Installing and Charging Batteries1. Turn off the radio.2. Observe for polarity before installing the batteries.3. Charge the battery by using the standard USB power source.4. Charging is complete when the battery icon on the radio stops blinking. Charging takes up to 8 hours. Notes:• You can use Alkaline AA batteries.• Motorola Solutions recommends that you use only the battery that comes with your radio. Otherwise, your radio might sink. Inserting and Removing a Belt Clip • To perform the required actions, follow the numbering in the image. Turning the Radio On and Off • Hold the Mode Switch/Power button until the display turns on or off. Channels and Sub Codes • You must set your radios with the same channel and sub code setting to enable communication with other radios. • The channel setting controls the radio frequency. To avoid jamming, you can select a channel that is not used by others in your area. For more information on selecting unused channel, see Scan in Table 2. • Match the sub code setting on the transmitt ing and receiving radios. Otherwise, the receiving radio blocks the received sig nals. This feature helps you to mute unwanted voices from other radio users transmitting on your channel. • When sub code is set to zero, radio does not block any signals. Everything that is picked up on the channel is sent to the speaker. Motorola Solutions recommends setting your sub code to zero if you are using T600 series radios with radios that do not support the sub code feature. For detailed instructions on ways to change set-tings, see Menu Navigation on page 2.You can copy channel and sub code settings from one radio to multiple radios simultaneously with the Easy Pairing feature. For ways to copy channel and sub code settings, see Radio Overview on page 1 . Navigating the Menu Pages1. Use the Menu button to scroll through the menu screen. 2. Press the PTT to exit any screen and return to home screen. Call Tone Send call tone (ring tone) to other radios by pressing the Call Tone button. Emergency Activate the Emergency Alert function by pressing and holding the Emergency button. Flashlight Turn on or off the flashlight and to change light color between red and white by pressing the Flashlight button. Note: Red light helps preserve vision in the dark. The flashlight turns off automatically after 30 minutes of non-activity or if the battery level is below 50%. Buttons Functionality Radio Set Up 1 2 Menu Navigation Two-Way Mode Monitor Menu Menu Mode/Power Button Scan Weather Mode Weather Channel Setting Weather Alert Setting Channel setting Sub Code setting Call Tone setting VOX (Voice Operated Transmission) setting Dual Watch Channel setting Dual Watch Channel Sub Code setting Vibrate Alert Setting Keypad Tone Setting Talk Confirmation Tone Setting This section describes the buttons and functions available on the radio. Table 1: Radio Overview Table 1: Buttons and Functionality Display Item Number Descriptions 1Mute2 Easy Pairing 3 Scan 4 Roger Tone 5 Dual Channel Monitor 6Lock7 Keypad Tone 8Sub Code9 Frequency 10 VOX or iVOX 11 Silent Mode (Vibrate Alert) 12 Call Tone 13 Transmit and Receive 14 Low or High Power 15 Weather Alert 16 Battery 17 Channel 18 Weather Radio (HOME) 19 Two-Way Mode Buttons Functionality Mode Switch/Power • Toggle between Two-Way and Weather modes by pressing the Mode Switch/Power button. • Turn on or off the radio by pressing and holding the Mode Switch/ Power button. Menu/Lock • Enter and scroll through the menu by pressing the Menu/Lock button. • Lock or unlock the Menu/Lock button by pressing and holding the Menu/Lock button. Volume/Adjust • Adjust the volume level by pressing the + or - button. • Change the settings or trigger actions in the menu screen by pressing the + or - button. PTT High/ PTT Low Button • Talk by pressing and holding the PTT High/PTT Low button. You can release the PTT High/PTT Low button to stop transmission. • Exit menu screen and return to home screen by pressing the PTT High/PTT Low button. Note: PTT Low button always transmit at 0.5 W. PTT High button transmits at a higher power when you select a high power channel (channel 1–7 and channel 15–22). Easy Pairing Copy the channel and sub code settings from Radio A to Radio B. • Prepare Radio B for pairing by pressing and holding the Easy Pairing button until you hear a beep. • Broadcast the channel and sub c ode settings by pressing and holding the Easy Pairing button on Radio A until you hear a double beep. Note: You can copy from one radio to multiple radios simultaneously. English (US) Radio Overview Antenna FlashlightButtonPTT (Low) Mode Switch/Power Menu/LockMicrophoneSpeaker Screen Easy Pairing Call Tone Volume/Adjust USB-CCharging Port Water Sensors Flashlight LED Accessory Port EmergencyButton PTT (High) 2'( 12345 67 8 9 10 11 1213 14 15 16 17 18 19 20 Table 2: Menu Navigation InstructionsEnsure that you are in the Two-Way mode by looking for the Two-Way icon on the LCD. You can return to the Two-Way mode by pushing the PTT button briefly.Talking or Transmitting1. Press and hold the PTT button, then start talking into the microphone. 2. Release the PTT button to stop transmission. Note: Do not press the PTT button when others are talking. When more than one radio transmits on the same channel, the airwave is jammed, and alltransmissions are lost. Listening or Receiving1. The radio speaker receives signal automaticall y if the radio is set to the same channel and code as the transmitting radio. 2. Ensure that the speaker volume is set to an appropriate level. Adjusting Speaker Volume • Press the + or - button from the home screen. Headset Usage • When a headset is connected to the radio, the radio speaker is disabled. Wear the connected headset to monitor and receive messages. • If your headset has the PTT button, you c an use the button to make a transmission with the microphone on the headset. • You can still use the PTT button on the radio to make a transmission with th…

Text truncated - open the document above for the full version.

FCC ID: AZ489FT4973 _______________________________________________________________________________________________________________________ Motorola Solutions Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 EXHIBIT 13B Revision 1 (2 Aug 2022) CONFIDENTIALITY REQUEST January 25, 2023 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ489FT4973 Dear Sir / Madam, Motorola Solutions Inc is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions Inc considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d), 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, ____________________ Deanna Zakharia Regulatory Compliance Manager E-mail: [email protected]

FCC ID: AZ489FT4973 _______________________________________________________________________________________________________________________ Motorola Solutions Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 EXHIBIT 13A Revision 3 (9 Sept 2022) Date: January 25, 2023 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for New Filing Certification of Transmitter with FCC ID: AZ489FT4973 Dear Sir/Madam, Motorola Solutions, Inc (8000 West Sunrise Boulevard, Fort Lauderdale, Florida) herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a portable radio application with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: Product Name Model Numbers Frequency Range RF Power FCC Rules Part T600 T605 T6B22201GWRAAW T6B22201GWCAAG FRS: (Chl 1-7) 462.5625 – 462.7125MHz (Chl 8-14) 467.5625 – 467.7125MHz (Chl 15-22) 462.5500 – 462.7250MHz Chl 1-7, Chl 15-22 1.16 W (ERP max calculated) Chl 8-14 0.27 W (ERP max calculated) 95B Weather Channel NOAA : 161 – 162.55 MHz Rx Only 15B *Remark: NOAA is short form of National Oceanic and Atmospheric Administration. It is a national weather service in US. We are requesting certification under Part(s) of the Commission’s Rules listed above to allow operation of this equipment. The subject transmitter complies with Section 95.337 and 95.363 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at (954) 723-4707. Sincerely, ____________________ Deanna Zakharia Regulatory Compliance Manager E-mail: [email protected]

Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973/ IC: 109U-89FT4973 EXHIBIT 2 Revision 1 (2 Aug 2022) SHEET 1 OF 1 EXHIBIT 2 Statement of Certification (Pursuant to FCC Part 2.907, 2.908 and RSP 100 Sec 4) 2.1 Statement of Certification Transceiver type described herein (AZ489FT4973/109U-89FT4973) is in compliance with all applicable parts of the FCC rules and ISED RSS standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Lim Kian Kwong SIGNATURE: DATE: 17 th January 2023 TITLE: Project Manager

Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 3A Revision 1 (16 Nov 2022) SHEET 1 OF 7 EXHIBIT 03 EXTERNAL PHOTOGRAPHS (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. Front View with Battery 3A 2. Back View with Battery . 3B 3. View of FCC/IC label location 3C 4. Side view (Right) with Battery 3D 5. Side view (Left) with Battery 3E 6. Top view with Battery 3F 7. Bottom view with Battery 3G Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 3A Revision 1 (16 Nov 2022) SHEET 2 OF 7 Exhibit 3A – Front View with Battery T6B22201GWRAAW T6B22201GWCAAG (IC MODEL: PMUE5712B) (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 3A Revision 1 (16 Nov 2022) SHEET 3 OF 7 Exhibit 3B – Back View with Battery T6B22201GWRAAW T6B22201GWCAAG (IC MODEL: PMUE5712B) (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 3A Revision 1 (16 Nov 2022) SHEET 4 OF 7 Exhibit 3C – View of FCC/IC label location T6B22201GWRAAW T6B22201GWCAAG (IC MODEL: PMUE5712B) (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 3A Revision 1 (16 Nov 2022) SHEET 5 OF 7 Exhibit 3D – Side view (Right) with Battery T6B22201GWRAAW T6B22201GWCAAG (IC MODEL: PMUE5712B) (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 3A Revision 1 (16 Nov 2022) SHEET 6 OF 7 Exhibit 3E – Si de view (Left) with Battery T6B22201GWRAAW T6B22201GWCAAG (IC MODEL: PMUE5712B) (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 3A Revision 1 (16 Nov 2022) SHEET 7 OF 7 Exhibit 3F – Top view with Battery T6B22201GWRAAW T6B22201GWCAAG (IC MODEL: PMUE5712B) (IC MODEL: PMUE5869A) Exhibit 3G – Bottom view with Battery T6B22201GWRAAW T6B22201GWCAAG (IC MODEL: PMUE5712B) (IC MODEL: PMUE5869A) *** END ***

Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 1 Revision 2 (12 Jan 2023) SHEET 1 OF 3 EXHIBIT 1 IDENTIFICATION LABEL (Pursuant to FCC Part 2.1033(c)(11), 2.1033(b)(7) and RSP 100 Annex C and Sec 3) LOCATION ____ See the Attached Photograph or Sketch ____ Bottom of the device ____ Front of the device ____ Back of the device ____ Back of the device under Belt Clip _ X _ In the Battery Compartment ____ Electronic labeling: In the user manual (Section: XX) TYPE X The label is a polyester silver film in white. _____ The label is an electronic print accessible in the device. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3 for the actual location of the FCC/IC label on the device. X Label Attached Below. See Attached Drawing. Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 1 Revision 2 (1 2 Jan 2023) SHEET 2 OF 3 Figure 1: FCC/IC Label for T600 (Made in Philippines) Figure 2: FCC/IC Label for T600 (Made in China) Applicant: Motorola Solutions Inc FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 1 Revision 2 (1 2 Jan 2023) SHEET 3 OF 3 Figure 3: FCC/IC Label for T605 (Made in Philippines) Figure 4: FCC/IC Label for T605 (Made in China) *** END ***

Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 9 Revision 1 (2 Aug 2022) SHEET 1 OF 7 EXHIBIT 9 Internal Photographs (Pursuant to FCC Part 2.1033(b)(7), 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. RF board with Shields (Top) 9A 2. RF board without Shields (Top) 9B 3. RF board with Shields (Bottom) 9C 4. RF board without Shields (Bottom) 9D 5. RF boards with chassis and housing for (Front Side) 9E 6. Chassis and housing (Back Side) 9F Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 9 Revision 1 (2 Aug 2022) SHEET 2 OF 7 EXHIBIT 9A : RF board with Shields (Top) T6B22201GWRAAW (IC MODEL: PMUE5712B) & T6B22201GWCAAG (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 9 Revision 1 (2 Aug 2022) SHEET 3 OF 7 EXHIBIT 9B : RF board without Shields (Top) T6B22201GWRAAW (IC MODEL: PMUE5712B) & T6B22201GWCAAG (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 9 Revision 1 (2 Aug 2022) SHEET 4 OF 7 EXHIBIT 9C : RF board with Shields (Bottom) T6B22201GWRAAW (IC MODEL: PMUE5712B) & T6B22201GWCAAG (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 9 Revision 1 (2 Aug 2022) SHEET 5 OF 7 EXHIBIT 9D : RF board without Shields (Bottom) T6B22201GWRAAW (IC MODEL: PMUE5712B) & T6B22201GWCAAG (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 9 Revision 1 (2 Aug 2022) SHEET 6 OF 7 EXHIBIT 9E : RF boards with chassis and housing for (Front Side) T6B22201GWRAAW (IC MODEL: PMUE5712B) & T6B22201GWCAAG (IC MODEL: PMUE5869A) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT4973 / IC: 109U-89FT4973 EXHIBIT 9 Revision 1 (2 Aug 2022) SHEET 7 OF 7 EXHIBIT 9F : Chassis and housing (Back Side) T6B22201GWRAAW (IC MODEL: PMUE5712B) & T6B22201GWCAAG (IC MODEL: PMUE5869A) *** END ***

FCC ID: AZ489FT4973 / IC: 109U-89FT4973 Report ID: P35850-EME-00003 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.31 Page 1 of 58 DECLARATION OF COMPLIANCE SAR ASSESSMENT Part 1 of 2 Motorola Solutions Inc. EME Test Laboratory Motorola Solutions Malaysia Sdn Bhd Plot 2A, Medan Bayan Lepas, Mukim 12 SWD 11900 Bayan Lepas Penang, Malaysia. Date of Report: 01/18/2023 Report Revision: B Responsible Engineer: Saw Sun Hock (EME Engineer) Report Author: Muhammad Akmal Naim Kasim (EME Technician) Date/s Tested: 12/9/2022–12/12/2022, 1/3/2023-1/4/2023, 1/7/2023-1/10/2023 Manufacturer: Motorola Solutions Inc. DUT Description: Handheld Portable – T600 Consumer Radio 462-467MHz Impact Green Test TX mode(s): CW (PTT) Max. Power output: Refer table 3 Nominal Power output: Refer table 3 Tx Frequency Bands: Refer table 3 Signaling type: FM Model(s) Tested: T6B22201GWRAAW (PMUE5712B) (IC MODEL: PMUE5712B) Model(s) Certified: T6B22201GWRAAW (PMUE5712B) (IC MODEL: PMUE5712B), T6B22201GWCAAG (PMUE5869A) (IC MODEL: PMUE5869A) Serial Number(s): 17520YX0001, 17520YX0004 Classification: Firmware Version: General Population/Uncontrolled Environment NA 002 Applicant Name: Motorola Solutions Inc. Applicant Address: 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 FCC ID: AZ489FT4973 FCC Test Firm Registration Number: 823256 IC: 109U-89FT4973 ISED Test Site registration: 24843 The test results clearly demonstrate compliance with General Population/Uncontrolled RF Exposure limits of 1.6 W/kg averaged over 1 gram per the requirements of FCC 47 CFR § 2.1093 and RSS-102 (Issue 5) Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 4.0 of this report (no deviation from standard methods). This report shall not be reproduced without written approval from an officially designated representative of the Motorola Solutions Inc EME Laboratory. I attest to the accuracy of the data and assume full responsibility for the completeness of these measurements. This reporting format is consistent with the suggested guidelines of the TIA TSB-150 December 2004. The results and statements contained in this report pertain only to the device(s) evaluated. Saw Sun Hock (Approval Signatory) Approval Date: 1/18/2023 FCC ID: AZ489FT4973 / IC: 109U-89FT4973 Report ID: P35850-EME-00003 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.31 Page 2 of 58 Part 1 of 2 1.0 Introduction............................................................................................................................ 4 2.0 FCC SAR Summary ............................................................................................................... 4 3.0 Abbreviations / Definitions .................................................................................................... 4 4.0 Referenced Standards and Guidelines ..................................................................................... 4 5.0 SAR Limits ............................................................................................................................ 5 6.0 Description of Device Under Test (DUT) ............................................................................... 5 7.0 Optional Accessories and Test Criteria ................................................................................... 6 7.1 Antennas .................................................................................................................... 6 7.2 Battery ........................................................................................................................ 6 7.3 Body worn Accessories .............................................................................................. 6 7.4 Audio Accessories ...................................................................................................... 7 8.0 Description of Test System..................................................................................................... 7 8.1 Descriptions of Robotics/Probes/Readout Electronics ................................................ 7 8.2 Description of Phantom(s) .......................................................................................... 8 8.3 Description of Simulated Tissue ................................................................................. 8 9.0 Additional Test Equipment ..................................................................................................... 9 10.0 SAR Measurement System Validation and Verification .......................................................... 9 10.1 System Validation ...................................................................................................... 9 10.2 System Verification .................................................................................................. 10 10.3 Equivalent Tissue Test Results ................................................................................. 10 11.0 Environmental Test Conditions ............................................................................................ 11 12.0 DUT Test Setup and Methodology ....................................................................................... 11 12.1 Measurements........................................................................................................... 11 12.2 DUT Configuration(s)............................................................................................... 12 12.3 DUT Positioning Procedures..................................................................................... 12 12.3.1 Body .......................................................................................................... 12 12.3.2 Head..................................................................................................…
