moves you■connects you Clarion Co., Ltd. ■Headquarters & Technology Center 7-2 Shintoshin Chuo-Ku, Saitama-Shi, Saitama, 330-0081, Japan TEL: +81-48-601-3700 ■Headquarters-Annex Office Land Axis Tower 30F, 11-2, Shintoshin, Chuo- Ku, Saitama-Shi, Saitama, 330-6030, Japan TEL: +81-48-601-3700 Letter of Authorization Date: August 7, 2015 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan FCC ID : AX2QY5153 Applicant : Clarion Co.,Ltd. To whom it may concern: Please be advised we authorize Yoshihisa Maeda of Consumer Technology Division, UL Japan, Inc. to act on our behalf, until otherwise notified, for applications submitted for Federal Communication Commission Radio equipment applications submitted to UL Japan, Inc. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. The application for the subject equipment has not been submitted to another TCB for certification. Thank you for your attention to this matter. Sincerely, Masahiko Shibata Clarion Co.,Ltd.
moves you■connects you Clarion Co., Ltd. ■Headquarters & Technology Center 7-2 Shintoshin Chuo-Ku, Saitama-Shi, Saitama, 330-0081, Japan TEL: +81-48-601-3700 ■Headquarters-Annex Office Land Axis Tower 30F, 11-2, Shintoshin, Chuo- Ku, Saitama-Shi, Saitama, 330-6030, Japan TEL: +81-48-601-3700 Declaration about Application Model and Tested Model Date: August 7, 2015 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan FCC ID : AX2QY5153 Applicant : Clarion Co.,Ltd. To Whom It May Concern: This application models, QY-5153 and PH-3805, are essentially the same device with the tested model, QY-5092. For the differences among these 3 models, please refer to “Theory of Operation-Differences”. These differences cause no influence to radio specification. There is no degradation of EMC characteristic. We consider them electrically identical. Sincerely, ________________ Masahiko Shibata Clarion Co Ltd
moves you■connects you Clarion Co., Ltd. ■Headquarters & Technology Center 7-2 Shintoshin Chuo-Ku, Saitama-Shi, Saitama, 330-0081, Japan TEL: +81-48-601-3700 ■Headquarters-Annex Office Land Axis Tower 30F, 11-2, Shintoshin, Chuo- Ku, Saitama-Shi, Saitama, 330-6030, Japan TEL: +81-48-601-3700 Request for Confidentiality Date: August 7, 2015 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan FCC ID : AX2QY5153 Applicant : Clarion Co.,Ltd. To whom it may concern: Please be advised that the following information is to be held confidential on behalf of us, referring to the FCC rules 0.457 and 0.459: Block Diagram Theory of Operation Schematics The application contains technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, Masahiko Shibata Clarion Co.,Ltd.
moves you■connects you Clarion Co., Ltd. ■Headquarters & Technology Center 7-2 Shintoshin Chuo-Ku, Saitama-Shi, Saitama, 330-0081, Japan TEL: +81-48-601-3700 ■Headquarters-Annex Office Land Axis Tower 30F, 11-2, Shintoshin, Chuo- Ku, Saitama-Shi, Saitama, 330-6030, Japan TEL: +81-48-601-3700 Request for Short-Term Confidentiality Date: August 7, 2015 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan FCC ID : AX2QY5153 Applicant : Clarion Co.,Ltd. To whom it may concern: Please be advised that the following information is to be held in confidence for 180 days from the date of the Grant of Equipment Authorization and behalf of us, referring to the FCC rules 0.457 and 0.459: External Photos Internal Photos Test Setup Photos User Manual The application contains technical information, which we deem to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, ____________________________________ Masahiko Shibata Clarion Co.,Ltd.
PH-3805 External Photos Front View Rear View Top View Bottom View Left side View Right side View
QY-5153 External Photos Front View Rear View Top View Bottom View Left side View Right side View
Inside of Product Module and Antenna position Photos LCD PCB ASSY Component - F2 View LCD PCB ASSY Component - F2 View Bluetooth Antenna mount position Wi-Fi Antenna mount position Bluetooth RF Antenna Connector Wi-Fi RF antenna Connector Wi-Fi and Bluetooth Combo Module Module and Antenna position Photos Outside view of Module Top View Bottom View Inside view of Module
UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Applicant: Clarion Co., Ltd. Type of Equipment : Display Audio Unit, Navigation Unit M odel No. : PH-3805, QY-5153 FCC ID: AX2QY5153 Clarion Co., Ltd. declares that M odel : PH-3805, QY-5153 complies with FCC radiation exposure requirement specified in the FCC Rules 2.1091. * The results for QY-5092 is used, since QY-5092, PH-3805 and QY-5153 have the identical RF output power. RF Exposure Calculations: The following inform ation provides the m inim um separation distance for the highest gain antenna provided with the “PH-3805, QY-5153“ as calculated from FCC Part 1, §1.1310, TABLE 1 (B) Limits for General Population / Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system , considering m axim um power and antenna gain, and considering a 1.0m W /cm ^2 uncontrolled exposure lim it. The Friis form ula used was: S = ( (P1 + P2 ) * G ) / (4* π * r 2 ) Where P1 = 22.08 mW (M aximum average output power ) *1) P2 = 1.44 mW (M aximum average output power) *2) G = 0.77 Numerical Antenna gain; equal to -1.11 dBi r =20.0 cm For: PH-3805, QY-5153S = 0.00362 mW/cm 2 Even taking into account the tolerance, this device can be satisfied with the limits. *1) W ireless LAN value *2) Bluetooth value This calculation was m ade to show that the EUT com plies with the lim it in sim ultaneous transm itting of W ireless LAN and Bluetooth. No. : 10399701S-F-R1/H-R1 RF Exposure / SAR Statement (Reference)
UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Applicant: Clarion Co., Ltd. Type of Equipment: Display Audio Unit, Navigation Unit M odel No. : PH-3805, QY-5153 FCC ID: AX2QY5153 Clarion Co., Ltd. declares that M odel : PH-3805, QY-5153 complies with FC C radiation exposure requirement specified in the FC C R ules 2.1091. * The results for QY-5092 is used, since QY-5092, PH-3805 and QY-5153 have the identical RF output power. RF Exposure Calculations: The following inform ation provides the m inim um separation distance for the highest gain antenna provided with the “PH-3805, QY-5153“ as calculated from FCC Part 1, §1.1310, TABLE 1 (B) Limits for General Population / Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system , considering maximum power and antenna gain, and considering a 1.0mW/cm^2 uncontrolled exposure limit. The Friis formula used was: S = (P * G ) / (4* π * r 2 ) Where P = 22.08 mW (M aximum average output power) G = 0.77 Numerical Antenna gain; equal to -1.11 dBi r =20.0 cm For: PH-3805, QY-5153S = 0.00340 mW/cm 2 Even taking into account the tolerance, this device can be satisfied with the lim its. No. : 10399701S-H-R1 RF Exposure / SAR Statement
UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone: +81 463 50 6400 Facsimile: +81 463 50 6401 RADIO TEST REPORT cover sheet Applicant : Clarion Co., Ltd. Type of Equipment : Display Audio Unit, Navigation Unit Model No. : PH-3805, QY-5153 FCC ID : AX2QY5153 The difference between 3 models (PH-3805, QY-5153 and QY-5092) doesn’t affect the radio characteristics. The electrical characteristics among those models are identical to each other. Therefore, we use test report No. 10399701S-F-R1 and 10399701S-H-R1. All the revisions made after testing date do not affect the test specification applied to the EUT. The EUT complies with FCC Part 15 Subpart C: 2015. Date August 5, 2015 Toyokazu Imamura Leader Consumer Technology Division Test report No. : 10399701S-H-R1 Page : 2 of 52 Issued date : January 21, 2015 Revised date : May 28, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 REVISION HISTORY Original Test Report No.: 10399701S-H Revision Test report No. Date Page revised Contents - (Original) 10399701S-H November 4, 2014 - - 1 10399701S-H-R1 January 21, 2015 - (Full-revision) Update 2 10399701S-H-R1 May 28, 2015 5, 6 Correction and Addition of description Test report No. : 10399701S-H-R1 Page : 3 of 52 Issued date : January 21, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Contents Page SECTION 1: Customer information ........................................................................................ 4 SECTION 2: Equipment under test (E.U.T.) .......................................................................... 4 SECTION 3: Test specification, procedures & results ........................................................... 6 SECTION 4: Operation of E.U.T. during testing .................................................................... 8 SECTION 5: 6dB bandwidth & Occupied bandwidth (99%) .............................................. 11 SECTION 6: Maximum peak output power .......................................................................... 11 SECTION 7: Out of band emissions (Antenna port conducted) ......................................... 11 SECTION 8: Peak power density ........................................................................................... 11 SECTION 9: Radiated emission ............................................................................................. 12 Contents of APPENDIXES ....................................................................................................... 14 APPENDIX 1: Data of Radio tests .......................................................................................... 15 APPENDIX 2: Test instruments ............................................................................................. 51 APPENDIX 3: Photographs of test setup ............................................................................... 52 Test report No. : 10399701S-H-R1 Page : 4 of 52 Issued date : January 21, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 SECTION 1: Customer information Company Name : Clarion Co., Ltd. Address : 7-2 Shintoshin, Chuo-ku, Saitama-shi, Saitama, 330-0081 Japan Telephone Number : +81-48-601-3602 Facsimile Number : +81-48-601-3802 Contact Person : Matsuhiro Hirano SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Navigation Unit Model Number : QY-5092 Serial Number : Refer to Section 4.2 Rating : DC10-16V Country of Mass-production : China Condition of EUT : Engineering prototype (Not for Sale: This sample is equivalent to mass-produced items.) Receipt Date of Sample : September 8, 2014 Modification of EUT : No modification by the test lab. 2.2 Product description Model: QY-5092 (referred to as the EUT in this report) is a Navigation Unit. Clock frequency(ies) in the system : 5.6448MHz, 6.144MHz, 8.192MHz, 12.2896MHz, 12.8MHz, 24.576MHz, 26MHz, 27MHz, 28.224MHz, 33.231MHz, 41.6MHz, 48MHz Test report No. : 10399701S-H-R1 Page : 5 of 52 Issued date : January 21, 2015 Revised date : May 28, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 <Bluetooth part> Equipment type : Transceiver Frequency of operation : 2402-2480MHz Bandwidth & channel spacing : 79MHz & 1MHz Type of modulation : GFSK, π/4DQPSK, 8DPSK Antenna type : Metal Sheet Antenna gain : -1.11dBi Antenna connector type : U.FL Operation temperature range : -30 to +70 deg.C. ITU code : F1D, G1D <Wireless LAN part> Equipment type : Transceiver Frequency of operation : 2412-2462MHz Bandwidth & channel spacing : 20MHz & 5MHz Type of modulation : CCK, OFDM Antenna type : Metal Sheet Antenna gain : -1.11dBi Antenna connector type : U.FL Operation temperature range : -30 to +70 deg.C. ITU code : G1D, D1D * For Bluetooth part, refer to the test report: 10399701S-F-R1. FCC 15.31 (e) The EUT provides stable voltage (DC3.3V) constantly to the wireless transmitter regardless of input voltage. Instead of a new battery, DC power supply was used for the test. That does not affect the test result, therefore the EUT complies with the requirement. FCC 15.203 The equipment and its antenna comply with the requirement since the antenna is built in the equipment and it cannot be replaced by end users. Test report No. : 10399701S-H-R1 Page : 6 of 52 Issued date : January 21, 2015 Revised date : May 28, 2015 FCC ID : AX2QY5092 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 640…
Text truncated - open the document above for the full version.
UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 APPENDIX 3: Photographs of test setup Radiated emission Front view Rear view (below 1GHz) Rear view (above 1GHz) END OF REPORT Test Report No 10399701S-H-R1 52 of 52
