AZ489FT7007Handheld Data Terminal with WAN & Bluetooth modem

Applicant: Motorola, Inc. FCC ID: AZ489FT7007 Exhibit 8 Exhibit VIII User Information and User Manual 1) User Card/Booklet - 2 pages, contains important information for safe usage and RF energy awareness and control information for compliance with RF energy exposure limits 2) User Service Manual HDT 600 Data Terminal - 29 PDF pages total, 22 numbered pages Please find the information required by Part 15.19, 15.21 & 15.105 in Owners Manual on page 7 of this PDF file, or click tab to FCC INTERFERENCE WARNING. Note: Items 1 & 2 above follow this cover page 68P02963C77-APlease retain for future use BEFORE USING THIS RADIO TERMINAL, READ THIS BOOKLET WHICH CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL INFORMATION FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND INTERNATIONAL STAN- DARDS. The information provided in this document supersedes information contained in user guides published prior to February 2002. For radio terminals that have been approved as intrinsically safe, read the instruc- tions and information on intrinsic safety in this booklet. Compliance with RF Energy Exposure Standards Notice: This radio terminal is intended for use in occupational/controlled applica- tions, where users have been made aware of the potential for exposure and can ex- ercise control over their exposure. This radio terminal device is NOT authorized for general population, consumer or similar use. Federal Communication Commission Regulations: The FCC established limits for safe exposure to radio frequency (RF) emissions from portable two-way radios. The FCC requires manufacturers to demonstrate compliance with RF exposure limits before portable two-way radios can be market- ed in the U.S. When two-way radios are approved for occupational /controlled envi- ronment exposure limits, the FCC requires users to be fully aware of and exercise control over their exposure. Awareness and control of RF exposure can be accom- plished by the use of labels, or by education or training through appropriate means, such as information and instructions in user manuals or safety booklets. Your Mo- torola two-way radio terminal has a RF exposure information label in the battery compartment. This user safety booklet includes useful information about RF expo- sure and helpful instructions on how to control your RF exposures. Your Motorola two-way radio terminal is designed and tested to comply with a num- ber of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio terminal complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/con- trolled RF exposure environment at usage factors of up to 50% transmit -50% re- ceive. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio terminal radiates measurable RF energy only while it is trans- mitting, not when it is receiving or in standby mode. Note: that the approved batter- ies, supplied with this radio terminal are rated for a 5-5-90 duty cycle (5% transmit- 5% receive - 90% standby), even though this radio terminal complies with the FCC occupational exposure limits at usage factors of up to 50% transmit. Your Motorola two-way radio terminal complies with the following RF energy exposure standards and guidelines: •United States Federal Communications Commission, Code of Federal Regula- tions; 47CFR part 2 sub-part J •American National Standards Institute (ANSI) / Institute of Electrical and Elec- tronic Engineers (IEEE) C95. 1-1992 •Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition •International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 •Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radio frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 •Australian Communications Authority Radio communications (Electromagnetic Radiation - Human Exposure) Standard 2001. •ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001) "addi- tional requirements for SMR, cellular and PCS product certification." Compliance and Control Guidelines and Operating Instructions for portable two-way radio terminals To control your exposure and ensure compliance with the occupational /controlled environment exposure limits always adhere to the following Procedures. •If you are not using a body-worn accessory and are not using the radio termi- nal in the intended use position in front of the face, then ensure the antenna and the radio terminal are kept 2.5 cm (one inch) from the body when transmit- ting. Keeping the radio terminal at a proper distance is important because of RF exposures decrease with distance from the antenna. •Use only Motorola approved supplied or replacement batteries, and accesso- HANDHELD PORTABLE TERMINAL HDT600 ab ries. Use of non-Motorola-approved, batteries and accessories may exceed FCC RF exposure guidelines. For additional information on RF exposure awareness information, visit the following Motorola website: www.mot.com/rfhealth. Electromagnetic Interference/Compatibility Note:Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed, or otherwise configured for electromagnet- ic compatibility. Facilities To avoid electromagnetic interference and/or compatibility conflicts, turn off your ra- dio terminal in any facility where posted notices instruct you to do so. Hospitals or health care facilities may be using equipment that is sensitive to external RF energy. Aircraft When instructed to do so, turn off your radio terminal when on board an aircraft. Any use of a radio terminal must be in accordance with applicable regulations per airline crew instructions. Medical Devices Pacemakers The Advanced Medical Technology Association (AdvaMed) recommends that a minimum separation of 6 inches (15 centimeter…

Text truncated - open the document above for the full version.

Ownerís Manual HDT 600 Handheld Data Terminal 68P02966C70-A 68P02966C70-A @6802966C70@ a Inca very small format.book Page 1 Thursday, May 22, 2003 7:57 PM Commercial, Government and Industrial Solutions Sector 1301 E. Algonquin Road, Schaumburg, IL 60196 68P02966C70-A June, 2003 © Motorola Inc., 2003 Contents COMPUTER SOFTWARE COPYRIGHTS...................... iii FCC INTERFERENCE WARNING................................. vi What is the HDT 600 Terminal ........................................ 1 HDT 600 Parts ................................................................ 3 Unpacking ....................................................................... 4 HDT 600 Cradle Connections ......................................... 5 Installing the Battery........................................................ 6 Removing the Battery...................................................... 6 First Time Battery Charge ............................................... 7 Charging the Battery ....................................................... 8 Battery Maintenance ...................................................... 9 Turning on the HDT 600 ................................................ 10 Suspend Mode .............................................................. 10 Turning off the HDT 600 ................................................ 10 Using the HDT 600........................................................ 11 Using the Stylus Pen ..................................................... 11 Scanning With the HDT 600 (Optional) ......................... 12 Resetting the HDT 600.................................................. 13 Cradle Installation ......................................................... 14 Maintaining the HDT 600 .............................................. 16 Accessories ................................................................... 17 What to Do If ................................................................. 18 Battery Warnings and Disposal ..................................... 20 Inca very small format.book Page i Thursday, May 22, 2003 7:57 PM ii This page intentionally left blank Inca very small format.book Page ii Thursday, May 22, 2003 7:57 PM iii COMPUTER SOFTWARE COPYRIGHTS The Motorola products described in this instruction manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs, including the exclu- sive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copy- righted Motorola computer programs contained In the Motorola products described in this instruction manual may not be copied or reproduced in any manner without the express written permission of Motor- ola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel. or otherwise. any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive, royalty free license to use that arises by operation of law in the sale of a product. EPS ñ 34440- B This warranty applies within the fifty (50) United States, the District of Columbia and Canada. LIMITED WARRANTY MOTOROLA COMMUNICATION PRODUCTS If the affected product is being purchased pursuant to a written Communications System Agreement signed by Motorola, the warranty contained in that written agreement will apply. Otherwise, the follow- ing warranty applies. I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG: Motorola Inc. or, if applicable, Motorola Canada Limited ("Motorola") warrants the Motorola manu- factured radio communications product, including original equipment crystal devices and channel ele- ments ("Product"), against material defects in material and workmanship under normal use and service for a period of One (1) Year from the date of shipment. Motorola, at its option, will at no charge either repair the Product (with new or reconditioned parts), replace it with the same or equivalent Product (using new or reconditioned Product), or refund the pur- chase price of the Product during the warranty period provided purchaser notifies Motorola according to the terms of this warranty. Repaired or replaced Product is warranted for the balance of the original applicable warranty period. All replaced parts of the Product shall become the property of Motorola. This express limited warranty is extended by Motorola to the original end user purchaser purchasing the Product for purposes of leasing or for commercial, industrial, or governmental use only, and is not assignable or transferable to any other party. This is the complete warranty for the Product manufac- tured by Motorola. Motorola assumes no obligations or liability for additions or modifications to this warranty unless made in writing and signed by an officer of Motorola. Unless made in a separate writ- ten agreement between Motorola and the original end user purchaser, Motorola does not warrant the installation, maintenance or service of the Product. Motorola cannot be responsible in any way for any ancillary equipment not furnished by Motorola which is attached to or used in connection with the Product, or for operation of the Product with any ancillary equipment, and all such equipment is expressly excluded from this warranty. Because each system which may use the Product is unique, Motorola disclaims liability for range, coverage, or oper- ation of the system as a whole under this warranty. Inca very small format.book Page iii Thursday, May 22, 2003 7:57 PM iv II. GENERAL PROVISIONS: This warranty sets forth the full extent of Motorolaís responsibilities regarding the Product. Repair, replacement or refund of the purchase price, at Motorolaís option, is the exclusive remedy. THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES. MOTOROLA DIS- CLAIMS ALL OTHER W…

Text truncated - open the document above for the full version.

Ownerís Manual HDT 600 Handheld Data Terminal 68P02966C70-A 68P02966C70-A @6802966C70@ a Inca very small format.book Page 1 Thursday, May 22, 2003 7:57 PM Commercial, Government and Industrial Solutions Sector 1301 E. Algonquin Road, Schaumburg, IL 60196 68P02966C70-A June, 2003 © Motorola Inc., 2003 Contents COMPUTER SOFTWARE COPYRIGHTS...................... iii FCC INTERFERENCE WARNING................................. vi What is the HDT 600 Terminal ........................................ 1 HDT 600 Parts ................................................................ 3 Unpacking ....................................................................... 4 HDT 600 Cradle Connections ......................................... 5 Installing the Battery........................................................ 6 Removing the Battery...................................................... 6 First Time Battery Charge ............................................... 7 Charging the Battery ....................................................... 8 Battery Maintenance ...................................................... 9 Turning on the HDT 600 ................................................ 10 Suspend Mode .............................................................. 10 Turning off the HDT 600 ................................................ 10 Using the HDT 600........................................................ 11 Using the Stylus Pen ..................................................... 11 Scanning With the HDT 600 (Optional) ......................... 12 Resetting the HDT 600.................................................. 13 Cradle Installation ......................................................... 14 Maintaining the HDT 600 .............................................. 16 Accessories ................................................................... 17 What to Do If ................................................................. 18 Battery Warnings and Disposal ..................................... 20 Inca very small format.book Page i Thursday, May 22, 2003 7:57 PM ii This page intentionally left blank Inca very small format.book Page ii Thursday, May 22, 2003 7:57 PM iii COMPUTER SOFTWARE COPYRIGHTS The Motorola products described in this instruction manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs, including the exclu- sive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copy- righted Motorola computer programs contained In the Motorola products described in this instruction manual may not be copied or reproduced in any manner without the express written permission of Motor- ola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel. or otherwise. any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive, royalty free license to use that arises by operation of law in the sale of a product. EPS ñ 34440- B This warranty applies within the fifty (50) United States, the District of Columbia and Canada. LIMITED WARRANTY MOTOROLA COMMUNICATION PRODUCTS If the affected product is being purchased pursuant to a written Communications System Agreement signed by Motorola, the warranty contained in that written agreement will apply. Otherwise, the follow- ing warranty applies. I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG: Motorola Inc. or, if applicable, Motorola Canada Limited ("Motorola") warrants the Motorola manu- factured radio communications product, including original equipment crystal devices and channel ele- ments ("Product"), against material defects in material and workmanship under normal use and service for a period of One (1) Year from the date of shipment. Motorola, at its option, will at no charge either repair the Product (with new or reconditioned parts), replace it with the same or equivalent Product (using new or reconditioned Product), or refund the pur- chase price of the Product during the warranty period provided purchaser notifies Motorola according to the terms of this warranty. Repaired or replaced Product is warranted for the balance of the original applicable warranty period. All replaced parts of the Product shall become the property of Motorola. This express limited warranty is extended by Motorola to the original end user purchaser purchasing the Product for purposes of leasing or for commercial, industrial, or governmental use only, and is not assignable or transferable to any other party. This is the complete warranty for the Product manufac- tured by Motorola. Motorola assumes no obligations or liability for additions or modifications to this warranty unless made in writing and signed by an officer of Motorola. Unless made in a separate writ- ten agreement between Motorola and the original end user purchaser, Motorola does not warrant the installation, maintenance or service of the Product. Motorola cannot be responsible in any way for any ancillary equipment not furnished by Motorola which is attached to or used in connection with the Product, or for operation of the Product with any ancillary equipment, and all such equipment is expressly excluded from this warranty. Because each system which may use the Product is unique, Motorola disclaims liability for range, coverage, or oper- ation of the system as a whole under this warranty. Inca very small format.book Page iii Thursday, May 22, 2003 7:57 PM iv II. GENERAL PROVISIONS: This warranty sets forth the full extent of Motorolaís responsibilities regarding the Product. Repair, replacement or refund of the purchase price, at Motorolaís option, is the exclusive remedy. THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES. MOTOROLA DIS- CLAIMS ALL OTHER W…

Text truncated - open the document above for the full version.

Please retain for future use 6802965C93-B July, 2003 @6802965C93@ Commercial, Government and Industrial Solutions Sector 1301 E. Algonquin Road, Schaumburg, IL 60196Copyright © 2003 Motorola All Rights Reserved. Safety and General Information RF Operational Characteristics Your data terminal contains a radio frequency transmitter to convey the information you wish to send as well as occasional automatic signals used to sustain connection to the wireless network, and a receiver which enables you to receive communication and connection information from the network.For data radio terminals that have been approved as intrinsically safe, read the in-structions and information on intrinsic safety in this booklet.PORTABLE RADIO PRODUCT OPERATION AND EME EXPOSUREYour Motorola radio product is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy (EME): • United States Federal Communications Commission, Code of Federal Regula- tions; 47CFR part 2 sub-part J • American National Standards Institute (ANSI) / Institute of Electrical and Elec- tronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radio frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radio communications (Electromagnetic Radiation - Human Exposure) Standard 2003. • ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001) "addi- tional requirements for SMR, cellular and PCS product certification." To assure optimal radio product performance and make sure human exposure to radio frequency electromagnetic energy is within the guidelines set forth in the above standards, always adhere to the following procedures: Body-worn operationTo maintain compliance with FCC RF exposure guidelines, if you wear a radio prod-uct on your body when transmitting, always place the radio product in a Motorola approved holster or carry case for this product . When placing your data ter- minal in a carry case approved for body-worn applications for this device, it must be inserted with the display facing away from the user's body . Use of non-Motorola-approved accessories may exceed FCC RF exposure guidelines. For additional information on RF exposure awareness information, visit the following Motorola website: www.mot.com/rfhealth. Electro Magnetic Interference/Compatibility NOTE: Nearly every electronic device is susceptible to electromag- netic interference (EMI) if inadequately shielded, designed or otherwise configured for electromagnetic compatibility. FacilitiesTo avoid electromagnetic interference and/or compatibility conflicts, turn off your ra-dio data terminal in any facility where posted notices instruct you to do so. Hospitals or health care facilities may be using equipment that is sensitive to external RF en-ergy.AircraftWhen instructed to do so, turn off your radio data terminal when on board an aircraft. Any use of a radio data terminal must be in accordance with applicable regulations per airline crew instructions. IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.READ THIS INFORMATION BEFORE USING YOUR HANDHELD DATA TERMINAL. HANDHELD DATATERMINALHDT 600 ab Medical DevicesPacemakersThe Advanced Medical Technology Association (AdvaMed) recommends that a minimum separation of 6 inches (15 centimeters) be maintained between a hand-held wireless radio data terminal and a pacemaker. These recommendations are consistent with those of the U.S. Food and Drug Administration.Persons with pacemakers should: • ALWAYS keep the radio data terminal more than 6 inches (15 centimeters) from their pacemaker when the radio data terminal is turned ON. • Do not carry the radio data terminal in the breast pocket.• Turn the radio data terminal OFF immediately if you have any reason to sus- pect that interference is taking place. Hearing AidsSome digital wireless radio data terminals may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufac-turer to discuss alternatives.Other Medical DevicesIf you use any other personal medical device, consult the manufacturer of your de-vice to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.Use While DrivingCheck the laws and regulations on the use of radio products in the area where you drive. Always obey them. When using the radio product while driving, please: • Give full attention to driving and to the road.• Use hands-free operation, if available.• Pull off the road and park before making or answering a call if driving condi- tions so require. Operational WarningsFor Vehicles With an Air BagDo not place a portable radio product in the area over the air bag or in the air bag deployment area. Air bags inflate with great force. If a portable radio is placed in the air bag deployment area and the air bag inflates, the radio product may be propelled with great force and cause serious injury to occupants of the vehicle.Potentially Explosive AtmospheresTurn off your radio data terminal prior to entering any area with a potentially explosive atmosphere, unless it is a radio data terminal type especially qualified for use in such areas as "Intrinsically Safe" (for example, Factory Mutual, CSA, UL, or CENELEC). Do not remove, install, or charge batteries in such areas. Sparks in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death. NOTE: The areas with potentially explosive atmospheres referred to above include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemica…

Text truncated - open the document above for the full version.

Applicant: Motorola, Inc.FCC ID: AZ489FT7007 Exhibit 2 FCC Certification Report for the FCC ID: AZ489FT7007 HDT 600 Terminal New Certification Exhibit 2 - Certification Data

Applicant : Motorola, Inc.FCC ID: AZ489FT7007 Exhibit 13 EXHIBIT XIII - Cover Letters New Certification Report for the FCC ID: AZ489FT7007 HDT 600 Terminal Cover Letter 1.) Certification action requested Cover Letter 2.) Request for Confidentiality under Part 0.459. Cover Letter 3.) Motorola Agent authorization letter allowing Rod Munro to sign FCC Form 731 on behalf of Motorola, Inc. Motorola, Inc., 8000 W. Sunrise Blvd., Plantation, FL 33322 Page 1 Date: 17 th April 2003 Authorization & Evaluation Division Federal Communication Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter authorizes Rod Munro, President of Spectrum Technology, Inc. to act for Motorola, Inc for the purpose of signing the FCC Form 731 electronically on behalf of Motorola, Inc. solely with respect to the HDT600 with FCC ID: AZ489FT7007. Also, to check ‘yes” in item 15 of the said form Section 5301 (Anti-Drug Abuse) certification. The applicant, Motorola, Inc., must certify that neither the applicant nor any party to the applicant is subject to denial of Federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse act of 1988, 21 USC Subpart 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. Please contact me at 954.723.5793 if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) FCC Liaison Email: [email protected]

Applicant: Motorola Inc FCC ID: AZ489FT7007 Motorola Inc., 8000 Sunrise Blvd West; Plantation, FL 33322 Date: 11 th June 2003 Steve Dayhoff Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Re: 1) Form 731 Confirmation Number: EA277418 with FCC ID: AZ489FT7007. 2) Form 731 Confirmation Number: EA804336 with FCC ID: AZ489FT7007. Dear Mr. Dayhoff, Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322, herein submits its response to your request for information on FCC ID: AZ489FT7007, EA277418 and EA804336 via Correspondence Numbers 25242 and 25216. Q1) Please clarify references in user manual to optional GPRS and DATATAC radios. It appears that these would be precluded under this FCC ID? R1) The attached User Manual was amended, please see page 7, for optional GPRS and DATATAC radios. Q2) Please reword RF exposure training wording. Wording appears consistent with PTT devices. This device appears fundamentally different. Please provide specific instructions about when a user will be exposed with this radio and how they should control their exposure. R2) See the attached amended RF Safety Card. If you have any questions, please contact me at 954-723-5793. Sincerely, /s/ Mike Ramnath FCC Liaison Email: [email protected]

Applicant: Motorola, Inc.FCC ID: AZ489FT7007 Exhibit 31 EXHIBIT 3 EXTERNAL PHOTOS HDT 600 Terminal Front and rear view of terminal Applicant: Motorola, Inc.FCC ID: AZ489FT7007 Exhibit 32 Identifier Label for the FCC ID:AZ489FT7007 Grantee: Motorola, Inc. Model: F4415A HDT600 iDEN case ( F4415A VA00010AB ) regulation label HDT 600 Terminal End View of Terminal and IrDA port used in the Office Dock 5 of 5 HDT 600 Terminal FCC identifier label location Rear view, battery and strap removed, FCC Identifier label location

Applicant: Motorola, Inc.FCC ID: AZ489FT7007 EXHIBIT 1 LIST OF EXHIBITS DESCRIPTION EXHIBITSREFERENCE I.Identification label Information12.1033 (b) 7 & 2.925 & General Information1A 1. Production Plans2.1031 2. Application ReferencesN/A 3. Data submittal Procedure 4. Similar Certified Transmitter II.Certification Data2 III.External Photographs32.1033 (b) 7 IV.Block Diagrams (Circuit Diagrams) 42.1033 (b) 5 V. Schematic Diagrams & Antenna Assembly52.1033 (b) 5 VI.Test Report #1, Part 15.247 – New Certification62.1033 (b) 6 Eleven Common Bluetooth Items6 Six tests required615.247 (a, b, c, g, h) 1) The Occupied Bandwidth Section 15.247(a)!ii 2) Conducted Output Power Section 15.247(b)1 3) EIRP limit Section 15.247(b)3 4) RF safety Section 15.247(b)4 see Exhibit XII 5) Spurious Emissions Section 15.247 (c) 6) Power Spectral Density in Acquistion Mode Test Report #2, Part 90 –Supplemental Report for Previously Certified Transmitter Exhibit 6A – RF Power Output 2.1046 Exhibit 6G – Transmitter Radiated Spurious Emissions 2.1053 Exhibit 6G - Equivalent Isotropic Radiated Power VII.Test Set-up Procedures72.1041 VIII.Instruction Manual82.1033 (b) 3 IX.Internal Photographs92.1033 (b) 7 X.Part List and Tune Up Procedures10N/A XI.RF Exposure Information112.1093 & 15.247 (b)4 XII.Operational Description122.1033 (b) 1, 2, 4, 8 Antenna Requirements1215.203 Technical Characteristics 1 - 5 1. Application XIII. Cover Letter, Action Requested13 Cover Letter, Authorization to sign FCC Form 73113 Please NOTE: Exhibits 4, 5 and 12 are requested to held confidential Applicant: Motorola, Inc.FCC ID: AZ489FT7007 EXHIBIT 1 EXHIBIT 1. FCC IDENTIFICATION LABEL Required Under Section: 47 CFR 2.1033(c) 11 FCC ID: AZ489FT7007 Identifier label for the Model: F4415A HDT600 iDEN case (F4415A VA00010AB) regulation label FCC Identification label located on back of terminal. Applicant: Motorola, Inc.FCC ID: AZ489FT7007 EXHIBIT 1 EXHIBIT 1A. General Information --- 47 CFR 2.1031 and 2.1061. 1A.1. Production Plans -- Pursuant 47 CFR 2.1031 Quantity production is planned. 1A.2.Application References -- Pursuant 47 CFR 2.1061 Reference is made to the following Motorola "Application References" 1. Part 15.247 - Intentional Radiators and there application 2. Part 90 - Land mobile systems and there application 1A.3.Data Submittal Procedure Data located in Exhibit 6 is supplied in accordance with Part 2, Sub- part J and Part 15, Sub-part C and Part 90 o…
