Authorization Number, properly pack, insure, prepay the shipping charges and ship the defective equipment or part to our factory or to the Authorized Warranty Repair Center indicated by us. Harris CorporationTelephone: (716) 244-5830 RF Communications DivisionFax: 716-242-4755 Customer Service http://www.harris.com 1680 University Avenue Rochester, NY 14610, U.S.A. Harris will repair or replace the defective equipment or part and pay for its return to you, provided the repair or replacement is due to a cause covered by this warranty. WHAT IS NOT COVERED – We regret that we cannot be responsible for: •Defects or failures caused by buyer or user abuse or misuse. •Defects or failures caused by unauthorized attempts to repair or alter the equipment in any way. •Consequential damages incurred by a buyer or user from any cause whatsoever, including, but not limited to transportation, non-Harris repair or service costs, downtime costs, costs for substituting equipment or loss of anticipated profits or revenue. •The performance of the equipment when used in combination with equipment not purchased from Harris. •HARRIS MAKES NO OTHER WARRANTIES BEYOND THE EXPRESS WARRANTY AS CONTAINED HEREIN. ALL EXPRESS OR IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE OR MERCHANTABILITY ARE EXCLUDED. SERVICE WARRANTY – Any repair service performed by Harris under this limited warranty is warranted to be free from defects in material or workmanship for sixty days from date of repair. All terms and exclusions of this limited warranty apply to the service warranty. IMPORTANT – Customers who purchased equipment for use in the United States must obtain a Return Authorization Number before shipping the defective equipment to us. Failure to obtain a Return Authorization Number before shipment may result in a delay in the repair/replacement and return of your equipment. IF YOU HAVE ANY QUESTIONS – Concerning this warranty or equipment sales or services, please contact our Customer Service Department. PUBLICATION NUMBER: 10515-0152-4300 JUNE 2000 Rev. 02 HARRIS CORPORATION RF COMMUNICATIONS DIVISION 1680 University Avenue Rochester, New York 14610-1887 USA Tel: 716-244-5830. Fax: 716-242-4755. http://www.harris.com MX-9325 TRANSCEIVER The material contained herein is subject to U.S. export approval. No export or re-export is permitted without written approval from the U.S. Government. Information and descriptions contained herein are the property of Harris Corporation. Such information and descriptions may not be copied or reproduced by any means, or disseminated or distributed without the express prior written permission of Harris Corporation, RF Communications Division, 1680 University Avenue, Rochester, New York 14610-1887. Copyright  2000 By Harris Corporation All Rights Reserved Firmware Release: rev. TBD MX-9325 ii For more information about these and other life–saving techniques, contact your Red Cross chapter for training. “When Breathing Stops” reproduced with permission from an American Red Cross Poster. When an Adult Stops Breathing Does the Person Respond?
Tap or gently shake victim.
Shout, “Are you OK?” 1 Roll Person Onto Back
Roll victim toward you by pulling slowly. 3 Open Airway
Tilt head back and lift chin. 4 Give 2 Full Breaths
Keep head tilted back.
Pinch nose shut.
Seal your lips tight around victim’s mouth.
Give 2 full breaths for 1 to 1-1/2 seconds each. 6 Check for Pulse at Side of Neck
Feel for pulse for 5 to 10 seconds. 7 Begin Rescue Breathing
Keep head tilted back.
Lift chin.
Pinch nose shut.
Give 1 full breath every 5 seconds.
Look, listen, and feel for breathing between breaths. 9 Shout, “Help!”
Call people who can phone for help. 2 Check for Breathing
Look, listen, and feel for breathing for 3 to 5 seconds. 5 Phone for Help
Send someone to call an ambulance. 8 Recheck Pulse Every Minute
Keep head tilted back.
Feel for pulse for 5 to 10 seconds.
If victim has pulse but is not breathing, continue rescue breathing. If no pulse, begin CPR. 10 WARNING DO NOT attemp…

Text truncated - open the document above for the full version.

Attachment to FCC Form 731 FCC ID: AQZ-MX-9325 Exhibit 2 Attestation Statement This is to certify that: With the exception of the radiated emission data, all data presented herein was either taken by me or by a qualified person under my supervision; The radiated emission tests were performed by Instrument Specialties Co. and the equipment was found to pass all requirements; The equipment upon which all tests were performed is representative of final production units; The equipment tested was found to comply with the applicable requirements of FCC Rule Parts 15 and 87; To the best of my knowledge and belief, the facts set forth herein are true and correct. C. Joseph Stoltz III Senior Principal Engineer Harris Corporation RF Communications Division

Attachment to FCC Form 731 FCC ID: AQZ-MX-9325 Exhibit 13 Cover Letters The following are scanned images of a letter and accompanying information sent to the Federal Aviation Administration on June 20, 2000, in accordance with § 87.147 (d) of the FCC Rules.

Attachment to FCC Form 731 FCC ID: AQZ-MX-9325 Exhibit 1 ID Label The equipment identification label to be used on the MX-9325 Transceiver is shown below and is actual size. FCC ID: AQZ-MX-9325 Made in U.S.A. VHF Transceiver 115/230 V; .22/.11 A 47-63 Hz B Z T Th is d e vice com plie s w ith Part 15 of the FC C Rules. O peration is sub ject to th e c o n d ition that this device does not cause harm ful interference. This label will be placed on the right rear side of the chassis, as viewed from the front. Refer to Exhibit 3, External Photos, for a showing of the exact label location.

Attachment to FCC Form 731 FCC ID: AQZ-MX-9325 Exhibit 12 Operational Description General Information The MX-9325 Transceiver is designed to be a multiple-mode radio for use in ground-to-air data communications applications. The A2D emission mode supports the Aircraft Communications Addressing and Reporting System (ACARS) service. In the G1D and G7D modes the transceiver will support future use in Flight Information Service (FIS) systems. These FIS systems will be implemented using VDL Mode 2 (G1D) or Mode 3 (G7D). The MX-9325 Transceiver employs digital microcontrollers that perform all control, modulation waveform synthesis and demodulation functions. The A2D emission consists of an amplitude modulated minimum-shift keying (AM-MSK) waveform which has a constant amplitude but a frequency that shifts between 1200 and 2400 Hz. The G1D and G7D emissions utilize a differentially encoded, 8 phase shift keying (D8PSK) modulated signal. The MX-9325 Transceiver is continuously adjustable over the range 5 watts to 25 watts. Closed loop power control is used to set and maintain the output power level. The transceiver operating mode (i.e. ACARS, Mode 2 or Mode 3) is selected by issuing a software command via the front panel maintenance connector, then power cycling the transceiver. The transceiver consists of several functional modules including receiver, exciter, power amplifier, low pass filter and power supply assemblies, which are contained within a single chassis. The transmit and receive circuits share common frequency control and reference oscillator circuits. For these reasons, the receiver part of the MX-9325 transceiver will be authorized under a grant of Verification pursuant to § 15.101(b), and the transceiver will have a single FCC identifier per § 2.925(b). The MX-9325 Transceiver is powered from the AC mains and operates over the voltage range of 110 to 220 VAC. 2.1033 (c)(10) Description of all circuitry and devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation, and for limiting power. Frequency stabilization. The MX-9325 Transceiver uses a temperature compensated crystal oscillator (TCXO) to achieve the required frequency stability over its operating temperature range. The TCXO is located on the Digital Processor board and is used as a master reference oscillator for all transceiver circuits. The TCXO is purchased as a completed unit and consists of a Colpitts oscillator with varactor-thermistor temperature compensating networks. The TCXO vendor tests and calibrates each unit before shipment to ensure that all specifications are met. The TCXO used in the MX-9325 has a frequency stability of 1 part per million (ppm) over the frequency range –30 to + 70 degrees Celsius. It also has a DC control pin which is used as a fine frequency adjust to set the oscillator precisely on frequency and correct for aging drift. Refer to Exhibit 5, Schematic Diagrams (filename digbd.PDF) for a schematic diagram of the circuit in which the TCXO is operated. Suppression of spurious radiation. For conducted spurious emissions, the MX- 9325 Transceiver employs a seventh order elliptic function low pass filter with a cutoff frequency of 155 MHz. This filter is physically located on the Directional Coupler/Low Pass filter board assembly. Electrically it is in the signal path between the power amplifier and the antenna connector in order to prevent conducted harmonic energy from reaching the antenna. For radiated emissions, the MX-9325 Transceiver is packaged inside a sheet metal enclosure. Top and bottom covers are equipped with RF gasketing material to prevent cabinet radiation from exceeding the limits specified in Part 15. Filtering is also used on all input/output connectors to further minimize radiation. Refer to Exhibit 5, Schematic Diagrams (filename: lpfdc.PDF) for the schematic diagram of the low pass filter and its associated circuits. Also please refer to Exhibit 9, Internal Photographs for pictures showing construction and mounting of the low pass filter. Modulation limiting. The MX-9325 Transceiver employs a digital signal processor (DSP) integrated circuit which runs firmware signal processing algorithms to synthesize the AM-MSK or D8PSK modulation waveforms. The algorithms contain leveling loops to ensure that the modulating waveforms are of constant amplitude. Since this transceiver accepts only digital data input, and does not have the provision for an external audio input, the usual pre-emphasis/clipper/low pass filter stages are not needed, and are not provided. Power limiting. The MX-9325 Transceiver has a closed-loop power control system that keeps the transmitter power constant over the frequency range and environmental conditions. The loop consists of a directional coupler at the output of the power amplifier; the digital signal processor; and a voltage variable attenuator (VVA) at the output of the exciter board. The directional coupler provides a dc output voltage proportional to the power output level; the digital signal processor compares this level to the power set point value and adjusts the VVA as required to maintain the desired power output. 2.1033 (c)(13) Detailed description of the digital modulation system to be used. For all emission modes, the transceiver accepts digital data from external equipment via a RS-530 synchronous serial interface, and internally formats this data and synthesizes the correct waveforms through the use of a digital signal processor. The A2D emission uses an amplitude modulated, minimum shift keying (AM- MSK) modulation scheme, which is a constant phase, frequency shift technique using two tones. In this transceiver the tones are 1200 Hz and 2400 Hz sine waves. The presence of 1200 Hz indicates a bit change from the previous bit, while the presence of 2400 Hz indicates no bit change. The phase of these two tones is controlled by the DSP such that minimum phase discontinuity occu…

Text truncated - open the document above for the full version.

Attachment to FCC Form 731 FCC ID: AQZ-MX-9325 Exhibit 10 Tune-up Information The following information is being provided in response to the requirement of 2.1033(c)(9). The MX-9325 Transceiver utilizes a solid-state power amplifier chain with wideband matching circuits. These matching circuits are comprised of fixed length transmission line segments which eliminate the need for tuning. The only adjustments provided in the transmit amplifier chain are for setting the bias on the various stages. These adjustments are set at the factory and do not require field adjustment. For procedures relating to setting channel frequency, power output and TCXO calibration, please refer to the instruction manual shown in Exhibit 8 of this Attachment.

Attachment to FCC Form 731Page 1 of 44 FCC ID AQZ MX-9325 107095 Attachment to FCC Form 731 FCC ID: AQZ-MX-9325 Exhibit 6 Test Report Table of Contents 2.1033 (c)(8) DC voltages and currents into the final amplifier stages................ 4 5 watt power level ......................................................................................... 4 25 watt power level ....................................................................................... 4 2.1046 - RF power output................................................................................. 5 Test Procedure ............................................................................................. 5 RF Power Test Data...................................................................................... 5 A2D Emission, 5 watt power level: ............................................................. 5 A2D Emission, 25 watt power level:............................................................ 6 G1D/G7D Emission, 5 watt power level: ..................................................... 6 G1D/G7D Emission, 25 watt power level: ................................................... 6 2.1047 - Modulation characteristics................................................................... 7 2.1049 - Occupied bandwidth........................................................................... 8 A2D Emission Limits ..................................................................................... 8 G1D/G7D Emission Limits ............................................................................. 8 Test Procedure – A2D Emission .................................................................... 8 A2D Emissions test block diagram ............................................................. 9 A2D Occupied Bandwidth Test Data.............................................................. 9 A2D Emission, 5 Watts 2400 Hz modulation 90% AM average.................... 9 A2D Emission, 5 Watts random data 90% AM average..............................10 A2D Emission, 5 Watts random data 90% AM peak hold ...........................11 A2D Emission, 25 Watts 2400 Hz modulation 90% AM average.................12 A2D Emission, 25 Watts random data 90% AM average ............................13 A2D Emission, 25 Watts random data 90% AM peak hold .........................14 Test Procedure – G1D and G7D Emissions ..................................................15 G1D/G7D Emissions Test set-up – Occupied Bandwidth and 1 st Adjacent channel power ..........................................................................................15 Attachment to FCC Form 731Page 2 of 44 FCC ID AQZ MX-9325 107095 1 st Adjacent Channel Test ........................................................................16 2 nd through 8 th Adjacent Channel Test .......................................................16 G1D/G7D Emissions Test Set-up – 2 nd through 8 th Adjacent channel power ................................................................................................................17 8 th Channel and Beyond Test ....................................................................17 G1D/G7D Emissions Test set-up – 8 th channel and greater ACP................18 G1D/G7D Occupied Bandwidth Test Data ....................................................19 G1D/G7D Emission, 127.5 MHz, 25 W (87.139(a) limits)...........................19 G1D/G7D Emission, 127.5 MHz, 5 W (87.139(a) limits).............................19 G1D/G7D Adjacent Channel Power – Tabular Data ......................................20 1 st Adjacent Channel Power in 16 KHz Bandwidth, 25 Watts......................20 1 st Adjacent Channel Power in 25 KHz Bandwidth, 25 watts ......................20 2 nd through 128 th Channel Power at 118 MHz, 25 watts.............................20 G1D/G7D 1 st Adjacent Channel Power Plots.................................................21 Burst Power Measurement Display ...........................................................21 127.5 MHz On-channel Power..................................................................22 127.5 MHz Upper 1 st Adjacent Channel, 16 KHz bandwidth .......................22 127.5 MHz Lower 1 st Adjacent Channel, 16 KHz bandwidth .......................23 127.5 MHz Upper 1 st Adjacent Channel, 25 KHz bandwidth .......................23 127.5 MHz Lower 1 st Adjacent Channel, 25 KHz bandwidth .......................24 136.975 MHz On-channel.........................................................................24 136.975 MHz Upper 1 st Adjacent Channel, 16 KHz bandwidth ...................25 136.975 MHz Lower 1 st Adjacent Channel, 16 KHz bandwidth ...................25 136.975 MHz Upper 1 st Adjacent Channel, 25 KHz bandwidth ...................26 136.975 MHz Lower 1 st Adjacent Channel, 25 KHz bandwidth ...................26 118.00 MHz On-channel...........................................................................27 118.00 MHz Upper 1 st Adjacent Channel, 16 KHz bandwidth .....................27 118.00 MHz Lower 1 st Adjacent Channel, 16 KHz bandwidth .....................28 118.00 MHz Upper 1 st Adjacent Channel, 25 KHz bandwidth .....................28 118.00 MHz Lower 1 st Adjacent Channel, 25 KHz bandwidth .....................29 2 nd through 128 th Channel ACP Plots using Crystal Filter ..............................30 118 MHz 2 nd Adjacent Channel (Fo=118.05 MHz)......................................30 Attachment to FCC Form 731Page 3 of 44 FCC ID AQZ MX-9325 107095 118 MHz 4th Adjacent Channel (Fo=118.10 MHz).....................................30 118 MHz 8 th Adjacent Channel (Fo=118.20 MHz)......................................31 118 MHz 16 th Adjacent Channel (Fo=118.40 MHz)....................................31 118 MHz 32 nd Adjacent Channel (Fo=118.80 MHz)....................................32 118 MHz 64 th Adjacent Channel (Fo=119.6 MHz)......................................32 118 MHz 128 th Adjace…

Text truncated - open the document above for the full version.

Attachment to FCC Form 731Page 1 of 7 FCC ID AQZ MX-9325 107096 Attachment to FCC Form 731 FCC ID: AQZ-MX-9325 Exhibit 6 Test Report 2.1053 – Field Strength of Spurious Radiation Spurious radiation measurements were made by Instrument Specialties Co. (ISC) at their World Compliance Center located in Delaware Water Gap, PA. Scanned images of the test data prepared by ISC are shown on the following pages. Attachment to FCC Form 731Page 2 of 7 FCC ID AQZ MX-9325 107096 Attachment to FCC Form 731Page 3 of 7 FCC ID AQZ MX-9325 107096 Attachment to FCC Form 731Page 4 of 7 FCC ID AQZ MX-9325 107096 Attachment to FCC Form 731Page 5 of 7 FCC ID AQZ MX-9325 107096 Attachment to FCC Form 731Page 6 of 7 FCC ID AQZ MX-9325 107096 Attachment to FCC Form 731Page 7 of 7 FCC ID AQZ MX-9325 107096
