FCC ID : AWA-NYNEROCK 1. RF EXPOSURE 1.1. The Requirement System operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See Section 15.247(b)(4) and Section 1.1307(b)(1) 1.2. Limit For Maximum Permissible Exposure (MPE) Limits for General Population/ Uncontrolled Exposure F = frequency in MHz, * Plane-wave equivalent power density 1.3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) ( 2 mW/cm) Averaging Time 2 E, 2 H or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the antenna is 2dBi, the RF power density can be obtained. 1.4. TEST RESULTS Maximum measured transmitter power For BT 4.1 LE GFSK mode Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Target power (dBm) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2402 20.00 -1.46 0.714 -1 ±1 1.585 1.000 0.0003 Pass 2440 20.00 -0.47 0.897 0 ±1 1.585 1.000 0.0005 Pass 2480 20.00 -2.14 0.611 -2 ±1 1.585 1.000 0.0003 Pass For BT 3.0+EDR GFSK mode Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Target power (dBm) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2402 20.00 2.22 1.667 2 ±1 1.585 1.000 0.0006 Pass 2441 20.00 2.85 1.928 2 ±1 1.585 1.000 0.0006 Pass 2480 20.00 1.71 1.483 2 ±1 1.585 1.000 0.0006 Pass ∏/4-DQPSK Mode Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Target power (dBm) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2402 20.00 0.32 1.076 0±1 1.585 1.000 0.0004 Pass 2441 20.00 1.72 1.486 1±1 1.585 1.000 0.0005 Pass 2480 20.00 -0.20 0.955 0±1 1.585 1.000 0.0004 Pass 8DPSK Mode Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Target power (dBm) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2402 20.00 0.70 1.175 0±1 1.585 1.000 0.0004 Pass 2441 20.00 1.42 1.387 1±1 1.585 1.000 0.0005 Pass 2480 20.00 0.13 1.030 0±1 1.585 1.000 0.0004 Pass The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure. 1.5. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm(8 inches) during normal operation. Proposed RF exposure safety information to include in User’s Manual.

Report No.: ATE20151956 Page 1 of 54 FCC ID: AWA-NYNEROCK ACCURATE TECHNOLOGY CO., LTD APPLICATION CERTIFICATION FCC Part 15C On Behalf of NYNE MULTIMEDIA INC. NYNE ROCK Model No.: NYNE ROCK FCC ID: AWA-NYNEROCK Prepared for : NYNE MULTIMEDIA INC. Address : 3451 LUNAR COURT, OXNARD, California, United States. 93030 Prepared by : ACCURATE TECHNOLOGY CO., LTD Address : F1, Bldg. A, Chan Yuan New Material Port, Keyuan Rd. Science & Industry Park, Nan Shan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report No. : ATE20151956 Date of Test : Sep 02-Oct 19, 2015 Date of Report : Oct 20, 2015 Report No.: ATE20151956 Page 2 of 54 FCC ID: AWA-NYNEROCK ACCURATE TECHNOLOGY CO., LTD TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 5 1.1. Description of Device (EUT) .................................................................................................................... 5 1.2. Carrier Frequency of Channels ................................................................................................................. 6 1.3. Special Accessory and Auxiliary Equipment ........................................................................................... 6 1.4. Description of Test Facility ...................................................................................................................... 7 1.5. Measurement Uncertainty ......................................................................................................................... 7 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 8 3. OPERATION OF EUT DURING TESTING ................................................................................. 9 3.1. Operating Mode ........................................................................................................................................ 9 3.2. Configuration and peripherals .................................................................................................................. 9 4. TEST PROCEDURES AND RESULTS ....................................................................................... 10 5. POWER LINE CONDUCTED MEASUREMENT ..................................................................... 11 5.1. Block Diagram of Test Setup .................................................................................................................. 11 5.2. Power Line Conducted Emission Measurement Limits .......................................................................... 11 5.3. Configuration of EUT on Measurement ................................................................................................. 11 5.4. Operating Condition of EUT .................................................................................................................. 11 5.5. Test Procedure ........................................................................................................................................ 12 5.6. Power Line Conducted Emission Measurement Results ........................................................................ 12 6. 6DB BANDWIDTH MEASUREMENT ........................................................................................ 19 6.1. Block Diagram of Test Setup .................................................................................................................. 19 6.2. The Requirement For Section 15.247(a)(2) ............................................................................................ 19 6.3. EUT Configuration on Measurement ..................................................................................................... 19 6.4. Operating Condition of EUT .................................................................................................................. 19 6.5. Test Procedure ........................................................................................................................................ 19 6.6. Test Result .............................................................................................................................................. 20 7. MAXIMUM PEAK OUTPUT POWER ....................................................................................... 22 7.1. Block Diagram of Test Setup .................................................................................................................. 22 7.2. The Requirement For Section 15.247(b)(3) ............................................................................................ 22 7.3. EUT Configuration on Measurement ..................................................................................................... 22 7.4. Operating Condition of EUT .................................................................................................................. 22 7.5. Test Procedure ........................................................................................................................................ 22 7.6. Test Result .............................................................................................................................................. 23 8. POWER SPECTRAL DENSITY MEASUREMENT .................................................................. 25 8.1. Block Diagram of Test Setup .................................................................................................................. 25 8.2. The Requirement For Section 15.247(e) ................................................................................................. 25 8.3. EUT Configuration on Measurement ..................................................................................................... 25 8.4. Operating Condition of EUT ........................................................................…
