ASTRO ® XTS TM 2500 Digital Portable Radio Model II User Guide ASTRO ® XTS™ 2500 Digital Portable Radio, Model IIQuick Reference Card Product Safety and RF Exposure Compliance ATTENTION! This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed wit h your radio (Motorola Publication part number 6881095C98) to ensure compliance with RF energy exposure limits.Write your radio’s programmed features on the dotted lines. Select a Zone Using the MenuSelect a ChannelMethod 1: Using the Select KnobAfter selecting the desired zone, turn the 16-position Select Knob to the desired channel.Method 2: Using the MenuSend an Emergency Alarm Send Silent Emergency AlarmAnswer a Phone CallSend a Phone Call Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio. ! C a u t i o n 16-Position Select Knob Speaker/Mic Top Button _ _ _ _ _ _ _ 3-Position Rotary Switch_ _ _ _ _ _ Display Home Button Menu Select Buttons Top Side Button_ _ _ _ _ _ _On/Off/Volume Knob Side Button 1_ _ _ _ _ _ _ Side Button 2_ _ _ _ _ _ _ PTT Button 4-Way Navigation Button App Button (for future use) 1Press U until 2Press D , E , or F directly below ZONE . 3Press U until the zone you desire is shown. 4Press h to confirm, or press PTT to transmit. 1Press U until 2Press D , E , or F directly below CHAN . 3Press U until channel you desire is shown. 4Press h to confirm, or press PTT to transmit. 1 Radio on and press Emergency button. You see red LED; you hear short, medium-pitched tone. 2 Display shows . 3 When acknowledgment is received, you hear four tones; alarm ends; radio exits emergency. ZONECHAN EMERGENCY 1 Radio on and press Emergency button. You see no LED; you hear no tone. 2Press PTT . 3 Alarm continues until you exit by: • Press and hold Emergency button for one second OR• Press PTT again. 1 Phone-like ringing, LED flashes GREEN, PHONE CALL and m are displayed 2Press Call Response button. 3Press PTT button to talk; release to listen 4Press h to hang up. 1Press U until 2Press D , E , or F directly below . 3Press U or V to scroll to phone number. 4Press PTT (or Quick Access button, if programmed) to talk, release to listen. PHON Display Status Symbols Menu Entries (Use With Menu Navigation)*Available at a future date. Call Received . Receiving an individual callView/Program Mode . The radio is in the view or program mode; On Steady = view mode; Flashing = program mode s Received Signal Strength Indication (RSSI) . Received signal strength for the current site (trunking only). The more stripes in the symbol, the stronger the signal. b Battery• Conventional = Flashes when the battery is low. • Smart = The number of bars (0-3) shown indicates the charge remaining in your battery. Note: Smart battery will be available at a future date. r Talkaround . You are talking directly to another radio or through a repeater; On = direct; Off = repeater C Monitor (Carrier Squelch) . This channel is being monitored. T Scan. The radio is scanning a scan list m pp Entry Menu Selection Page BATT Smart Battery* 15 CALL Private Call 48 CHAN Select a Channel 22 CLCK Edit Time and Date 62 DIR Repeater/Direct 52 PAGE Call Alert Page 50 PHON Phone 43 Entry Menu Selection Page PWR TX Power Level 29 RPGM Reprogram Request 55 SCAN Scan On/Off 39 SITE Site Lock 59 TGRP Talkgroup Call 51 VIEW Viewing a List 37 ZONE Select a Zone 21 Menu Navigation U to find Menu Entry D , or E , or F directly below Menu Entry to select h to exit V or U to scroll through sub-list D , or E , or F directly below Menu Entry to select i ASTRO ® XTS™ 2500 Digital Portable Radio Model II User Guide 6881094C05-D MOTOROLA, the Stylized M Logo, ASTRO, and CommPort are registered in the U.S. Patent & Trademark Office. All other product or service names are the property of their respective owners. P25 radios contain technology patented by Digital Voice Systems, Inc. © Motorola, Inc. 2004. All Rights Reserved. Printed in the U.S.A. 4/15/04. Motorola, Inc. 8000 W. Sunrise Blvd. Ft. Lauderdale, FL 33322 ii This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below. DECLARATION OF CONFORMITY Per FCC CFR 47 Part 2 Section 2.1077(a) Responsible Party Name: Motorola, Inc. Address: 8000 West Sunrise Boulevard Plantation, FL 33322 USA Phone Number: 1-888-567-7347 Hereby declares that the product: Model Name: XTS 2500 conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a) Class B Digital Device As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. this device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. Note:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into a…

Text truncated - open the document above for the full version.

EXHIBIT 13B SHEET 1 FCC ID: AZ489FT4865 REQUEST FOR CONFIDENTIALITY Date: 19 th August 2004 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Application for Certification of Transmitter with FCC ID: AZ489FT4865 Dear Sir / Madam, Motorola is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. We are also requesting that the FCC mark Exhibit 3 (External Photos), 8 (Users Manual) and Exhibit 9, (Internal Photos) as Temporary Confidentiality as outlined in Public Notice DA 04-1705, dated June 15, 2004. This provision will give Motorola temporary confidentiality prior to product launch. Please mark Exhibits 4, 5, 10, and 12 as “Confidential” and Exhibit 3 (External Photos), 8 (Users Manual) and 9 (Internal Photos) as “Short-Term Confidential”. Contact me if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected]

Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 1 OF 12 EXHIBIT 3 EXTERNAL PHOTOGRAPHS Pursuant to 47 CFR 2.1033(c) 12 Figure 3-1: Front view of display and full keypad radio Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 2 OF 12 Figure 3-2: Front view of display and half keypad radio Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 3 OF 12 Figure 3-3: Front view of no display and no keypad radio Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 4 OF 12 Figure 3-4: Front view of XTS2250 radio Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 5 OF 12 Figure 3-5: Front view of MT1500 radio Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 6 OF 12 Figure 3-6: Back view of complete radio Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 7 OF 12 Figure 3-7: Right side (side connector) view of complete radio Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 8 OF 12 Figure 3-8: Left side (PTT) view of complete radio Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 9 OF 12 Safety Label Location FCC Label Location Figure 3-9: Rear view of radio showing FCC & Safety labels location Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 10 OF 12 Figure 3-10: Close-up view of FCC & RF Safety Label Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 11 OF 12 Whip NAE 6549AR (White) Helical NAE 6547AR (Green) Helical NAE 6546AR (Red) Figure 3-11: Types of Antenna Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 3 SHEET 12 OF 12 Model List Sales Model Number Name Plates Tanapa Number Descriptions H46QDF9PW6AN H46QDH9PW7AN H46QDH9PW7ANI H66QDC9PW5AN H66QDC9PW5AN H66QDC9PW5AN H67QDC9PW5AN H67QDC9PW5AN XTS2500 XTS2500 XTS2250 XTS1500 XTS1500 XTS1500 MT1500 MT1500 PMUE 2110A PMUE2111A PMUE2285A PMUE2289A PMUE2290A PMUE2291A PMUE2292A PMUE2293A 380-470 MHz, 12.5/25 kHz 1-5 Watt ASTRO25, 255 Channels, 3x2 keypad, 6-line display (Model 2) 380-470 MHz, 12.5/25 kHz 1-5 Watt ASTRO25, 255 Channels, 3x6 keypad, 6-line display (Model 3) 380-470 MHz, 12.5/25 kHz 1-5 Watt ASTRO25, 255 Channels, 3x6 keypad, 6-line display (Model 3) 380-470 MHz, 12.5/25 kHz 1-5 Watt 9600 ASTRO25 Digital Trunking, 16 Channels No keypad, no display, grey 380-470 MHz, 12.5/25 kHz 1-5 Watt 3600 Analog and Digital Trunking, 16 Channels No keypad, no display, grey 380-470 MHz, 12.5/25 kHz 1-5 Watt P25 Digital Conventional, 16 Channels No keypad, no display, grey 380-470 MHz, 12.5/25 kHz 1-5 Watt MDC 1200 Analog Conventional, 48 Channels No keypad, no display, grey 380-470 MHz, 12.5/25 kHz 1-5 Watt 3600 Analog Trunking, 48 Channels No keypad, no display, grey

Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 1 SHEET 1 OF 1 EXHIBIT 1 IDENTIFICATION LABEL Pursuant to 47 CFR 2.925(a), 2.1033(c), 2.0165 EXHIBIT 1A - LABEL LOCATION A nameplate of the type presented below will be affixed to every transmitter. It will be placed on the bottom of the unit near the front. Shown below is a photo of the actual label affixed to the cast chassis of the transmitter. Figure 1-1: FCC Label EXHIBIT 1B - GENERAL INFORMATION 1. Application References: TIA/EIA-603B Land Mobile FM or PM Communications Equipment Measurement and Performance Standards Code of Federal Regulations Title 47, Part 2, Sec. 2.1033-2.1057, Sec. 2.1077(a), Part 80 and Part 90, Section 90.210. 2. Data Submittal Procedure: Data is supplied in accordance with Part 2, Sub-part J of the Commission’s rules. The intended use of this transceiver includes applications covered in the Code of Federal Regulations Title 47, Part 80 and Part 90. Maximum transmitter power shall not be adjustable by the user. 3. Applicable Reference • Reference Certification FCC ID: AZ489FT4865 • EIA/TIA-603 Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. • FCC Federal Regulations Part 47 Sec. 2.1033-2.1057 • FCC Federal Regulations Part 80, Marine Application • FCC Federal Regulations Part 90 Sec.90.210

Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 9 SHEET 1 OF 3 EXHIBIT 9 INTERNAL PHOTOGRAPHS Pursuant to 47 CFR 2.1033(c)12 Figure 9-1: Top Side of PCB (with shields) Figure 9-2: Top Side of PCB (without shields) Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 9 SHEET 2 OF 3 Figure 9-3: Bottom Side of PCB (with shields) Figure 9-4: Bottom Side of PCB (without shields) Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 9 SHEET 3 OF 3 Figure 9-5: Top View of chassis. Figure 9-6: Bottom View of chassis.

CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 1 of 22 CGISS EME Test Laboratory 8000 West Sunrise Blvd Fort Lauderdale, FL. 33322 S.A.R. EME Compliance Test Report Part 1 of 2 Note: Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 2.0 of this report. Signature on file 8/9/04 ____________________________________________________________ _________________________ Ken Enger Date Approved Senior Resource Manager, Laboratory Director, CGISS EME Lab Note: This report shall not be reproduced without written approval from an officially designated representative of the Motorola EME Laboratory. Certificate Number: 1449-01 Date of Report: August 6, 2004 Report Revision: Rev. O Manufacturer: Motorola Product Description: XTS Portable UHF digital; 380-470MHz, 1.0-5.0 watts nominal FCC ID: AZ489FT4865 Device Model: H66QDC9PW5AN Test Period: 7/27/04 - 8/02/04 EME Tech: Ed Church Responsible Eng: Deanna Zakharia (Elect. Principle Staff Eng.) Author: Michael Sailsman (Global EME Regulatory Affairs Liaison) CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 2 of 22 TABLE OF CONTENTS Part 1 of 2 1.0 Introduction 2.0 Reference Standards and Guidelines 3.0 Description of Test Sample 3.1 Test Signal 3.2 Test Output Power 4.0 Description of Test Equipment 4.1 Description of S.A.R Measurement System 4.2 Description of Phantom 4.2.1 Flat Phantom 4.2.2 SAM phantom 4.3 Simulated Tissue Properties 4.3.1 Type of Simulated Tissue 4.3.2 Simulated Tissue Composition (System Performance) 4.4 Test conditions 5.0 Probe Scan Procedures 5.1 Shortened scan rationale 5.2 Description of Test Procedure 5.3 Device Test Positions 5.3.1 Body 5.3.2 Head 5.3.3 Face 5.4 Test Position Photographs 6.0 Measurement Uncertainty 7.0 S.A.R. Test Results 7.1 S.A.R. results 7.2 Peak S.A.R. location 7.3 Highest S.A.R. results calculation methodology 8.0 Conclusion Part 2 of 2 Appendix A: Power Slump Data/Shortened scan Appendix B: Data Results Appendix C: Dipole System Performance Check Results Appendix D: Calibration Certificates Appendix E: Illustration of Body-worn Accessories Appendix F: Accessories and options test status and separation distances CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 3 of 22 REVISION HISTORY Date Revision Comments 8/9/04 O Release of Pilot results CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 4 of 22 1.0 Introduction This report details the utilization, test setup, test equipment, and test results of the Specific Absorption Rate (S.A.R.) measurements performed at the CGISS EME Test Lab for model number H66QDC9PW5AN, FCC ID: AZ489FT4865. The applicable exposure environment is Occupational/Controlled. 2.0 Reference Standards and Guidelines This product is designed to comply with the following national and international standards and guidelines. • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • IEEE 1528, 2003 "Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques" • American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Terminal frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation - Human Exposure) Standard 2003 • ANATEL, Brazil Regulatory Authority, Resolution No. 303 of July 2, 2002 "Regulation of the limitation of exposure to electrical, magnetic, and electromagnetic fields in the radio frequency range between 9KHz and 300 GHz." and “Attachment to resolution # 303 from July 2, 2002” CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 5 of 22 3.0 Description of Test Sample FCC ID: AZ489FT4865 is capable of APCO 25 (C4FM) digital voice frequency modulated PTT device. The intended operating positions are “at the face” with the DUT 1 to 2 inches from the mouth, and “at the body” by means of the offered body-worn accessories. Audio and PTT operation while the radio is at the body is accomplished by means of optional remote accessories that connect to the radio. The maximum transmit duty cycle is a conservative 50% and is controlled by the user via the PTT function. This device will be marketed to and used by employees solely for work-related operations, such as public safety agencies, e.g. police, fire and emergency medical. User training is the responsibility of these agencies, which can be expected to employ the usage instructions, safety information and operational cautions set forth in the user's manual, instructional sessions or other means. Motorola also makes available to its customers training classes on the proper use of two-way radios and wireless data devices. FCC ID: AZ489FT4865 is capable of operating in the 380-470 MHz band. The nominal conducted output power is 1 to 5 watts and the maximum conducted output power is 5.9 watts. The stated maximum output powers are as defined by the upper limit of the production line final test station. CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 6 of 22 FCC ID: AZ489FT4865 is offered with the following options and accessories: Antenna Description NAE6549AR ¼ wave Whip antenna; 380-520 MHz; 13.3 cm; -5.15 dBi NAE6547AR ¼ wave Helical antenna; 435-470 MHz; 7.8 cm; -8.0 dBi NAE6546AR ¼ wave Helical antenna; 380-435 MHz; 8.3 cm; -7.0 dBi Batteries NTN9857A 1800 mAh NiMH Ultra-Hi capacity FM Intrinsically Safe NTN9816A 1525 mAh NiCad high capacity FM Intrinsically Safe NTN9815A 1525 mAh NiCad high capacity NTN9858A 1800 mAh NiMH Ultra-high capacity NTN…

Text truncated - open the document above for the full version.

42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 1 of42 CGISS EME Test Laboratory 8000 West Sunrise Blvd Fort Lauderdale, FL. 33322 S.A.R. EME Compliance Test Report Part 2 of 2 Note: Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 2.0 of this report. Signature on File 8/9/04 ____________________________________________________________ _________________________ Ken Enger Date Approved Senior Resource Manager, Laboratory Director, CGISS EME Lab Note: This report shall not be reproduced without written approval from an officially designated representative of the Motorola EME Laboratory. Certificate Number: 1449-01 Date of Report: August 6, 2004 Report Revision: Rev. O Manufacturer: Motorola Product Description: XTS Portable UHF digital; 380-470MHz, 1.0-5.0 watts nominal FCC ID: AZ489FT4865 Device Model: H66QDC9PW5AN Test Period: 7/27/04 - 8/02/04 EME Tech: Ed Church Responsible Eng: Deanna Zakharia (Elect. Principle Staff Eng.) Author: Michael Sailsman (Global EME Regulatory Affairs Liaison ) 42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 2 of42 APPENDIX A Power Slump Data/Shortened Scan 42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 3 of42 DUT Power versus time data 42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 4 of42 Shortened Scan Results FCC ID: AZ489FT4865; Test Date: 7/30/04 Motorola CGISS EME Laboratory Run #: EC-Ab-R1-040730-23 Model #: H66QDC9PW5AN SN: 407TDY7007 TX Freq: 407.225 MHz Sim Tissue Temp: 20.4 (Celsius) Start Power : 6.09 W Antenna: NAE6546AR Battery Kit: NTN9857B Carry Acc: HLN6853A Audio/Data Acc.: NTN1625A Shortened scan reflect highest S.A.R. producing configuration; Run time 7 minutes. Representative “normal” scan run time was 26 minutes “Shortened” scan max calculated S.A.R. using S.A.R. drift: 1-g Avg. = 5.96 mW/g; 10-g Avg. = 4.29mW/g “Normal” scan max calculated S.A.R. using S.A.R. drift: 1-g Avg. = 5.57mW/g; 10-g Avg. = 4.03mW/g (see section 7.1 run # EC-Ab-R1-040730-22) DUT with belt clip against phantom Flat Phantom; Device Section; Position: (90°,90°); Probe: ET3DV6 - SN1384(Cal Date 27 May 04); ConvF(7.60,7.60,7.60); Probe cal date: 27/5/04; Crest factor: 1.0; FCC Body 425 MHz: σ = 0.93 mho/m ε = 55.4 ρ = 1.00 g/cm3; DAE SN: 363 DAE Cal Date: 05/26/04 Cube 5x5x7: SAR (1g): 10.8 mW/g, SAR (10g): 7.77 mW/g, (Worst-case extrapolation) Cube 5x5x7: Dx = 8.0, Dy = 8.0, Dz = 5.0; SAR (1g): 10.8 mW/g, SAR (10g): 7.77 mW/g Power Drift: -0.43 dB 42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 5 of42 FCC ID: AZ489FT4865; Test Date: 8/02/04 Motorola CGISS EME Laboratory Run #: DZ-Face-R1-040802-03 Model #: H66QDC9PW5AN SN: 407TDY7007 TX Freq: 407.225 MHz Sim Tissue Temp: 21.1 (Celsius) Start Power: 6.11 W Antenna: NAE6546AR Battery Kit: NTN9857B Carry case: None Audio/Data Acc.: None Shortened scan reflect highest S.A.R. producing configuration; Run time 7 minutes. Representative “normal” scan run time was 26 minutes “Shortened” scan max calculated S.A.R. using S.A.R. drift: 1-g Avg. = 4.12 mW/g; 10-g Avg. = 3.06mW/g “Normal” scan max calculated S.A.R. using S.A.R. drift: 1-g Avg. = 4.17mW/g; 10-g Avg. = 3.10mW/g (see section 7.1 run # DZ-Face-R1-040802-02) DUT with front towards the phantom with 2.5cm separation Flat Phantom; Device Section; Position: (90°,90°); Probe: ET3DV6 - SN1384(Cal Date 27 May 04); ConvF(7.60,7.60,7.60); Probe cal date: 27/5/04; Crest factor: 1.0; IEEE Head 425 MHz: σ = 0.86 mho/m ε = 45.1 ρ = 1.00 g/cm3; DAE SN: 363 DAE Cal Date: 05/26/04 Cube 5x5x7: SAR (1g): 8.23 mW/g, SAR (10g): 6.11 mW/g, (Worst-case extrapolation) Cube 5x5x7: Dx = 8.0, Dy = 8.0, Dz = 5.0; SAR (1g): 8.23 mW/g, SAR (10g): 6.11 mW/g Power Drift: 0.01 dB 42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 6 of42 APPENDIX B Data Results 42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 7 of42 FCC ID: AZ489FT4865; Test Date: 7/30/04 Motorola CGISS EME Laboratory Run #: EC-Ab-R1-040730-22 Model #: H66QDC9PW5AN SN: 407TDY7007 TX Freq: 407.225 MHz Sim Tissue Temp: 20.4 (Celsius) Start Power: 6.16 W Antenna: NAE6546AR Battery Kit: NTN9857B Carry Acc: HLN6853A Audio/Data Acc.: NTN1625A DUT with belt clip against the phantom Flat Phantom; Device Section; Position: (90°,90°); Probe: ET3DV6 - SN1384(Cal Date 27 May 04); ConvF(7.60,7.60,7.60); Probe cal date: 27/5/04; Crest factor: 1.0; FCC Body 425 MHz: σ = 0.93 mho/m ε = 55.4 ρ = 1.00 g/cm3; DAE SN: 363 DAE Cal Date: 05/26/04 Cube 7x7x7: SAR (1g): 8.63 mW/g, SAR (10g): 6.24 mW/g * Max outside, (Worst-case extrapolation) Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0; Max at 24.0, 135.0, 4.7 Power Drift: -1.11 dB Note: “Max outside” has been identified by SPEAG as an unresolved intermittent occurrence with the DASY 3 application even when the entire peak area is captured. 42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 8 of42 FCC ID: AZ489FT4865; Test Date: 8/2/04 Motorola CGISS EME Laboratory Run #: DZ-Face-R1-040802-02 Model #: H66QDC9PW5AN SN: 407TDY7007 TX Freq: 407.225 MHz Sim Tissue Temp: 20.9 (Celsius) Start Power : 6.15 W Antenna: NAE6546AR Battery Kit: NTN9857B Carry Acc: NONE Audio/Data Acc.: NONE DUT with front towards the phantom with 2.5cm separation Flat Phantom; Device Section; Position: (90°,90°); Probe: ET3DV6 - SN1384(Cal Date 27 May 04); ConvF(7.60,7.60,7.60); Probe cal date: 27/5/04; Crest factor: 1.0; IEEE Head 425 MHz: σ = 0.86 mho/m ε = 45.1 ρ = 1.00 g/cm3; DAE SN: 363 DAE Cal Date: 05/26/04 Cube 5x5x7: SAR (1g): 7.63 mW/g, SAR (10g): 5.67 mW/g, (Worst-case extrapolation) Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0; Max at 52.5, 144.0, 4.7 Power drift: -0.39 dB 42 CGISS EME Form-SAR-Rpt-Rev. 3.00 Page 9 of42 APPENDIX C Dipole System Performance Check Results Dipole validation scans at the head from SPEAG are provided in APPENDIX D. The CGISS EME lab validated the dipole to the applicable IEEE system performance targets. Within the same day system validation was pe…

Text truncated - open the document above for the full version.

English Product Safety and RF Energy Exposure Booklet for Portable Two-Way Radios The information provided in this document supersedes the general safety information contained in user guides published prior to February 2002. BEFORE USING THIS RADIO, READ THIS BOOKLET WHICH CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL INFORMATION AND OPERATIONAL INSTRUCTIONS FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND INTERNATIONAL STANDARDS. ALSO READ THE OPERATIONAL INSTRUCTIONS FOR SAFE USAGE. FOR RADIOS THAT HAVE BEEN APPROVED AS INTRINSICALLY SAFE, READ THE INSTRUCTIONS AND INFORMATION ON INTRINSIC SAFETY ON PAGE 10 OF THIS BOOKLET. ! C a u t i o n © Motorola, Inc. 2004 8000 W. Sunrise Blvd., Ft. Lauderdale, FL 33322 Printed in U.S.A. 5/04. *6881095C98* 68P81095C98-B 2 English RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use NOTICE: This radio is intended for use in occupational/controlled conditions where users have full knowledge of their exposure and can exercise control over their exposure to meet the occupational limits in FCC and International standards. This radio device is NOT authorized for general population consumer use. This two-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. It uses radio frequency (RF) energy or radio waves to send and receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to, sunlight and x-rays. RF energy, however, should not be confused with these other forms of electromagnetic energy, which when used improperly, can cause biological damage. Very high levels of x-rays, for example, can damage tissues and genetic material. Experts in science, engineering, medicine, health, and industry work with organizations to develop standards for safe exposure to RF energy. These standards provide recommended levels of RF exposure for both workers and the general public. These recommended RF exposure levels include substantial margins of protection. All Motorola two-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In addition, manufacturers also recommend specific operating instructions to users of two-way radios. These instructions are important because they inform users about RF energy exposure and provide simple procedures on how to control it. 3 English Please refer to the following websites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits: http://www.fcc.gov/oet/rfsafety/rf-faqs.html http://www.osha.gov/SLTC/radiofrequencyradiation/index.html Federal Communication Commission (FCC) Regulations The FCC rules require manufacturers to comply with the FCC RF energy exposure limits for portable two-way radios before they can be marketed in the U.S. When two-way radios are used as a consequence of employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure awareness can be facilitated by the use of a product label directing users to specific user awareness information. Your Motorola two-way radio has a RF Exposure Product Label. Also, your Motorola user manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Compliance with RF Exposure Standards Your Motorola two-way radio is designed and tested to comply with a number of national and International standards and guidelines (listed below) for human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/controlled RF exposure environments at operating duty factors of up to 50% talk-50% listen and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with these exposure guidelines, your radio generates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. NOTE:The approved batteries, supplied with this radio, are rated for a 5-5-90 duty factor (5% talk-5% listen-90% standby) even though this radio complies with FCC occupational exposure limits and may operate at duty factors of up to 50% talk. 4 English Your Motorola two-way radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation – Human Exposure) Standard, 2003 • ANATEL ANNEX to Resolution No. 303 of July 2, 2002 "Regulation of limitation of exposure to electrical, magnetic and electromagnetic fields in the radio frequency range between 9 KHz and 300 GHz" and "Attachment to resolution # 303 from July 2, 2002" RF Exposure Compliance and Control Guidelines and Operating Instructions To control your exposure and ensure compliance with the occupational/controlled environment exposure limits, always adhere to the following procedures. Guidelines: • Do not remove the RF Exposure Label from the device. • User awareness instructions should accompany device when transferred to other users. • Do not use this device if the operational requirements described herein are…

Text truncated - open the document above for the full version.

Applicant: Motorola Inc. FCC ID: AZ489FT4865 EXHIBIT 6 SHEET 1 OF 37 EXHIBIT 6 INDEX OF SUBMITTED MEASURED DATA This exhibit contains …
