AZ489FT5799iDEN i3000 Portable Transmitter

Motorola ® iDEN ® Digital Multi-Service Data-Capable Phone i3000plus™ Phone User’s Guide @NTN9468A@ NTN9468-A i3000plus Phone Features Bookmark You can use this fold-out diagram as a bookmark, making it easy to refer to while you learn to use your i3000plus phone. Learning to Use Your i3000plus Phone NOTE: Remove the plastic film lens protector from the display. NOTE: The display backlight is activated by pressing any key. 1Tear off the Quick Reference Card located on the back cover, complete the information and keep it handy. 2Read Safety and General Information. 3Familiarize yourself with the Table of Contents. 4Use the i3000plus Phone CD included in the box. Antenna Earpiece Display Menu Key Option Key Photosensor Send Key Microphone/ Speaker Accessory Connector Next Word Key/ International Plus Dialing Back Key/ Pause Dialing Headset Jack Alphanumeric Keypad Punctuation Key End/Home Key 4-Way Navigation Key Option Key Push-To-Talk (PTT) Button Volume Control Buttons Audio Speaker Key Power Button Status Light 3000plus 3 Table of Contents Table of Contents ................................................................................. 3 Introduction ........................................................................... 9 Driving Safety Tips ...................................................................................... 10 Getting Started................................................................................... 11 Getting Started.............................................................................................. 11 i3000plus Phone Essentials .......................................................................... 11 Batteries........................................................................................................ 14 Attaching the Battery ............................................................................ 14 Detaching the Battery............................................................................ 15 Charging the Battery ............................................................................. 15 Activating Your i3000plus Phone ................................................................ 16 Powering On the Phone......................................................................... 16 Powering Off the Phone ........................................................................17 Security Features of the i3000plus Phone .................................................... 17 SIM Card Personal Identification Number (PIN) ................................. 17 Entering the PIN............................................................................... 17 Changing the PIN ............................................................................. 18 Unblocking the PIN.......................................................................... 19 Disabling/Enabling the PIN Requirement........................................ 20 Removing/Inserting the SIM Card ................................................... 21 Keypad Lock ......................................................................................... 22 Activating Keypad Lock .................................................................. 23 Receiving Incoming Calls ................................................................ 23 Receiving New Message Mail ......................................................... 23 Receiving Voice Mail ...................................................................... 24 Receiving Private Calls .....................................................................24 Deactivating Keypad Lock............................................................... 24 Status of Your i3000plus Phone ................................................................... 24 My Information ............................................................................................ 25 Viewing/Editing My Information.......................................................... 25 Display Essentials .............................................................................. 27 Desktop Essentials........................................................................................ 27 Ready Screen ................................................................................................27 Status and Application Icons................................................................. 27 Text Display Area ................................................................................. 27 Menu Icon .............................................................................................28 Display Options..................................................................................... 28 4 www.motorola.com Navigating Menus and Lists ........................................................................ 28 Main Menu Options ..................................................................................... 29 Digital Cellular................................................................................... 31 Making Phone Calls..................................................................................... 31 Using Direct Dial .................................................................................. 32 Making Calls from the Phonebook ....................................................... 32 Making Calls from the Recent Calls List ............................................. 33 Using Speed Dial .................................................................................. 33 Using Turbo Dial .................................................................................. 33 Voice Tags ............................................................................................ 34 Automatic Redial .................................................................................. 34 Placing International Phone Calls......................................................... 34 Plus Dialing ..............…

Text truncated - open the document above for the full version.

FCC Filing Package for Motorola i3000 Transceiver FCC ID: AZ489FT5799 IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 2- 1 Exhibit 2. Statement of Certification -- Pursuant to 47 CFR 2.907 The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The following is a statement of my qualifications: B.S. in Electrical Engineering, 2000, Florida Atlantic University. 2 years experience in RF/EMI measurement NAME: Anthony Stampalia SIGNATURE: Anthony Stampalia DATE: 8/02/2000 POSITION: Electrical Engineer I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: NAME: Humberto E. Garcia SIGNATURE: Humberto Garcia DATE: 8/02/2000 POSITION: Engineering Section Manager

Applicant: Motorola Inc FCC ID: AZ489FT5799 www.mot.com/iDEN iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 Page: 13- 1 August 9, 2000 Mr. Frank Coperich Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Dear Mr. Coperich; Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322, herein submits it’s application for Certification of the transmitter with FCC ID: AZ489FT5799. This variable power (0.24 to 750 milliwatt ERP) transmitter is part of a handheld transceiver used in a SMR and EA SMR trunking system operating in the United States 806-821/851-866 MHz frequency band. Certification is sought for, and performance data is provided for, 2 interchangeable power amplifiers from 2 different semiconductor suppliers. This measure is taken to mitigate the component supply shortages that have been limiting production in the radio equipment industry. This transceiver is of the receive-first type described in International Telecommunications Union Recommendation ITU-R M.1221 entitled Technical And Operational Requirements For Cellular Multimode Mobile Radio Stations. It must first find, acquire and lock onto a control channel from a predefined set of control channel frequencies assigned to a companion Authorized base station (e.g. – FCC ID: ABZ89FC5792). Transmission is not possible until lock to a base station control channel has been achieved, then transmission is limited to digitally modulated service request bursts on the reverse control channel. Upon recognition of a proper request, the control channel base station transmitter will then assign the transceiver a traffic channel for transmission of digital voice or circuit-switched data from the set of frequencies for which the trunking system is licensed. Attached Exhibit 12.1 provides additional descriptive details. It is expected that this handheld time division multiplexed transceiver marketed in the United States will also be used for itinerant operation with companion Authorized Base Stations by users requesting trunked radio and telephone interconnect service while roaming outside the United States. In some countries the companion base stations are licensed to operate at frequencies in the 821-825/866-870 MHz band in addition to some of those in the 806-821/851-856 MHz band normally used in United States SMR systems. Consequently, this transmitter has been designed to meet FCC requirements for operation in the 806-821 MHz band over the more global band of 806 - 825 MHz when used with a companion Authorized Base Station. Thus, performance data is provided to substantiate FCC compliant operation with a Companion Base Station over the broader 806 to 825 MHz band expected for global use of this handheld transceiver. Applicant: Motorola Inc FCC ID: AZ489FT5799 www.mot.com/iDEN iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 Page: 13- 2 To facilitate global roaming it is kindly requested that a note be provided in the Grant for Equipment Authorization which states that this ‘receive first’ type of equipment is compliant for transmitter operation over the broader range 806-825 MHz when used with a compatible Authorized Base Station. This will aid equipment authorization in foreign countries which accept a United States FCC Grant for Equipment Authorization, yet not jeopardize United States public safety or cellular systems licensed to operate in the 821-825 MHz frequency band since no compatible base station may be authorized on those frequencies in the United States. It is also expected that this transceiver type will be marketed outside the United States and brought into the United States for itinerant “roaming” operation on compatible 806 - 821 MHz base stations located within the United States. Consequently, upon receipt of Authorization, only those units of this equipment type authorized for marketing in countries outside the United States will also bear a label with the specified FCC identifier. In accordance with 47 CFR 2.1093(c) this transmitter may be used in “covered” SMR service so it has been subjected to routine environmental evaluation for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). The subject transmitter complies with 47 CFR 90.203 of the rules in that the operator cannot directly program transmit frequencies using only the unit's normally accessible external controls. Enclosed is a complete Certification Application comprised of 13 Exhibits. Contact me at (954) 723-5793 if you require any additional information. Regards, Mike Ramnath FCC Liaison Email: [email protected]

Applicant: Motorola Inc FCC ID: AZ489FT5799 www.mot.com/iDEN iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 Page: 13- 1 August 9, 2000 Mr. Frank Coperich Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Type Acceptance of Transmitter with FCC ID: AZ489FT5799. Dear Mr. Coperich; Motorola is requesting that Exhibit 4 (Circuit Description), Exhibit 5 (Schematic Diagrams), Exhibit 9 (Internal Photographs) and Exhibit 10 (Semiconductor/Active Device List) not be made routinely available for public inspection. Motorola is in the process of licensing the technology and has a number of Patent applications pending. Please mark Exhibit 4, 5, 9 and 10 as Confidential. Contact me at (954) 723-5793 if you require any additional information. Regards, Mike Ramnath FCC Liaison Email: [email protected]

Applicant: Motorola Inc FCC ID: AZ489FT5799 www.mot.com/iDEN iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33324 Page: 13- 1 November 17, 2000. Mr. Errol Chang Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Re: Form 731 Confirmation Number: EA 98411 with FCC ID: AZ489FT5799. Dear Mr. Chang; Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322, herein submits its response to your 3 November, 2000 request for information correspondence numbers 16955, and 7 November, 2000 request for information correspondence numbers16991 and 16992. 1) Regarding Correspondence No. 16955 As indicated in the cover letter which accompanied the application, and in the Exhibit 10 NOTE, authorization is requested to use either of two mechanically and electrically interchangeable different RF power Amplifier modules from two different vendors for U500 to assure mass production of a given model without interruption. Measured data was provided in Exhibit 6.1 for each of the two configurations which, for convenience, have been termed primary and alternate. The Primary U500 Data provided in Exhibit 6.1 was measured using the U500 device listed in the Device List of Exhibit 10 as RFPA (primary); the Alternate U500 Data provided in Exhibit 6.1 was measured using the device listed in Exhibit 10 as RFPA (alternate). The reported performance of these two nearly identical units differed within the production variance that is expected, and both met the specified maximum Output Power of 700 milliwatts (Pulse average) intended to be specified in revised Exhibit 12.1.A that was attached to our reply dated 30 October, 2000. To clarify the variable power nature of the transmitter item 12.1.A has been restated in attached Exhibit 12 (revision 2) to state the Output Power Range. The maximum and minimum values of the variable output power range remains unchanged at 700 and 0.221 milliwatts respectively. Different models may bear the stated FCC identifier, not because of the two different power amplifiers, but for product differentiation reasons such as those stated in the callout text in Photograph 3.2 of Exhibit 3. Applicant: Motorola Inc FCC ID: AZ489FT5799 www.mot.com/iDEN iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33324 Page: 13- 2 2) Regarding Correspondence No. 16991 Attached as new Exhibit 6.7 is the radiated performance data requested which was inadvertently omitted from our October 30, 2000 reply. This data was obtained using the methodology described in item A1 of that reply with the exception that the discussion therein referred to cell references in an Excel spreadsheet. To facilitate electronic communication these have been pasted into the word processing document submitted for Exhibit 6.7. 3) Regarding Correspondence No. 16992 1) The revised SAR report was inadvertently omitted from our October 30, 2000 reply. Further, it is now observed that the reference in that reply should have been to attached version B, not version A. 2) Thank you for your observation of the extraneous word ‘is’ in the Data Operation paragraph in the preliminary version of the user manual. It has been deleted in the current draft. 3) The value 1.0 W/kg listed in the preliminary user manual provided with our previous reply as the maximum calculated SAR is the correct value. It agrees with the value stated in Section 7.1 of the revised SAR report that was inadvertently omitted. Given this clarification then it is recommended that your Proposed Grant Conditions be revised to agree with Section 7.1 of SAR Report revision B. It is further recommended that the words “...is limited to...” in the third sentence of the Proposed Grant Conditions be changed to “...has been certified...” or some equivalent so the sentence would read “SAR compliance for body-worn operating configurations has been certified for the specific Motorola belt-clip and leather carry - case tested for this filing. “ This revision affirms the fact that compliance data was submitted and accepted for these configurations only, but does not preclude use of other technically compliant body-worn devices (e.g. - a case made from nylon mesh or vinyl) as possibly inferred from your proposal. Additionally, the proposed condition about informing end-users about body-worn requirements is redundant. Such information is already set forth in detail in the Safety and General Information section of the User’s Manual. Please contact me at (954) 723-5793 if you require any additional information. Regards, Mike Ramnath FCC Liaison Email: [email protected] Attachments: Exhibit 12, revision 2 Exhibit 6.7 SAR Report, revision B

Applicant: Motorola Inc FCC ID: AZ489FT5799 www.mot.com/iDEN iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 Page: 13- 1 December 12, 2000. Mr. Errol Chang Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Re: Form 731 Confirmation Number: EA 98411 with FCC ID: AZ489FT5799. Dear Mr. Chang; Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322, herein submits its response to your 6 December, 2000 request for information correspondence number 17275. As requested, both measured and maximum calculated Effective Radiated Power (ERP) data are provided in attached Exhibit 6.7, revision 1. This information is provided in both tabular and graphical form. Also provided therein is an example calculation to illustrate the methodology. All are provided based on the substitution method with power scaling procedure described in the last paragraph of Exhibit 7.1 (which was part of the original filing). Please contact me at (954) 723-5793 if you require any additional information. Sincerely, Mike Ramnath FCC Liaison Email: [email protected] Attachments: Exhibit 6.7, revision 1

FCC Filing Package for Motorola i3000 Transceiver FCC ID: AZ489FT5799 IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 3- 1 Exhibit 3. External Photographs -- Pursuant to 47 CFR 2.1033(c)12 Photograph 3-1: Front View of radio, antenna retracted. Housing Color May Vary Keypad Color And Shape May Vary Photograph 3-2: Front View of radio, antenna extended. FCC Filing Package for Motorola i3000 Transceiver FCC ID: AZ489FT5799 IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 3- 2 Photograph 3-3: Button Side View of radio, antenna retracted. Photograph 3-4: Rear view of radio, with battery, antenna retracted. FCC Filing Package for Motorola i3000 Transceiver FCC ID: AZ489FT5799 IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 3- 3 Photograph 3-5: Rear View of radio, battery removed to show FCC label orientation. Photograph 3-6: Close up of the FCC label.

FCC Filing Package for Motorola i3000 Transceiver FCC ID: AZ489FT5799 IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 1- 1 Table of Contents EXHIBIT 1.IDENTIFICATION LABEL -- 47 CFR. 2.925, 2.1065 & 2.1033 (C) (11)..................................................... 1-1 EXHIBIT 1A.GENERAL INFORMATION................................................................................................ 1-2 1A.1. Production Plans ............................................................................................................................................................ 1-2 1A.2. Application References................................................................................................................................................... 1-2 1A.3. Data Submittal Procedure .............................................................................................................................................. 1-2 1A.4. Similar, currently Type Accepted Transmitter................................................................................................................. 1-2 EXHIBIT 2.STATEMENT OF CERTIFICATION -- 47 CFR. 2.907................................................................................ 2-1 EXHIBIT 3.EXTERNAL PHOTOGRAPHS -- Pursuant 47 CFR 2.1033 (C )12............................................................... 3-1 EXHIBIT 4.CIRCUIT DESCRIPTION-----47 CFR. 2.1033(C)10.................................................................................... 4-1 4.1. Carrier Frequency Generation and Stabilization................................................................................................................. 4-2 4.2. Digital Modulation Techniques.......................................................................................................................................... 4-4 4.3. Modulation Limiting and Post Limiter Filter..................................................................................................................... 4-5 4.4. Means for Output Power Limiting..................................................................................................................................... 4-6 4.5. Spurious and Harmonic Emissions Suppression................................................................................................................. 4-7 EXHIBIT 5.CIRCUIT DIAGRAMS-- Pursuant 47 CFR 2.1033(C)10.............................................................................. 5-1 5.1. Schematic Diagram of the Transmitter Block...................................................................................................................... 5-1 EXHIBIT 6.MEASURED DATA-----47 CFR. 2.1041 & 2.1033 (c) (14).......................................................................... 6-1 6.1. RF Power -- Pursuant 47 CFR 2.1046(a) & 2.1033(c)8 ..................................................................................................... 6-1 6.2. Modulation Characteristics Data -- Pursuant 47 CFR 2.1047 (d) & 2.1033 (c)13................................................................ 6-2 6.3. Occupied Bandwidth Data -- Pursuant 47 CFR 2.1049(h), 90.210(g) & 90.691................................................................... 6-5 6.4. Radiated Spurious Emissions Data -- Pursuant 47 CFR 2.1053, 2.1057, 90.210 (g) & 90.691(a)....................................... 6-19 6.5. Frequency Stability Data -- Pursuant 47 CFR 2.1055(a)1, 2.1055(d)2............................................................................... 6-25 6.6. Power Line Conducted Spurious Emissions -- Pursuant 47 CFR 15.207........................................................................... 6-28 EXHIBIT 7.MEASUREMENT PROCEDURES-----47 CFR. 2.947................................................................................. 7-1 7.1. RF Power -- Pursuant to 47 CFR 2.947(c).......................................................................................................................... 7-1 7.2. Occupied Bandwidth -- Pursuant to 47 CFR 2.947(b)......................................................................................................... 7-2 7.3. Radiated Spurious Emissions -- Pursuant to 47 CFR 2.947(b)............................................................................................ 7-3 7.4. Frequency Stability -- Pursuant to 47 CFR 2.947(c)........................................................................................................... 7-4 7.5. Power Line Conducted Spurious Emissions -- Pursuant 47 CFR 15.107............................................................................. 7-6 7.6. Measurement Equipment List ---- 47 CFR 2.947(d)........................................................................................................... 7-7 EXHIBIT 8.USER INSTRUCTION MANUAL-- Pursuant 47 CFR 2.1033(C)3............................................................... 8-1 EXHIBIT 9.INTERNAL PHOTOGRAPHS-- Pursuant 47 CFR 2.1033(C)12................................................................... 9-1 EXHIBIT 10.SEMICONDUCTOR/ACTIVE DEVICE LIST AND TUNE UP PROCEDURE.......................................... 10-1 10.1. Semiconductor / Active Device List ---- 47 CFR 2.1033(c)(10)...................................................................................... 10-1 10.2. Tune Up Procedure ---- 47 CFR 2.1033-(c)(9)............................................................................................................... 10-1 EXHIBIT 11.RF EXPOSURE INFORMATION-- Pursuant 47 CFR 2.1093..................................................................... 11-1 EXHIBIT 12.TRANSMITTER DESCRIPTION -- 47 CFR. 2.1033(C)............................................................................. 12-1 12.1. Transmitter Technical Characteristics -- Pursuant 47 CFR 2.1033(c)4, 5, 6, 7, 8.................................................…

Text truncated - open the document above for the full version.

FCC Filing Package for Motorola i3000 Transceiver FCC ID: AZ489FT5799 IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 12- 1 Exhibit 12. Transmitter Description -- Pursuant 47 CFR 2.1033 (c) 12.1Transmitter Technical Characteristics -- 2.1033(c)4, 5, 6, 7, 8 The handheld trunked radio transceiver is of the receive first type, meaning it must first find, acquire and lock onto a control channel from a predefined set of control channel frequencies assigned to a compatible base station. Transmission is not possible until acquisition and lock has been achieved, then it is limited to transmission of service request bursts on the digitally modulated reverse control channel. Upon recognition of a proper request, the control channel base station transmitter will then assign the transceiver a traffic channel for transmission of digital voice, circuit- switched data, or packet-switched data from the set of frequencies for which the trunking system is licensed. The technical capability of the transceiver exceeds FCC emissions requirements for the 806 - 821 MHz range for which companion base stations are authorized in the United States. It is expected that this handheld transceiver marketed in the United States will also be used for itinerant roaming operation outside the United States with companion base stations that may operate anywhere within the broader frequency range 806 - 825 MHz. It is also expected that this transceiver type will be marketed outside the United States and brought into the United States for itinerant “roaming” operation on compatible 806 - 821 MHz base stations located in the United States. Thus performance data is provided to substantiate FCC compliant operation with a companion base station over the broader international 806 to 825 MHz band expected in use of this handheld transceiver outside the United States. The trunking system basic protocol uses a 90ms frame divided into six 15ms time slots. The base station allocates the number of 15ms time division multiplex (TDM) time slots in which the transceiver transmits, depending on the user requested transmission mode. Packet data transmission uses 15ms time slots in a 1.8 second frame. These slot allocations are summarized in Table 12-1. FCC Filing Package for Motorola i3000 Transceiver FCC ID: AZ489FT5799 IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 12- 2 Transmission Service ModeTime Slots Allocated per six slot frame 1.) Dispatch (push-to-talk)1 2.) Telephone Interconnect1 or 2 (base station preset) 3.) Circuit-Switched Data* 2 4.) Packet-Switched Data* # 1 to 6 in any particular frame (up to a maximum of 81 slots in 20 contiguous frames) * via a peripheral serial port at an input rate of 19,600 bps maximum for circuit-switched data and 115,200 bps maximum for packet-switched data. # via an internal world wide web browser Table 12-1: TDM Time Slot Allocation In addition to controlling the assigned frequency to which the transceiver will be slaved, the compatible base station frequency serves as an accurate, stable reference for the transceiver local reference oscillator by virtue of a transceiver AFC function inherent in the acquisition and lock process. The RF output power of the transceiver also is dynamically controlled by the radio which senses the received signal strength and adjusts transmitter output power in approximately 1dB steps over the range from rated power to 35 dB cutback. A. Output Power0.221 to 700 milliWatts (Pulse average) B. Maximum Antenna Gain0.3 dBd C. Maximum ERP 0.236 to 750 milliWatts (Pulse average) D. Frequency Range806-825 MHz** E. Frequency Stability£ 1.9 PPM * F. Emission Designator18K3D7W G. Spurious Emissions< -15 dBm H. Maximum DC Voltage and 3.89 V RMS in transmit slot # Current into the final RF 1.03 A RMS in transmit slot # amplifier stage (at nominal battery voltage) ** See Exhibit 12.1 * See Exhibit 6.5 # See Exhibit 6.1 FCC Filing Package for Motorola i3000 Transceiver FCC ID: AZ489FT5799 IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 12- 3 12.2. Transmitter Application The radio is characterized by the following features, options, and accessories. A. Power Supply Available: 1. 800 mAH Lithium Ion (SNN5705) Optionally available batteries: a). 500 mAH Lithium Polymer (SNN5717) b). 1100 mAH Lithium Ion (SNN5706) c). 1350 mAH Lithium Ion (SNN5716) 2.This radio contains a built in battery charger which charges an attached battery via…
