Operational Buttons Note) There may be no button and different position in each models. Disc in Slot To Information Scree n To Audio Select Screen HOME Button Audio Power Off Button Eject Butt on Capacitive Touch Panel Switch Volume Up Button Volume Down Button MENU Button Back Button Di mm er Button To HondaLink Screen HOME SCREEN To Aha Screen To Navigation Screen To Phone Screen To Sett ing Screen To SmartPhone Conn ect Screen To App List Screen (Previous page of HOME SCREEN) Audio Select Touch Audio button. Touch SOURCE button. Touch the button you want to play. For example, USB play CD play Bluetooth A2DP play Ex.1: CD play screenEx.2: USB Audio play screen Bluet ooth (Wi-Fi) Settings Touch Setting button. Touch Bluetooth/Wi-Fi button. Touch Bluetooth Device List button. When you want to connect Wi-Fi, touch Wi-Fi Network List button. When Bluetooth Device List button. is gray, park your car. When Status is Off, touch and set to On. Touch Add Bluetooth Device button. Touch Continue button. Touch your device. You can find parring is sucsess.
PH-3709 External Photos Front View Rear View Top View Bottom View Left side View Right side View
QY-5089 External Photos Front View Rear View Top View Bottom View Left side View Right side View
QY-5099 External Photos Front View Rear View Top View Bottom View Left side View Right side View
Label position
Internal Photos (Module and Antenna position Photos) LCD PCB ASSY Component - F2 View LCD PCB ASSY - F1 View Wi-Fi and Bluetooth ComboModule Bluetooth Antenna mount position Bluetooth RF Antenna Connector Wi-Fi RF antenna Connector Wi-Fi Antenna mount position
UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Applicant: Clarion Co., Ltd. Type of Equipment: Navigation Unit Model No. : QY-5092 Similar Model No. : PH-3709, QY-5099, QY-5089 FCC ID: AX2QY5099 Clarion Co., Ltd. declares that Model : QY-5092 complies with FCC radiation exposure requirement specified in the FCC Rules 2.1091. RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided with the βQY-5092β as calculated from FCC Part 1, Β§1.1310, TABLE 1 (B) Limits for General Population / Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0mW/cm^2 uncontrolled exposure limit. The Friis formula used was: S = ( (P1 + P2 ) * G) / (4* Ο * r 2 ) Where P1 = 22.08 mW (Maximum average output power ) *1) P2 = 1.44 mW (Maximum average output power) *2) G = 0.77 Numerical Antenna gain; equal to -1.11dBi r =20.0 cm For: QY-5092S =0.00362mW/cm 2 Even taking into account the tolerance, this device can be satisfied with the limits. *1) Wireless LAN value *2) Bluetooth value This calculation was made to show that the EUT complies with the limit in simultaneous transmitting No. : 10399701S-F/H-R1 RF Exposure / SAR Statement (Reference)
UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Applicant: Clarion Co., Ltd. Type of Equipment: Navigation Unit Model No. : QY-5092 Similar Model: PH-3709, QY-5099, QY-5089 FCC ID: AX2QY5099 Clarion Co., Ltd. declares that Model : QY-5092 complies with FCC radiation exposure requirement specified in the FCC Rules 2.1091. RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided with the βQY-5092β as calculated from FCC Part 1, Β§1.1310, TABLE 1 (B) Limits for General Population / Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0mW/cm^2 uncontrolled exposure limit. The Friis formula used was: S = (P * G) / (4* Ο * r 2 ) Where P = 22.08 mW (Maximum average output power) G = 0.77 Numerical Antenna gain; equal to-1.11 dBi r =20.0 cm For: QY-5092S = 0.00340mW/cm 2 Even taking into account the tolerance, this device can be satisfied with the limits. No. : 10399701S-H-R1 RF Exposure / SAR Statement
UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone: +81 463 50 6400 Facsimile: +81 463 50 6401 RADIO TEST REPORT cover sheet Applicant : Clarion Co., Ltd. Type of Equipment : Car Audio Model No. : PH-3709, QY-5099, QY-5089 FCC ID : AX2QY5099 The difference between 4 models (PH-3709, QY-5099, QY-5089 and QY-5092) doesnβt affect the radio characteristics. The electrical characteristics among those models are identical to each other. Therefore, we use test report No. 10399701S-F-R1 and 10399701S-H-R1. Date May 28, 2015 Toyokazu Imamura Leader Consumer Technology Division Test report No. : 10399701S-H-R1 Page : 2 of 52 Issued date : January 21, 2015 Revised date : May 28, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 REVISION HISTORY Original Test Report No.: 10399701S-H Revision Test report No. Date Page revised Contents - (Original) 10399701S-H November 4, 2014 - - 1 10399701S-H-R1 January 21, 2015 - (Full-revision) Update 2 10399701S-H-R1 May 28, 2015 5, 6 Correction and Addition of description Test report No. : 10399701S-H-R1 Page : 3 of 52 Issued date : January 21, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Contents Page SECTION 1: Customer information ........................................................................................ 4 SECTION 2: Equipment under test (E.U.T.) .......................................................................... 4 SECTION 3: Test specification, procedures & results ........................................................... 6 SECTION 4: Operation of E.U.T. during testing .................................................................... 8 SECTION 5: 6dB bandwidth & Occupied bandwidth (99%) .............................................. 11 SECTION 6: Maximum peak output power .......................................................................... 11 SECTION 7: Out of band emissions (Antenna port conducted) ......................................... 11 SECTION 8: Peak power density ........................................................................................... 11 SECTION 9: Radiated emission ............................................................................................. 12 Contents of APPENDIXES ....................................................................................................... 14 APPENDIX 1: Data of Radio tests .......................................................................................... 15 APPENDIX 2: Test instruments ............................................................................................. 51 APPENDIX 3: Photographs of test setup ............................................................................... 52 Test report No. : 10399701S-H-R1 Page : 4 of 52 Issued date : January 21, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 SECTION 1: Customer information Company Name : Clarion Co., Ltd. Address : 7-2 Shintoshin, Chuo-ku, Saitama-shi, Saitama, 330-0081 Japan Telephone Number : +81-48-601-3602 Facsimile Number : +81-48-601-3802 Contact Person : Matsuhiro Hirano SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Navigation Unit Model Number : QY-5092 Serial Number : Refer to Section 4.2 Rating : DC10-16V Country of Mass-production : China Condition of EUT : Engineering prototype (Not for Sale: This sample is equivalent to mass-produced items.) Receipt Date of Sample : September 8, 2014 Modification of EUT : No modification by the test lab. 2.2 Product description Model: QY-5092 (referred to as the EUT in this report) is a Navigation Unit. Clock frequency(ies) in the system : 5.6448MHz, 6.144MHz, 8.192MHz, 12.2896MHz, 12.8MHz, 24.576MHz, 26MHz, 27MHz, 28.224MHz, 33.231MHz, 41.6MHz, 48MHz Test report No. : 10399701S-H-R1 Page : 5 of 52 Issued date : January 21, 2015 Revised date : May 28, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 <Bluetooth part> Equipment type : Transceiver Frequency of operation : 2402-2480MHz Bandwidth & channel spacing : 79MHz & 1MHz Type of modulation : GFSK, Ο/4DQPSK, 8DPSK Antenna type : Metal Sheet Antenna gain : -1.11dBi Antenna connector type : U.FL Operation temperature range : -30 to +70 deg.C. ITU code : F1D, G1D <Wireless LAN part> Equipment type : Transceiver Frequency of operation : 2412-2462MHz Bandwidth & channel spacing : 20MHz & 5MHz Type of modulation : CCK, OFDM Antenna type : Metal Sheet Antenna gain : -1.11dBi Antenna connector type : U.FL Operation temperature range : -30 to +70 deg.C. ITU code : G1D, D1D * For Bluetooth part, refer to the test report: 10399701S-F-R1. FCC 15.31 (e) The EUT provides stable voltage (DC3.3V) constantly to the wireless transmitter regardless of input voltage. Instead of a new battery, DC power supply was used for the test. That does not affect the test result, therefore the EUT complies with the requirement. FCC 15.203 The equipment and its antenna comply with the requirement since the antenna is built in the equipment and it cannot be replaced by end users. Test report No. : 10399701S-H-R1 Page : 6 of 52 Issued date : January 21, 2015 Revised date : May 28, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 SECTION 3: Test specification, procedures & results 3.1 Test specification Test specification : FCC Part 15 Subpart C: 2014, final revised on December 23, 201β¦
