ATH2425311VHF FM MOBILE TRANSMITTER

DIGITAL/ANALOG MOBILE RADIO OPERATING MANUAL 5300 SERIESMOBILERADIO APCO Project 25 Conventional APCO Project 25 Trunked SMARTNET ® /SmartZone ® Analog (FM) Conventional VHF UHF 800 MH Z Part No. 242-53xx-xxx Part Number: 002-5300-00xCD NR November 2004 5300 SERIES MOBILE OPERATING MANUAL ■APCO PROJECT 25 CONVENTIONAL ■APCO PROJECT 25 TRUNKED ■SMARTNET ® /SmartZone ® ■ANALOG (FM) CONVENTIONAL VHF/UHF/800 MHz Copyright© 2004 by the EFJohnson Company The EFJohnson Company, which was founded in 1923, provides wireless communication systems solutions for public safety, government, and commercial customers. The company designs, manufactures, and markets conventional and trunked radio systems, mobile and portable subscriber radios, repeaters, and Project 25 digital radio products. EFJohnson is a wholly owned subsidiary of EFJ, Inc. Viking Head/EFJohnson logo and Call Guard ® are trademarks of the EFJohnson Company. SMARTNET ® , SmartZone ® , SecureNet ™ , Call Alert ™ , Enhanced Private Conversation ™ , and Private Conversation II ™ are trademarks of Motorola, Inc. All other company and/or product names used in this manual are trademarks and/or registered trademarks of their respective manufacturer. The IMBE™ voice coding technology embodied in this product is protected by intellectual property rights including patent rights of Digital Voice Systems, Inc. LAND MOBILE PRODUCT WARRANTY - The manufacturer’s warranty statement for this product is available from your product supplier or from EFJohnson Company, 1440 Corporate Drive, Irving, TX 75038-2401. Phone (800) 328-3911. Information in this manual is subject to change without notice. Current Software Versions: Flash 2.2.2/3.2.2, ARM 1.24.1/DSP 1.58.0, PCConfigure 1.22.0 SAFETY INFORMATION 3 RF ENERGY EXPOSURE AWARENESS AND CONTROL INFORMATION, AND OPERATIONAL INSTRUCTIONS FOR FCC OCCUPATIONAL USE REQUIREMENTS Before using your mobile two-way radio, read this important RF energy awareness and control infor- mation and operational instructions to ensure compliance with the FCC’s RF exposure guidelines. NOTICE: This radio is intended for use in occupa- tional/controlled conditions, where users have full knowledge of their exposure and can exercise control over their exposure to meet FCC limits. This radio device is NOT authorized for general population, consumer, or any other use. This two-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. It uses radio frequency (RF) energy or radio waves to send and receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to, electric power, sunlight and x-rays. RF energy, however, should not be confused with these other forms of electromagnetic energy, which when used improperly can cause biological damage. Very high levels of x-rays, for example, can damage tissues and genetic material. Experts in science, engineering, medicine, health and industry work with organizations to develop standards for exposure to RF energy. These standards provide recom- mended levels of RF exposure for both workers and the general public. These recommended RF exposure levels include substantial margins of protection. All two-way radios marketed in North America are designed, manufac- tured and tested to ensure they meet government established RF exposure levels. In addition, manufacturers also recom- mend specific operating instructions to users of two-way radios. These instructions are important because they inform users about RF energy exposure and provide simple proce- dures on how to control it. Please refer to the following web sites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits. http://www.fcc.gov/oet/rfsafety/rf-faqs.html http://www.osha.gov/SLTC/radiofrequencyradiation/ index.html FEDERAL COMMUNICATIONS COMMISSION REGULATIONS The FCC rules require manufacturers to comply with the FCC RF energy exposure limits for mobile two-way radios before they can be marketed in the U.S. When two- way radios are used as a consequence of employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational requirements. Expo- sure awareness can be facilitated by the use of a label directing users to specific user awareness information. Your EFJohnson two-way radio has a RF exposure product label. Also, your EFJohnson user manual, or product manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. COMPLIANCE WITH RF EXPOSURE STANDARDS Your EFJohnson two-way radio is designed and tested to comply with a number of national and international stan- dards and guidelines (listed below) regarding human expo- sure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at duty factors of up to 50% talk and 100% listen and is authorized by the FCC for occupational use. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio antenna radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. Your EFJohnson two-way radio complies with the following RF energy exposure standards and guidelines: •United States Federal Communications Commission, Code of Federal Regulations; 47 CFR §§ 2 sub-part J. •American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1- 1992. •Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition. RF EXPOSURE COMPLIANCE AND CONTROL GUIDELINES AND OPERATING INSTRUCTIONS To control exposure to yourself and others and ensure compliance with the occupational/controlled environment…

Text truncated - open the document above for the full version.

Waseca Office: E.F. Johnson Company • 299 Johnson Ave., P.O. Box 1249 • Waseca, MN 56093-0514 • 800-328-3911 • 507-835-6222 • Fax 507-835-8356 www.efjohnson.com November 23, 2004 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: The following information is to be held confidential pursuant of 47 CFR Part 0 §0.457 and Section 552(b)(4) of the Freedom of Information Act, because the information provided contains trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. • Schematics • Product Description • Block Diagram • Bill of Materials (Parts List) Sincerely, John Oblak VP New Technology E. F. Johnson Co.

Radio front view Radio top view Radio bottom view showing label Radio side showing RF safety label Radio back view

Radio bottom view showing label Radio side showing RF safety label

Radio bottom with cover removed showing logic board Radio top view with cover removed Radio top view with RF module cover removed RF module top view without shields RF module bottom view without shields

M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, fax (480) 926-3598 MFA p04a0002, d04b0060 Date: November 30, 2004 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: E. F. Johnson Company Equipment: 242-5317-211-AAAA FCC ID: ATH2425311 FCC Rules: 90, Confidentiality Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Michael Schafer, General Manager enclosure(s) cc: Applicant MS/del M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, fax (480) 926-3598 MFA p04a0002, d04b0060 Transmitter Certification of FCC ID: ATH2425311 Model: 242-5317-211-AAAA to Federal Communications Commission Rule Part(s) 90, Confidentiality Date of report: November 30, 2004 On the Behalf of the Applicant: E. F. Johnson Company At the Request of: P.O. 171006 E. F. Johnson Company, 299 Johnson Ave. Waseca, MN 56093-0514 Attention of: (507) 835-6579; FAX: -6666 John Oblak, Director, Radio Products Development E-mail: [email protected] Supervised by: David E. Lee, Compliance Test Manager M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, fax (480) 926-3598 MFA p04a0002, d04b0060 List of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: E. F. Johnson Company FCC ID: ATH2425311 By Applicant: 1. Letter of Authorization 2. Confidentiality Request: 0.457 And 0.459 3. Part 90.203(e) & (g) Attestation 4. Identification Drawings, 2.1033(c)(11) Label Location of Label Compliance Statement Location of Compliance Statement 5. Photographs, 2.1033(c)(12) 6. Documentation: 2.1033(c) (3) User Manual (9) Tune Up Info (10) Schematic Diagram (10) Circuit Description Block Diagram Parts List Active Devices 7. MPE Report By M.F.A. Inc.: A. Testimonial & Statement of Certification M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, fax (480) 926-3598 MFA p04a0002, d04b0060 The Applicant has been cautioned as to the following: 15.21 Information to the User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, fax (480) 926-3598 MFA p04a0002, d04b0060 Table of Contents Rule Description Page 2.1033(c)(14) Rule Summary 2 . Standard Test Conditions and Engineering Practices 3 2.1033(c) General Information Required 4 2.1046(a) Carrier Output Power (Conducted) 8 2.1046(a) ERP Carrier Power (Radiated) 10 2.1046(a) RF Power Output (Radiated) 12 2.1053(a) Field Strength of Spurious Radiation 14 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 18 90.214 Transient Frequency Behavior 29 2.1047(a) Audio Low Pass Filter (Voice Input) 35 2.1047(a) Audio Frequency Response 37 2.1047(b) Modulation Limiting 39 2.1055(a)(1) Frequency Stability (Temperature Variation) 42 2.1055(b)(1) Frequency Stability (Voltage Variation) 44 2.202(g) Necessary Bandwidth and Emission Bandwidth 46 M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 1 of 46 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, (480) 926-3598 fax MFA p04a0002, d04b0060 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d04b0060 d) Client: E. F. Johnson Company, 299 Johnson Ave. Waseca, MN 56093-0514 e) Identification: 242-5317-211-AAAA (FCC ID: ATH2425311) EUT Description: VHF/FM Mobile Transceiver f) EUT Condition: Not required unless specified in individual tests. g) Report Date: November 30, 2004 EUT Received: September 20, 2004 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David …

Text truncated - open the document above for the full version.

M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, fax (480) 926-3598 MFA p04a0002, d04c0007 Date: December 3, 2004 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: E. F. Johnson Company Equipment: 242-5317-211-AAAA FCC ID: ATH2425311 FCC Rules: Radiofrequency Radiation Exposure Limits 47 CFR 1.1310 MPE - Mobiles X Fixed Based Station Gentlemen: On behalf of the Applicant, enclosed please find the Supplemental Test Data Report, the whole for Environmental Assessment (MPE) of the referenced equipment as shown. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, David E. Lee, Compliance Test Manager enclosure(s) cc: Applicant DEL/del M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, fax (480) 926-3598 MFA p04a0002, d04c0007 Environmental Assessment for Mobile Station for FCC ID: ATH2425311 Model:242-5317-211-AAAA to Federal Communications Commission 47 CFR 1.1310 (MPE) Radiofrequency Radiation Exposure Limits Date Of Report: December 3, 2004 On the Behalf of the Applicant: E. F. Johnson Company At the Request of: P.O. 171006 E. F. Johnson Company, 299 Johnson Ave. Waseca, MN 56093-0514 Attention of: (507) 835-6579; FAX: -6666 John Oblak, Director, Radio Products Development E-mail: [email protected] Supervised By: David E. Lee, Compliance Test Manager M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, fax (480) 926-3598 MFA p04a0002, d04c0007 Table of Contents Rule Description Page . Test Report 1 . Identification of the Equipment Under Test 2 2.1033(c) General Information Required 3 . Standard Test Conditions and Engineering Practices 4 1.1310 Environmental Assessment 5 M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 1 of 7 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, (480) 926-3598 fax MFA p04a0002, d04c0007 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report (Supplemental) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d04c0007 d) Client: E. F. Johnson Company, 299 Johnson Ave. Waseca, MN 56093-0514 e) Identification: 242-5317-211-AAAA (FCC ID: ATH2425311) Description: VHF/FM Mobile f) EUT Condition: Not required unless specified in individual tests. g) Report Date: December 3, 2004 EUT Received: September 20, 2004 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David E. Lee, Compliance Test Manager n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 2 of 7 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, (480) 926-3598 fax MFA p04a0002, d04c0007 Identification of the Equipment Under Test (EUT) Name and Address of Applicant: E. F. Johnson Company 299 Johnson Ave. Waseca, MN 56093-0514 Manufacturer: EF Johnson Company Irving, Texas FCC ID: ATH2425311 Model Number: 242-5317-211-AAAA Description: VHF/FM Mobile Type of Emission: 16K0F3E, 11K0F3E, 8K10F1E, 8K10F1D Frequency Range, MHz: 136Mhz to 174Mhz Power Rating, Watts: 55 Switchable X Variable N/A Modulation: AMPS TDMA CDMA X OTHER Antenna: Helical Monopole X Whip Other Note: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 0dBd) and RF Power set to highest nominal power across all channels. M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 3 of 7 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, (480) 926-3598 fax MFA p04a0002, d04c0007 A2LA “A2LA has accredited M. Flom Associates, Inc. Chandler, AZ for technical competence in the field of Electrical Testing. The accreditation covers the specific tests and types of tests listed on the agreed scope of accreditation. This laboratory meets the requirements of ISO/IEC 17025 – 1999 ‘General Requirements for the Competence of Testing and Calibration Laboratories’ and any additional program requirements in the identified field of testing.” Certificate Number: 2152-01 NIST I am pleased to inform you that your laboratory has been validated by the Chinese Taipei Bureau of Standards, Metrology and Inspection (BSMI) under the Asia Pacific Economic Cooperation Mutual Recognition Agreement (APEC MRA). Your laboratory is now formally designated to act as a Conformity Assessment Body (CAB) under Appendix B, Phase I Procedures, of the APEC MRA between the American Institute in Taiwan (AIT) and the Taipei Economic and Cultural Representative Office (TECRO) in the United States, covering equipment subject to Electro-Magnetic Compatibility (EMC) requirements. The names of all validated and nominated laboratories will be posted on the NIST website at http://ts.nist.gov/mra under the ‘Asia’ category.” BSMI Number: SL2-IN-E-041R M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 4 of 7 Chandler, Arizona 85225-7176 FCC ID: ATH2425311 (480) 926-3100 phone, (480) 926-3598 fax MFA p04a0002, d04c0007 Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-1992/2001, section 6.1.9, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipmen…

Text truncated - open the document above for the full version.
