AWA-NYNEEDGEBluetooth speaker

Do not use the device if any abnormality occurs. If any smoke or odor becomes apparent, contact your dealer immediately. Do not try to repair the device yourself. Avoid using dropped or damaged appliances. If the device is dropped and the housing is damaged, the internal components may not function normally. Stop use and contact your dealer for shock. To reduce the risk of electric shock, do not touch any connector with wet hands. Never remove the housing of the device. Never lubricate any part of the device. Never place the device on top of any other electrical equipment. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. Notice Modification device, without prior authorization from the manufacturer, may void your warranty and authority to operate the device. FCC compliance statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Radiation Exposure Statement: This equipment complies with FCC radiation exposure requirement. The device can be used in portable exposure condition without RF striction CE statement This product complies with the radio interference requirements of the European Community. Recycling Packaging Observe the local regulations for how to dispose of the packaging materials. Important Safety within an equilateral triangle is intended to alert the user to the presence of un-isolated, dangerous voltage within the inside of the to constitute a risk of electric shock to persons. Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the device. WARNING: Where the mains plug/appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. WARNING: The battery (battery or batteries or battery pack) the like. Read these instructions before operation. Keep these instructions for future reference. Follow all instructions for installation, use and maintenance of the device. This device complies with the IPX5 waterproof standard. Before using the device in the rain or moisty conditions or rinsing the device with fresh water, always securely close the protective cover at the back of the device. Never open the protective cover when the device is still wet after use. Always clean with a soft dry cloth and let it dry in a well-ventilated place away from direct sunlight. and dry cloth. To ensure compatibility, only use accessories recommended by the manufacturer. When the device is suddenly moved from cold to warm surroundings, condensation may form in the housing of the device. Before use, leave the device in the warm environment until the moisture evaporates. Keep the device away from heat sources, such as a radiator, placed on the apparatus. device, the lens may get very hot after some time. This is not a malfunction. Never block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not expose the device to sand or dust, or cover it with items, such as newspapers, table cloths, or curtains. • Do not operate the device in an enclosed cabinet. Leave ventilation. Do not attempt to repair or service the device yourself. Opening or removing the cabinet may expose you to electric shock, and other hazards. If repair is required, contact your dealer and refer EN WEEE NOTICE The Directive on Waste Electrical and Electronic Equipment (WEEE), which entered into force as European law on 13th February 2003, resulted in a major change in the treatment of electrical equipment at end - of - life. WEEE, and in addition, to promote the reuse, recycling and other forms of recovery of such wastes so as to reduce disposal. The WEEE logo on the product or on its box indicating collection for electrical and electronic equipment consists of the crossed -out wheeled bin, as shown below. This product must not be disposed of or dumped with your other household waste. You are liable to dispose of all your electronic or electrical waste equipment for recycling of such hazardous waste. Isolated collection and proper recovery of your electronic and electrical waste equipment at the time of disposal will allow us to help conserving natural resources. Moreover, proper recycling of the electronic and electrical waste equipment will ensure safety of human health and…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 NYNE MULTIMEDIA INC 2015-04-28 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, NYNE MULTIMEDIA INC hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product Description: Bluetooth speaker Model name: NYNE Edge FCC ID: AWA-NYNEEDGE Sincerely, Client’s signature: Client’s name / title: Arman Arami / manager Contact information / address: 3451 LUNAR COURT,OXNARD,California,United States.93030

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 NYNE MULTIMEDIA INC 2015-04-28 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: AWA-NYNEEDGE We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Arman Arami / Manager Contact information / address: 3451 LUNAR COURT,OXNARD,California,United States.93030

FCC Warnings: Embossed 0.5mm up 18mm 45mm Rating Label SIZE: 23mm x 34.2mm Serial number SIZE: 40mm x 10mm

Antenna

FCC ID : AWA-NYNEEDGE Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 D01 General RF Exposure Guidance v05, section 4.3.1 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. GFSK Frequency (MHz) Output Power(dBm) Output Power(mW) Target power (dBm) Calculation Value Threshold Value 2402 3.61 2.30 3 ± 1 0.78 3.0 2440 2.48 1.77 3 ± 1 0.78 3.0 2480 2.43 1.75 3 ± 1 0.79 3.0 ∏/4-DQPSK Frequency (MHz) Output Power(dBm) Output Power(mW) Target power (dBm) Calculation Value Threshold Value 2402 3.33 2.15 4 ± 2 1.23 3.0 2440 4.49 2.81 4 ± 2 1.24 3.0 2480 5.42 3.48 4 ± 2 1.25 3.0 8DPSK Frequency (MHz) Output Power(dBm) Output Power(mW) Target power (dBm) Calculation Value Threshold Value 2402 3.47 2.22 4 ± 2 1.23 3.0 2440 4.69 2.94 4 ± 2 1.24 3.0 2480 5.59 3.62 4 ± 2 1.25 3.0 Threshold at which no SAR required is ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A

REPORT NO. ATE20150498 Page 1 of 93 FCC ID: AWA-NYNEEDGE ACCURATE TECHNOLOGY CO. LTD APPLICATION CERTIFICATION On Behalf of NYNE MULTIMEDIA INC Bluetooth speaker Model No.: NYNE Edge FCC ID: AWA-NYNEEDGE Prepared for : NYNE MULTIMEDIA INC Address : 3451 LUNAR COURT,OXNARD,California,United States.93030 Prepared by : ACCURATE TECHNOLOGY CO. LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20150498 Date of Test : Mar 16-Apr 20,2015 Date of Report : Apr 20,2015 REPORT NO. ATE20150498 Page 2 of 93 FCC ID: AWA-NYNEEDGE ACCURATE TECHNOLOGY CO. LTD TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 5 1.1. Description of Device (EUT)....................................................................................................................5 1.2. Description of Test Facility ......................................................................................................................6 1.3. Measurement Uncertainty.........................................................................................................................6 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 7 3. OPERATION OF EUT DURING TESTING ................................................................................. 8 3.1. Operating Mode ........................................................................................................................................8 3.2. Configuration and peripherals ..................................................................................................................8 4. TEST PROCEDURES AND RESULTS ......................................................................................... 9 5. 20DB BANDWIDTH TEST............................................................................................................10 5.1. Block Diagram of Test Setup..................................................................................................................10 5.2. The Requirement For Section 15.247(a)(1) ............................................................................................10 5.3. EUT Configuration on Measurement .....................................................................................................10 5.4. Operating Condition of EUT ..................................................................................................................10 5.5. Test Procedure ........................................................................................................................................11 5.6. Test Result ..............................................................................................................................................11 6. CARRIER FREQUENCY SEPARATION TEST........................................................................ 12 6.1. Block Diagram of Test Setup..................................................................................................................17 6.2. The Requirement For Section 15.247(a)(1) ............................................................................................17 6.3. EUT Configuration on Measurement .....................................................................................................17 6.4. Operating Condition of EUT ..................................................................................................................17 6.5. Test Procedure ........................................................................................................................................18 6.6. Test Result ..............................................................................................................................................18 7. NUMBER OF HOPPING FREQUENCY TEST ......................................................................... 24 7.1. Block Diagram of Test Setup..................................................................................................................24 7.2. The Requirement For Section 15.247(a)(1)(iii) ......................................................................................24 7.3. EUT Configuration on Measurement .....................................................................................................24 7.4. Operating Condition of EUT ..................................................................................................................24 7.5. Test Procedure ........................................................................................................................................25 7.6. Test Result ..............................................................................................................................................25 8. DWELL TIME TEST ..................................................................................................................... 27 8.1. Block Diagram of Test Setup..................................................................................................................27 8.2. The Requirement For Section 15.247(a)(1)(iii) ......................................................................................27 8.3. EUT Configuration on Measurement .....................................................................................................27 8.4. Operating Condition of EUT ..................................................................................................................27 8.5. Test Procedure ........................................................................................................................................28 8.6. Test Result .......................................…

Text truncated - open the document above for the full version.
