AZ489FT5829Dual-Band GSM Phone

Motorola Solutions, Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jul 06, 2004
Application Purpose: Original Equipment
Date of Application: Apr 25, 2004
Equipment Note: Dual-Band GSM Phone
Frequency Range: 1850.20000000 - 1909.80000000
Company: Motorola Solutions, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

D R AFT Motorola CN620 Dual Network WLAN/Cellular Phone User’s Guide Second Draft 04/08/04 @6864255H01@6864255H01 D R AFT D R AFT IMPORTANT NOTICE: PLEASE READ PRIOR TO USING YOUR PHONEThe SIM card provided in this kit is intended for use with the CN620 phone provided in this package. For more info rmation on SIM card compatibility, go to www.motorola.com/xxxxxx. D R AFT D R AFT i ContentsGetting Started........................................... 1 What’s Included in the Box .............................. 1Battery ............................................................. 3Locating Your SIM Card .................................. 5Powering Up/Powering Down .......................... 8Main Menu ..................................................... 12Status Icons ................................................... 13Status Indicators/N otifications ....................... 14 Making and Receiving Calls .......... ......... 15 Call Handover Feature................................... 15Dialing ............................................................ 15Making TTY Calls .......................................... 19Receiving Calls .............................................. 20Caller ID ......................................................... 20Call Waiting.................................................... 21Missed Phone Calls ....................................... 21Instant Voice .................................................. 21Ending Calls................................................... 22 Managing Calls........................................ 23 Multiple Call Appearances ............................. 23Using Speakerphone ..................................... 23Putting a Call on Hold .................................... 23Muting a Call .................................................. 23Transferring a Call ......................................... 24Conferencing.................................................. 24 Message Center....................................... 27 Voice Mail ...................................................... 27Entering Text.................................................. 27Email .............................................................. 30Managing Memory ......................................... 31Short Messaging Service (SMS) .................... 31Browser Messages ........................................ 33 Personal Information and Phone Management ............................................ 35 Call Log .......................................................... 35Contacts ......................................................... 37Calendar ........................................................ 41Tasks ............................................................. 45Synchronizing Information ............................. 45Shortcuts ........................................................ 45 D R AFT ii Service Dial Numbers .................................... 46Timers and Meters ......................................... 46 Data Access and Data Tools................... 48 Internet Browsing ........................................... 48Intranet Browsing ........................................... 48NET Applications ........................................... 48Speeds........................................................... 49SIM Application Toolkit .................................. 49 Phone Settings......................................... 50 Sounds........................................................... 50Ring Tones .................................................... 50Phone Status ................................................. 52Security .......................................................... 52Initial Setup .................................................... 52Display/Info Features ..................................... 52Call Settings................................................... 53Network Settings............................................ 55 Accessory Support.................................. 57 For More Information ..................................... 57 Phone Security ........................................ 58 Passwords ..................................................... 58Virtual Private Network (VPN)........................ 58SIM PIN.......................................................... 59SIM Lock ........................................................ 61Phone Lock .................................................... 61Authentication ................................................ 61Encryption ...................................................... 61 Understanding Status Messages........... 62Safety and General Information............. 65 RF Operational Characteristics ...................... 65Portable Radio Product Operation and EME Exposure ........................................................ 65Electromagnetic Interference/Compatibility ... 68Medical Devices ............................................. 68Operational Warnings .................................... 69Operational Cautions ..................................... 70Accessory Safety Information ........................ 71 D R AFT iii Driving Safety Tips .................................. 79Limited WarrantyMotorola Communication Products....... 81Patent and Trademark Information ........ 85 D R AFT iv D R AFT v DECLARATION OF CONFORMITYPer FCC CFR 47 Part 2 Section 2.1077(a)Responsible Party Name: Motorola, Inc.Address: 8000 West Sunrise BoulevardPlantation, FL 33322 USAPhone Number: 1 (800) 453-0920Hereby declares that the product:Product Name: CN620Model Number: H77UB6JA5AA Conforms to the following regulations:FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a)Class B Digital Device Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a …

Text truncated - open the document above for the full version.

Cover Letter(s)

Applicant: Motorola Inc FCC ID: AZ489FT5829 Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 1 Date: 14 th June 2004 Diane Poole Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Re: Form 731 Confirmation Number: EA504905 with FCC ID: AZ489FT5829. Dear Miss Poole, Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322, herein submits its response to your 7 th June 2004 request for information via correspondence number 26927. Q1). Please restate all simultaneous transmission conditions. Discussion on page 5 of 40 of Part 1 of the SAR report was difficult to understand and appears to only mentions 12 second transient situation. Also, does the voice mode mentioned in point 5) refer to both GSM and WLAN voice modes? Additionally, the Appendix G contains simultaneous SAR for GSM 900 mode and WLAN 5200. Is this a 12 second transient or continuous condition? Are there similar modes for GSM 850 and 1900 and WLAN 2400? Provide SAR results as applicable. R1). The device is capable of performing transitional “handovers” from either GSM to WLAN or WLAN to GSM transmission modes without dropping a call. These transitional “handover” modes are referred to as “Hand In” and “Hand Out” modes and are described in Table 1 below. Note, that if the radio is in data mode, no handover can be performed from WLAN to GSM modes or vice versa. The computational assessments for the simultaneous SAR for GSM 900 and WLAN 5200 modes presented in APPENDIX G reflect the 12 second transient condition. There are similar modes for GSM 850, 1900, and WLAN 2400. However, based on the individual assessments of these modes, the worst case was determined to be GSM 900 and WLAN 5200. Appendix G describes in detail the SAR calculation used for this mode. A summary of the simultaneous transmit modes for this device is presented below in table 1. Table 1: Description of Simultaneous Transmit Modes Mode Description Duration Hand-In GSM voice to WLAN voice transition 12 seconds Hand-OUT WLAN voice to GSM voice 12 seconds Applicant: Motorola Inc FCC ID: AZ489FT5829 Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 2 transition Simultaneous Transmit (GSM +WLAN) WLAN can be 2412 – 2472 MHz 802.11b/g) or 5180 – 5320 MHz(802.11a) GSM can be any of the four bands 824.2-848.8 MHz 880.2-914.8 MHz 1710.2-1784.8 MHz 1850.2-1909.8 MHz For WLAN 14.3% for 11 Mbps (802.11b) 14.3% for 36 Mbps (802.11g) 14.3% for 36 Mbps (802.11a) FOR GSM 1:8 for voice mode Q2). Can the device be used at the head with the flip cover closed? The device shape on contour plots do not seem to agree with set up photos. If so please provide corresponding SAR results. R2). The device is not intended to be used at the head with the flip closed. The relevant contour plots presented in the submitted report depicting a device with the flip closed was due to inadvertent selections of the incorrect device contour. The applicable sections of the revised report are attached with the relevant plots corrected. Q3). Please explain the large increase in SAR seen without an "attachment" on table 10 on page 30 of 40 (1.37 SAR). R3). Engineering judgment suggest that the loading effect presented by “attachments” redistributes the currents that affect SAR and does so to varying degrees depending on the specific design and layout of the device under test. Historically, Motorola’s iDEN products have exhibited this type of performance characteristic with similar attached accessories. The increase in SAR demonstrated during assessments without an “attachment” is a function of the products’ inherent performance. If you have any questions, please call me at 954-723-5793. Sincerely, /s/ Mike Ramnath (signed) Manager, Regulatory Compliance Email: [email protected]

Cover Letter(s)

FCC ID: AZ489FT5829 ______________________________________________________________________________ iDEN, Motorola Inc 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. (954) 723-5793 CONFIDENTIALITY REQUESTED Date: 1st July 2004 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ489FT5829. Dear Sir or Madam: Motorola is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. We are also requesting that the FCC mark Exhibit 3 (External Photos) and Exhibit 9, (Internal Photos) as Temporary Confidentiality as outlined in Public Notice DA 04-1705, dated June 15, 2004. This provision will give Motorola temporary confidentiality prior to product launch. Please mark Exhibits 4, 5, 10, and 12 as “Confidential” and Exhibit 3 (External Photos), 8 (Users Manual) and 9 (Internal Photos) as “Temporary Confidential”. Please contact me if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Manager, Regulatory Compliance Tel: (954) 723-5793 E-mail: [email protected] EXHIBIT 13B

Cover Letter(s)

FCC ID: AZ489FT5829 ______________________________________________________________________________ iDEN, Motorola Inc 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. (954) 723-5793 CONFIDENTIALITY REQUESTED Date: 7th July 2004 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ489FT5829. Dear Sir or Madam: Motorola is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. We are also requesting that the FCC mark Exhibit 3 (External Photos), 8 (Users Manual) and Exhibit 9, (Internal Photos) as Temporary Confidentiality as outlined in Public Notice DA 04-1705, dated June 15, 2004. This provision will give Motorola temporary confidentiality prior to product launch. Please mark Exhibits 4, 5, 10, and 12 as “Confidential” and Exhibit 3 (External Photos), 8 (Users Manual) and 9 (Internal Photos) as “Temporary Confidential”. Please contact me if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Manager, Regulatory Compliance Tel: (954) 723-5793 E-mail: [email protected] Exhibit 13b

External Photos

ID Label/Location Info

FCC Filing Package for Motorola CN620 Transceiver FCC ID: AZ489FT5829 ______________________________________________________________________________________ IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Exhibit 1. Identification Label -- Pursuant to 47 CFR 2.925, 2.1065 and 2.1033(c)11 1.1 Location Back side of the radio product unit chassis (Photograph 1.1). 1.2 Type The label is a white polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with minimum peel strength of 5 lbs/in. 1.3 Markings (Text) Enlarged view of label (showing FCC ID and manufacturer type number): Photograph 1.1: Location of label on back of unit’s housing (battery cover removed). Photograph 1.2: Zoom view of labels containing FCC ID and FCC Logo FCC Filing Package for Motorola CN620 Transceiver FCC ID: AZ489FT5829 ______________________________________________________________________________________ IDEN, Motorola Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322, USA WWW.MOT.COM/iDEN Exhibit 1A. General Information 1A. 1 Production Plans Quantity production is planned. 1A.2 Application References – Pursuant to 47 CFR 2.948 and 2.1061 Reference is made to following Motorola “Application References” 1. Open Area Test Site “PC Test” (FCC Registration: ?? / Industry of Cananda: IC?) 1A.3 Data Submittal Procedure Data located in Exhibit 6 is supplied in accordance with 47CFR2, Sub-part J and Part 90, Sub-parts 1 and Sub-part S of the Commission’s rules. 1A.4 Similar, currently Certified Transceiver FCC ID: IHDT56DR1 (GSM Only) 1A.5 Additional Considerations A Declaration of Conformity in accordance with 47CFR2.1077(a) is provided in Exhibit 8 as evidence of compliance with Part 15 requirements for these additional Class B digital device functionalities per 47CFR15.101(a). Compliance with Part 15 requirements for the Direct-Conversion (zero IF superheterodyne) receiver has been determined by verification in accordance with 47CFR15.1.

Internal Photos

RF Exposure Info

CGISS EME Form-SAR-Rpt-Rev. 2.00 Page 1 of 40 CGISS EME Test Laboratory 8000 West Sunrise Blvd Fort Lauderdale, FL. 33322 S.A.R. EME Compliance Test Report Part 1 of 5 Note: Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 2.0 of this report. Signature on File 6/15/04 ____________________________________________________________ _________________________ Ken Enger Date Approved Senior Resource Manager, Laboratory Director, CGISS EME Lab Note: This report shall not be reproduced without written approval from an officially designated representative of the Motorola EME Laboratory. Date of Report: June 14, 2004 Report Revision: Rev. C Manufacturer: Motorola Product Description: CN620; Quad band GSM and Tri band WLAN (802.11a, b, and g) FCC ID: AZ489FT5829 Device Model: H77UBH6JA5AA Certificate Number: 1449-01 Test Period: 2/19/04-3/24/04 EME Tech: Ed Church Responsible Eng: Deanna Zakharia (Elect. Principle Staff Eng.) Author: Michael Sailsman (Global EME Regulatory Affairs Liaison) CGISS EME Form-SAR-Rpt-Rev. 2.00 Page 2 of 40 TABLE OF CONTENTS Part 1 of 5 1.0 Introduction 2.0 Reference Standards and Guidelines 3.0 Description of Test Sample 3.1 Test Signal 3.2 Test Output Power 4.0 Description of Test Equipment 4.1 Description of S.A.R Measurement System 4.2 Description of Phantom 4.2.1 Flat Phantom 4.2.2 SAM phantom 4.3 Simulated Tissue Properties 4.3.1 Type of Simulated Tissue 4.3.2 Simulated Tissue Composition 4.4 Test conditions 5.0 Probe Scan Procedures 5.1 Shortened scan rationale 5.2 Description of Test Procedure 5.3 Device Test Positions 5.3.1 Body 5.3.2 Head 5.3.3 Face 5.4 Test Position Photographs 6.0 Measurement Uncertainty 7.0 S.A.R. Test Results 7.1 S.A.R. results 7.2 Peak S.A.R. location 7.3 Highest S.A.R. results calculation methodology 8.0 Conclusion Part 2 of 5 Appendix A: Power Slump Data/Shortened scan Appendix B: Data Results Appendix C: Dipole System Performance Check Results Part 3 of 5 Appendix C: Dipole System Performance Check Results (Continued) Appendix D: Probe/Dipole Calibration Certificates Part 4 of 5 Appendix D: Probe/Dipole Calibration Certificates (continued) Appendix E: Illustration of Body-worn Accessories Appendix F: Accessories and options test status and separation distances Part 5 of 5 Appendix G: Explanation of 5GHz assessment and description of test methodology CGISS EME Form-SAR-Rpt-Rev. 2.00 Page 3 of 40 REVISION HISTORY Date Revision Comments 4/13/04 O Release of Prototype results 4/15/04 A Revised report partitions to accommodate FCC file size limitation 4/22/04 B Revised report to update descriptive language in section 3.0 and 5.0 6/14/04 C Revised parts 1 and 2 of the report to update revision history and to replace incorrect contour plots for applicable head assessments. Parts 3, 4, and 5 were updated to Rev C to be synchronized with the parts 1 and 2. CGISS EME Form-SAR-Rpt-Rev. 2.00 Page 4 of 40 1.0 Introduction This report details the utilization, test setup, test equipment, and test results of the Specific Absorption Rate (S.A.R.) measurements performed at the CGISS EME Test Lab for model number H77UBH6JA5AA, FCC ID: AZ489FT5829. The applicable exposure environment is General Population/Uncontrolled. 2.0 Reference Standards and Guidelines This product is designed to comply with the following national and international standards and guidelines. • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • IEEE 1528, 2003 "Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques" • American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engi- neers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Terminal frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation - Human Exposure) Standard 2003 • ANATEL, Brazil Regulatory Authority, Resolution 256 (April 11, 2001) "additional requirements for SMR, cellular and PCS product certification." CGISS EME Form-SAR-Rpt-Rev. 2.00 Page 5 of 40 3.0 Description of Test Sample FCC ID: AZ489FT5829 is a class B GSM and WLAN capable device. The device is class 4 capable in the GSM 850 and 900 MHz bands and class 1 capable in the 1800 and 1900 MHz bands. The device also supports GPRS class 10 (2 uplink and 4 downlink slots) functionality. The WLAN section supports 802.11 b/g(2.4 GHz) and 802.11a(5.24 GHz). The following modes are supported with this device: (1) 1:8 duty cycle GSM voice only mode, (2) 14.3% duty cycle WLAN voice mode (6 Mbps, though higher data rates up to 54 Mbps is supported dependent on selected modulation scheme. Note that maximum power occurs at 36Mbps; however, the typical duty cycle is 4%), (3) GSM packet data (25% duty cycle, two TX slots in one frame), (4) WLAN packet data at 99.5% duty cycle for 11 Mbps CCK at 2.4 GHz, 97.1% for 36 Mbps in 2.4 GHz, and 97.1% for 36 Mbps in 5 GHz band, (5) 12 second dual mode simultaneous operation occur during voice mode to WLAN packet data handovers. Simultaneous transmission does not occur during handovers to GSM (GPRS) modes. This device incorporates two antennas; an internal PIFA and ¼ wave “Stubby” antennas. The internal PIFA antenna is utilized for WLAN modes only but supports both 2.4 and 5 GHz WLAN operation. The stubby antenna supports all four GSM bands (850/900/1800/1900) and both WLAN bands (2.4/5 GHz). During WLAN operation, the WLAN …

Text truncated - open the document above for the full version.

Test Report

PCTEST PT. 22/24 REPORT FCC Measurement Report Reviewed By: Quality Manager Test Report S/N: 22/24.240217123-R1AZ4 Test Dates: February 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: AZ489FT5829 Page 1 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com PRECOMPLIANCE TESTING FCC Part 22/ 24 Certification MOTOROLA, INC. Dates of Tests: February 25-26, 2004 8000 West Sunrise Bolevard Test Report S/N: 22/24.240217123-R1.AZ4 Plantation, FL 33322-9947 Test Site: PCTEST Lab, Columbia MD FCC ID AZ489FT5829 APPLICANT MOTOROLA, Inc. Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §24(E), §22.901(d); §2 EUT Type: Dual-Band GSM Phone Model: H77UBH6JA5AA Tx Frequency Range: 824.20 – 848.80MHz (GSM850) / 1850.20 – 1909.80MHz (GSM1900) Rx Frequency Range: 869.20 – 893.80MHz (GSM850) / 1930.20 – 1989.80MHz (GSM1900) Max. RF Output Power: 1.876 W ERP GSM850 (32.733 dBm) /1.889 W EIRP GSM1900 (32.751 dBm) Emission Designator(s): 250KGXW (GSM850), 247KGXW (GSM1900) Test Device Serial No. Identical Prototype [S/N: 1] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. If the EUT contains any additional embedded transmitters, then those transmitters were active during all tests. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 22/24 REPORT FCC Measurement Report Reviewed By: Quality Manager Test Report S/N: 22/24.240217123-R1AZ4 Test Dates: February 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: AZ489FT5829 Page 2 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-9 5.1 EFFECTIVE RADIATED POWER OUTPUT 10 6.1 EQUIVALENT ISOTROPIC RADIATED POWER 11 7.1 RADIATED MEASUREMENTS 12-17 8.1 FREQUENCY STABILITY 18-21 9.1 PLOTS OF EMISSIONS 22 10.1 LIST OF TEST EQUIPMENT 23 11.1 SAMPLE CALCULATIONS 24 12.1 CONCLUSION 25 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL PCTEST PT. 22/24 REPORT FCC Measurement Report Reviewed By: Quality Manager Test Report S/N: 22/24.240217123-R1AZ4 Test Dates: February 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: AZ489FT5829 Page 3 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: MOTOROLA INC. Address: 8000 West Sunrise Boulevard Plantation, FL 33322-9947 • Model: H77UBH6JA5AA • Quantity: Quantity production is planned • Emission Designators: 250KGXW (GSM850), 247KGXW (GSM1900) • Tx Freq. Range: 824.20 – 848.80 MHz (GSM850)/1850.20 – 1909.80 MHz (GSM1900) • Rx Freq. Range: 869.20 – 893.80 MHz (GSM850)/1930.20 – 1989.80 MHz (GSM1900) • Max. Power Rating: 1.876 W ERP GSM850 (32.733 dBm)/ 1.889 W EIRP GSM1900 (32.751 dBm) • FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) • Equipment (EUT) Type: Dual-Band GSM Phone • Modulation(s): GSM • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): § 24(E), §22.901(d) • Dates of Tests: February 25-26, 2004 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 22/24.240217123-R1.AZ4 PCTEST PT. 22/24 REPORT FCC Measurement Report Reviewed By: Quality Manager Test Report S/N: 22/24.240217123-R1AZ4 Test Dates: February 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: AZ489FT5829 Page 4 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and spurious measurements were made outdoors at a 3-meter test range (see Figure2). The equipment under test is placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. A half- wave dipole was substituted in place of the EUT. This dipole antenna was driven by a signal generator and the level of the signal generator was adjusted to obtai…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Arine Lee(Certification Manager)

[email protected]+602240258Fax: --

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Non-Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

Test Firm

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]4102906652Fax: 4102906654

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	1.889 W	247KGXW	0.1 ppm
