ATH2425331UHF FM TRANSMITTER

DIGITAL/ANALOG MOBILE RADIO OPERATING MANUAL 5300 SERIESMOBILERADIO APCO Project 25 Conventional APCO Project 25 Trunked SMARTNET ® /SmartZone ® Analog (FM) Conventional VHF UHF 800 MH Z Part No. 242-53xx-xxx May 2004 Part Number: 002-5300-009CD Supersedes: 002-5300-008; 6/03 2 SAFETY INFORMATION SAFETY INFORMATION The FCC has adopted a safety standard for human expo- sure to RF energy. Proper operation of this radio under normal conditions results in user exposure to RF energy below the Occupational Safety and Health Act and Federal Communication Commission limits. WARNING DO NOT allow the antenna to touch or come in very close proximity with the eyes, face, or any exposed body parts while the radio is transmitting. To comply with FCC RF exposure limits, DO NOT operate the transmitter of a mobile radio when a person outside the vehicle is within one 1 meter of the antenna with standard power models or 1.5 meters with high power (100 watt) models. To comply with FCC RF exposure limits, DO NOT operate the transmitter of a stationary radio (base station or marine radio) when a person is within one 1 meter of the antenna with standard power models or 1.5 meters with high power (100 watt) models. DO NOT operate the radio in explosive or flammable atmospheres. The transmitted radio energy could trigger blasting caps or cause an explosion. DO NOT operate the radio without the proper antenna installed. DO NOT allow children to operate or play with this radio. NOTE: The above warning list is not intended to include all hazards that may be encountered when using this radio. This device complies with Part 15 of the FCC rules. Oper- ation is subject to the condition that this device does not cause harmful interference. In addition, changes or modi- fications to this equipment not expressly approved by EFJohnson could void the user’s authority to operate this equipment (FCC rules, 47CFR Part 15.19). FCC EXPOSURE LIMITS This mobile radio was tested by the manufacturer with an appropriate antenna in order to verify compliance with Maximum Permissible Exposure (MPE) limits set under Section 2.1091 of the FCC Rules and Regulations. The guidelines used in the evaluation are derived from Table 1 (B) titled “Limits For General Population/ Uncontrolled Exposure” which is from FCC report OET bulletin #65. Table 2 lists the antenna whips and bases tested for use in each frequency range. Each model of this radio was tested with the appropriate antenna listed. The antenna was mounted in the center of the roof of a domestically manufactured four-door passenger sedan. The radio manufacturer has determined that the user and service personnel should remain one (1) meter in distance away from the antenna when transmitting. By maintaining this distance, these individuals are not exposed to radio frequency energy or magnetic fields in excess of the guidelines set forth in Table 1. Table 1 FCC Limits for Maximum Permissible Exposure (MPE) (B) Limits For General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) 0.3-1.346141.63(100)* 1.34-30824/f2.19/f(180/f 2 )* 30-30027.50.0730.2 300-1500----f/1500 1500-100,000----1.0 f = Frequency in MHz*Plane-wave equivalent power density Table 2 Tested Antenna Whips and Bases (Antenna Manufacturer - Antenna Specialists) FrequencyWhip Model No. Base Model No. 136-144 MHzASPJ1415KM220 144-152 MHzASPA1415KM220 152-162 MHzASPB1415KM220 162-174 MHzASPC1415KM220 400-430 MHzASPE1615KM220 430-470 MHzASPD1615KM220 470--512 MHzASPF1615KM220 806-869 MHzASPA1855KM220 890-960 MHzASPG1865KM220 5300 SERIES MOBILE OPERATING MANUAL ■APCO PROJECT 25 CONVENTIONAL ■APCO PROJECT 25 TRUNKED ■SMARTNET ® /SmartZone ® ■ANALOG (FM) CONVENTIONAL VHF/UHF/800 MHz Copyright© 2004 by the EFJohnson Company The EFJohnson Company, which was founded in 1923, provides wireless communication systems solutions for public safety, government, and commercial customers. The company designs, manufactures, and markets conventional and trunked radio systems, mobile and portable subscriber radios, repeaters, and Project 25 digital radio products. EFJohnson is a wholly owned subsidiary of EFJ, Inc. Viking Head/EFJohnson logo and Call Guard ® are trademarks of the EFJohnson Company. SMARTNET ® , SmartZone ® , SecureNet ™ , Call Alert ™ , Enhanced Private Conversation ™ , and Private Conversation II ™ are trademarks of Motorola, Inc. All other company and/or product names used in this manual are trademarks and/or registered trademarks of their respective manufacturer. The IMBE™ voice coding technology embodied in this product is protected by intellectual property rights including patent rights of Digital Voice Systems, Inc. LAND MOBILE PRODUCT WARRANTY - The manufacturer’s warranty statement for this product is available from your product supplier or from EFJohnson Company, 299 Johnson Avenue, Box 1249, Waseca, MN 56093-0514. Phone (507) 835-6222. Information in this manual is subject to change without notice. Current Software Versions: Flash 2.2.2/3.2.2, ARM 1.24.1/DSP 1.58.0, PCConfigure 1.22.0 4 TABLE OF CONTENTS TABLE OF CONTENTS SAFETY INFORMATION FCC Exposure Limits . . . . . . . . . . . . . . . . . . . . . . . 2 1GENERAL 1.1Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1.2General Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Conventional Features . . . . . . . . . . . . . . . . . . . . 7 SMARTNET/SmartZone Features . . . . . . . . . . . 7 Project 25 Trunked Features . . . . . . . . . . . . . . . . 8 2CONTROLS AND DISPLAY 2.1Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . 9 2.2Rear Panel Connectors. . . . . . . . . . . . . . . . . . . . . . 10 2.3Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3GENERAL OPERATION 3.1Turning Power On and Setting Volume . . . . . . . . 12 Power ON/OFF . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Waseca Office: E.F. Johnson Company • 299 Johnson Ave., P.O. Box 1249 • Waseca, MN 56093-0514 • 800-328-3911 • 507-835-6222 • Fax 507-835-8356 www.efjohnson.com November 23, 2004 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: The following information is to be held confidential pursuant of 47 CFR Part 0 §0.457 and Section 552(b)(4) of the Freedom of Information Act, because the information provided contains trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. • Schematics • Product Description • Block Diagram • Bill of Materials (Parts List) Sincerely, John Oblak VP New Technology E. F. Johnson Co.

Radio front view Radio top view Radio bottom view showing label Radio side showing RF safety label Radio back view

Radio bottom view showing label Radio side showing RF safety label

FCC and IC Labels FCC ID: ATH2425331 EF Johnson Co. U.S.A. Model 242-5337-211-AAAA Made in DALLAS, TX USA IC: 933B-2425331 Serial No 53370A000A 00001 FCC/IC Label Radiation Safety Label Restricted to occupational use to satisfy FCC RF exposure limits. See user manual for operating requirements ATTENTION! Label is made of durable vinyl material and is affixed with permanent adhesive

Radio bottom with cover removed showing logic board Radio top view with cover removed showing shields Radio top view with PA shield removed Radio top view with RF module cover removed RF module top with shields removed RF module bottom with shields removed

M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0001 Date: December 2, 2004 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: E. F. Johnson Company Equipment: 242-5337-211-AAAA FCC ID: ATH2425331 FCC Rules: 90, Confidentiality Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Michael Schafer, General Manager enclosure(s) cc: Applicant MS/del M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0001 Transmitter Certification of FCC ID: ATH2425331 Model: 242-5337-211-AAAA to Federal Communications Commission Rule Part(s) 90, Confidentiality Date of report: December 2, 2004 On the Behalf of the Applicant: E. F. Johnson Company At the Request of: P.O. 170502 E. F. Johnson Company, 299 Johnson Ave. Waseca, MN 56093-0514 Attention of: (507) 835-6579; FAX: -6666 John Oblak, Director, Radio Products Development E-mail: [email protected] Supervised by: David E. Lee, Compliance Test Manager M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0001 List of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: E. F. Johnson Company FCC ID: ATH2425331 By Applicant: 1. Letter of Authorization 2. Confidentiality Request: 0.457 And 0.459 3. Part 90.203(e) & (g) Attestation 4. Identification Drawings, 2.1033(c)(11) Label Location of Label Compliance Statement Location of Compliance Statement 5. Photographs, 2.1033(c)(12) 6. Documentation: 2.1033(c) (3) User Manual (9) Tune Up Info (10) Schematic Diagram (10) Circuit Description Block Diagram Parts List Active Devices 7. MPE Report By M.F.A. Inc.: A. Testimonial & Statement of Certification M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0001 The Applicant has been cautioned as to the following: 15.21 Information to the User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0001 Table of Contents Rule Description Page 2.1033(c)(14) Rule Summary 2 . Standard Test Conditions and Engineering Practices 3 . Expository Statement for Permissive Changes 5 2.1046(a) Carrier Output Power (Conducted) 8 2.1046(a) ERP Carrier Power (Radiated) 10 2.1051 Unwanted Emissions (Transmitter Conducted) 12 2.1053(a) Field Strength of Spurious Radiation 14 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 18 90.214 Transient Frequency Behavior 29 2.1047(a) Audio Low Pass Filter (Voice Input) 35 2.1047(a) Audio Frequency Response 37 2.1047(b) Modulation Limiting 39 2.1055(a)(1) Frequency Stability (Temperature Variation) 42 2.1055(b)(1) Frequency Stability (Voltage Variation) 44 2.202(g) Necessary Bandwidth and Emission Bandwidth 46 M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 1 of 46 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, (480) 926-3598 fax MFA p0490011, d04c0001 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d04c0001 d) Client: E. F. Johnson Company, 299 Johnson Ave. Waseca, MN 56093-0514 e) Identification: 242-5337-211-AAAA (FCC ID: ATH2425331) EUT Description: UHF/FM Mobile Transceiver f) EUT Condition: Not required unless specified in individual tests. g) Report Date: December 2, 2004 EUT Received: September 30, 2004 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supe…

Text truncated - open the document above for the full version.

M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c00088 Date: December 3, 2004 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: E. F. Johnson Company Equipment: 242-5337-211-AAAA FCC ID: ATH2425331 FCC Rules: Radiofrequency Radiation Exposure Limits 47 CFR 1.1310 MPE - Mobiles X Fixed Based Station Gentlemen: On behalf of the Applicant, enclosed please find the Supplemental Test Data Report, the whole for Environmental Assessment (MPE) of the referenced equipment as shown. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, David E. Lee, Compliance Test Manager enclosure(s) cc: Applicant DEL/del M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c00088 Environmental Assessment for Mobiles/Fixed Base Station for FCC ID: ATH2425331 Model:RS-5331 to Federal Communications Commission 47 CFR 1.1310 (MPE) Radiofrequency Radiation Exposure Limits Date Of Report: December 3, 2004 On the Behalf of the Applicant: E. F. Johnson Company At the Request of: P.O. 170502 E. F. Johnson Company, 299 Johnson Ave. Waseca, MN 56093-0514 Attention of: (507) 835-6579; FAX: -6666 John Oblak, Director, Radio Products Development E-mail: [email protected] Supervised By: David E. Lee, Compliance Test Manager M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c00088 Table of Contents Rule Description Page 2.1033(c) General Information Required 3 . Standard Test Conditions and Engineering Practices 4 1.1310 Environmental Assessment 5 M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 1 of 7 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0008 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report (Supplemental) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d04c0008 d) Client: E. F. Johnson Company, 299 Johnson Ave. Waseca, MN 56093-0514 e) Identification: 242-5337-211-AAAA FCC ID: ATH2425331 Description: UHF FM Mobile Transceiver f) EUT Condition: Not required unless specified in individual tests. g) Report Date: December 3, 2004 EUT Received: September 20, 2004 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David E. Lee, Compliance Test Manager n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 2 of 7 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0008 Identification of the Equipment Under Test (EUT) Name and Address of Applicant: E. F. Johnson Company 299 Johnson Ave. Waseca, MN 56093-0514 Manufacturer: EF Johnson Company Irving, Texas FCC ID: ATH2425331 Model Number: 242-5337-211-AAAA Description: UHF FM Mobile Transceiver Type of Emission: 16K0F3E, 14K0F3E, 11K0F3E, 8K10F1E, 8J10F1D Frequency Range, MHz: 380 to 470 Power Rating, Watts: 45 Switchable Variable N/A Modulation: AMPS TDMA CDMA X OTHER Antenna: Helical Monopole X Whip Other Note: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 0 dBd) and RF Power set to highest nominal power across all channels. M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 3 of 7 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0008 A2LA “A2LA has accredited M. Flom Associates, Inc. Chandler, AZ for technical competence in the field of Electrical Testing. The accreditation covers the specific tests and types of tests listed on the agreed scope of accreditation. This laboratory meets the requirements of ISO/IEC 17025 – 1999 ‘General Requirements for the Competence of Testing and Calibration Laboratories’ and any additional program requirements in the identified field of testing.” Certificate Number: 2152-01 NIST I am pleased to inform you that your laboratory has been validated by the Chinese Taipei Bureau of Standards, Metrology and Inspection (BSMI) under the Asia Pacific Economic Cooperation Mutual Recognition Agreement (APEC MRA). Your laboratory is now formally designated to act as a Conformity Assessment Body (CAB) under Appendix B, Phase I Procedures, of the APEC MRA between the American Institute in Taiwan (AIT) and the Taipei Economic and Cultural Representative Office (TECRO) in the United States, covering equipment subject to Electro-Magnetic Compatibility (EMC) requirements. The names of all validated and nominated laboratories will be posted on the NIST website at http://ts.nist.gov/mra under the ‘Asia’ category.” BSMI Number: SL2-IN-E-041R M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Page 4 of 7 Chandler, Arizona 85225-7176 FCC ID: ATH2425331 (480) 926-3100 phone, fax (480) 926-3598 MFA p0490011, d04c0008 Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-1992/2001, section 6.1.9, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a differen…

Text truncated - open the document above for the full version.
