AZ489FT4903BLUETOOTH TRANSMITTER

APX™ Two-Way Radios APX 6000User GuideModel 3 English mASTRO ® APX™ 6000 Series Digital Portable RadiosQuick Reference Card Product Safety and RF Exposure Compliance ATTENTION! This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C98) to ensure compliance with RF energy exposure limits. Radio Controls Radio On/OffZones and Channels Receiving and TransmittingSending an Emergency Alarm To exit emergency at any time, press and hold the Emergency button. Sending an Emergency Call Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio. !  Top (Orange) Button__________ 2-Position Concentric Switch__________ Main Display Keypad Menu Select Buttons 3-Position A/B/C Switch __________ 4-Way Navigation Button Accessory Connector Home Button Microphone Data Feature Button • On – On/Off/Volume knob clockwise. • Off – On/Off/Volume knob counterclockwise. • Zone – Zone switch to desired zone. • Channel – Channel switch to desired channel. Battery Side Button 1__________Side Button 2__________ PTT Button On/Off/Volume Control Knob 16-Position Select Knob __________ Top Side (Select) Button__________ Main Speaker Microphone Antenna Bluetooth Pairing Indicator Top Display 1 Select zone/channel. 2 Listen for a transmission.ORPress and hold Volume Set button. ORPress Monitor button and listen for activity. 3 Adjust volume, if necessary. 4 Press the PTT button to transmit; release to receive. 1 Press the Emergency button. 2 The display shows Emergency and the current zone/channel. A short, medium-pitched tone sounds, and the LED rapidly blinks red. 3 When acknowledgment is received, you hear four beeps; alarm ends; and radio exits emergency. 1 Press the Emergency button. *PMLN5717A* PMLN5717A © 2010 by Motorola, Inc. All Rights Reserved. 12/101301 E. Algonquin Rd., Schaumburg,IL 60196-1078, U.S.A. English Menu Navigation < or > to Menu Entry. { , | , or } directly below Menu Entry to select. H to exit. U or D to scroll through sub-list. { , | , or } directly below Menu Entry to select. To exit emergency at any time, press and hold the Emergency button. Sending a Silent Emergency Call To exit emergency at any time, press and hold the Emergency button. Display Status Icons 2 Press and hold the PTT button. Speak clearly into the microphone. 3 Release the PTT button to end call. 4 Press and hold Emergency button to exit emergency. 1 Press the Emergency button. 2 The display does not change; the LED does not light up, and there is no tone. 3 Silent emergency continues until you:Press and hold the Emergency button to exit emergency state.ORPress and release the PTT button to exit the Silent Emergency Alarm mode and enter regular dispatch or Emergency Call mode. Receiving a call or dataTransmitting a call or dataReceived an Individual Call.Blinks when the battery is low. u t F 8 The more stripes, the stronger the signal strength for the current site (trunking only).Direct radio to radio communication or connected through a repeater.On = Direct Off = Repeater This channel is being monitored.L = Radio is set at Low power. H = Radio is set at High power. Scanning a scan list.Blinking dot = Detects activity on the Priority-One Channel during scan. Steady dot = Detects activity on the Priority-Two Channel during scan. The vote scan feature is enabled. v O M H OR . i j k On steady = View mode Blinking = Program mode On = Secure operation. Off = Clear operation. Blinking = Receiving an encrypted voice call. On = AES Secure operation. Off = Clear operation. Blinking = Receiving an encrypted voice call.On = Location feature enabled, and location signal available. Off = Location feature disabled. Blinking = Location feature enabled, but location signal unavailable.On = User is currently associated with the radio. Off = User is currently not associated with the radio. Blinking = Device registration or user registration with the server failed due to an invalid username or pin.Data activity is present.Bluetooth is ready.Bluetooth is connected to the device. m l G no b a Declaration of Conformity English i Declaration of Conformity This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below. DECLARATION OF CONFORMITYPer FCC CFR 47 Part 2 Section 2.1077(a)Responsible Party Name: Motorola, Inc.Address: 1301 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A.Phone Number: 1-800-927-2744Hereby declares that the product: Model Name: APX 6000 conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a) Class B Digital DeviceAs a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Declaration of Conformity English ii Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct …

Text truncated - open the document above for the full version.

English Product Safety and RF Energy Exposure Booklet for Portable Two-Way Radios BEFORE USING THIS RADIO, READ THIS BOOKLET WHICH CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL INFORMATION AND OPERATIONAL INSTRUCTIONS FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND INTERNATIONAL STANDARDS. ALSO READ THE OPERATIONAL INSTRUCTIONS FOR SAFE USAGE. FOR RADIOS THAT HAVE BEEN APPROVED AS INTRINSICALLY SAFE, READ THE INSTRUCTIONS AND INFORMATION ON INTRINSIC SAFETY ON PAGE 11 OF THIS BOOKLET. Caution Motorola Solutions, Inc. 1303 E. Algonquin Rd., Schaumburg, IL 60196, U.S.A. *6881095C98* 6881095C98-F *NNTN7223C* NNTN7223C MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. © 2007 – 2011 Motorola Solutions, Inc. All rights reserved. 2 English RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use NOTICE: This radio is intended for use in occupational/controlled conditions where users have full knowledge of their exposure and can exercise control over their exposure to meet the occupational limits in FCC and International standards. This radio device is NOT authorized for general population consumer use. This two-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. It uses radio frequency (RF) energy or radio waves to send and receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to, sunlight and x-rays. RF energy, however, should not be confused with these other forms of electromagnetic energy, which when used improperly, can cause biological damage. Very high levels of x-rays, for example, can damage tissues and genetic material. Experts in science, engineering, medicine, health, and industry work with organizations to develop standards for safe exposure to RF energy. These standards provide recommended levels of RF exposure for both workers and the general public. These recommended RF exposure levels include substantial margins of protection. All Motorola two-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In addition, manufacturers also recommend specific operating instructions to users of two-way radios. These instructions are important because they inform users about RF energy exposure and provide simple procedures on how to control it. 3 English Please refer to the following websites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits: http://www.fcc.gov/oet/rfsafety/rf-faqs.html http://www.osha.gov/SLTC/radiofrequencyradiation/index.html Federal Communication Commission (FCC) Regulations The FCC rules require manufacturers to comply with the FCC RF energy exposure limits for portable two-way radios before they can be marketed in the U.S. When two-way radios are used as a consequence of employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure awareness can be facilitated by the use of a product label directing users to specific user awareness information. Your Motorola two-way radio has a RF Exposure Product Label. Also, your Motorola user manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Compliance with RF Exposure Standards Your Motorola two-way radio is designed and tested to comply with a number of national and International standards and guidelines (listed below) for human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/controlled RF exposure environments at operating duty factors of up to 50% talk-50% listen and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with these exposure guidelines, your radio generates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. 4 English NOTE:The approved batteries, supplied with this radio, are rated for a 5-5-90 duty factor (5% talk-5% listen-90% standby) even though this radio complies with FCC occupational exposure limits and may operate at duty factors of up to 50% talk. Your Motorola two-way radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission (FCC), Code of Federal Regulations; 47 CFR et seq. • FCC, OET Bulletin 65 • Institute of Electrical and Electronic Engineers (IEEE) C95.1 • International Commission on Non-Ionizing Radiation Protection (ICNIRP) • Ministry of Health (Canada) Safety Code 6 • Industry Canada RSS-102 • Australian Communications Authority Radiocommunications Standard et seq. • ANATEL ANNEX to Resolution No. 303 et seq. RF Exposure Compliance and Control Guidelines and Operating Instructions To control your exposure and ensure compliance with the occupational/controlled environment exposure limits, always adhere to the following procedures. Guidelines: • DO NOT remove the RF Exposure Label from the device. • User awareness instructions should accompany device when transferred to other users. • DO NOT use this device if the operational requirements described herein are not met. 5 English Operating Instructions • Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting 50% of the time, or less, is important because this radio generates measurable RF energy exposur…

Text truncated - open the document above for the full version.

FCC ID: AZ489FT4903 ______________________________________________________________________________ Motorola Solutions, Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 Date: 12 th September 2011 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT4903. Dear Sir or Madam: Motorola Solutions Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida, herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a Portable Radio environment with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: 450 – 520 MHz: 1.0 – 5.6 Watts (30 – 37.48 dBm) The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. Additionally, the radio is equipped with a Bluetooth transmitter capable of clear communications with fixed power operating within the following frequency ranges: 2402 – 2480 MHz: 0.009 Watts The Bluetooth transmitter complies with the requirements of FCC Part 15 subpart C. A complete application for certification is enclosed. Please contact Mike Ramnath at (954) 723-5793 if you require any additional information. Sincerely, Mike Ramnath (signed above) Manager, Regulatory Compliance Tel: (954) 723-5793 E-mail: [email protected] EXHIBIT 13a

FCC ID: AZ489FT4903 ______________________________________________________________________________ Motorola Solutions, Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. CONFIDENTIALITY REQUESTED 31 st August 2011 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT4903. Dear Sir or Madam: Motorola Solutions Inc (Motorola) is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Sections 0.457(d), 0.459 and 552(b)(4) of the Freedom of Information Act. This information is only for internal Motorola use and the use of dealers and service providers that have entered into confidential business agreements with Motorola. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, Mike Ramnath (signed above) Manager, Regulatory Compliance Tel: (954) 723-5793 E-mail: [email protected] EXHIBIT 13b

Applicant: Motorola Solutions FCC ID: AZ489FT4903 External Photographs The following photographs are attached. Exhibit 1. Front view with battery. 3A 2. Back view with battery. 3B 3. Front view with FCC Label. 3C 4. Side view (Right). 3D 5. Side view (Left). 3E 6. Top view (Controls). 3F EXHIBIT 3 Applicant: Motorola Solutions FCC ID: AZ489FT4903 FRONT VIEW WITH BATTERY EXHIBIT 3A Applicant: Motorola Solutions FCC ID: AZ489FT4903 BACK VIEW WITH BATTERY EXHIBIT 3B Applicant: Motorola Solutions FCC ID: AZ489FT4903 FRONT VIEW WITH FCC LABELS EXHIBIT 3C No Keypad/Display Limited Keypad Full Keypad/Display Applicant: Motorola Solutions FCC ID: AZ489FT4903 SIDE VIEW (RIGHT) EXHIBIT 3D Applicant: Motorola Solutions FCC ID: AZ489FT4903 SIDE VIEW (LEFT) EXHIBIT 3E Applicant: Motorola Solutions FCC ID: AZ489FT4903 TOP VIEW EXHIBIT 3F

Applicant: Motorola Solutions FCC ID: AZ489FT4903 Identification Label LOCATION See the Attached Photograph or Sketch X Back of Radio Back of Radio under Belt Clip TYPE X The label is a paper polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with minimum peel strength of 40 oz/inch. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3C for the actual location of the FCC label on the device. Label Attached Below. See Attached Drawing. APX6000 APX6000 APX6000 No Key pad/Display Limited Keypad Full Keypad/Display EXHIBIT 1A Applicant: Motorola Solutions FCC ID: AZ489FT4903 General Information I. Production Plans Quantity production is planned. II. Application References Reference is made to the following Motorola "Application References" 1. Portable Products and their application. 2. Portable Products Transmitter Modulations Methods. 3. Motorola EMC Laboratory-Plantation, Florida III. Data Submittal Procedure: Data is supplied in accordance with Part 2, Subpart J of the Commissions’ rules. IV. Applicable References: • Reference Certification FCC ID: AZ489FT4903 • RSS Gen, RSS102, RSS 119, RSS 210. • EIA/TIA-603 Land Mobile FM or PM Communications Equipment Measurement and Performance Standards • CFR 47, Rule Part 2, 15, and 90 EXHIBIT 1B

Applicant: Motorola Solutions FCC ID: AZ489FT4903 Internal Photographs The following photographs are attached. Exhibit 1. RF board with Shields (Top). 9A 2. RF board without Shields (Top). 9B 3. RF board with Shields (Bottom). 9C 4. RF board without Shields (Bottom). 9D 5. Vocon board with Shields (Top). 9E 6. Vocon board without Shields (Top). 9F 7. Vocon board with Shields (Bottom). 9G 8. Vocon board without Shields (Bottom). 9H 9. Expander board with Shields (Top). 9I 10. Expander board without Shields (Top). 9J 11. Expander board with Shields (Bottom). 9K 12. Expander board without Shields (Bottom). 9L EXHIBIT 9 Applicant: Motorola Solutions FCC ID: AZ489FT4903 RF board with Shields (Top) EXHIBIT 9A Applicant: Motorola Solutions FCC ID: AZ489FT4903 RF board without Shields (Top) EXHIBIT 9B Applicant: Motorola Solutions FCC ID: AZ489FT4903 RF board with Shields (Bottom) EXHIBIT 9C Applicant: Motorola Solutions FCC ID: AZ489FT4903 RF board without Shields (Bottom) EXHIBIT 9D Applicant: Motorola Solutions FCC ID: AZ489FT4903 Vocon board with Shields (Top) EXHIBIT 9E Applicant: Motorola Solutions FCC ID: AZ489FT4903 Vocon board without Shields (Top) EXHIBIT 9F Applicant: Motorola Solutions FCC ID: AZ489FT4903 Vocon board with shields (Bottom) EXHIBIT 9G Applicant: Motorola Solutions FCC ID: AZ489FT4903 Vocon board without shields (Bottom) EXHIBIT 9H Applicant: Motorola Solutions FCC ID: AZ489FT4903 Expander board with shields (Top) EXHIBIT 9I Applicant: Motorola Solutions FCC ID: AZ489FT4903 Expander board without shields (Top) EXHIBIT 9J Applicant: Motorola Solutions FCC ID: AZ489FT4903 Expander board with shields (Bottom) EXHIBIT 9K Applicant: Motorola Solutions FCC ID: AZ489FT4903 Expander board without shields (Bottom) EXHIBIT 9L

3998 FAU Blvd. Suite 310 Boca Raton, FL 33431 Tel: 561-961-5585 Fax: 561-961-5587 Certification Test Report FCC ID: AZ489FT4903 IC: 109U-89FT4903 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-2043.W06.11.A Manufacturer: Motorola Solutions, Inc. Model: APX 6000 UHF RANGE 2 Test Begin Date: July 2, 2011 Test End Date: July 11, 2011 Report Issue Date: July 15, 2011 FOR THE SCOPE OF ACCREDITATION UNDER CERTIFICATE NUMBER AT-1533 This report must not be used by the client to claim product certification, approval, or endorsement by ACLASS, ANSI, or any agency of the Federal Government. Project Manager: Reviewed by: Thierry Jean-Charles Kirby Munroe EMC Engineer Director, Wireless Certifications Advanced Compliance Solutions, Inc. Advanced Compliance Solutions, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 60 pages 3998 FAU Blvd. Suite 310 Boca Raton, FL 33431 Tel: 561-961-5585 Fax: 561-961-5587 TABLE OF CONTENTS 1 GENERAL ...................................................................................................... 3 1.1 Purpose .............................................................................................................................................. 3 1.2 Manufacturer Information .............................................................................................................. 3 1.3 Product description .......................................................................................................................... 3 1.4 Test Methodology and Considerations ........................................................................................... 4 1.5 Emission Designators ....................................................................................................................... 4 2 TEST FACILITIES .......................................................................................... 5 2.1 Location ............................................................................................................................................. 5 2.2 Laboratory Accreditations/Recognitions/Certifications ............................................................... 5 2.3 Radiated & Conducted Emissions Test Site Description .............................................................. 6 3 APPLICABLE STANDARD REFERENCES ................................................... 7 4 LIST OF TEST EQUIPMENT .......................................................................... 8 5 SUPPORT EQUIPMENT ................................................................................ 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM .............................. 9 7 SUMMARY OF TESTS ................................................................................. 10 7.1 Antenna Requirement – FCC: Section 15.203 ............................................................................. 10 7.2 Power Line Conducted Emissions – FCC: Section 15.207 IC: RSS-Gen 7.2.2 .......................... 11 7.3 Radiated Emissions – FCC: Section 15.109(Unintentional Radiation) IC: RSS-210 2.6 .......... 13 7.4 Peak Output Power - FCC Section 15.247(b) (2) IC: RSS-210 A8.4 (1)..................................... 14 7.5 Channel Usage Requirements ........................................................................................................ 15 7.6 Band-Edge Compliance and Spurious Emissions-FCC 15.247d IC: RSS-210 2.6, A8.5 .......... 30 8 CONCLUSION .............................................................................................. 59 Model: APX 6000 UHF RANGE 2 FCC ID: AZ489FT4903 IC: 109U-89FT4903 ACS Report: 11-2043.W06.11.A Advanced Compliance Solutions Page 3 of 60 1 GENERAL 1.1 Purpose The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations and Industry Canada’s Radio Standards Specification RSS-210. 1.2 Manufacturer Information Motorola Solutions, Inc. 8000 West Sunrise Blvd. Plantation, FL 33322 1.3 Product description APX 6000 UHF RANGE 2 is a portable push-to-talk radio with Bluetooth 2.0 + EDR. Additional features consist of GPS, accelerometer, & secure audio. The EUT operates at a nominal power of 7.5VDC, 2A with a 50-ohm antenna load on UHF TX. The available modulation formats and operation characteristics of the Bluetooth radio are provided below. Table 1.3-1: Bluetooth Radio Properties Mode of Operation Frequency Range (MHz) Number of Channels Channel Separation (kHz) Data Rates Supported (kbps) GFSK 2402 - 2480 79 1000 1000 π/4-DQPSK 2402 - 2480 79 1000 2000 8DPSK 2402 - 2480 79 1000 3000 Model Number: UHF R2 Model 3.5: H98SDH9PW7AN Test Sample Serial Number(s): CAI110CKTGS, CAI110KTKG Test Sample Condition: Good Table 1.3-2: APX 6000 UHF RANGE 2 Model Variants Model Name Model Number Description Tested APX 6000 UHF RANGE 2 Model 3.5 H98SDH9PW7AN Front display, all front buttons Yes APX 6000 UHF RANGE 2 Model 2.5 H98SDF9PW6AN Front display, few front buttons ------ APX 6000 UHF RANGE 2 Model 1.5 H98SDD9PW5AN No front display, no front buttons ------ Model: APX 6000 UHF RANGE 2 FCC ID: AZ489FT4903 IC: 109U-89FT4903 ACS Report: 11-2043.W06.11.A Advanced Compliance Solutions Page 4 of 60 1.4 Test Methodology and Considerations The APX 6000 UHF RANGE 2, Model No. H98SDH9PW7AN, was tested to the applied test standards for the GFSK, π/4-DQPSK and 8DPSK modulation formats. Conducted power line emissions were performed on the EUT Hopping for all the available modulation formats and for the EUT in the receive mode. Results are provided for the configuration leading to the worst case emissions. For the radiated emissions, preliminary evaluations were performed for the EUT setup in three orthogonal orientations, corresponding to th…

Text truncated - open the document above for the full version.

Applicant: Motorola Solutions FCC ID: AZ489FT4903 EXHIBIT 7 Measurement Procedure & Test Equipment Used Except where otherwise stated, all measurements are made following the Electronic Industries Association (EIA) Minimum Standard for Portable/Personal Land Mobile Communications FM or PM Equipment 25-1000 MHz-(EIA/TIA-603). This exhibit presents a brief summary of how the measurements were made, the required limits, and the test equipment used. The following procedures are presented with this application. 1. Test Equipment List x 2. RF Power Output Data x 3. Audio Frequency Response x 4. Audio Low Pass Filter Response x 5. Modulation Limiting x 6. Occupied Bandwidth x 7. Radiated Spurious Emissions x 8. Conducted Spurious Emissions x 9. Power Line Conducted Emissions x 10. Frequency Stability (Volt/Temp) x 11. Transient Frequency Behavior x Applicant: Motorola Solutions FCC ID: AZ489FT4903 EXHIBIT 7 Test Equipment List Pursuant To FCC Rules 2.947 (d) MODEL MANUFACTURER Instrument 1 8901 Hewlett‐Packard MOD. ANALYZER 2 2670 MOTOROLA COMM ANALYZER 3 3052 TEKTRONIX O SCOPE 4 8657 Hewlett Packard SIGNAL GENERATOR 5 2042 IFR SIGNAL GENERATOR 6 3488 Hewlett‐Packard SWITCH CONTROL 7 8903B Hewlett‐Packard AUDIO ANALYZER 8 2041 IFR SIGNAL GENERATOR 9 PM2534 PHILLIPS MULTIMETER 10 11722A Hewlett‐Packard RF POWER SENSOR 11 SM8C THERMOTRON TEMP CHAMBER 12 6672 AGILENT POWER SUPPLY 13 3488A Hewlett‐Packard SWITCH CONTROL 14 6672A Hewlett‐Packard POWER SUPPLY 15 E4440 AGILENT SPECTRUM ANALYZER 16 8656A Hewlett‐Packard SIGNAL GENERATOR 17 8902A Hewlett‐Packard MEASURING RECEIVER 18 8903A Hewlett‐Packard AUDIO ANALYZER 19 8530W Hewlett‐Packard COMPUTER 20 E4402B AGILENT SPECTRUM ANALYZER 21 U8903A AGILENT AUDIO ANALYZER 22 6632B Hewlett‐Packard POWER SUPPLY 23 89441A Hewlett‐Packard SIGNAL ANALYZER 24 6033A Hewlett‐Packard POWER SUPPLY 25 8901B Hewlett‐Packard MOD. ANALYZER 26 8903B Hewlett‐Packard AUDIO ANALYZER 27 107 TEST EQUITY TEMP CHAMBER 28 4419B AGILENT POWER METER Applicant: Motorola Solutions FCC ID: AZ489FT4903 EXHIBIT 7 RF Power Output Pursuant to FCC Rules 2.1046 (a) Method of Measurement The RF power output is measured with the transmitter adjusted in accordance with the tune-up procedure outlined in Exhibit 10 to give the value of voltage and current as specified in Exhibit 12 as required by 2.1033(c) (8). A 50-ohm RF attenuator of proper power rating was used as a load for making these measurements. The power measurements are made using an Agilent series E4419B RF power meter and 30 dB attenuator. Audio Frequency Response Pursuant FCC Rules 2.1047 (a) Method of Measurement Operate the transmitter under standard test conditions and monitor the output with a frequency deviation meter or calibrated test receiver. With 1000 Hz sine wave audio input applied through a dummy microphone circuit, adjust the audio input to give 20% of full rated system deviation. Maintaining a constant input voltage, vary the input frequency from 300 to 3000 Hz, and observe the deviation. Minimum Standard The audio frequency response shall not vary more than +1 or -3 dB from 300 to 3000 Hz from a true 6 dB per octave pre-emphasis characteristic as referenced to 1000 Hz level, with the exception of a permissible 6 dB/octave roll off below 500 Hz. Equivalent to TIA/EIA 603 Section 5.2.6.2 mask. Audio Low Pass Filter Response Pursuant FCC Rules 2.1047 (a) Method of Measurement A Dynamic Signal Analyzer is used to sweep the response from 1kHz to 25kHz. The source of the analyzer is connected to the AUDIO IN port of the radio interface box. The audio input level is adjusted to produce a standard test modulation. The transmitter is operated under standard test conditions and the output of the Switch Cap Filter is monitored, with the post limiter low pass filter within the lineup. The output is connected to channel 2 of the analyzer and referenced to its input signal. A sinusoidal sweep from 1K to 25kHz will produce the frequency response of the low pass filter during TX mode. FCC Limits -- Per applicable rule parts. 450 to 869 MHz & VHF Marine. Frequencies between 3 kHz and 20 kHz shall be attenuated greater than the attenuation at 1 kHz by 60 1og 10 (f/3) dB. Frequencies above 20 kHz shall be attenuated at least 50 dB. Applicant: Motorola Solutions FCC ID: AZ489FT4903 EXHIBIT 7 Modulation Limiting Pursuant FCC Rules 2.1047 (b) Method of Measurement The transmitter shall be adjusted for full rated system deviation. Adjust the audio input for 60% of rated system deviation at 1000 Hz. Using this level as a reference (0 dB) vary the audio input level from the reference to a level 20 dB above it for modulation frequencies between 300 and 3000 Hz in 100Hz steps. Record the system deviation obtained as a function of the input level. FCC Limits Minimum Standard - The transmitter modulation must not exceed rated system deviation at any audio frequency input or reasonable change in input level. In the exhibit, 100% corresponds to the maximum rated system deviation for the given channel bandwidth. Occupied Bandwid…

Text truncated - open the document above for the full version.
