AZ489FT4961Consumer Radio 462-467 MHz with Weather band receiver

en-US fr - CA es - LA pt-BR 7$/.$%287 Š  7:2:$<  5$',2  7;7;  6(5,(6USER GUIDE Front Cover.fm Page 1 Wednesday, July 8, 2020 10:28 AM Front Cover.fm Page 2 Wednesday, July 8, 2020 10:28 AM 1 English SAFETY AND GENERAL INFORMATIONCautionBefore using this radio, read this booklet which contains important operating instructions. For information on product details, brochures, user manuals and approved accessories. Please refer to www.motorolasolutions.com . Compliance with RF Exposure Standards National and international regulations require manufacturers to comply with the RF energy exposure limits for portable two-way radios before they can be marketed. Your Motorola Solutions two-way radio is designed, manufactured, and tested to comply with all applicable national and international regulations for human exposure to radio frequency electromagnetic energy.RF Energy Exposure Awareness and Control Information and Operational Instructions for Gene ral Population and Uncontrolled Environment Use For more information on what RF energy exposure is, see the following websites:• https://www.fcc.gov/ • http://www.who.int/peh-emf/project/en/ • http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/ sf11467.html • http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/ sf01904.html For additional information, see https://www.motorolasolutions.com/en_us/about/company-overview/corporate-responsibility/governance-and-policies.html Operating Instructions• Transmit no more than 50% of the time. To transmit (talk), press the Push-To-Talk ( PTT ) button. To receive calls, release the PTT button. • Hold the radio in a vertical position in front of the face with the microphone (and other parts of the radio including the antenna) at least 1 in. (2.5 cm) away from the nose or lips. Antenna should be kept away from the eye. • When worn on the body, always place the radio in a Motorola Solutions-approved clip, holder, holster, case, or body harness for this product. • DO NOT hold the antenna when the radio is transmitting.• DO NOT use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result. • To ensure continued compliance with applicable RF exposure limits, use only Motorola Solutions-approved, supplied or replacement antennas, batteries, and accessories. • For a list of Motorola Solutions-approved accessories please refer to your user manual or visit www.motorolasolutions.com 01_MN006555A01_en-US.fm Page 1 Friday, July 10, 2020 1:17 PM 2 English Acoustic SafetyExposure to loud noises from any source for extended periods of time may temporarily or permanently affect your hearing. The louder the volume of the radio, the sooner your hearing will be affected. Hearing damage from loud noise is sometimes undetectable at first, and can have a cumulative effect.To protect your hearing, follow these precautions:• Use the lowest volume necessary to do your job.• Turn up the volume only if you are in noisy surroundings.• Turn down the volume before putting on a headset or headphones. • Limit the amount of time you use a headset or headphones at high volume. • When using the radio without a headset or headphones, do not place the speaker of the radio directly against your ear. Medical DevicesIf you use a personal medical device, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.Holsters Incorporating MagnetsSome Motorola Solutions holsters incorporate strong, neodymium magnets. If you use a personal medical device, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it can be used in close proximity to magnets. Your physician may be able to assist you in obtaining this information. Also be aware that magnets can damage other products, including cell phones, computers, hard drives, and other electronic devices, as well as credit cards and magnetic media. Keep the holster away from any mechanical device that could be affected by a magnetic field. Consult the manufacturer of your product to determine if your device or product can be used in close proximity to magnets. Operational WarningsThe following explains the operational warnings:For Vehicle With Air Bags Warning:• Refer to vehicle manufacturer's manual prior to installation of electronic equipment to avoid interference with air bag wiring. • DO NOT place a portable radio in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a portable radio is placed in the air bag deployment area and the air bag inflates, the radio may be propelled with great force and cause serious injury to occupants of the vehicle. ! W A R N I N G ! 01_MN006555A01_en-US.fm Page 2 Friday, July 10, 2020 1:17 PM 3 English Potentially Explosive Atmosphere s Blasting Caps and Blasting Areas Batteries • Caution : Risk of explosion if the battery is replaced by an incorrect type. • Use only Motorola Solutions approved batteries. • Charge your battery using the approved Motorola Solutions charger. • Use the battery in accordance with its water and/or dust Ingress Protection (IP) rating. • DO NOT discard your battery into a fire.• DO NOT replace the battery in any area labeled “Hazardous Atmosphere”. • DO NOT disassemble, crush, puncture, shred, or otherwise attempt to change the form of your battery. • DO NOT dry a wet or damp battery with an appliance or heat source, such as a hair dryer or microwave oven. • DO NOT allow conductive material such as jewelry, keys, or beaded chains to touch exposed battery terminals. • Do not dispose of batteries with household waste. Warning:• Use of a radio that is not intrinsically safe in a potentially explosive atmosphere could result in a serious injury, or death. You should only use a certified Intrinsically Safe radio in potentially explosive atmospheres. • Explosive at…

Text truncated - open the document above for the full version.

Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961/ IC: 109U-89FT4961 EXHIBIT 2 SHEET 1 OF 1 EXHIBIT 2 Statement of Certification (Pursuant to FCC Part 2.907, 2.908 and RSP 100 Sec 4) 2.1 Statement of Certification Transceiver type described herein (AZ489FT4961/109U-89FT4961) is in compliance with all applicable parts of the FCC rules and ISED RSS standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: WONG SONG KUI SIGNATURE: DATE: 15-June-2020 TITLE: SENIOR ENGINEERING PROJECT LEAD

FCC ID: AZ489FT4961 ___________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13A Date: August 4, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT4961 Dear Sir/Madam, Motorola Solutions Malaysia Sdn Bhd herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a portable radio application with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: Product Name Model Numbers Description Frequency Range RF Power T270 T270TP T271TP T27X T27X T27X T270 FRS CONSUMER RADIO 462-467MHZ BLUE T270TP FRS CONSUMER RADIO 462-467MHZ BLUE T271TP FRS CONSUMER RADIO 462-467MHZ YELLOW FRS: (Chl 1 – 7) 462.5625 – 462.7125MHz (Chl 8 – 14) 467.5625 – 467.7125MHz (Chl 15-22) 462.5500 – 462.7250MHz FRS: Chl 1-7, Chl 15-22 ERP: 0.98 W (max measured); 1 W (max declared) Chl 8-14 ERP: 0.48 W (max measured); 0.5 W (max declared) NOAA: 161.65 – 162.55 MHz RX Only Remark: NOAA is short form of National Oceanic and Atmospheric Administration. It is a national weather service in US. We are requesting certification under Part(s) of the Commission’s Rules listed above to allow operation of this equipment. The transmitter is intended for general populations under Part 95B of the FCC Rules. The subject transmitter complies with Section 95.337 and 95.363 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at +604-224 0258. Sincerely, Arine Lee FCC/IC Certification Manager E-email : [email protected]

FCC ID: AZ489FT4961 ___________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13B CONFIDENTIALITY REQUEST Date : August 4, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ489FT4961 Dear Sir / Madam, Motorola Solutions Malaysia Sdn Bhd is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d), 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, Arine Lee, FCC/IC Certification Manager E-mail : [email protected]

____________________________________________________________________________ Motorola Solutions Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 Certification Department Date: 4 August 2020 Subject: Application Authorization for FCC/IC filing To Whom It May Concern: I hereby authorize Arine Lee to apply, on my behalf, the application for the following FCC/IC ID: FCC/IC ID: AZ489FT4961 / 109U-89FT4961 Please contact me if there are any questions or issues. Regards, Deanna Zakharia Regulatory Compliance Manager Tel: (954) 723 4707 Email: [email protected]

Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 1 OF 15 EXHIBIT 3 EXTERNAL PHOTOGRAPHS (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. Front View 3A 2. Back View with Battery Cover and Belt Clip 3B 3. Back View (FCC/IC label location). 3C 4. Side View (Right) 3D 5. Side View (Left) 3E 6. Top View 3F 7. Bottom View 3G Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 2 OF 15 EXHIBIT 3A: Front View T27X Series Front View T270 and T270TP (Blue) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 3 OF 15 T27X Series Front View T271TP (Yellow) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 4 OF 15 EXHIBIT 3B: Back View with Battery Cover and Belt Clip T27X Series Back View T270 and T270TP (Blue) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 5 OF 15 T27X Series Back View T271TP (Yellow) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 6 OF 15 EXHIBIT 3C: Back View (FCC/IC label location) T27X Series T270 and T270TP (Blue) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 7 OF 15 T27X Series T271TP (Yellow) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 8 OF 15 EXHIBIT 3D: Side View (Right) T27X Series T270 and T270TP (Blue) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 9 OF 15 T27X Series T271TP (Yellow) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 10 OF 15 EXHIBIT 3E: Side View (Left) T27X Series T270 and T270TP (Blue) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 11 OF 15 T27X Series T271TP (Yellow) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 12 OF 15 EXHIBIT 3F: Top View T27X Series T270 and T270TP (Blue) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 13 OF 15 T27X Series T271TP (Yellow) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 14 OF 15 EXHIBIT 3G: Bottom View T27X Series T270 and T270TP (Blue) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 3 SHEET 15 OF 15 T27X Series T271TP (Yellow) *** END ***

Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 1 SHEET 1 OF 3 EXHIBIT 1 IDENTIFICATION LABEL (Pursuant to FCC Part 2.1033(c)(11), 2.1033(b)(7) and RSP 100 Annex C and Sec 3) LOCATION See the Attached Photograph or Sketch Bottom of Radio Top of Radio X Back of Radio Back of Radio under Belt Clip TYPE X The label is a poly carbonate film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with the minimum peel strength of 40 oz/inch. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3 for the actual location of the FCC/IC label on the device. X Label Attached Below. See Attached Drawing. Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 1 SHEET 2 OF 3 Figure 1: FCC/IC Label for T270&T270TP Applicant: Motorola Solutions Inc FCC ID: AZ489FT4961 / IC: 109U-89FT4961 EXHIBIT 1 SHEET 3 OF 3 Figure 2: FCC/IC Label for T271TP *** END ***

Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 1 EXHIBIT 9 Internal Photographs (Pursuant to FCC Part 2.1033(b)(7), 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. RF board with Shields (Front View) 9A 2. RF board without Shields (Front View) 9B 3. RF board with Shields (Back View) 9C 4. RF board without Shields (Back View) 9D 5. RF Board with Chassis and Housing (Front View) 9E 6. Chassis and Housing (Back View) 9F 7. Exploded View of Radio 9G Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 2 EXHIBIT 9A: RF board with Shields (Front View) T270 Blue/ T270TP Blue/T271TP Yellow (Note: All series using the same PCB) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 3 EXHIBIT 9B: RF board without Shields (Front View) T270 Blue/ T270TP Blue/T271TP Yellow (Note: All series using the same PCB) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 4 EXHIBIT 9C: RF board with Shields (Back View) T270 Blue/ T270TP Blue/T271TP Yellow (Note: All series using the same PCB) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 5 EXHIBIT 9D: RF board without Shields (Back View) T270 Blue/ T270TP Blue/T271TP Yellow (PCB with Weather IC) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 6 EXHIBIT 9E: RF Board with Chassis and Housing (Front View) T270/ T270TP (Blue) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 7 T271TP Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 8 EXHIBIT 9F: Chassis and Housing (Back View) T270 Blue/ T270TP Blue T271TP Yellow Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4961 / IC: 109U-89FT4961 Exhibit 9 Page | 9 EXHIBIT 9G: Exploded View of Radio T270 Blue/ T270TP Blue/T271TP Yellow (Note: All series same exploded view) *** END ***

Report Template Document Number : FCD-0085 Report ID: 21302-EMC-00007 Report Template Revision Number : Rev. L FCC ID: AZ489FT4961 IC: 109U-89FT4961 1 MOTOROLA PENANG ADV. COMM. LABORATORY FCC / ISED TEST REPORT Motorola Solutions Malaysia SDN BHD, Report Revision : Rev.A Plot 2A, Medan Bayan Lepas, Mukim 12 S.W.D, 11900 Bayan Lepas, Penang, Malaysia. : 1-June-2020 to 2-June-2020 : MOTOROLA SOLUTIONS MALAYSIA SDN BHD : PLOT 2A, MEDAN BAYAN LEPAS MUKIM 12, S.W.D 11900 BAYAN LEPAS PENANG, MALAYSIA : WONG SONG KUI : Portable : T27X (PMUE5688A) : 161.650-162.550MHz (Weather Channel) : 002 : N/A (Weather Channel) : Date/s Tested Manufacturer Manufacturer Address Requestor Product Type Model Number Frequency Band Firmware Version Max Output Power Applicant Name Applicant Address ISED Registrations FCC Registrations : : Motorola Solutions Inc 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. The equipment was tested accordance to the requirement listed below: FCC 47 CFR Part 15B / IC RSS-GEN PASS This report shall not be reproduced without written approval from an officially designated representative of the Motorola Penang Adv. Comm. Laboratory. The results and statements contained in this report pertain only to the device(s) evaluated. Prepared By: Approved By: _________________________ Azil Ezzaddin Khalil Technician ________________________ Vincent Foong Deputy Technical Manager : MY0001 461337 Report Template Document Number : FCD-0085 Report ID: 21302-EMC-00007 Report Template Revision Number : Rev. L FCC ID: AZ489FT4961 IC: 109U-89FT4961 2 Table of Contents 1.0. General Information ............................................................................................................................ 3 2.0. Summary of Test Results..................................................................................................................... 3 3.0. Measurement Uncertainty .................................................................................................................... 4 4.0. Equipment List .................................................................................................................................... 5 5.0. Test Condition..................................................................................................................................... 7 5.1 Receiver Test Conditions .............................................................................................................. 7 6.0. Receiver Test Parameters .................................................................................................................... 8 6.1. Conducted Spurious Output Power ...................................................................................................... 8 6.1.1. Test Setup ............................................................................................................................ 8 6.1.2. Test Result ........................................................................................................................... 8 6.1.3. Test Limit ............................................................................................................................ 8 6.2. Radiated Spurious Output Power ......................................................................................................... 9 6.2.1. Test Setup ............................................................................................................................ 9 6.2.2. Test Result ......................................................................................................................... 10 6.2.3. Test Limit .......................................................................................................................... 14 6.3. AC Power Line Conducted Spur Emissions ....................................................................................... 15 6.3.1. Test Setup .......................................................................................................................... 15 6.3.2. Test Result ......................................................................................................................... 16 6.3.3. Test Limits ........................................................................................................................ 17 7.0. Appendix: Test Setup Photo .............................................................................................................. 18 7.1. Conducted Spur Emission ATE Station Setup ................................................................................. 18 7.2. Radiated Spur Emission Station Setup ............................................................................................ 18 7.3. AC Power Line Conducted Emission Station Setup ........................................................................ 18 7.4. Photographs – EUT ........................................................................................................................... 19 REVISION HISTORY Revision History Description Date Originator Rev. A Initial Report 3-June-2020 Azil Ezzaddin Khalil Report Template Document Number : FCD-0085 Report ID: 21302-EMC-00007 Report Template Revision Number : Rev. L FCC ID: AZ489FT4961 IC: 109U-89FT4961 3 1.0. General Information EUT Description: Technologies Land Mobile Radio (LMR) Modulation Type Analog The EUT contains following accessory devices and data cable: Item Brand Model or P/N AA ALKALINE Battery NA NA General Description of Applied Standards The EUT is a RF Product. According to the specifications of the manufacturer, the EUT is to comply with the requirements of the following standards: ANSI C63.4.2014 2.0. Summary of Test Results FCC General Rules Part (47CFR) IC General Rules Part Test Item Result 15.111 RSS-Gen 7.4 Conducted Spurious Output Power NA 15.109 RSS-Gen 7.3 Radiated Spurious Output Power Pass 15.107 RSS-Gen 7.2 AC Power Conducted Spurious E…
