AZ489FT5801iDEN i2000plus

Motorola iDEN ® Digital Multi-Service Data Capable Phone i2000plus User’s Guide @NTN9487A@ NTN9487A i Patent and Trademark Information Patent and Trademark Information This product is protected under one or more of the following patents: 4817157, 4896361, 4857928, 5041793, 5060294, 5066923, 5134718, 5140156, 5239963, 5257411, 5287387, 5265219, 5289504, 5316168, 5317247, 5338396, 5389927, 5406588, 5424921, 5457376, 5460906, 5551063, 5557079, 5596487, 5615412, 5638403, 5559468, 5469465, 5170413, 5140615, 5519730, 5241544, 5584059, 5574992, 5396656, 5487091, 5533004, 5299199, 5343499, 5369501, 5509031, 5515379, 5528723, 5598417, 5066923, 5241650, 5278833, 5359696, 5548631, 5410632, 5440582, 5457735, 5457818, 5471670, 5477550, 5481537, 5566181, 5229767, 5208804, 5295140, 5381449, 5440590, 5467398, 5490230, 5620242, 5623523, 5655913, 5715240, 5771440, 5854578, 5675281, 5721787, 5729539, 5788523, 5869204, 5911124, 5946620, 5949774, 5949821, 5951317, 5987332, 6002948 Additional patents are pending. MOTOROLA. the stylized M logo, and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ®Reg. U.S. Pat. & Tm. Off. Manufactured under one or more of the U.S. patents listed in the User’s Guides. T9 is a trademark owned by Tegic Communications, Inc. All other trademarks mentioned in this manual are trademarks of their respective companies. © Copyright 2000, Motorola, Inc. All rights reserved. IMPORTANT! Be sure to read “Safety and General Information” on page 73 before using your i2000plus ii i 2000plus User’s Guide Table of Contents iii Table of Contents Patent and Trademark Information.................................................................. i Table of Contents ......................................................................................... iii i2000plus Phone Features............................................................................... 7 Learning to Use Your i2000plus Phone .................................................. 7 Getting Started.............................................................................................. 10 Setting Up Your i2000plus Phone for Use............................................ 10 Inserting the SIM Card .......................................................................... 11 Charging and Attaching the Battery...................................................... 12 Turning On Your i2000plus Phone ....................................................... 13 Light Sensor .......................................................................................... 14 SIM Card PIN........................................................................................ 14 Entering the PIN................................................................................14 Unblocking the PIN.......................................................................... 15 Changing the PIN ............................................................................. 15 Disabling the PIN Requirement ....................................................... 16 Enabling the PIN Requirement ........................................................ 16 Display Icons......................................................................................... 18 About Modes and Menus ...................................................................... 19 Setting the Time and Date ..................................................................... 19 Changing the Display Language ........................................................... 21 Selectable Backlight Timer ................................................................... 22 Making Phone Calls ..................................................................................... 23 International Phone Calls Using Plus Dialing.................................. 23 Inserting Pauses into Phone Numbers.............................................. 23 Using Other Dialing Methods ............................................................... 23 Scroll ................................................................................................ 23 Speed Dial ........................................................................................ 24 Name Search .................................................................................... 24 Last Number Redial ......................................................................... 24 Turbo Dial® Feature ........................................................................ 24 Automatic Redial ............................................................................. 25 Emergency Dial................................................................................ 25 Hands-Free Speakerphone..................................................................... 25 Receiving a Phone Call ........................................................................ 26 Missed Call Indicator ............................................................................ 26 What Is My Phone Number? ................................................................. 27 VibraCall® Feature ............................................................................... 27 Selecting VibraCall for All Incoming Calls and Messages ............. 27 Selecting VibraCall for Individual Services .................................... 28 Keypad Lock ......................................................................................... 29 Setting the Ringer Volume .................................................................... 29 Selecting a Ring Style ........................................................................... 29 Additional Call Services............................................................................... 31 iv i 2000plus User’s Guide Call Forwarding .................................................................................... 31 Unconditional Call Forwarding ................................................…

Text truncated - open the document above for the full version.

Motorola iDEN ® Digital Multi-Service Data Capable Phone i2000plus User’s Guide @NTN9487A@ NTN9487A Patent and Trademark Information i Patent and Trademark Information This product is protected under one or more of the following patents: 4817157, 4896361, 4857928, 5041793, 5060294, 5066923, 5134718, 5140156, 5239963, 5257411, 5287387, 5265219, 5289504, 5316168, 5317247, 5338396, 5389927, 5406588, 5424921, 5457376, 5460906, 5551063, 5557079, 5596487, 5615412, 5638403, 5559468, 5469465, 5170413, 5140615, 5519730, 5241544, 5584059, 5574992, 5396656, 5487091, 5533004, 5299199, 5343499, 5369501, 5509031, 5515379, 5528723, 5598417, 5066923, 5241650, 5278833, 5359696, 5548631, 5410632, 5440582, 5457735, 5457818, 5471670, 5477550, 5481537, 5566181, 5229767, 5208804, 5295140, 5381449, 5440590, 5467398, 5490230, 5620242, 5623523, 5655913, 5715240, 5771440, 5854578, 5675281, 5721787, 5729539, 5788523, 5869204, 5911124, 5946620, 5949774, 5949821, 5951317, 5987332, 6002948 Additional patents are pending. MOTOROLA, the stylized M logo, and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ®Reg. U.S. Pat. & Tm. Off. Manufactured under one or more of the U.S. patents listed in the User’s Guides. T9 is a trademark owned by Tegic Communications, Inc. All other trademarks mentioned in this manual are trademarks of their respective companies. © Copyright 2000, Motorola, Inc. All rights reserved. ii www.motorola.com Contents iii Contents CONTENTS Patent and Trademark Information ............................ i Wireless Phone Safety Tips....................................... viii Welcome ....................................................................... 11 Setting Up Your i2000plus Phone for Use................................ 12 TTY Access............................................................................... 12 Large Print Manuals.................................................................. 12 Features of Your i2000plus Phone ........................................... 13 Inserting the SIM Card.............................................................. 15 Charging and Attaching the Battery.......................................... 16 Turning On Your i2000plus Phone ........................................... 17 Light Sensor .............................................................................. 18 SIM Card PIN ........................................................................... 19 Entering the PIN ................................................................... 19 Unblocking the PIN .............................................................. 19 Changing the PIN ................................................................. 20 Disabling the PIN Requirement............................................ 21 Enabling the PIN Requirement............................................. 21 Keypad Lock ............................................................................. 22 Display Icons............................................................................. 22 About Modes and Menus .......................................................... 23 Setting the Time and Date......................................................... 24 Changing the Display Language ............................................... 25 Selectable Backlight Timer ....................................................... 26 Making Phone Calls .................................................... 27 International Phone Calls Using Plus Dialing ...................... 27 Inserting Pauses into Phone Numbers .................................. 27 Using Other Dialing Methods ................................................... 27 Scroll..................................................................................... 28 Speed Dial ............................................................................ 28 Name Search......................................................................... 28 Last Number Redial.............................................................. 28 Turbo Dial®......................................................................... 28 Automatic Redial.................................................................. 29 Emergency Dial .................................................................... 29 Hands-Free Speakerphone ........................................................ 29 Receiving a Phone Call ............................................................ 30 iv www.motorola.com Missed Call Indicator ................................................................ 30 What Is My Phone Number?..................................................... 31 VibraCall® Alert....................................................................... 31 Selecting VibraCall Alert for All Incoming Calls and Messages........................................................................ 32 Selecting VibraCall Alert for Individual Services................ 32 Setting the Ringer Volume........................................................ 33 Selecting a Ring Style ............................................................... 33 Additional Call Services ............................................. 35 Call Forwarding ........................................................................ 35 Unconditional Call Forwarding ............................................ 35 Conditional Call Forwarding ................................................ 36 Call Waiting .............................................................................. 37 Call Hold ................................................................................... 37 3-Way Calling ........................................................................... 37 Call Barring ............................................................................... 38 Barring Incoming Calls ........................................................ 38 Barring Outgoing Calls.............................…

Text truncated - open the document above for the full version.

Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 2- 1 Exhibit 2. Statement of Certification ----- 47 CFR 2.911 The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The following is a statement of my qualifications: M.Sc. Electrical Engineering, 1981, Technical University of Warsaw, Poland 18 years of Design and Development experience in the field of two-way radio communication. NAME: Waldemar Sierocinski SIGNATURE: DATE:____8/25/2000___ POSITION: RF Lead Engineer I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: NAME: Alex Capo SIGNATURE: DATE:____8/25/2000________ POSITION: Engineering Manager

Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 4 - 1 Exhibit 4. Circuit Description-----47 CFR. 2.1033(C) 10 This section provides the description of circuits required by subpart 2.1033 of the Commissions’ rules. The following are included: 4.1) Carrier Frequency Generation and Stabilization 4.2) Digital Modulation Techniques 4.3) Modulation Limiting and Post Limiter Filter 4.4) Means for Output Power Limiting 4.5) Spurious and Harmonic Emissions Suppression Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 4 - 2 4.1.Carrier Frequency Generation and Stabilization As shown in Figure 4-1 the synthesizer IC (U301) reference oscillator employs a crystal controlled Colpitts oscillator running at a frequency of 16.8MHz. The oscillator transistor, start- up circuit, and temperature compensation circuit are located in the IC (U301) while the oscillator feedback capacitors, crystal, and tuning varactor are external. This oscillator is temperature compensated to an accuracy of +/-2.5PPM from –20 o C to 60 o C. The method of temperature compensation is to apply an inverse Bechmann voltage curve, which matches the crystal's Bechmann curve to a varactor that constantly shifts the oscillator back on frequency. U301 AFC & Temperature Adjustment Frequency Programming from DSP Y300 16.8 MHz XTAL 16.8 MHz output D300 ENABLE Figure 4-1: 16.8 MHz reference oscillator Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 4 - 3 The reference oscillator runs at 16.8 MHz. The signal from this reference oscillator is routed within the synthesizer IC (U301) which is used to control the stability of the main Voltage Controlled Oscillator (VCO) which oscillates at a frequency between 956.9 - 979.65 MHz (see figure 4-2). The synthesizer also buffers the 16.8 MHz signal and provides it to the U601, U602, U502, and U801 ICs (see figure 4-2 and 4-3). The PLL inside the U602 uses the 16.8MHz clock to be used as the reference for the TX offset. The frequency of the TX offset VCO (Q605) is 301.8 MHz which is divided by two in U502 and mixed with the main VCO to generate the transmit frequency. The frequency control for each VCO is accomplished by a PLL that compares the VCO frequency to the reference frequency thus locking each VCO to the reference oscillator. The transmitter frequency is programmed to a single frequency between 806-825 MHz composed by subtracting half of the TX offset VCO (Q605) frequency (301.8 MHz) from the main VCO (Q306) frequency 956.9- 979.65 MHz. The subtraction is done by a mixer in the U502 followed by a band pass filter FL501 (see figure 4-3) which selects the transmitter frequency of 806 - 825 MHz from the other mixing products and rejects spurious signals. ∏8 Main VCO 956.9-979.65MHz ∏8 150.9 MHz 806-825MHz SYNTHESIZER Phase-Detector and Filter ∏ 2 U301 U502 U602 Q605 Q306 16.8MHz OSCILLATOR 301.8MHz 150.9MHz Figure 4-2 : Transmitter frequency generation subsystem Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 4 - 4 4.2.Digital Modulation Techniques The subject radio makes use of 3 different modulation techniques termed Quad-16QAM, Quad-64QAM, and Quad-QPSK. In voice mode, the radio will function in Quad-16QAM mode only. In data mode, the radio will use any one of the three different modulation techniques (Quad-16QAM, Quad-64QAM, and Quad-QPSK) in a given time division multiplexed slot. The following describes each of the modulation techniques. The modulation technique termed Quad-QPSK is a linear digital modulation of a multi- channel variant of a 4-state Quadrature Amplitude Modulation. Data bits to be transmitted are split into four parallel lower rate streams, each of which is QPSK modulated to its own sub carrier frequency at a rate of 4k symbols per second. The four resulting sub channel signals are then combined in frequency division multiplex fashion to produce the composite M-QPSK signal. This spectrally efficient linear modulation can achieve transmission at 32 kilobits per second in a 25 kHz channel. The transmitter is configured using TDMA time slotting so that up to 6 radio users can simultaneously share the 25 kHz channel. The modulation technique termed Quad-16QAM is a linear digital modulation of a multi- channel variant of a 16-state Quadrature Amplitude Modulation. Data bits to be transmitted are split into four parallel lower rate streams, each of which is 16QAM modulated to its own sub carrier frequency at a rate of 4k symbols per second. The four resulting sub channel signals are then combined in frequency division multiplex fashion to produce the composite M-16QAM signal. This spectrally efficient linear modulation can achieve transmission at 64 kilobits per second in a 25 kHz channel. The transmitter is configured using TDMA time slotting so that up to 6 radio users can simultaneously share the 25 kHz channel. The modulation technique termed Quad-64QAM is a linear digital modulation of a multi- channel variant of a 64-state Quadrature Amplitude Modulation. Data bits to be transmitted are split into four parallel lower rate streams, each of which is 64QAM modulated to its own sub carrier frequency at a rate of 4k symbols per second. The four resulting sub channel signals are then combined in frequency division multiplex fashion to produce the composite M-64QAM signal. This spectrally efficient linear modulation can achieve transmission at 96 kilobits per second in a 25 kHz channel. The transmitter is configured using TDMA time slotting so that up to 6 radio users can simultaneously share the 25 kHz channel. Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, US…

Text truncated - open the document above for the full version.

Applicant: Motorola Inc FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 13- 1 Date: September 01, 2000 Mr. Frank Coperich Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Dear Mr. Coperich; Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322, herein submits it’s application for Certification of transmitter AZ489FT5801, which is an adaptation of previously authorized transmitter AZ489FT5794. This variable power (0.00013 to 0.63 Watt ERP) transmitter is part of a handheld transceiver with an integral antenna used in a SMR or EA SMR trunking system operating in the 806-821/851-866 MHz frequency band. This transceiver is of the receive first type described in International Telecommunications Union Recommendation ITU-R M.1221 entitled Technical And Operational Requirements For Cellular Multimode Mobile Radio Stations. It must first find, acquire and lock onto a control channel from a predefined set of control channel frequencies assigned to a companion Authorized base station (e.g. – FCC ID: ABZ89FC5763 and ABZ89FC5772). Transmission is not possible until lock to a base station control channel has been achieved, then transmission is limited to digitally modulated service request bursts on the reverse control channel. Upon recognition of a proper request, the control channel base station transmitter will then assign the transceiver a traffic channel for transmission of digital voice or packet data from the set of frequencies for which the trunking system is licensed. Attached Exhibit 12.1 provides additional descriptive details. It is expected that this handheld time division multiplexed transceiver, marketed in the United States will also be used for itinerant operation with companion Authorized base stations by users requesting trunked radio and telephone interconnect service while roaming outside the United States. In some countries the companion base stations are licensed to operate at frequencies in the 821-825/866-870 MHz band in addition to some of those in the 806-821/851-856 MHz band normally used in United States SMR systems. Consequently, this transmitter has been designed to meet FCC requirements for operation in the 806-821 MHz band over the more global band of 806 - 825 MHz when used with a companion Authorized base station. Thus, performance data is provided to substantiate FCC compliant operation with a companion base station over the broader 806 to 825 MHz band expected for global use of this handheld transceiver. To facilitate global roaming it is kindly requested that a note be provided in the Grant of Authorization which states that this ‘receive first’ type of equipment is compliant for transmitter operation over the broader range 806-825 MHz when used with a compatible Authorized base Applicant: Motorola Inc FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 13- 2 station. This will aid equipment authorization in foreign countries which accept a United States FCC Grant of Authorization, yet not jeopardize United States public safety or cellular systems licensed to operate in the 821-825 MHz frequency band since no compatible base station may be authorized on those frequencies in the United States. This radio product is intended to be sold in the United States to provide itinerant “roaming” operation outside the United States via access to 935 - 960 MHz GSM compatible base stations. As a consequence, the scanning process of the receiver includes an oscillatory search for GSM systems as well. When operating in the iDEN state, search for a GSM system is suspended since that service is not available domestically. Similarly, when operating in the GSM state outside the United States, search for an iDEN system is suspended once it is locked onto a GSM system. To facilitate international distribution, it is kindly requested that a note be provided in the Grant of Authorization which states that this equipment includes an auxiliary receiver function operating in the frequency range 935 to 960 MHz. In accordance with 47 CFR 2.1093(c) this transmitter may be used in “covered” SMR service so it has been subjected to routine environmental evaluation for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). The subject transmitter complies with 47 CFR 90.203 of the rules in that the operator cannot directly program transmit frequencies using only the unit's normally accessible external controls. Enclosed is a complete Certification Application comprised of 12 Exhibits. Contact me at (954) 723-5793 if you require any additional information. Regards, Mike Ramnath FCC Liaison Email: [email protected]

Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 3- 1 Exhibit 3. External Photographs--------pursuant 47 CFR 2.1033(c) 12 Photogaph 3-1: Front view of the radio (color may vary) Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 3- 2 Photograph 3-2: Side view of the radio with NTN8615 battery (additional batteries listed in Exhibit 12.2.1) Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 3- 3 Photograph 3-3: Rear view of the radio, showing FCC label Applicant: Motorola, Inc. FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page: 3- 4 Photograph 3-4: Rear view of the radio, with battery attached

Applicant: Motorola, Inc.FCC ID: AZ489FT5801 iDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Page:1- 1 Table of Contents EXHIBIT 1.IDENTIFICATION LABEL-----47 CFR. 2.1033-(C) 11............................................................................ 1-1 EXHIBIT 1A.GENERAL INFORMATION-----47 CFR. 2.1031, 2.1061......................................................................... 1-2 1A.1. Production Plans -- Pursuant 47 CFR 2.1031............................................................................................................. 1-2 1A.2. Application References -- Pursuant 47 CFR 2.1061.................................................................................................. 1-2 1A.3. Data Submittal Procedure.......................................................................................................................................... 1-2 1A.4. Similar, currently Type Accepted Transmitter........................................................................................................... 1-2 EXHIBIT 2.STATEMENT OF CERTIFICATION-----47 CFR. 2.911......................................................................... 2-1 EXHIBIT 3.EXTERNAL PHOTOGRAPHS---47CFR. 2.1033-(C) 12.......................................................................... 3-1 EXHIBIT 4.CIRCUIT DESCRIPTION-----47 CFR. 2.1033-(C)-10.............................................................................. 4-1 4.1. Carrier Frequency Generation and Stabilization........................................................................................................... 4-2 4.2. Digital Modulation Techniques.................................................................................................................................... 4-4 4.3. Modulation Limiting and Post Limiter Filter................................................................................................................ 4-4 4.4. Means for Output Power Limiting................................................................................................................................ 4-5 4.5. Spurious and Harmonic Emissions Suppression........................................................................................................... 4-6 EXHIBIT 5.CIRCUIT DIAGRAMS-----47 CFR. 2.1033-(D)-10................................................................................... 5-1 5.1. Schematic Diagram of Transmitter Block...................................................................................................................... 5-1 EXHIBIT 6.MEASURED DATA-----47 CFR. 2.1033-(C) 14......................................................................................... 6-1 6.1. RF Power Output Data -- Pursuant 47 CFR 2.1046(a), 2.1033(c)(6), 2.1033(c)(7) and 2.1033(c)(8)............................. 6-1 6.2. Modulation Characteristics Data -- Pursuant 47 CFR 2.1047 and 2.1033(c)(13)........................................................... 6-1 6.3. Occupied Bandwidth Data -- Pursuant 47 CFR 2.1049, 90.210(g) and 90.691.............................................................. 6-4 6.4. Radiated Spurious Emissions Data -- Pursuant 47 CFR 2.1053,2.1057, 90.210(g) and 90.691(a)................................ 6-12 6.5. Conducted Spurious Emissions Data -- Pursuant 47 CFR 2.1051, 2.1057, 90.210 (g) and 90.691............................... 6-20 6.6. Frequency Stability Data -- Pursuant 47 CFR 2.1055.................................................................................................. 6-22 6.7. Power Line Conducted Spurious Emissions -- Pursuant 47 CFR 15.107..................................................................... 6-25 EXHIBIT 7.MEASUREMENT PROCEDURES-----47 CFR. 2.1041............................................................................ 7-1 7.1. RF Power Output -- Pursuant 47 CFR 2.1046............................................................................................................... 7-1 7.2. Occupied Bandwidth -- Pursuant 47 CFR 2.1049......................................................................................................... 7-1 7.3. Radiated Spurious Emissions -- Pursuant 47 CFR 2.1053............................................................................................. 7-2 7.4. Conducted Spurious Emissions -- Pursuant 47 CFR 2.1051.......................................................................................... 7-3 7.5. Frequency Stability -- Pursuant to 47 CFR 2.1055 and 90.213...................................................................................... 7-3 7.6. Power Line Conducted Spurious Emissions -- Pursuant 47 CFR 15.107....................................................................... 7-4 7.7. Measurement Equipment List ---- 47 CFR 2.1041........................................................................................................ 7-5 EXHIBIT 8.INSTRUCTION MANUAL........................................................................................................................ 8-1 EXHIBIT 9.INTERNAL PHOTOGRAPHS.................................................................................................................. 9-1 EXHIBIT 10.SEMICONDUCTOR/A…

Text truncated - open the document above for the full version.
