AZ489FT5806Astro Digital XTS5000 Hand Held Portable Radio
Motorola Solutions, Inc.
Click to zoom
Application Details
- Equipment Class
- TNF - Licensed Non-Broadcast Transmitter Held to Face
- Date of Grant
- Nov 15, 2001
- Application Purpose
- Original Equipment
- Date of Application
- Aug 30, 2001
- Equipment Note
- Astro Digital XTS5000 Hand Held Portable Radio
- Frequency Range
- 764.00000000 - 870.00000000
- Company
- Motorola Solutions, Inc.
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
ASTRO ® Digital XTS 5000™ Model III User Guide 68P81094C27-O Document Creation Date: 8/21/01 Document Modification Date: 8/27/01 94C27-O_XTS5000Mdl3.book Page 1 Monday, August 27, 2001 9:23 AM Preface Before operating your radio, please review the “Safety and General Information” section in the front of this user guide. Also, be sure to retain this publication for future reference. Computer Software Copyrights The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs, including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied, reproduced, modified, reverse- engineered, or distributed in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product. 94C27-O_XTS5000Mdl3.book Page 2 Monday, August 27, 2001 9:23 AM ASTRO ® Digital XTS 5000™ Model III Radio Quick Reference Card Write your radio’s programmed features on the dotted lines. Radio On/OffZones/ChannelsReceive/TransmitSend Emergency Alarm Send Emergency CallSend Silent Emergency Alarm 16-Position Select Knob _ _ _ _ _ _ _ Speaker/Mic Top Button _ _ _ _ _ _ _ Concentric Switch_ _ _ _ _ _ Display Keypad Menu Select, 4-Way Nav, and Home Top Side Button_ _ _ _ _ _ _On/Off/Volume Knob Side Button 1_ _ _ _ _ _ _Side Button 2_ _ _ _ _ _ _ PTT Button 3-Position Switch _ _ _ _ _ _ _ 1 On - On/Off/Volume knob clockwise. 2 Off - On/Off/Volume knob counterclockwise. 1 Zone - Zone switch to desired zone. 2 Channel - Channel switch to desired channel. 1 Radio on and select zone/channel. 2 Listen for a transmission. - or - Press and hold Volume Set button. - or - Press Monitor button and listen for activity. 3 Adjust volume, if necessary. 4 Press PTT to transmit; release to receive. Radio on and press Emergency button. Display shows current zone/channel, E EE E M MM M E EE E R RR R G GG G E EE E N NN N C CC C Y YY Y , and e . Red LED lights; you hear short, medium-pitched tone. Note: To exit emergency at any time, press and hold Emergency button. When acknowledgment is received, you hear four beeps; alarm ends; radio exits emer-gency. 1 Radio on and press Emergency button. Note: To exit emergency at any time, press and hold Emergency button. 2 Press and hold PTT . Announce your emergency into the microphone. 3 Release PTT to end call. 4 Press and hold Emergency button to exit emergency. 1 Radio on and press Emergency button. Display does not change; you see no LED; you hear no tone. Note: To exit emergency at any time, press and hold Emergency button. 2 Silent emergency continues until you: • Press and hold Emergency button to exit emergency state. - or - • Press and release PTT to exit silent emergency and enter regular emergency (alarm, call, or alarm with call). QRcard.fm Page 1 Thursday, August 16, 2001 9:23 AM Display Status Symbols Menu Entries (Use With Menu Navigation) H L Power Level. H = high power; L = low power m Receiving an individual call p The radio is in the view or program mode; On Steady = view mode; Flashing = program mode s Received signal strength for the current site (trunking only). The more stripes in the symbol, the stronger the signal. b Flashes when the battery is low. r You are talking directly to another radio or through a repeater; On = direct; Off = repeater C This channel is being monitored. c Your radio is in secure operation; On = secure operation; Off = clear operation; Flashing = receiving an encrypted voice call T The radio is scanning a scan list S Priority 1 Channel during scan S Priority 2 Channel during scan e The radio is in Emergency state Entry Menu Selection Page B BB B A AA A T TT T T TT T Smart Battery 16 C CC C A AA A L LL L L LL L Private Call 62 C CC C H HH H A AA A N NN N Select a Channel 23 C CC C L LL L C CC C K KK K Set the Real Time Clock 84 D DD D I II I R RR R Repeater/Direct 71 L LL L O OO O G GG G F FF F Radio Lock 32 M MM M U UU U T TT T E EE E Keypad Mute 33 N NN N A AA A M MM M E EE E Text Select 43 N NN N U UU U M MM M Number Select 41 P PP P A AA A G GG G E EE E Call Alert Page 65 P PP P H HH H O OO O N NN N Phone 58 Entry Menu Selection Page P PP P R RR R O OO O G GG G Editing 41 P PP P S SS S W WW W D DD D Password 31 P PP P W WW W R RR R TX Power Level 29 R RR R P PP P G GG G M MM M Reprogram Request 77 S SS S C CC C A AA A N NN N Scan On/Off 54 S SS S I II I T TT T E EE E Site Lock 81 S SS S T TT T S SS S Status Call 69 T TT T G GG G R RR R P PP P Talkgroup Call 67 V VV V I II I E EE E W WW W Viewing a List 40 Z ZZ Z O OO O N NN N E EE E Select a Zone 22 Menu Navigation U to find Menu Entry D , or E , or F directly below Menu Entry to select h to exit V or U to scroll through sub-list D , or E , or F directly below Menu Entry to select QRcard.fm Page 2 Thursday, August 16, 2001 9:23 AM ASTRO Digital XTS 5000 Model IIIi Contents Safety and General Information Transmit and Receive Procedure .....................................................vii Exposure to Radio Frequency Energy .............................................vii Two-Way Radio Operation ....................................................... viii Body-Worn Operation ............................................................... viii Antenna Care ............................................................................ ix Approved Accessories ......................................................…
Text truncated - open the document above for the full version.
Users Manual
ASTRO Digital XTS 5000 Model IIIvii Vr ThsrU hvvthqBrr hy Ds hv S@69 UCDT DHQPSU6IU DIAPSH6UDPI PI T6A@ 6I9 @AAD8D@IUPQ@S6UDPI7@APS@VTDIB`PVSHPUPSPG6 C6I9C@G9QPSU67G@UXPX6`S69DP Uurvs hv vqrqvuvqprr rqrurtrr hy hsrvs hvphvrqvr tvqriyvurq v Er ! A vs hv rth qvt hqvrvhuhh qhur r yrhr rsr urAhp HhyAH6 hyHhhyTyrr D pv8h quvpuvvpyqrqvu hqvqryuhssr uv phhivyv 8yvhprvuSA@r t@ r Thqh q ` H yhh hqvvqrvtrqhqrrqpyvuh ir shvhyhqvr hvhyhqh qhqtvqryvryvrq iry rth qvtuhr r hqvs rrpryrp htrvp rr tUuv hqvpyvrvuurD@@@A88hqD8IDSQ r ryvvs pphvhyp yyrqSAr rrv r hqppyrs$1hyx$1yvrhquyqirrqs pphvhyryDr srh vtSArr ts pyvhprvuurA88r rtvqryvr hqv hqvhr rh hiyrSArr tyuvyrvv hvvtq vthyxvt urvv rprvvtyvrvt vhqiqrIruhur h rqyvrqihr vrs uv hqvh r hrqs h$$(q ppyr$1hyx$1yvr(1hqirrutuuv hqv pyvrvuurA88pphvhyr ryvvhqppyrs $1hyx ` H yhh hqvpyvrvuursyyvtSA rr tr rhqh qhqtvqryvr) • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 &2 B;76 0GO ERRN3DJ HY L L 7K X UVGD \2FWREHU 3 0 viii Vr ThsrU hvvthqBrr hyDs hv • Institute of Electrical and Electronic Engineers (IEEE) C95.1- 1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation - Human Exposure) Standard 1999 (applicable to wireless phones only) • ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001) "additional requirements for SMR, cellular and PCS product certification." Pr hvhyD pvhqU hvvtBvqryvr Ur rvhyr s hprhqpyvhprvu urpphvhyp yyrqrv rSArr t r ryvvvurhirhqh qhqtvqryvr r uyq hv ruh$1survr hqhyhhqur rursyyvt prq r) U hvhqSrprvr •To transmit (talk), push the Push-To-Talk (PTT) button; to receive, release the PTT button. Chquryq hqvr hv •Hold the radio in a vertical position with the microphone one to two inches (2.5 to 5 cm) away from the lips. 7q r hv •Always place the radio in a Motorola approved clip, holder, holster, case, or body harness for this product. Use of non- Motorola-approved accessories may exceed FCC RF exposure guidelines. • If you do not use a Motorola approved body-worn accessory and are not using the radio in the intended use position in front &2 B;76 0GO ERRN3DJ HY L L L 7KXUVGD \2FWRE HU 3 0 ASTRO Digital XTS 5000 Model IIIix Vr ThsrU hvvthqBrr hyDs hv of the face, then ensure the antenna and the radio are kept 2.5 cm (one inch) from the body when transmitting. 6rh.7hr vr •Use only Motorola approved supplied antenna or Motorola approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the radio and may violate FCC regulations. •Use only Motorola approved, supplied batteries or Motorola approved replacement batteries. Use of non- Motorola-approved antennas or batteries may exceed FCC RF exposure guidelines. 6 rq6ppr vr • For a list of Motorola approved accessories see the appendix of this user manual or visit the following website which lists approved accessories: u) yhpptv hiyr$uy @yrp htrvpDr sr rpr8hvivyv Ir)Irh yrr ryrp vpqrvprvprviyr ryrp htrvpvr sr rpr@HDvsvhqrhryuvryqrq qrvtrq ur vrpsvt rqs ryrp htrvp phvivyv Ahpvyvvr Uhvqryrp htrvpvr sr rprhq phvivyvpsyvp ss hqvvhshpvyvur rrqvprv p qCvhy urhyuph rshpvyvvrhirvtrvruh vrvvrrr hySArr t 6v p hs Xurv prqq ss hqvurih qh hv p hs6rsh hqvirvhpp qhprvuhyvphiyr rtyhvr hv yvrp rv pv &2 B;76 0GO ERRN3DJ HL [ 7K X UVGD \2FWREHU 30 x Vr ThsrU hvvthqBrr hyDs hv Hrqvphy9rvpr Qhprhxr Uur6qhprqHrqvphyUrpuyt6pvhv6qhHrq rprquhhvvrh hvs%vpur $prvrr irhvhvrqirrrhuhquryqv ryr hqvhqhhprhxr Uurr rprqhvh rpvrvuursurVTAq hq9 t6qvv hv Qr vuhprhxr uyq) ; 6GX6`Txrrur hqv ruh%vpur $prvrr s urv hprhxr urur hqvv rqPI ; ph ur hqvvuri rhpxr ; rurrh vrurhprhxr vvvrurrvhy s vr sr rpr ; ur hqvPAAvrqvhryvsuhrh rh rpuhvr sr rprvhxvtyhpr Crh vt6vq Trqvtvhyv ryr hqvhvr sr rvururh vthvqD urrrspuvr sr rpr…
Text truncated - open the document above for the full version.
Users Manual
ASTRO Digital XTS 5000 Model III95 Accessories Motorola provides the following approved accessories to improve the productivity of your XTS 5000 portable two-way radio. Antennas Audio Adapters Batteries NAF5037800 MHz Whip, Halfwave (806-870 MHz) NAF5042800 MHz Stubby, Quarterwave (806-870 MHz) NAF5080700/800 MHz Whip (764-870 MHz) BDN6676Adapter, 3.5mm w/PTT Switch HNN9031 1525 mAH NiCd Smart HNN9032 1525 mAH NiCd Smart FM NTN8294 1525 mAH NiCd, Ul tra-H igh Capac ity NTN8295 1525 mAH NiCd Hi gh-C apacity FM NTN8297 1525 mAH NiCd High-Capacity FM, Rugged NTN8299 1750 mAH NiMH Ul tra-C apacity FM NTN8610 1650 mAH Lithium Ion NTN8923 1800 mAH NiMH Ultra-Capacity NTN9177Battery Holder, Clamshell Black NTN9183 Battery Hol der, Clamshell Orange NTN9533 2400 mAH Lithium Ion Smart NTN9862 2000 mAH Lithium Ion Smart, Slim RNN4006_R 3000 mAH NiMH RNN4007_R 3000 mAH NiMH FM
Attestation Statements
MOTOROLA INC FCC ID: AZ489FT5806 EXHIBIT 2 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The following is a statement of my qualifications: 1) MSEE Oklahoma State University MBA Oklahoma State University 2) 8 years experience in the development, testing and certification of Land Mobile Communications Products NAME: Stephen L. Kersten SIGNATURE: DATE: 28 August 2001 POSITION: Senior Staff Electrical Engineer I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: NAME: Daniel Marks SIGNATURE: DATE: 28 August 2001 POSITION: Engineering Manager
Cover Letter(s)
FCC ID: AZ489FT5806 ______________________________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. (954) 723-5000 31 ST August 2001 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT5806. Gentlemen: Motorola Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida, herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a Portable Radio environment with capabilities for clear communications with a variable transmit power of 1-3 Watt (30-34.8 dBm). The FCC Rules allow the transmitter to operate in the following frequency bands: 764-767 MHz, 773-776 MHz, 794-797 MHz, 803-806 MHz and 806-824 MHz, 851-869 MHz. However, to aid equipment authorization in foreign countries which accept United States FCC Grant for equipment authorization, Motorola is asking the FCC to list on the FCC Grant the following frequencies: 764-870 MHz. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact Mike Ramnath at (954) 723-5793 Sincerely, /s/ Mike Ramnath Mike Ramnath FCC Liaison Email: [email protected] EXHIBIT 13
Cover Letter(s)
Applicant: Motorola Inc. FCC ID: AZ489FT5806 Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 Page: 13-a REQUEST FOR CONFIDENTIALITY 31st August 2001 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Type Acceptance of Transmitter with FCC ID: AZ489FT5806. Gentlemen; Motorola is requesting that Exhibit 4 (Circuit Description), Exhibit 5 (Schematic Diagrams), Exhibit 9 (Internal Photographs) and Exhibit 10 (Semiconductor/Active Device List) not be made routinely available for public inspection. Motorola is in the process of licensing the technology and has a number of Patent applications pending. Please mark Exhibit 4, 5, 9 and 10 as Confidential. Contact me at (954) 723-5793 if you require any additional information. Regards, /s/ Mike Ramnath FCC Liaison Email: [email protected]
Cover Letter(s)
FCC ID: AZ489FT5806 17 th October 2001 Mr. Frank Coperich Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Re: Form 731 Confirmation Number: EA102220 with FCC ID: AZ489FT5806. Dear Mr. Coperich; Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322, herein submits its response to the 12 th October 2001request for information in Correspondence Number 20890. Q1). Confidentiality for Internal Photographs is not normally granted because the unit is available for examination after it is sold. Please modify your Confidentiality request accordingly. R1). Attached is a corrected Confidentiality Request (Exhibit 13a) deleting Exhibit 9, Internal Photos. Q2). Please clarify - Exhibit 12 states that the power output is variable over the range 1 - 3 W. However, Page 29 of the User Manual describes a high / low power output selection. R2. The radio is continuously variable in power, however from the user perspective, as outlined in the user guide, the user has the capability of choosing a discrete high (3 Watt maximum) and low power setting (1 Watt minimum) which appears on the radio display. The high power or low power setting can be any power level between 1 and 3 Watts. The power settings, as requested by the customer, will be pre-set at the factory or the dealer prior to shipment to the customer. Please note that this radio cannot be programmed by the customer. Q3). The Modulation Limiting plots you have submitted, Exhibit 6D, are not acceptable. Please send plots showing the transmitter deviation as a function of input level for several different modulating tones - per Section 2.1047(b). R3). See the attached addendum to Exhibit 6, which contains the Modulation Limiting Plot that was requested. Q4). Please supply frequency stability data for battery end-point voltage per Section 2.1055(d)(2). Your data in Exhibit 6J-2 does not cover this range. R4). See the attached addendum to Exhibit 6, which contains the Frequency Stability Chart that was requested. Q5). Multiple (4) batteries are indicated in Exhibit 12, but only one was tested during the SAR measurements. Please supply additional data for the remainder of the batteries. R5). See the amended Exhibit 12, which now reflects the one battery chemistry tested as Ni-Cad. FCC ID: AZ489FT5806 Q6). Please identify the Accessory NTN1624A used in the SAR test, Page 17 or 20 and the Accessory NMN1624A used in the SAR test, Page 11 of 22. Also, please justify your choice of the various accessories for testing. R6). A typographical error has been identified in the SAR Report Appendix A on page 11 of 22. The audio accessory is incorrectly identified as NMN1624A; the correct kit number is NTN1624A. The SAR Report (page 17 of 20) correctly identifies the audio accessory as NTN1624A. This audio accessory is described in section 3.0 of the SAR Report (page 6 of 20). Section 5.0 of the SAR Report contains detailed descriptions of the test configurations and also states "All antennas, batteries, and accessories listed in section 3.0 were included in the SAR test plan in order to determine the highest SAR levels." Regarding the audio accessories, Section 3.0 states: "Many different audio/push - to - talk accessories are available. They can generally be grouped into categories of 1) microphones, 2) earpieces, and 3) headsets depending on how they are used relative to the body. Representative samples were chosen as being typical within each group." To further clarify, Motorola's standard practice for two-way radios is to complete all abdomen tests first with the Remote Speaker Microphone (RSM) audio accessory as described in section 5.0.1 of the SAR Report. A Remote Speaker Microphone is the most common audio accessory for two-way radio users. SAR test experience has shown that other audio accessory options present comparable or lower SAR results. Q7). SAR report page 7 4.2: What is opening width of "supporting non-metallic structure"? Loss-tangent of support structure may influence SAR distribution on device. Supplement C suggests flat phantom length and width should be at least 2x device length and width => opening width should be 2x device width, or supporting data should be given for other conditions. R7). The opening width of the “supporting non-metallic structure” is 15.9 cm. The length of the opening is 61.0 cm. The supporting structure is a table made exclusively of wood with a loss tangent less than .05 at the frequency of interest. This is consistent with Supplement-C Appendix D requirements for loss tangent of the phantom and positioner. There are no metal connecting components associated with the structure. The structure is assembled with glue and wooden pegs. Contact me at (954) 723-5793 if you require any additional information. Regards, /s/ Mike Ramnath FCC Liaison Email: [email protected]
Cover Letter(s)
Applicant: Motorola Inc. FCC ID: AZ489FT5806 Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 Page: 13-a REQUEST FOR CONFIDENTIALITY 17th October 2001 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Type Acceptance of Transmitter with FCC ID: AZ489FT5806. Gentlemen; Motorola is requesting that Exhibit 4 (Circuit Description), Exhibit 5 (Schematic Diagrams), and Exhibit 10 (Semiconductor/Active Device List) not be made routinely available for public inspection. Motorola is in the process of licensing the technology and has a number of Patent applications pending. Please mark Exhibit 4, 5 and 10 as Confidential. Contact me at (954) 723-5793 if you require any additional information. Regards, /s/ Mike Ramnath FCC Liaison Email: [email protected]
Cover Letter(s)
FCC ID: AZ489FT5806 13 th November 2001 Mr. Frank Coperich Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Re: Form 731 Confirmation Number: EA102220 with FCC ID: AZ489FT5806. Dear Mr. Coperich; Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322, herein submits its request to add three additional battery chemistries to the above pending Grant for Equipment Authorization per Confirmation 21225. See the attached amended Exhibit 12 that shows NiCd and the additional battery chemistries, Li Ion, Ni MH, Alkaline. We are also attaching an addendum to the SAR Report to show that the additional batteries comply with the 8.0 W/kg RF Exposure Limits for Occupational/Controlled Exposure of Rule Part 2.1093 (d) (1). Contact me at (954) 723-5793 if you require any additional information. Regards, /s/ Mike Ramnath FCC Liaison Email: [email protected]
External Photos
MOTOROLA INC. FCC ID: AZ489FT5806 EXTERNAL PHOTOGRAPHS The following photographs are attached. 1. Front view. 2. Back view with battery. 3. Back view (FCC label location). 4. Side view (Right). 5. Side view (Left). 6. Top view (Controls). EXHIBIT 3 MOTOROLA INC. FCC ID: AZ489FT5806 FRONT VIEW EXHIBIT 3-1 MOTOROLA INC. FCC ID: AZ489FT5806 BACK VIEW WITH BATTERY EXHIBIT 3-2 MOTOROLA INC. FCC ID: AZ489FT5806 BACK VIEW (FCC LABEL) EXHIBIT 3-3 MOTOROLA INC. FCC ID: AZ489FT5806 SIDE VIEW (RIGHT) EXHIBIT 3-4 MOTOROLA INC. FCC ID: AZ489FT5806 SIDE VIEW (LEFT) EXHIBIT 3-5 MOTOROLA INC. FCC ID: AZ489FT5806 TOP VIEW EXHIBIT 3-6
ID Label/Location Info
MOTOROLA INC FCC ID: AZ489FT5806 LIST OF EXHIBITS DESCRIPTION EXHIBIT REFERENCE I. Identification label information 1 2.1033-(c) 11 & General Information 1a 1. Production Plans 2.1033-(c) 2. Application References 2.1061 3. Data Submittal Procedure II. Certification of Data 2 III. External Photographs 3 2.1033-(c) 12 IV. Block Diagrams (Circuit Diagrams) 4 V. Schematic Diagrams 5 2.1033-(c)-10 VI. Test Report 6 1. Data Index 6 2. RF Output Data 6A 2.1046 3. Modulation Characteristics 2.1047 A. Audio Response & Low Pass Filter Response 6B B. Low Pass Filter Response 6C C. Modulation Limiting 6D 4. Occupied Bandwidth 6E 2.1049 5. Adjacent Channel Coupled Power Ratio 6F 90.543 6. Conducted Spurious Emissions 6G 2.1051 7. Radiated Spurious Emissions 6H 2.1053 8. 1559 – 1610 Radiated Spurious 6I 90.543-(e) 9. Frequency Stability (Temperature & Supply Voltage) 6J-1, 6J-2 2.1055 VII. Test Set-up Procedures 7 2.1041 VIII. Instruction Manual 8 2.1033-(c) 3 IX. Internal Photographs. 9 2.1033-(c) 11, 12 X. Parts List and Tune-Up procedures 10 2.1033-(c) 9, 10 XI. RF Exposure Information 11 2.1093 XII. Operational Description 12 2.1033-(c) 4, 5 1. Technical Characteristics 2. Application XIII. Cover Letter 13 MOTOROLA INC FCC ID: AZ489FT5806 IDENTIFICATION LABEL LOCATION See the Attached Photograph or Sketch X Back Of Radio Back Of Radio under Belt Clip TYPE X The label is a paper polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with a minimum peel strength of 40 oz/inch. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3-3 for the actual location of the FCC label on the device. Label Attached Below. See Attached Drawing. EXHIBIT 1 MOTOROLA INC FCC ID: AZ489FT5806 GENERAL INFORMATION I. Production Plans -- Pursuant 2.1033 (c) Quantity production is planned. II. Application References -- Pursuant 2.1061 Reference is made to the following Motorola "Application References" 1. Portable Products and their application. 2. Portable Products Transmitter Modulations Methods. 3. Plantation, Florida Antenna Range. III. Data Submittal Procedure: Data is supplied in accordance with Part 2, Sub-part J of the Commissions’ rules. Necessary Bandwidth Computation for 8K10F1E Emission Designator The FCC Rule & Regulations Part 2, §2.202(b) defines Necessary Bandwidth as the minimum value of the occupied bandwidth sufficient to ensure that transmission of information at the rate and with the quality required for the system employed. §2.202(c) lists four methods of determining the necessary bandwidth, including the use of formulas in §2.202(g), and measurement in cases where the other methods of §2.202(c) do not apply. It is felt that while these formulas apply well to voice and many older digital modulation systems, the formulas do not apply to the high performance digital modulation employed in the system submitted for Certification because of difficulties determining representative values for the factors K and M. We have, therefore, used the measurement criteria of §2.202(c)(4). The value cited, 8K10, is the bandwidth that contains 99% of the total transmitted power. The 99% value was chosen because §2.202(b) defines Necessary Bandwidth as the minimum value of the occupied bandwidth . In turn, §2.202(b) defines Occupied Bandwidth as the frequency bandwidth such that, below its lower and above its upper frequency limits, the mean powers radiated are each equal to 0.5% of the total mean power radiated by a given emission, i.e., contains 99% of the total transmitted power. IV. Applicable References: • Reference Certification FCC ID: AZ489FT5806 •EIA/TIA-603 Land Mobile FM or PM Communications Equipment Measurement and Performance Standards • FCC Federal Regulations Part 47 Sec. 2.1033 – 2.1055 • FCC Federal Regulations Part 90 Sec.90.210 EXHIBIT 1a
Internal Photos
MOTOROLA INC. FCC ID: AZ489FT5806 CONFIDENTIALITY REQUESTED INTERNAL PHOTOGRAPHS The following photographs are attached. 1. RF board (Top). 2. RF board (Bottom). 3. RF board, less shields (Top) 4. RF board, less shields (Bottom). 5. Vocon board (Top). 6. Vocon board (Bottom). EXHIBIT 9 MOTOROLA INC. FCC ID: AZ489FT5806 RF BOARD (TOP VIEW) EXHIBIT 9-1 MOTOROLA INC. FCC ID: AZ489FT5806 RF BOARD (BOTTOM VIEW) EXHIBIT 9-2 MOTOROLA INC. FCC ID: AZ489FT5806 RF BOARD , less shields (TOP VIEW) EXHIBIT 9-3 MOTOROLA INC. FCC ID: AZ489FT5806 RF BOARD, less shields (BOTTOM VIEW) EXHIBIT 9-4 MOTOROLA INC. FCC ID: AZ489FT5806 VOCON BOARD (TOP VIEW) EXHIBIT 9-5 MOTOROLA INC. FCC ID: AZ489FT5806 VOCON BOARD (BOTTOM VIEW) EXHIBIT 9-6
Operational Description
MOTOROLA INC FCC ID: AZ489FT5806 DESCRIPTION I. Transmitter Technical Characteristics -- Pursuant 2.1033 (c) A. RF Power Output 1 – 3 Watt (Variable Power) B. Frequency Range 764 - 870 MHz C. Frequency Stability 0.00015 % D. Emissions 16K0F3E, 11K0F3E, 8K10F1E, 8K10F1D, E. Spurious Emissions - 75 dBc F. DC Voltage and Current into 7.5 Volts the final RF amplifier stage/stages 1.3 Amps II. Transmitter Application: This transmitter is primarily intended for use as a hand-held portable radio. The transmitter is characterized by the following features, options and accessories. A. Power Supply Available Ni-Cad Battery X , Mercury Battery , Alkaline Battery X , AC , Lead Acid Battery , Ni-MH Battery X ,Li-Ion X B. Antenna Available 1. Helical , Telescopic , Whip X , Dipole X , Dribble External , External . C. Squelch Types Available 1. Carrier Squelch X . 2. Tone "Private Line" X . 3. Digital "Private Line" X . D. Microphone - Control 1. Handset/Palm Microphone X 2. Wireline control X . E. Maximum Transmit Channel Capability 350 . F. Housing The transmitter will be housed in the housing shown in the accompanying photographs. G. Other Options 1. Single Tone Encoder X 2. Multiple Single Tone Encoder 3. Touch Code Encoder 4. Unit ID Encoder X 5. EMS Telemetry Encoder 6. Time out Timer X 7. Voice Encryption X 8. Digital Signaling X 9. Sel-Call Decode X 10. Trunking X 11. Conventional X 12. Digital Voice X _ EXHIBIT 12
Operational Description
MOTOROLA INC FCC ID: AZ489FT5806 DESCRIPTION I. Transmitter Technical Characteristics -- Pursuant 2.1033 (c) A. RF Power Output 1 – 3 Watt (Variable Power) B. Frequency Range 764 - 870 MHz C. Frequency Stability 0.00015 % D. Emissions 16K0F3E, 11K0F3E, 8K10F1E, 8K10F1D, E. Spurious Emissions - 75 dBc F. DC Voltage and Current into 7.5 Volts the final RF amplifier stage/stages 1.3 Amps II. Transmitter Application: This transmitter is primarily intended for use as a hand-held portable radio. The transmitter is c…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Deanna Zakharia(Regulatory Compliance Manager)
Technical Contact
Motorola IncMike Ramnath
[email protected]954-723-5793
8000 West Sunrise Blvd · Ft. Lauderdale, Florida · United States
