AZ489FT3856Portable 2-Way Radio

en-US es-LA fr-CA pt-BR RF Energy Exposure Training and Product Safety Information for Portable Two-Way Radios Formation sur l’exposition aux RF et information sur la sécurité du produit pour radios bidirectionnelles portatives Capacitación sobre la exposición a energía de radiofrecuencia e información de protección del producto para radios de dos vías portátiles Treinamento sobre a Exposição à Energia de RF e Informações de Segurança do Produto para Rádios Portáteis Bidirecionais https://learning.motorolasolutions.com/User_Documentation Caution Before using this radio, read this booklet which contains important operating instructions. For information on product details, brochures, user manuals and approved accessories. Please refer to www.motorolasolutions.com. For Australia and New Zealand users, please visit https:// www.motorolasolutions.com/en_xa/products.html Compliance with RF Exposure Standards National and international regulations require manufacturers to comply with the RF energy exposure limits for portable two-way radios before they can be marketed. Your Motorola Solutions two-way radio is designed, manufactured, and tested to comply with all applicable national and international regulations for human exposure to radio frequency electromagnetic energy . When two-way radios are used as a consequence of employment, applicable regulations may require users to be fully aware of and able to control their exposure to meet occupational requirements. RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use NOTE: This radio is intended for use in occupational/controlled conditions where users are aware of their exposure and can exercise control over their exposure to meet the requirements in national and international regulations. This radio device is not authorized for general population, consumer use. For more information on what RF energy exposure is, and how to control your exposure to ensure compliance with established RF exposure limits, consult the following websites: ●https://www.fcc.gov/ ●https://www.osha.gov/ ●https://osha.europa.eu/en ●https://www.who.int/health-topics/electromagnetic-fields/ ●http://www .ic.gc.ca/eic/site/smt-gst.nsf/eng/sf11467.html ●http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01904.html For additional user training information on exposure requirements, consult the following websites: ●http://responsibility.motorolasolutions.com/index.php/ourapproach/ wirelesscommhealth/ ●http://learning.motorolasolutions.com/ RF Exposure Compliance and Control Guidelines To control your exposure, and ensure compliance with the relevant RF exposure limits, always adhere to the following guidelines: ●Do not remove any of the RF Exposure Labels if present from this device or its related accessories. ●Attach these instructions to the device when you transfer it to other users. ●Do not use this device if the operational requirements described herein are not met. Notice to Users (FCC) This device complies with Part 15 of the FCC rules per the following conditions: ●This device may not cause harmful interference. ●The device must accept any interference received, including interference that may cause undesired operation. ●Changes or modifications made to this device, not expressly approved by Motorola Solutions, could void the authority of the user to operate this equipment. Operating Instructions ●Transmit no more than 50% of the time. T o transmit (talk), press the Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting more than 50% of the time may cause RF exposure compliance requirements to be exceeded. ●Hold the radio in a vertical position in front of the face with the microphone (and other parts of the radio including the antenna) at least 1 in. (2.5 cm) away from the nose or lips. Antenna should be kept away from the eye. English 1 ●When worn on the body, always place the radio in a Motorola Solutions-approved clip, holder, holster, case, or body harness for this product. ●DO NOT hold the antenna when the radio is transmitting. ●DO NOT use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result. ●T o ensure continued compliance with applicable RF exposure limits, use only Motorola Solutions approved, supplied or replacement antennas, batteries, and accessories. ●For a list of Motorola Solutions approved accessories please refer to your user manual or visit www.motorolasolutions.com. Acoustic Safety Exposure to loud noises from any source for extended periods of time may temporarily or permanently affect your hearing. The louder the volume of the radio, the sooner your hearing will be affected. Hearing damage from loud noise is sometimes undetectable at first, and can have a cumulative effect. To protect your hearing: ●Use the lowest volume necessary to do your job. ●Turn up the volume only if you are in noisy surroundings. ●Turn down the volume before adding headset or earpiece. ●Limit the amount of time you use headsets or earpieces at high volume. ●When using the radio without a headset or earpiece, do not place the radio's speaker directly against your ear. Medical Devices If you use a personal medical device, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information. Holsters Incorporating Magnets Some Motorola Solutions holsters incorporate strong, neodymium magnets. If you use a personal medical device, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it can be used in close proximity to magnets. Your physician may be able to assist you in obtaining this information. Also be aware that magnets can damage other products, including cell phones, computers, hard drives, and other electronic devices, as well as credit cards and magnetic …

Text truncated - open the document above for the full version.

Mag One BPR 50dX Portable Radio User Guide DIGITAL TWO-WAY RADIO FEBRUARY 2024 © 2024 Motorola Solutions, Inc. All Rights Reserved. *MN010575A01* MN010575A01-AA Contents Legal and Support...............................................................................................................4 Intellectual Property and Regulatory Notices...........................................................................................4 Legal and Compliance Statements..........................................................................................................5 Supplier's Declaration of Conformity.............................................................................................5 Important Safety Information.........................................................................................................6 Notice to Users (FCC)..................................................................................................................6 Chapter 1: Read Me First.....................................................................................................7 Chapter 2: Radio Overview..................................................................................................8 2.1 Programmable Buttons......................................................................................................................9 2.1.1 Assignable Radio Function.................................................................................................. 9 Chapter 3: Radio LED Indications.................................................................................... 10 Chapter 4: Getting Started.................................................................................................11 4.1 Charging the Battery........................................................................................................................11 4.2 Attaching the Battery........................................................................................................................11 4.3 Removing the Battery...................................................................................................................... 12 4.4 Attaching the Antenna......................................................................................................................13 4.5 Removing the Antenna.................................................................................................................... 14 4.6 Attaching the Belt Clip......................................................................................................................15 4.7 Removing the Belt Clip.................................................................................................................... 15 4.8 Attaching the Universal Connector Cover........................................................................................16 4.9 Removing the Universal Connector Cover.......................................................................................16 4.10 Turning the Radio On.....................................................................................................................17 4.11 Turning the Radio Off.....................................................................................................................17 4.12 Adjusting the Volume.....................................................................................................................17 Chapter 5: Time-Out Timer................................................................................................18 Chapter 6: Selecting Channels......................................................................................... 19 Chapter 7: Calls..................................................................................................................20 7.1 Group Calls......................................................................................................................................20 7.1.1 Making Group Calls............................................................................................................20 7.1.2 Responding to Group Calls................................................................................................20 7.2 Private Calls ....................................................................................................................................20 7.2.1 Making Private Calls.......................................................................................................... 21 7.2.2 Responding to Private Calls...............................................................................................21 7.3 All Calls............................................................................................................................................21 7.3.1 Making All Calls..................................................................................................................21 MN010575A01-AA Contents 2 Notice to Users (ISED)..................................................................................................................6 Chapter 8: Authorized Accessories List..........................................................................23 MN010575A01-AA Contents 3 Legal and Support Intellectual Property and Regulatory Notices Copyrights The Motorola Solutions products described in this document may include copyrighted Motorola Solutions computer programs. Laws in the United States and other countries preserve for Motorola Solutions certain exclusive rights for copyrighted computer programs. Accordingly, any copyrighted Motorola Solutions computer programs contained in the Motorola Solutions products described in this document may not be copied or reproduced in any manner without the express written permission of Motorola Solutions. No part of this document may be reproduced, transmitted, stored in a retrieval system, or translated into any language or com…

Text truncated - open the document above for the full version.

_______________________________________________________________________________________________________________________ Motorola Solutions Inc, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13f Template Revision 5 (7 May 2024) Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Attestation Statements pursuant to Part 2.911 (d)(7) Dear Sir/Madam, This letter is to confirm that Motorola’s Solutions Inc has a US Representative on behalf of for all future FCC certification/registrations. As the FCC Representative, we are aware of the requirements involved as outlined in US applicable document (FCC 22-84 and KDB 986446). US Representative Company Name: Motorola Solutions, Inc FRN Number: 0003778479 Company Grantee Code: AZ4 Contact Name: Mary Sampson Address: 2000 Progress Pkwy, Schaumburg, IL. 60196 Telephone Number: (770) 338-3464 E-mail: [email protected] Applicant Company Name: Motorola Solutions, Inc Company Grantee Code: AZ4 Applicant FRN: 0003778479 Contact Name: Arine Lee Address: Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia Telephone Number: +6042240258 Signed by the Applicant, Signed by the Agent, Name: Arine Lee Name: Mary Sampson Email: [email protected] E-mail: [email protected] Mary Sampson

FCC ID: AZ489FT3856 _______________________________________________________________________________________________________________________ Motorola Solutions, Inc., Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13e Template Revision 3 (3 May 2024) Date: June 19, 2024 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Attestation Statements pursuant to Part 2.911 (d)(5)(i) with FCC ID: AZ489FT3856 Dear Sir/Madam, According to FCC 22-84 and KDB 986446, Motorola Solutions, Inc., certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, ____________________ Arine Lee FCC/IC Certification Manager E-mail : [email protected] FCC ID: AZ489FT3856 _______________________________________________________________________________________________________________________ Motorola Solutions, Inc., Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13e Template Revision 3 (3 May 2024) Date: June 19, 2024 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Attestation Statements pursuant to Part 2.911 (d)(5)(ii) with FCC ID: AZ489FT3856 Dear Sir/Madam, According to FCC 22-84 and KDB 986446, Motorola Solutions, Inc., certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ____________________ Arine Lee FCC/IC Certification Manager E-mail : [email protected]

Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 2a Template Revision 9 (1 July 2024) SHEET 1 OF 3 EXHIBIT 2 Attestation and Product Family Declaration (Pursuant to FCC Part 2.907, 2.908 and RSP 100 Sec 4) 2.1 Statement of Certification Transceiver type described herein (AZ489FT3856/109U-89FT3856) is in compliance with all applicable parts of the FCC rules and ISED RSS standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Wong Chew Looi SIGNATURE: DATE: 2 nd July 2024 TITLE: Engineering Manager Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 2a Template Revision 9 (1 July 2024) SHEET 2 OF 3 2.2 Spectrum Efficiency Declaration The device supports TDMA (F2) transmission with 12.5 kHz spacing. Each transmit slot is 30 ms long and it is followed by 30 ms standby / receive. Transmission in digital TDMA mode (according to 6.25e efficiency standard) allows improved spectrum utilization whereby, the existing 12.5 kHz channel now allows two voice conversations to take place instead of one. Furthermore, the portable radio has integrated voice & data feature that extends the capability of the system to send & receive data through conventional infrastructure. This device is also capable of supporting a minimum data rate of 4800 bits per second per 6.25kHz channel bandwidth. NAME: Wong Chew Looi SIGNATURE: DATE: 2 nd July 2024 TITLE: Engineering Manager Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 2a Template Revision 9 (1 July 2024) SHEET 3 OF 3 2.3 Product Family Declaration FCC Model Number Hardware Version Identification Number (HVIN) Product Marketing Name (PMN) Software Version (FVIN) Description AAH88LDK8AD5BN AAH88LDK8AD5BN BPR 50dX I001.058 BPR 50DX 136-174 MHZ 5W NKP Note: 1. Product model labelled as BPR 50dX. 2. Product logo labeled with Mag one by Motorola. 3. BPR 50dX model is open to all customers in NA region. NAME: Wong Song Kui SIGNATURE: DATE: 2 nd July 2024 TITLE: Electrical Engineer

FCC ID: AZ489FT3856 _______________________________________________________________________________________________________________________ Motorola Solutions, Inc.,Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13C Template Revision 4 (10 May 2024) June 19, 2024 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification for Certification of Transmitter with FCC ID: AZ489FT3856. Dear Sir/Madam: This transmitter is designed to operate in the frequency ranges as described in Exhibit 13a: To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Motorola Solutions is requesting that the FCC lists the above applicable frequencies range under FCC Rule Parts 22 and 90 on the FCC Grant. For the FCC’s Rule Parts 22 and 90 applications, this radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, etc. as indicated in the table below. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Frequency Range (MHz) Part 22 Part 90 Federal Other Regions 136-150.8* x x 150.8-152.855 x 152.855-154 x 154-156.2475 x 156.2475-157.1875 157.1875-157.45 x 157.45-161.575 x x 161.575-161.625 161.625-161-775 161.775-161.9625 x 161.9625-162.025 162.025-162.0375* x x 162.0375-173.4 x 173.4-174* x *Canada Please contact me if you required any additional information. Sincerely, ____________________ Arine Lee FCC/IC Certification Manager E-mail : [email protected]

FCC ID: AZ489FT3856 _______________________________________________________________________________________________________________________ Motorola Solutions, Inc., Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13b(i) Template Revision 3 (3 May 2024) CONFIDENTIALITY REQUEST June 19, 2024 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ489FT3856 Dear Sir / Madam, Motorola Solutions, Inc., is requesting that Exhibit 4 (Block Diagram), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d), 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10 and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, ____________________ Arine Lee FCC/IC Certification Manager E-mail : [email protected]

FCC ID: AZ489FT3856 _______________________________________________________________________________________________________________________ Motorola Solutions, Inc., Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13A Template Revision 5 (3 May 2024) Date: June 19, 2024 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for New Filing Certification of Transmitter with FCC ID: AZ489FT3856 Dear Sir/Madam, Motorola Solutions, Inc., herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a portable radio application with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: Product Name Model Numbers Frequency Range RF Power FCC Rules Part BPR 50dX AAH88LDK8AD5BN LMR: 136 - 174 MHz 6.0W (Max declared) 22, 90 We are requesting certification under Part(s) of the Commission’s Rules listed above to allow operation of this equipment. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at +604-2240258. Sincerely, ____________________ Arine Lee FCC/IC Certification Manager E-mail : [email protected]

EXHIBIT 2d Template Revision 2 (11 April 2024) SHEET 1 OF 1 Certification Department Date: June 19, 2024 Subject: Authorization for FCC and IC filing To Whom It May Concern: I hereby authorize Wong Chew Looi and Wong Song Kui to apply to sign Ex02a_Attestation_Product Family Declaration on my behalf, for the following FCC and IC: FCC ID: AZ489FT3856 IC: 109U-89FT3856 Please contact me if there are any questions or issues. Regards, Arine Lee FCC/IC Certification Manager Tel: 604-2240258 E-mail : [email protected]

Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 3A Template Revision 1 (16 Nov 2022) SHEET 1 OF 7 EXHIBIT 3A EXTERNAL PHOTOGRAPHS (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. Front View with Battery 3A 2. Back View with Battery 3B 3. View of FCC/IC label location 3C 4. Side view (Right) with Battery 3D 5. Side view (Left) with Battery 3E 6. Top view with Battery 3F 7. Bottom view with Battery 3G Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 3A Template Revision 1 (16 Nov 2022) SHEET 2 OF 7 Exhibit 3A – Front View with Battery BPR 50dX Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 3A Template Revision 1 (16 Nov 2022) SHEET 3 OF 7 Exhibit 3B –Back View with Battery BPR 50dX Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 3A Template Revision 1 (16 Nov 2022) SHEET 4 OF 7 Exhibit 3C –View of FCC/IC label location BPR 50dX Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 3A Template Revision 1 (16 Nov 2022) SHEET 5 OF 7 Exhibit 3D – Side view (Right) with Battery Audio Jack Port USB-C Charging port BPR 50dX Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 3A Template Revision 1 (16 Nov 2022) SHEET 6 OF 7 Exhibit 3E – Side view (Left) with Battery BPR 50dX Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 3A Template Revision 1 (16 Nov 2022) SHEET 7 OF 7 Exhibit 3F – Top view with Battery BPR 50dX Exhibit 3G – Bottom view with Battery BPR 50dX *** END ***

Applicant: Motorola Solutions Inc FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 1 Template Revision 4 (29 Aug 2023) SHEET 1 OF 1 EXHIBIT 1 IDENTIFICATION LABEL (Pursuant to FCC Part 2.1033(c)(11), 2.1033(b)(7) and RSP 100 Annex C and Sec 3) MARKINGS (TEXT) X See Exhibit 3 for the actual location of the FCC/IC label on the device. X Label Attached Below. Figure 1: FCC/IC Label for BPR 50dX *** END ***

Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 9 Template Revision 2 (2 Jan 2024) SHEET 1 OF 7 EXHIBIT 9 Internal Photographs (Pursuant to FCC Part 2.1033(b)(7), 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. RF board with Shields (Top) 9A 2. RF board without Shields (Top) 9B 3. RF board with Shields (Bottom) 9C 4. RF board without Shields (Bottom) 9D 5. RF boards with chassis and housing for (Front Side) 9E 6. Chassis and housing (Back Side) 9F Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 9 Template Revision 2 (2 Jan 2024) SHEET 2 OF 7 Exhibits 9A - RF board with Shields (Top) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 9 Template Revision 2 (2 Jan 2024) SHEET 3 OF 7 Exhibits 9B - RF board without Shields (Top) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 9 Template Revision 2 (2 Jan 2024) SHEET 4 OF 7 Exhibit 9C - RF board with Shields (Bottom) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 9 Template Revision 2 (2 Jan 2024) SHEET 5 OF 7 Exhibit 9D - RF board without Shields (Bottom) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 9 Template Revision 2 (2 Jan 2024) SHEET 6 OF 7 Exhibit 9E - RF boards with chassis and housing for (Front Side) BPR 50dX BPR 50dX Main board Applicant: Motorola Solutions Inc. FCC ID: AZ489FT3856/ IC: 109U-89FT3856 EXHIBIT 9 Template Revision 2 (2 Jan 2024) SHEET 7 OF 7 Exhibit 9F - Chassis and housing (Back Side) BPR 50dX BPR 50dX Main board *** END ***

FCC ID: AZ489FT3856 / IC: 109U-89FT3856 Report ID: P41384-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.33 Page 1 of 14 DECLARATION OF COMPLIANCE SAR ASSESSMENT Part 2 of 2 Motorola Solutions Inc. EME Test Laboratory Motorola Solutions Malaysia Sdn Bhd Plot 2A, Medan Bayan Lepas, Mukim 12 SWD 11900 Bayan Lepas Penang, Malaysia. Date of Report: 07/02/2024 Report Revision: B Responsible Engineer: Puteri Alifah Ilyana Binti Nor Rahim (EME Engineer) Report Author: Puteri Alifah Ilyana Binti Nor Rahim (EME Engineer) Date/s Tested: 5/15/2024-5/16/2024 & 5/24/2024 Manufacturer: Motorola Solutions Inc. Manufacturer Location: Sanmina, Penang DUT Description: Handheld Portable – TANAPA BPR 50DX 136-174 MHz 5W NKP Test TX mode(s): CW (PTT) Max. Power output: Refer Table 3 Nominal Power: Refer Table 3 Tx Frequency Bands: Refer Table 3 Signaling type: Refer Table 3 Model(s) Tested: AAH88LDK8AD5BN Model(s) Certified: Refer Section 1.0 Introduction (HVIN/PMN) Serial Number(s): 02721AE0323 Classification: Firmware Version (FVIN): Occupational/Controlled Environment I001.058 Applicant Name: Motorola Solutions Inc. Applicant Address: Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia FCC ID: AZ489FT3856 This report contains results that are immaterial for FCC equipment approval, which are clearly identified. FCC Test Firm Registration Number: 823256 IC: 109U-89FT3856 This report contains results that are immaterial for ISED equipment approval, which are clearly identified. IC Test Site registration: 24843 The test results clearly demonstrate compliance with Occupational/Controlled RF Exposure limits of 8 W/kg averaged over 1 gram per the requirements of FCC 47 CFR § 2.1093 and RSS-102 (Issue 5) Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 4.0 of this report (no deviation from standard methods). This report shall not be reproduced without written approval from an officially designated representative of the Motorola Solutions Inc EME Laboratory. I attest to the accuracy of the data and assume full responsibility for the completeness of these measurements. This reporting format is consistent with the suggested guidelines of the TIA TSB-150 December 2004. The results and statements contained in this report pertain only to the device(s) evaluated. Saw Sun Hock (Approval Signatory) Approved Date: 07/02/2024 FCC ID: AZ489FT3856 / IC: 109U-89FT3856 Report ID: P41384-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.33 Page 2 of 14 Appendix D System Verification Check Scans FCC ID: AZ489FT3856 / IC: 109U-89FT3856 Report ID: P41384-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.33 Page 3 of 14 Table 13 FCC ID: AZ489FT3856 / IC: 109U-89FT3856 Report ID: P41384-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.33 Page 4 of 14 Appendix E DUT Scans FCC ID: AZ489FT3856 / IC: 109U-89FT3856 Report ID: P41384-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.33 Page 5 of 14 Highest SAR Configuration of LMR assessments at the FCC Body (150.8-173.4 MHz) Table 18 …

Text truncated - open the document above for the full version.
