AZ489FT3847Portable 2-way radio

PROFESSIONAL DIGITAL TWO-WAY RADIO MOTOTRBO™ CP100d NON-KEYPAD PORTABLE RADIO USER GUIDE APRIL 2020 © 2020 Motorola Solutions, Inc. All rights reserved. MN006549A01-AA @ MN006549A01@ en-US fr-CA Supplier's Declaration of Conformity Supplier's Declaration of Conformity Per FCC CFR 47 Part 2 Section 2.1077(a) Responsible Party Name: Motorola Solutions, Inc. Address: 1303 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A. Phone Number: 1-800-927-2744 Hereby declares that the product: Model Name: CP100d conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d), and section 15.109(a) Class B Digital Device As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: English 2 1This device may not cause harmful interference, and 2This device must accept any interference received, including interference that may cause undesired operation. NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter- ference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio or TV technician for help. English 3 Contents Supplier's Declaration of Conformity..............................2 Important Safety Information..........................................6 Notice to Users...............................................................7 Software Version............................................................8 Copyrights......................................................................9 Computer Software Copyrights....................................11 Chapter 1: Introduction.................................................12 Icon Information.................................................12 Conventional Analog and Digital Modes............12 Chapter 2: Getting Started........................................... 14 Charging the Battery..........................................14 Attaching the Battery.........................................14 Removing the Battery........................................14 Attaching the Antenna.......................................15 Attaching and Removing the Belt Clip...............16 Attaching the Belt Clip............................ 16 Removing the Belt Clip...........................17 Turning the Radio On........................................17 Adjusting the Volume.........................................17 Chapter 3: Radio Controls............................................19 Programmable Buttons......................................19 Assignable Radio Functions...................19 Assignable Settings or Utility Functions..20 Push-To-Talk Button..........................................20 Chapter 4: Status Indicators.........................................21 LED Indicators ..................................................21 Tones.................................................................21 Audio Tones............................................22 Indicator Tones.......................................22 Chapter 5: Zone and Channel Selections.................... 23 Selecting Zones ................................................23 Selecting Channels............................................23 Chapter 6: Calls............................................................24 Group Calls........................................................24 Making Group Calls................................24 Responding to Group Calls.....................25 Private Calls .................................................25 Making Private Calls ..........................26 Responding to Private Calls ..............26 All Calls..............................................................27 English 4 Receiving All Calls..................................27 Broadcast Voice Calls....................................... 27 Making Broadcast Voice Calls................28 Receiving Broadcast Voice Calls............28 Unaddressed Calls............................................28 Making Unaddressed Calls.....................28 Responding to Unaddressed Calls.........29 Open Voice Channel Mode (OVCM).................29 Making OVCM Calls............................... 30 Responding to OVCM Calls....................30 Chapter 7: Advanced Features.................................... 31 Talkaround.........................................................31 Toggling Between Repeater and Talkaround Modes..................................31 Monitor Feature ................................................31 Monitoring Channels...............................31 Permanent Monitor ................................32 Turning Permanent Monitor On or Off............................................32 Scan Lists..........................................................32 Scan.................................................................. 32 Turning Scan On or Off ..........................33 Responding to Transmissions During Scanning.................................................33 Deleting Nuisance Channels.................. 34 Restoring Nuisance Channels.......…

Text truncated - open the document above for the full version.

en-US es-LA fr-CA pt-BR RF Energy Exposure Training and Product Safety Information for Portable Two-Way Radios Formation sur l’exposition aux RF et information sur la sécurité du produit pour radios bidirectionnelles portatives Capacitación sobre la exposición a energía de radiofrecuencia e información de protección del producto para radios de dos vías portátiles Treinamento sobre a Exposição à Energia de RF e Informações de Segurança do Produto para Rádios Portáteis Bidirecionais https://learning.motorolasolutions.com/User_Documentation 2 Caution Before using this radio, read this booklet which contains important operating instructions. For information on product details, brochures, user manuals and approved accessories. Please refer to www.motorolasolutions.com. Compliance with RF Exposure Standards National and international regulations require manufacturers to comply with the RF energy exposure limits for portable two-way radios before they can be marketed. Your Motorola Solutions two-way radio is designed, manufactured, and tested to comply with all applicable national and international regulations for human exposure to radio frequency electromagnetic energy. When two-way radios are used as a consequence of employment, applicable regulations may require users to be fully aware of and able to control their exposure to meet occupational requirements. RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use Notice: This radio is intended for use in occupational/controlled conditions where users are aware of their exposure and can exercise control over their exposure to meet the requirements in national and international regulations. This radio device is not authorized for general population, consumer use. For more information on what RF energy exposure is, and how to control your exposure to ensure compliance with established RF exposure limits, consult the following websites: •https://www.fcc.gov/ •https://www.osha.gov/ •https://osha.europa.eu/en •http://www.who.int/peh-emf/project/en/ •http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf11467.html •http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01904.html For additional user training information on exposure requirements, consult the following websites: •https://www.motorolasolutions.com/en_us/about/company-overview/ corporate-responsibility/governance-and-policies/wireless- communication-and-health-faqs.html •http://learning.motorolasolutions.com/ RF Exposure Compliance and Control Guidelines To control your exposure, and ensure compliance with the relevant RF exposure limits, always adhere to the following guidelines: • Do not remove any of the RF Exposure Labels if present from this device or its related accessories. • Attach these instructions to the device when you transfer it to other users. • Do not use this device if the operational requirements described herein are not met. Operating Instructions • Transmit no more than 50% of the time. To transmit (talk), press the Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting more than 50% of the time may cause RF exposure compliance requirements to be exceeded. • Hold the radio in a vertical position in front of the face with the microphone (and other parts of the radio including the antenna) at least 1 in. (2.5 cm) away from the nose or lips. Antenna should be kept away from the eye. • When worn on the body, always place the radio in a Motorola Solutions-approved clip, holder, holster, case, or body harness for this product. • DO NOT hold the antenna when the radio is transmitting. • DO NOT use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result. • To ensure continued compliance with applicable RF exposure limits, use only Motorola Solutions approved, supplied or replacement antennas, batteries, and accessories. • For a list of Motorola Solutions approved accessories please refer to your user manual or visit www.motorolasolutions.com English 3 Notice to Users (FCC) This device complies with Part 15 of the FCC rules per the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. • Changes or modifications made to this device, not expressly approved by Motorola Solutions Standard, could void the authority of the user to operate this equipment. Acoustic Safety Exposure to loud noises from any source for extended periods of time may temporarily or permanently affect your hearing. The louder the volume of the radio, the sooner your hearing will be affected. Hearing damage from loud noise is sometimes undetectable at first, and can have a cumulative effect. To protect your hearing: • Use the lowest volume necessary to do your job. • Turn up the volume only if you are in noisy surroundings. • Turn down the volume before adding headset or earpiece. • Limit the amount of time you use headsets or earpieces at high volume. • When using the radio without a headset or earpiece, do not place the radio's speaker directly against your ear. Medical Devices If you use a personal medical device, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information. Holsters Incorporating Magnets Some Motorola Solutions holsters incorporate strong, neodymium magnets. If you use a personal medical device, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it can be used in close proximity to magnets. Your physician may be able to assist you in obtaining this information. Also be aware that magnets can damage other products, including cell phones, computers, hard drives, and other electronic devices, as well as credit cards and magnetic media. Keep the holster aw…

Text truncated - open the document above for the full version.

Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 2 SHEET 1 OF 1 EXHIBIT 2 Statement of Certification (Pursuant to FCC Part 2.907, 2.908 and RSP 100 Sec 4) 2.1 Statement of Certification Transceiver type described herein (AZ489FT3847/109U-89FT3847) is in compliance with all applicable parts of the FCC rules and ISED RSS standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Vasu Subramaniam SIGNATURE: DATE: 9 th April 2020 TITLE: Engineering Manager

FCC ID: AZ489FT3847 ___________________________________________________________________________________________________________ Morola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13A Date : April 29, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT3847 Dear Sir/Madam, Motorola Solutions Malaysia Sdn Bhd, herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a portable radio application with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: Product Name Model Numbers Frequency Range RF Power FCC Rules Part CP100d AAH87JDF9JA2AN LMR: 136 - 174MHz 5.0W (Rated) 6.0W (Max) 22, 90 AAH87JDH9JA2AN AAH87JDC9JA2AN We are requesting certification under Part(s) of the Commission’s Rules listed above to allow operation of this equipment. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at +6042240258. Sincerely, Arine Lee FCC/IC Certification Manager E-mail: [email protected]

FCC ID: AZ489FT3847 ___________________________________________________________________________________________________________ Morola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13B CONFIDENTIALITY REQUEST April 29, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ489FT3847 Dear Sir / Madam, Motorola Solutions Malaysia Sdn Bhd is requesting that Exhibit 4 (Block Diagram), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d), 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, Arine Lee FCC/IC Certifcation Manager E-mail: [email protected]

FCC ID: AZ489FT3847 _______________________________________________________________________________________________ Morola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13C April 29, 2020 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification for Certification of Transmitter with FCC ID: AZ489FT3847. Dear Sir/Madam: This transmitter was designed to operate in the following frequency ranges: Band / Mode Frequency ranges FCC rule parts VHF 136 – 174 MHz 22, 90 To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Motorola Solutions is requesting that the FCC lists the frequencies range under FCC Rule Parts 22 and 90 on the FCC Grant. For the FCC’s Rule Parts 22 and 90 applications, this radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, etc. as indicated in the table below. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Frequency Range (MHz) Part 22 Part 90 Federal Other Regions 136-150.8* x x 150.8-152.855 x 152.855-154 x 154-156.2475 x 156.2475-157.1875 157.1875-157.45 x 157.45-161.575 x x 161.575-161.625 161.625-161-775 161.775-161.9625 x 161.9625-162.025 162.025-162.0375* x x 162.0375-173.4 x 173.4-174* x *Canada Please contact me if you required any additional information. Sincerely, Arine Lee FCC/IC Certification Manager E-mail: [email protected]

Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 1 OF 21 EXHIBIT 3 EXTERNAL PHOTOGRAPHS (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. Front View 3A 2. Back View with Battery . 3B 3. Back View (FCC/IC label location). 3C 4. Side View (Right). 3D 5. Side View (Left). 3E 6. Top view. 3F 7. Bottom view with Battery 3G Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 2 OF 21 Exhibit 3A – Front View Front View of Radio ( FKP model, AAH87JDF9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 3 OF 21 Front View of Radio ( LKP model, AAH87JDH9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 4 OF 21 Front View of Radio ( NKP model, AAH87JDC9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 5 OF 21 Exhibit 3B – Back View with Battery Back View with Battery ( FKP model, AAH87JDF9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 6 OF 21 Back View with Battery (LKP model, AAH87JDH9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 7 OF 21 Back View with Battery ( NKP model, AAH87JDC9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 8 OF 21 Exhibit 3C – Back View (FCC/IC Label Location) Back View (FCC/IC Label Location) ( FKP model, AAH87JDF9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 9 OF 21 Back View (FCC/IC Label Location) (LKP model, AAH87JDH9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 10 OF 21 Back View (FCC/IC Label Location) ( NKP model, AAH87JDC9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 11 OF 21 Exhibit 3D – Side View (Right) Side View (Right) ( FKP model, AAH87JDF9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 12 OF 21 Side View (Right) (LKP model, AAH87JDH9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 13 OF 21 Side View (Right) ( NKP model, AAH87JDC9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 14 OF 21 Exhibit 3E –Side View (Left) Side View (Left) ( FKP model, AAH87JDF9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 15 OF 21 Side View (Left) (LKP model, AAH87JDH9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 16 OF 21 Side View (Left) ( NKP model, AAH87JDC9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 17 OF 21 Exhibit 3F – Top View Top View (with Antenna) ( FKP model, AAH87JDF9JA2AN) Top View (without Antenna) ( FKP model, AAH87JDF9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 18 OF 21 Top View (with Antenna) (LKP model, AAH87JDH9JA2AN) Top View (without Antenna) (LKP model, AAH87JDH9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 19 OF 21 Top View (with Antenna) (NKP model, AAH87JDC9JA2AN) Top View (without Antenna) ( NKP model, AAH87JDC9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 20 OF 21 Exhibit 3G – Bottom View with Battery Bottom View with Battery (FKP model, AAH87JDF9JA2AN) Bottom View with Battery (LKP model, AAH87JDH9JA2AN) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847/ IC: 109U-89FT3847 EXHIBIT 3 SHEET 21 OF 21 Bottom View with Battery ( NKP model, AAH87JDC9JA2AN) *** END ***

Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847 / IC: 109U-89FT3847 EXHIBIT 1 SHEET 1 OF 4 EXHIBIT 1 IDENTIFICATION LABEL (Pursuant to FCC Part 2.1033(c)(11), 2.1033(b)(7) and RSP 100 Annex C and Sec 3) LOCATION See the Attached Photograph or Sketch Bottom of Radio Top of Radio X Back of Radio Back of Radio under Belt Clip TYPE X The label is a poly carbonate film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with the minimum peel strength of 40 oz/inch. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3 for the actual location of the FCC/IC label on the device. X Label Attached Below. See Attached Drawing. Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847 / IC: 109U-89FT3847 EXHIBIT 1 SHEET 2 OF 4 Figure 1A: FCC/IC Label for FKP Model (AAH87JDF9JA2AN, CP100d, 136-174MHz, 5W FKP) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847 / IC: 109U-89FT3847 EXHIBIT 1 SHEET 3 OF 4 Figure 1B: FCC/IC Label for LKP Model (AAH87JDH9JA2AN, CP100d, 136-174MHz, 5W LKP) Applicant: Motorola Solutions Inc FCC ID: AZ489FT3847 / IC: 109U-89FT3847 EXHIBIT 1 SHEET 4 OF 4 Figure 1C: FCC/IC Label for NKP Model (AAH87JDC9JA2AN, CP100d, 136-174MHz, 5W NKP) *** END ***

Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 1 EXHIBIT 9 Internal Photographs (Pursuant to FCC Part 2.1033(b)(7), 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. RF board with Shields (Top) 9A 2. RF board without Shields (Top) 9B 3. RF board with Shields (Bottom) 9C 4. RF board without Shields (Bottom) 9D 5. RF boards with chassis and housing (Front Side) 9E 6. Chassis and housing (Back Side) 9F 7. Exploded view of radio 9G Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 2 Exhibits 9A – RF board with Shields (Top) RF board with Shields (Top) -Full Keypad (FKP) model, AAH87JDF9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 3 RF board with Shields (Top) -Limited Keypad (LKP) model, AAH87JDH9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 4 RF board with Shields (Top) -Non Keypad (NKP) model, AAH87JDC9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 5 Exhibits 9B – RF board without Shields (Top) RF board without Shields (Top) -Full Keypad (FKP) model, AAH87JDF9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 6 RF board without Shields (Top) -Limited Keypad (LKP) model, AAH87JDH9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 7 RF board without Shields (Top) -Non Keypad (NKP) model, AAH87JDC9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 8 Exhibit 9C – RF board with Shields (Bottom) RF board with Shields (Bottom) - Full Keypad (FKP) model, AAH87JDF9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 9 RF board with Shields (Bottom) -Limited Keypad (LKP) model, AAH87JDH9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 10 RF board with Shields (Bottom) -Non Keypad (NKP) model, AAH87JDC9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 11 Exhibit 9D – RF board without Shields (Bottom) RF board without Shields (Bottom) -Full Keypad (FKP) model, AAH87JDF9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 12 RF board without Shields (Bottom) -Limited Keypad (LKP) model, AAH87JDH9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 13 RF board without Shields (Bottom) -Non Keypad(NKP) model, AAH87JDC9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 14 Exhibit 9E – RF board with chassis and housing (Front Side) RF board with chassis and housing (front side) -Full Keypad (FKP) model, AAH87JDF9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 15 RF board with chassis and housing (front side) -Limited Keypad (LKP) model, AAH87JDH9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 16 RF board with chassis and housing (front side) -Non Keypad (NKP) model, AAH87JDC9JA2AN)- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 17 Exhibit 9F – Chassis and housing (Back Side) Chassis and Housing (Back side) -Full Keypad (FKP) model, AAH87JDF9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 18 Chassis and Housing (Back side) -Limited Keypad (LKP) model, AAH87JDH9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 19 Chassis and Housing (Back side) -Non Keypad (NKP) model, AAH87JDC9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 20 Exhibit 9G – Exploded view of radio Exploded View of Radio -Full Keypad (FKP) model, AAH87JDF9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 21 Exploded View of Radio -Limited Keypad (LKP) model, AAH87JDH9JA2AN- Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3847/ IC: 109U-89FT3847 Exhibit 9 Page | 22 Exploded View of Radio -Non Keypad(NKP) model, AAH87JDC9JA2AN- *** END ***

FCC ID: AZ489FT3847 / IC: 109U-89FT3847 Report ID: P20216-EME-00001/00002 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev.13.27 Page 1 of 23 DECLARATION OF COMPLIANCE SAR ASSESSMENT Part 2 of 2 Motorola Solutions Inc. EME Test Laboratory Motorola Solutions Malaysia Sdn Bhd Plot 2A, Medan Bayan Lepas, Mukim 12 SWD 11900 Bayan Lepas Penang, Malaysia. Date of Report: 04/20/2020 Report Revision: B Responsible Engineer: Ch’ng Jian Sheng Report Author: Ch’ng Jian Sheng Date/s Tested: 01/07/2020 - 01/13/2020, 01/15/2020, 01/21/2020 Manufacturer: Motorola Solutions Inc. DUT Description: Handheld Portable – CP100d 136-174M 5W FKP Test TX mode(s): CW (PTT) Max. Power output: 6.0 W Nominal Power: 5.0 W Tx Frequency Bands: 136-174MHz Signaling type: FM, TDMA Model(s) Tested: AAH87JDF9JA2AN (PMUD3484A) Model(s) Certified: AAH87JDF9JA2AN (PMUD3484A), AAH87JDC9JA2AN (PMUD3486A), AAH87JDH9JA2AN (PMUD3485A) Serial Number(s): 278TVZ3129 Classification: Occupational/Controlled Applicant Name: Motorola Solutions Inc. Applicant Address: 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 FCC ID: AZ489FT3847; 150.8-173.4MHz This report contains results that are immaterial for FCC equipment approval, which are clearly identified. IC: 109U-89FT3847; 138-174MHz This report contains results that are immaterial for ISED equipment approval, which are clearly identified. ISED Test Site registration: 24843 FCC Test Firm Registration Number: 823256 The test results clearly demonstrate compliance with FCC Occupational/Controlled RF Exposure limits of 8 W/kg averaged over 1 gram per the requirements of FCC 47 CFR § 2.1093 and RSS-102 (Issue 5). Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 4.0 of this report (no deviation from standard methods). This report shall not be reproduced without written approval from an officially designated representative of the Motorola Solutions Inc EME Laboratory. I attest to the accuracy of the data and assume full responsibility for the completeness of these measurements. This reporting format is consistent with the suggested guidelines of the TIA TSB-150 December 2004. The results and statements contained in this report pertain only to the device(s) evaluated. Tiong Nguk Ing Deputy Technical Manager (Approved Signatory) Approval Date: 4/20/2020 FCC ID: AZ489FT3847 / IC: 109U-89FT3847 Report ID: P20216-EME-00001/00002 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev.13.27 Page 2 of 23 Appendix D System Verification Check Scans FCC ID: AZ489FT3847 / IC: 109U-89FT3847 Report ID: P20216-EME-00001/00002 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev.13.27 Page 3 of 23 FCC ID: AZ489FT3847 / IC: 109U-89FT3847 Report ID: P20216-EME-00001/00002 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev.13.27 Page 4 of 23 FCC ID: AZ489FT3847 / IC: 109U-89FT3847 Report ID: P20216-EME-00001/00002 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev.13.27 Page 5 of 23 FCC ID: AZ489FT3847 / IC: 109U-…

Text truncated - open the document above for the full version.
