AZ489FT3814Portable 2-Way Radio

English Product Safety and RF Energy Exposure Booklet for Portable Two-Way Radios The information provided in this document supersedes the general safety information contained in user guides published prior to February 2002. BEFORE USING THIS RADIO, READ THIS BOOKLET WHICH CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL INFORMATION AND OPERATIONAL INSTRUCTIONS FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND INTERNATIONAL STANDARDS. ALSO READ THE OPERATIONAL INSTRUCTIONS FOR SAFE USAGE. FOR RADIOS THAT HAVE BEEN APPROVED AS INTRINSICALLY SAFE, READ THE INSTRUCTIONS AND INFORMATION ON INTRINSIC SAFETY ON PAGE 10 OF THIS BOOKLET. ! C a u t i o n © 2006 by Motorola, Inc. 1301 E. Algonquin Rd., Schaumburg, IL 60196-1078, U.S.A. 11/06 68P81095C98 68P81095C98-D 95C98-D_SafetyBooklet-Portable_Eng.fm Page 1 Wednesday, November 1, 2006 5:24 PM 2 English RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use NOTICE: This radio is intended for use in occupational/controlled conditions where users have full knowledge of their exposure and can exercise control over their exposure to meet the occupational limits in FCC and International standards. This radio device is NOT authorized for general population consumer use. This two-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. It uses radio frequency (RF) energy or radio waves to send and receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to, sunlight and x-rays. RF energy, however, should not be confused with these other forms of electromagnetic energy, which when used improperly, can cause biological damage. Very high levels of x-rays, for example, can damage tissues and genetic material. Experts in science, engineering, medicine, health, and industry work with organizations to develop standards for safe exposure to RF energy. These standards provide recommended levels of RF exposure for both workers and the general public. These recommended RF exposure levels include substantial margins of protection. All Motorola two-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In addition, manufacturers also recommend specific operating instructions to users of two-way radios. These instructions are important because they inform users about RF energy exposure and provide simple procedures on how to control it. 95C98-D_SafetyBooklet-Portable_Eng.fm Page 2 Wednesday, November 1, 2006 5:24 PM 3 English Please refer to the following websites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits: http://www.fcc.gov/oet/rfsafety/rf-faqs.html http://www.osha.gov/SLTC/radiofrequencyradiation/index.html Federal Communication Commission (FCC) Regulations The FCC rules require manufacturers to comply with the FCC RF energy exposure limits for portable two-way radios before they can be marketed in the U.S. When two-way radios are used as a consequence of employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure awareness can be facilitated by the use of a product label directing users to specific user awareness information. Your Motorola two-way radio has a RF Exposure Product Label. Also, your Motorola user manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Compliance with RF Exposure Standards Your Motorola two-way radio is designed and tested to comply with a number of national and International standards and guidelines (listed below) for human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/controlled RF exposure environments at operating duty factors of up to 50% talk-50% listen and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with these exposure guidelines, your radio generates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. NOTE:The approved batteries, supplied with this radio, are rated for a 5-5-90 duty factor (5% talk-5% listen-90% standby) even though this radio complies with FCC occupational exposure limits and may operate at duty factors of up to 50% talk. 95C98-D_SafetyBooklet-Portable_Eng.fm Page 3 Wednesday, November 1, 2006 5:24 PM 4 English Your Motorola two-way radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation – Human Exposure) Standard, 2003 • ANATEL ANNEX to Resolution No. 303 of July 2, 2002 "Regulation of limitation of exposure to electrical, magnetic and electromagnetic fields in the radio frequency range between 9 KHz and 300 GHz" and "Attachment to resolution # 303 from July 2, 2002" RF Exposure Compliance and Control Guidelines and Operating Instructions To control your exposure and ensure compliance with the occupational/controlled environment exposure limits, always adhere to the following procedure…

Text truncated - open the document above for the full version.

m ASTRO ® XTS ™ 4000 Digital Portable Radio User Guide 6871618L01-A XTS4000.book.fm Page i Monday, October 2, 2006 5:29 PM This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below. DECLARATION OF CONFORMITY Per FCC CFR 47 Part 2 Section 2.1077(a) Responsible Party Name: Motorola, Inc. Address: 8000 West Sunrise Boulevard Plantation, FL 33322 USA Phone Number: 1-888-567-7347 Hereby declares that the product: Model Name: XTS 4000 conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a) Class B Digital Device As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. this device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. Note:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. XTS4000.book.fm Page ii Monday, October 2, 2006 5:29 PM Product Safety and RF Exposure Compliance ATTENTION! This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 68P81095C98) to ensure compliance with RF energy exposure limits. Computer Software Copyrights The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs, including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product. Documentation Copyrights No duplication or distribution of this document or any portion thereof shall take place without the express written permission of Motorola. No part of this manual may be reproduced, distributed, or transmitted in any form or by any means, electronic or mechanical, for any purpose without the express written permission of Motorola. Disclaimer The information in this document is carefully examined, and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies. Furthermore, Motorola reserves the right to make changes to any products herein to improve readability, function, or design. Motorola does not assume any liability arising out of the applications or use of any product or circuit described herein; nor does it cover any license under its patent rights, nor the rights of others. MOTOROLA, the Stylized M Logo and ASTRO are registered in the U.S. Patent & Trademark Office. All other product or service names are the property of their respective owners. P25 radios contain technology patented by Digital Voice Systems, Inc. © Motorola, Inc. 2006. All Rights Reserved. Printed in the U.S.A. 7/06. Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio. !  XTS4000.book.fm Page iii Monday, October 2, 2006 5:29 PM Notes XTS4000.book.fm Page iv Monday, October 2, 2006 5:29 PM ASTRO XTS 4000 v General Radio Operation . . . . . . . . . . . . . . . . . . . . . . . 1 Notations Used in This Manual ......................................................... 1 Your XTS 4000 Radio ....................................................................... 2 Physical Features of the XTS 4000 Radio ........................................ 3 Programmable Controls .................................................................... 3 Display .............................................................................................. 4 Keypad ............................................................................................ 10 Alert Tones ...................................................................................... 12 Standard Accessories ..................................................................... 15 Radio On and Off ............................................................................ 17 Set the Volume ................................................................................ 17 Zones and Channels ...…

Text truncated - open the document above for the full version.

44 Common Radio Features Selective Calls (ASTRO Conventional Only) A Selective Call is intended to provide privacy and to eliminate the annoyance of having to listen to conversations that are of no interest to you. It is used to “set up” the call with the target unit, and to allow announcements type messages to an individual or group of units. Quick Access (One-Touch) If your radio is preprogrammed for Quick Access (One-Touch) Selective Call, you can make a call to one preprogrammed ID number without having to select the feature or an ID number. Answer a Selective Call Initiate a Selective Call 1Press the Quick Access Selective Call button to start the Selective Call. 2When you are connected, you see the called ID. Press and hold the PTT button to talk; release the PTT to listen. 3Press to hang up and return to the home display. 1When a Selective Call is received, you hear two alert tones, the call received symbol ( ) flashes, and Call Received is displayed. 2The display will remain active for two seconds, and then the speaker will unmute. 3Press and hold the PTT button to talk; release it to listen. 4Press to hang up and return to the home display. 1Press to find Call. 2Press directly below Call. You see the last transmitted or received ID number. XTS4000.book.fm Page 44 Monday, October 2, 2006 5:29 PM ASTRO XTS 4000 45 Common Radio Features Select an ID Number Use the Menu Use the Keypad Make a Selective Call 3Go to “Select an ID Number”, below. OR Go to “Make a Selective Call” on page 45. 1Press to find the ID number you want. Note:Press LNum to go to the last number dialed. 2Go to “Make a Selective Call” on page 45. 1Use the keypad to enter the ID number you want. Note:Press LNum to go to the last number dialed. 2Go to “Make a Selective Call”, below. 1Press the PTT button to start the Selective Call. 2When you are connected, you see the called ID. Press and hold the PTT button to talk; release the PTT to listen. 3When your call is completed, press to hang up. The radio returns to the home display. XTS4000.book.fm Page 45 Monday, October 2, 2006 5:29 PM 46 Common Radio Features Call Alert Paging Call Alert allows your radio to work like a pager. Even if other users are away from their radios, or if they are unable to hear their radios, you can still send them a Call Alert page. You can also verify if a radio is active on the system. In conventional operation, you can send either an individual Call Alert page or a group Call Alert page. ID numbers for individuals are preceded by Id: and for groups by Gr:. Quick Access (One-Touch) If your radio is preprogrammed for Quick Access (One-Touch) Call Alert Paging, you can send a page to one preprogrammed ID number without having to select the feature or an ID number. Answer a Call Alert Page 1Press the Quick Access Call Alert button to send the Call Alert. You see Please Wait. 2When you are connected, you see the home display. Press and hold the PTT button to talk; release the PTT to listen. OR If an individual Call Alert page is not acknowledged, you see No Acknowledge. If a group Call Alert page is not acknowledged, you do not see No Acknowledge. The radio will merely exit Call Alert and return to normal operation. 3Press or the Call Response button to hang up and return to the home display. 1When a Call Alert page is received, you hear four repeating alert tones, the call received symbol ( ) flashes, and Page Received is displayed. 2Press and hold the PTT button to talk; release it to listen. XTS4000.book.fm Page 46 Monday, October 2, 2006 5:29 PM ASTRO XTS 4000 47 Common Radio Features Initiate a Call Alert Page Select an ID Number Use the Menu 1Press to find Page. 2Press directly below Page. If an individual Call Alert page was last transmitted or received, you see the individual ID number. If a group Call Alert page was last transmitted, you see blanks in the individual ID scratchpad and the group ID transmitted to in the group ID scratchpad (accessed by pressing once). If a group Call Alert page was last received, you see the ID of the sending radio in the individual ID scratchpad and the group ID transmitted to in the group ID scratchpad. 3Go to “Select an ID Number” on page 47. OR Go to “Send a Call Alert Page” on page 48. 1Press to find the ID number you want. Note:Press LNum to go to the last number dialed. 2Go to “Send a Call Alert Page”, below. Page Id: 0000002 ListList Page TETRA Id: 0000001 LNumLNum XTS4000.book.fm Page 47 Monday, October 2, 2006 5:29 PM 48 Common Radio Features Use the Keypad Send a Call Alert Page 1Use the keypad to enter the ID number you want. Note:Press LNum to go to the last number dialed. 2Go to “Send a Call Alert Page”, below. 1Press the PTT button to send the Call Alert to the displayed number. You see Please Wait. 2When you are connected, you see the home display. Press and hold the PTT button to talk; release the PTT to listen. OR If an individual Call Alert page is not acknowledged, you see No Acknowledge. If a group Call Alert page is not acknowledged, you do not see No Acknowledge. The radio will merely exit Call Alert and return to normal operation. 3Press to hang up and return to the home display. XTS4000.book.fm Page 48 Monday, October 2, 2006 5:29 PM ASTRO XTS 4000 49 Common Radio Features Conventional Talkgroup Calls (Conventional Operation Only) Talkgroup Call lets you define a group of conventional system users so that they can share the use of a conventional channel. Encryption keys are slaved to talkgroups. When talkgroups are enabled, encryption keys are changed by changing the active talkgroup. See “Secure Operations” on page 55. Select a Talkgroup 1Press to find TGrp. 2Press directly below TGrp. You see the last talkgroup that was selected and stored, and Sel and Pset. 3Press or to find the talkgroup you want. OR Use the keypad to enter the number of the corresponding talk- group in the list. 4Press directly below Sel or Pset. Sel (Select) — Saves the currently displayed talkgroup and …

Text truncated - open the document above for the full version.

EXHIBIT 13A SHEET 1 FCC ID: AZ489FT3814 Date: 13 th November 2006 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT3814. Dear Sir / Madam, Motorola Inc., 8000 West Sunrise Blvd., Fort Lauderdale, FL, herein submits application for Certification of the equipment identified by FCC ID number AZ489FT3814. This transmitter is primarily intended for use in a portable radio application with capabilities for conventional communications with a conducted transmit power which is adjustable from 1 Watt to 2.8 Watts. The subject transmitter complies with CFR Title 47, Section 90.203, in that the operator cannot directly program the transmit frequencies using only the normally accessible external controls of the unit. Enclosed is a complete Certification Application. Please contact me at 954- 723-5793 if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected]

EXHIBIT 13B SHEET 1 FCC ID: AZ489FT3814 REQUEST FOR CONFIDENTIALITY Date: November 2, 2006 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT3814 Dear Sir / Madam, Motorola is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune-Up Procedures), and Exhibit 12 (Transmitter Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. Motorola is also requesting that the FCC mark Exhibit 3 (External Photos) and Exhibit 9, (Internal Photos) as Temporary Confidentiality as outlined in Public Notice DA 04-1705, dated June 15, 2004. This provision will give Motorola temporary confidentiality prior to product launch. Please mark Exhibits 4, 5, 10, and 12 as “Confidential” And Exhibit 3 and 9 as “Temporary Confidential”. Please contact me if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected]

Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 1 OF 11 EXHIBIT 3 EXTERNAL PHOTOGRAPHS - Pursuant to 47 CFR 2.1033(c) 12 Figure 3-1: Front view of the radio Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 2 OF 11 Figure 3-2: Front view of the radio with antenna extended Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 3 OF 11 Figure 3-3: Front view of the radio with flip open Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 4 OF 11 Figure 3-4: Back view of complete radio Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 5 OF 11 Figure 3-5: Right side view of complete radio Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 6 OF 11 Figure 3-6: Right side view (audio jack) of complete radio with flip open Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 7 OF 11 Figure 3-7: Left side (PTT) view of complete radio Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 8 OF 11 Figure 3-8: Left side (PTT) view of complete radio with flip open Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 9 OF 11 Figure 3-9: Rear view of radio showing FCC & Safety labels location FCC Label Location RF Safety Label Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 10 OF 11 Figure 3-10: Top view of complete radio Figure 3-11: Bottom view of complete radio Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 3 SHEET 11 OF 11 Figure 3-12: Close-up view of FCC RF Safety Label Figure 3-13: Antenna view when extended and retracted

Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 1 SHEET 1 OF 1 EXHIBIT 1 IDENTIFICATION LABEL - Pursuant to 47 CFR 2.925(a), 2.1033(c), 2.0165 EXHIBIT 1A - LABEL LOCATION A nameplate of the type presented below will be affixed to every transmitter. It will be placed on the bottom of the unit near the front. Shown below is a photo of the actual label affixed to the cast chassis of the transmitter. Please note that Motorola complies to FCC Rule Part 2.925 (d) that the label is permanently affixed and is readily visible to the purchaser at the time of purchase” Figure 1-1: FCC Label EXHIBIT 1B - GENERAL INFORMATION 1. Application References: TIA/EIA-603B Land Mobile FM or PM Communications Equipment Measurement and Performance Standards Code of Federal Regulations Title 47, Part 2, Sec. 2.1033-2.1057, Sec. 2.1077(a), Part 80 and Part 90, Section 90.210. 2. Data Submittal Procedure: Data is supplied in accordance with Part 2, Sub-part J of the Commission’s rules. The intended use of this transceiver includes applications covered in the Code of Federal Regulations Title 47, Part 80 and Part 90. Maximum transmitter power shall not be adjustable by the user. 3. Applicable Reference • Reference Certification FCC ID: AZ489FT3814 • EIA/TIA-603 Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. • FCC Federal Regulations Part 47 Sec. 2.1033-2.1057 • FCC Federal Regulations Part 80, Marine Application Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 1 SHEET 1 OF 1 • FCC Federal Regulations Part 90 Sec.90.210

Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 1 SHEET 1 OF 1 EXHIBIT 1 IDENTIFICATION LABEL - Pursuant to 47 CFR 2.925(a), 2.1033(c), 2.0165 EXHIBIT 1A - LABEL LOCATION A nameplate of the type presented below will be affixed to every transmitter. It will be placed on the bottom of the unit near the front. Shown below is a photo of the actual label affixed to the cast chassis of the transmitter. Please note that Motorola complies to FCC Rule Part 2.925 (d) that the label is permanently affixed and is readily visible to the purchaser at the time of purchase” Figure 1-1: FCC Label EXHIBIT 1B - GENERAL INFORMATION 1. Application References: TIA/EIA-603B Land Mobile FM or PM Communications Equipment Measurement and Performance Standards Code of Federal Regulations Title 47, Part 2, Sec. 2.1033-2.1057, Sec. 2.1077(a), Part 80 and Part 90, Section 90.210. 2. Data Submittal Procedure: Data is supplied in accordance with Part 2, Sub-part J of the Commission’s rules. The intended use of this transceiver includes applications covered in the Code of Federal Regulations Title 47, Part 80 and Part 90. Maximum transmitter power shall not be adjustable by the user. 3. Applicable Reference • Reference Certification FCC ID: AZ489FT3814 • EIA/TIA-603 Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. • FCC Federal Regulations Part 47 Sec. 2.1033-2.1057 • FCC Federal Regulations Part 80, Marine Application Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 1 SHEET 1 OF 1 • FCC Federal Regulations Part 90 Sec.90.210

Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 9 SHEET 1 OF 2 EXHIBIT 9 INTERNAL PHOTOGRAPHS - Pursuant to 47 CFR 2.1033(c) 12 Figure 9-1: Top Side of PCB (with shields) Figure 9-2: Top Side of PCB (without shields) Applicant: Motorola Inc. FCC ID: AZ489FT3814 EXHIBIT 9 SHEET 2 OF 2 Figure 9-3: Bottom Side of PCB (with shields) Figure 9-4: Bottom Side of PCB (without shields)

FCC ID: AZ489FT3814 SR4417 N&E EME Form-SAR-Rpt-Rev. 5.04 Page 1 of 30 Certificate Number: 2518.01 FCC ID: AZ489FT3814 DECLARATION OF COMPLIANCE SAR ASSESSMENT Part 1 of 3 Networks & Enterprise EME Test Laboratory 8000 West Sunrise Blvd Fort Lauderdale, FL. 33322 Date of Report: 10/18/2006 Report Revision: O Report ID: XTS4000_Rev O_061018 SR4417 Responsible Engineer: Stephen C. Whalen Sr. Staff EME Eng. Date/s Tested: 9/21/06-10/2/06 Manufacturer/Location: Motorola – Schaumburg IL Sector/Group/Div.: Networks and Enterprises Date submitted for test: 9/18/2006 DUT Description: XTS 4000 PORTABLE ASTRO DIGITAL 136-174MHZ 1-2W Test TX mode(s): FM APCO 25 Max. Power output: 2.8W Nominal Power: 2 Watts, conducted, constant envelope (APCO) Tx Frequency Bands: 136-174 MHz Signaling type: FM APCO 25 Model(s) Tested: H18KCN9PW9AN Model(s) Certified: H18KCN9PW9AN Serial Number(s): 687T000506 Classification: Occupational/Controlled Rule Part(s): 90 Antenna(s): NAD6583A retractable (162-174 MHz ¼ wave -13.3 dBi), NAD6582A retractable (136-151 MHz ¼ wave -13.3 dBi), NAD6581A retractable (145-166 MHz ¼ wave -13.3 dBi) Battery(ies): NNTN6944A Li Ion Body worn accessory(ies): NNTN6946A leather pouch, NNTN6945A plastic holster Audio/Data cable accessory(ies): SYN8390B Ear Piece, NNTN5006BP Ear Piece, NNTN5211A Ear Piece Max. Calc. : 1-g Avg. SAR: 0.37 W/kg (Body); 10-g Avg. SAR: 0.19 W/kg (Body) Max. Calc. : 1-g Avg. SAR: 0.17 W/kg (Face); 10-g Avg. SAR: 0.13 W/kg (Face) Max. Calc. : 1-g Avg. SAR: 1.64 W/kg (Head); 10-g Avg. SAR: 0.71 W/kg (Head) Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 2.0 of this report. This report shall not be reproduced without written approval from an officially designated representative of the Motorola EME Laboratory. This reporting format is consistent with the test report guidelines of the TIA TSB-150 December 2004 The results and statements contained in this report pertain only to the device(s) evaluated. signature on file Ken Enger N&E EME Lab Senior Resource Manager, Laboratory Director, Approval Date: 10/20/06 Certification Date: [ ] Certification No.: [ ] FCC ID: AZ489FT3814 SR4417 N&E EME Form-SAR-Rpt-Rev. 5.04 Page 2 of 30 Part 1 of 3 1.0 Introduction and Overview...................................................................................... 3 2.0 Referenced Standards and Guidelines ..................................................................... 3 2.1 SAR Limits ................................................................................................... 4 3.0 Description of Device Under Test (DUT) ............................................................... 4 4.0 Description of Test System ..................................................................................... 5 4.1 Description of Robotics/Probes/Readout Electronics ................................... 5 4.2 Description of Phantom(s) ............................................................................ 5 4.2.1 Flat Phantom................................................................................... 5 4.2.2 SAM Phantom ................................................................................ 5 4.3 Description of Equivalent Tissues ................................................................ 6 5.0 Additional Test Equipment...................................................................................... 6 6.0 SAR Measurement System Verification.................................................................. 7 6.1 Equivalent Tissue Test results ...................................................................... 7 6.2 System Check Test results ............................................................................ 8 7.0 DUT Test Strategy and Methodology ..................................................................... 8 7.1 DUT Configuration(s) .................................................................................. 8 7.2 Device Positioning Procedures ..................................................................... 9 7.2.1 Body ............................................................................................... 9 7.2.2 Head ............................................................................................... 9 7.2.3 Face ....................................................…

Text truncated - open the document above for the full version.
