AQZ-XG-100M00Unity MultiBand Mobile

Installation and Product Safety Manual 14221-1200-4000 May/11 UNITY ® XG-100M Full-Spectrum Front and Remote-Mount Mobile Radios Includes CH-100 Control Head and CH-721 Scan and System Control Heads 14221-1200-4000 2 MANUAL REVISION HISTORY REV. DATE REASON FOR CHANGE – May/11 N/A (5/6/2011) Harris Corporation, Public Safety and Professional Communications (PSPC) Business, continually evaluates its technical publications for completeness, technical accuracy, and organization. You can assist in this process by submitting your comments and suggestions to the following: Harris Corporation fax your comments to: 1-434-455-6851 PSPC Business or Technical Publications e-mail us at: PSPC _ TechPubs @ harris.com 221 Jefferson Ridge Parkway Lynchburg, VA 24501 ACKNOWLEDGEMENT This device is made under license under one or more of the following US patents: 4,590,473; 4,636,791; 5,148,482; 5,185,796; 5,271,017; 5,377,229; 4,716,407; 4,972,460; 5,502,767; 5,146,497; 5,164,986; 5,185,795; 5,226,084; 5,247,579; 5,491,772; 5,517,511; 5,630,011; 5,649,050; 5,701,390; 5,715,365; 5,754,974; 5,826,222; 5,870,405; 6,161,089; and 6,199,037 B1. DVSI claims certain rights, including patent rights under aforementioned U.S. patents, and under other U.S. and foreign patents and patents pending. Any use of this software or technology requires a separate written license from DVSI. CREDITS Harris, assuredcommunications, Unity and EDACS are registered trademarks of and ProVoice is a trademark of Harris Corporation. AMBE is a registered trademark and IMBE, AMBE+, and AMBE+2 are trademarks of Digital Voice Systems, Inc. Bird is a registered trademark of Bird Electronic Corporation. Bluetooth is a registered trademark of Bluetooth SIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. SmartSiren is a registered trademark of Federal Signal Corporation. All other brand and product names are trademarks, registered trademarks, or service marks of their respective holders. NOTICE! The material contained herein is subject to U.S. export approval. No export or re-export is permitted without written approval from the U.S. Government. Rated: EAR99 in accordance with U.S. Dept. of Commerce regulations 15CFR774, Export Administration Regulations. Information and descriptions contained herein are the property of Harris Corporation. Such information and descriptions may not be copied or reproduced by any means, or disseminated or distributed without the express prior written permission of Harris Corporation, PSPC Business, 221 Jefferson Ridge Parkway, Lynchburg, VA 24501. The voice coding technology embodied in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc. The user of this technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into human-readable form. Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier. Any repairs, alterations or substitutions of recommended parts made by the user to this equipment not approved by the manufacturer could void the user's authority to operate the equipment in addition to the manufacturer's warranty. This product conforms to the European Union WEEE Directive 2002/96/EC. Do not dispose of this product in a public landfill. Take it to a recycling center at the end of its life. This manual is published by Harris Corporation without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Harris Corporation at any time and without notice. Such changes will be incorporated into new editions of this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of Harris Corporation. Copyright © 2011, Harris Corporation 14221-1200-4000 3 TABLE OF CONTENTS Section Page 1 REGULATORY AND SAFETY INFORMATION .................................................................................... 7 1.1 SAFETY SYMBOL CONVENTIONS ................................................................................................. 7 1.2 RF ENERGY EXPOSURE AWARENESS AND CONTROL INFORMATION FOR FCC OCCUPATIONAL USE REQUIREMENTS ........................................................................................ 7 1.2.1 Federal Communications Commission Regulations ............................................................... 8 1.3 COMPLIANCE WITH RF EXPOSURE STANDARDS ...................................................................... 8 1.3.1 Mobile Antennas .................................................................................................................... 9 1.3.2 Approved Accessories ............................................................................................................ 9 1.3.3 Contact Information .............................................................................................................. 10 1.4 REGULATORY APPROVALS ......................................................................................................... 10 1.4.1 FCC Part 15 .......................................................................................................................... 10 1.4.2 Industry Canada .................................................................................................................... 10 1.5 OCCUPATIONAL SAFETY GUIDELINES AND SAFETY TRAINING INFORMATION ........... 10 1.6 COMMON HAZARDS ...................................................................................................................... 10 1.7 SAFE DRIVING RECOMMENDATIONS ...................................…

Text truncated - open the document above for the full version.

Operator’s Manual 14221-1200-2010 May/11 UNITY ® XG-100M Mobile Radio With CH-100 Control Head Full-Spectrum Multiband Radio 10515-0372-4200, Rev. B 2 MANUAL REVISION HISTORY REV. DATE REASON FOR CHANGE - May/11 Initial release. Harris Corporation, Public Safety and Professional Communications (PSPC) Business continually evaluates its technical publications for completeness, technical accuracy, and organization. You can assist in this process by submitting your comments and suggestions to the following: Harris Corporation fax your comments to: 1-434-455-6851 PSPC Business or Technical Publications e-mail us at: PSPC _ TechPubs @ harris.com 221 Jefferson Ridge Parkway Lynchburg, VA 24501 ACKNOWLEDGEMENT This product was developed using GEOTRANS, a product of the National Geospatial Intelligence Agency and U.S. Army Engineering Research and Development Center. Use of this software does not indicate endorsement or approval of the product by the Secretary of Defense or the National Geospatial Intelligence Agency. This device made under license under one or more of the following US patents: 4,590,473; 4,636,791; 5,148,482; 5,185,796; 5,271,017; 5,377,229; 4,716,407; 4,972,460; 5,502,767; 5,146,697; 5,164,986; 5,185,795. The Advanced Multi-Band Excitation implementation 2 (AMBE+2) voice coding Technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to extract, remove, decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into a human-readable form. U.S. Patent Nos. #5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and #5,195,166. CREDITS Harris, assuredcommunications, VIDA, EDACS, NetworkFirst, and OpenSky are registered trademarks of Harris Corporation. Bluetooth is a registered trademark of Bluetooth SIG, Inc. All brand and product names are trademarks, registered trademarks, or service marks of their respective holders. Motorola is a registered trademark of Motorola, Inc. AMBE is a registered trademark and IMBE, AMBE+, and AMBE+2 are trademarks of Digital Voice Systems, Inc. NOTICE! The material contained herein is subject to U.S. export approval. No export or re-export is permitted without written approval from the U.S. Government. Rated: EAR99; in accordance with U.S. Dept. of Commerce regulations 15CFR774, Export Administration Regulations. Information and descriptions contained herein are the property of Harris Corporation. Such information and descriptions may not be copied or reproduced by any means, or disseminated or distributed without the express prior written permission of Harris Corporation, PSPC Business, 221 Jefferson Ridge Parkway, Lynchburg, VA 24501. Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier. Any repairs, alterations or substitutions of recommended parts made by the user to this equipment not approved by the manufacturer could void the user's authority to operate the equipment in addition to the manufacturer's warranty. This product conforms to the European Union WEEE Directive 2002/96/EC. Do not dispose of this product in a public landfill. Take it to a recycling center at the end of its life. This manual is published by Harris Corporation without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Harris Corporation at any time and without notice. Such changes will be incorporated into new editions of this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of Harris Corporation. Copyright © 2011, Harris Corporation. 14221-1200-2010 3 TABLE OF CONTENTS Section Page 1. SAFETY SYMBOL CONVENTIONS.................................................................................................. 6 2. RF ENERGY EXPOSURE INFORMATION ..................................................................................... 7 2.1 RF ENERGY EXPOSURE AWARENESS, CONTROL INFORMATION, AND OPERATION INSTRUCTIONS FOR FCC OCCUPATIONAL USE REQUIREMENTS ................................ 7 2.1.1 Federal Communications Commission Regulations ........................................................ 7 2.2 COMPLIANCE WITH RF EXPOSURE STANDARDS............................................................. 8 2.2.1 Mobile Antennas (Vehicle Installations) ......................................................................... 8 2.2.2 Approved Accessories ..................................................................................................... 9 2.2.3 Contact Information ......................................................................................................... 9 2.3 REGULATORY APPROVALS ................................................................................................. 10 2.3.1 Part 15 ............................................................................................................................ 10 2.3.2 Industry Canada ............................................................................................................. 10 3. OPERATION SAFETY RECOMMENDATIONS ............................................................................ 11 3.1 TRANSMITTER HAZARDS..................................................................................................... 11 3.2 SAFE DRIVING RECOMMENDATIONS ........................................................................…

Text truncated - open the document above for the full version.

Operator’s Manual 14221-1200-2000 May/11 UNITY ® XG-100M Mobile Radio Full-Spectrum Multiband Radio With CH721 Control Head 14221-1200-2000 2 MANUAL REVISION HISTORY REV DATE REASON FOR CHANGE - May/11 Initial Release. Harris Corporation, Public Safety and Professional Communications (PSPC) Business continually evaluates its technical publications for completeness, technical accuracy, and organization. You can assist in this process by submitting your comments and suggestions to the following: Harris Corporation fax your comments to: 1-434-455-6851 PSPC Business or Technical Publications e-mail us at: PSPC _ TechPubs @ harris.com 221 Jefferson Ridge Parkway Lynchburg, VA 24501 ACKNOWLEDGEMENT This device is made under license under one or more of the following US patents: 4,590,473; 4,636,791; 5,148,482; 5,185,796; 5,271,017; 5,377,229; 4,716,407; 4,972,460; 5,502,767; 5,146,497; 5,164,986; 5,185,795; 5,226,084; 5,247,579; ; 5,491,772; 5,517,511; 5,630,011; 5,649,050; 5,701,390; 5,715,365; 5,754,974; 5,826,222; 5,870,405; 6,161,089; and 6,199,037 B1. DVSI claims certain rights, including patent rights under aforementioned U.S. patents, and under other U.S. and foreign patents and patents pending. Any use of this software or technology requires a separate written license from DVSI. CREDITS Harris, Unity, and assuredcommunications are registered trademarks of Harris Corporation. All other brand and product names are trademarks, registered trademarks, or service marks of their respective holders. AMBE is a registered trademark and IMBE, AMBE+, and AMBE+2 are trademarks of Digital Voice Systems, Inc. NOTICE ! The material contained herein is subject to U.S. export approval. No export or re-export is permitted without written approval from the U.S. Government. Rated: EAR99; in accordance with U.S. Dept. of Commence regulations 15CFR774, Export Administration Regulations. Information and descriptions contained herein are the property of Harris Corporation. Such information and descriptions may not be copied or reproduced by any means, or disseminated or distributed without the express prior written permission of Harris Corporation, PSPC Division, 221 Jefferson Ridge Parkway, Lynchburg, VA 24501. Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier. Any repairs, alterations or substitutions of recommended parts made by the user to this equipment not approved by the manufacturer could void the user's authority to operate the equipment in addition to the manufacturer's warranty. This product conforms to the European Union WEEE Directive 2002/96/EC. Do not dispose of this product in a public landfill. Take it to a recycling center at the end of its life. This manual is published by Harris Corporation without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Harris Corporation at any time and without notice. Such changes will be incorporated into new editions of this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of Harris Corporation. Copyright © 2011 Harris Corporation. 14221-1200-2000 3 TABLE OF CONTENTS Page 1 SAFETY SYMBOL CONVENTION .................................................................................................... 5 2 RF ENERGY EXPOSURE INFORMATION ..................................................................................... 6 2.1 RF ENERGY EXPOSURE AWARENESS, CONTROL INFORMATION, AND OPERATION INSTRUCTIONS FOR FCC OCCUPATIONAL USE REQUIREMENTS ................................ 6 2.1.1 Federal Communications Commission Regulations ........................................................ 6 2.2 COMPLIANCE WITH RF EXPOSURE STANDARDS ............................................................. 7 2.2.1 Mobile Antennas (Vehicle Installations) ......................................................................... 7 2.2.2 Approved Accessories ..................................................................................................... 8 2.2.3 Contact Information ......................................................................................................... 8 2.3 REGULATORY APPROVALS ................................................................................................... 9 2.3.1 Part 15 .............................................................................................................................. 9 2.3.2 Industry Canada ............................................................................................................... 9 3 OPERATION SAFETY RECOMMENDATIONS ............................................................................ 10 3.1 TRANSMITTER HAZARDS ..................................................................................................... 10 3.2 SAFE DRIVING RECOMMENDATIONS ................................................................................ 10 4 OPERATING RULES AND REGULATIONS .................................................................................. 11 5 PRODUCT DESCRIPTION ................................................................................................................ 12 6 OPERATION ........................................................................................................................................ 13 6.1 TURN THE RADIO ON ............................................................................................................. 13 6.2 CH721 FRONT PANEL COMPONENTS ................................................................................. 13 6.3 KEYPAD LOCK/UNLOCK ....................................................................................................... 14…

Text truncated - open the document above for the full version.

Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway Model: XG-100M Suite 1400 ID’s: AQZ-XG-100M00/122D-XG100M00 Herndon, VA20170 Standards: FCC Part 80, 90 http://www.rheintech.com Report #: 2011028 154 of 172 Appendix C: FCC Confidentiality Request Letter Please refer to the following page. HARRIS CORPORATION 221 Jefferson Ridge Parkway Lynchburg, VA 24501 www.harris.com April 29, 2011 ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 Subject: FCC ID: AQZ-XG-100M00 Original Grant CONFIDENTIALITY Harris wishes to submit this confidentiality letter for the record on FCC ID: AQZ-XG- 100M00 , Unity MultiBand mobile radio. Harris is requesting that parts lists, schematics, block diagrams, tune up procedure, and operational descriptions for this application not be made routinely available for public inspection. Harris considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457 and Section 0.459 of the FCC rules. Thank you for your attention to this matter. Daryl Popowitch Regulatory Manager

Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway Model: XG-100M Suite 1400 ID’s: AQZ-XG-100M00/122D-XG100M00 Herndon, VA20170 Standards: FCC Part 80, 90 http://www.rheintech.com Report #: 2011028 153 of 172 Appendix B: Agency Authorization Please refer to the following page. HARRIS CORPORATION 221 Jefferson Ridge Parkway Lynchburg, VA 24501 www.harris.com ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 April 29, 2011 Subject: FCC ID: AQZ-XG-100M00 Original Grant The following organization is granted authority to act on Harris’ behalf, to file documentation for Harris equipment with FCC ID: AQZ-XG-100M00, Unity MultiBand mobile radio, as it applies to an original Grant. Ms. Kathy Grzovic Rhein Tech Laboratories, Inc. 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Harris certifies that it is not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C.862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Sincerely, Daryl Popowitch Regulatory Manager

Engineering Solutions & Electromagnetic Compatibility Services XG-100M External Photographs Photograph 1: Control Head Top Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 2: Control Head Bottom Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 3: Side Photograph 4: Connectors Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 5: CH-721 Control Head Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 6: Control Head for Remote Operation - Front Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 7: Control Head for Remote Operation – Back Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 8: Mobile Microphone

Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway Model: XG-100M Suite 1400 ID’s: AQZ-XG-100M00/122D-XG100M00 Herndon, VA20170 Standards: FCC Part 80, 90 http://www.rheintech.com Report #: 2011028 159 of 172 Appendix H: ID Label & Location Photograph 1: ID Label Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway Model: XG-100M Suite 1400 ID’s: AQZ-XG-100M00/122D-XG100M00 Herndon, VA20170 Standards: FCC Part 80, 90 http://www.rheintech.com Report #: 2011028 160 of 172 Photograph 2 : ID Label Location ID Label Location

Engineering Solutions & Electromagnetic Compatibility Services XG-100M Internal Photographs Photograph 1: Digital Board Front Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 2: Digital Board Back Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 3: Digital Housing Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 4: Digital Board Mounted Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 5: PA Board Front Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 6: PA Board Back Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 7: PA Mobile Housing Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 8: PA Board Front – Mounted Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 9: PA Board Connected – Back Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 10: RES Front Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 11: RES Back Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 12: RES Housing Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 13: RES Mounted Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 14: Control Head Front Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 15: Control Head Back Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 16: Control Head Housing Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 17: Control Head Board Front Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 18: Control Head Board Back Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 19 Control Head Connector Board Front Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 20: Control Head Connector Board Back Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 21: Control Head Front Cover Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 22: Back Half of Control Head 1 Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 23: Back Half of Control Head 2 Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 24: Control Head Gasket Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway, Ste. 1400 Model: XG-100M Herndon, VA 20170 IDs: AQZ-XG-100M00/122D-XG100M00 http://www.rheintech.com WO #: 2011028 Photograph 25: Control Head Display

Engineering Solutions & Electromagnetic Compatibility Services 360 Herndon Pkwy | Suite 1400 | Herndon | Virginia 20170 Phone: 703.689.0368 | Fax: 703.689.2056 | www.rheintech.com FCC Part 15.247 & IC RSS-210 Certification Report Harris Corporation 1680 University Avenue Rochester, NY 14610 Model: XG-100M Unity MultiBand Mobile Radio FCC ID: AQZ-XG-100M00 IC: 122D-XG100M00 March 4, 2011 Standards Referenced for this Report American National Standard Institute ANSI C63.4-2003: Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Classification DSS – Part 15 Spread Spectrum Transmitter FCC Rule Part(s) FCC Rules Part 15.247: Operation within the bands 920-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz Frequency Hopping System (10-01-10) IC Standard RSS-210 Issue 8: Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment FCC Procedure ANSI C63.10-2009: American National Standard for Testing Unlicensed Wireless Devices Digital Interface Information Digital Interface was found to be compliant Frequency Range (MHz) Rated Transmit Power (W) (Conducted) Frequency Tolerance (ppm) Emission Designator 2402 – 2480 0.100 N/A 1M13FXD 2402 – 2480 0.100 N/A 1M42GXD Report Prepared By: Dan Baltzell Document Number: 2011028DSS This report may not be reproduced, except in full, without the full written approval of Rhein Tech Laboratories, Inc. and Harris Corporation. Test results relate only to the item tested. These tests are accredited and meet the requirements of ISO/IEC 17025 as verified by ANSI-ASQ National Accreditation Board/ACLASS. Refer to certificate and scope of accreditation AT-1445. Rhein Tech Laboratories, Inc. Client: Harris Corporation 360 Herndon Parkway Model: XG-100M Suite 1400 IDs: AQZ-XG-100M00/122D-XG100M00 Herndon, VA 20170 Standards: FCC 15.247/IC RSS-210 http://www.rheintech.com Report #: 2011028DSS 2 of 36 Table of Contents 1 General Information 5 1.1 Scope ...............................…

Text truncated - open the document above for the full version.
