AZ489FT7042PORTABLE MULTIBAND 2-WAY RADIO

Motorola Solutions, Inc.
PORTABLE MULTIBAND 2-WAY RADIO - FCC ID AZ489FT7042 - Motorola Solutions, Inc.
Click to zoom

Application Details

Equipment Class
TNF - Licensed Non-Broadcast Transmitter Held to Face
Date of Grant
Jun 15, 2010
Application Purpose
Original Equipment
Date of Application
Jun 15, 2010
Equipment Note
PORTABLE MULTIBAND 2-WAY RADIO
Frequency Range
851.00000000 - 869.00000000
Company
Motorola Solutions, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Attestation Statements

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗
↗
↗
↗
↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

APX 7000 User Guide Top Display 6875952M01-D 6875952M01-D_TopD.book Page 1 Wednesday, May 12, 2010 11:35 AM 6875952M01-D_TopD.book Page 2 Wednesday, May 12, 2010 11:35 AM English mASTRO ® APX™ 7000 Series Digital Portable RadiosQuick Reference Card Product Safety and RF Exposure Compliance ATTENTION! This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C98) to ensure compliance with RF energy exposure limits. Radio Controls Radio On/OffZones and Channels Receiving and TransmittingSending an Emergency Alarm To exit emergency at any time, press and hold the Emergency button. Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio. !  Top (Orange) Button__________ 2-Position Concentric Switch______________ 3-Position A/B/C Switch __________________ Accessory Connector • On – On/Off/Volume knob clockwise. • Off – On/Off/Volume knob counterclockwise. • Zone – Zone switch to desired zone. • Channel – Channel switch to desired channel. Battery Side Button 1__________Side Button 2__________ PTT Button On/Off/Volume Control Knob 16-Position Select Knob __________ Top Side (Select) Button__________ Main Speaker Top Display Antenna 1 Select zone/channel. 2 Listen for a transmission.ORPress and hold Volume Set button. ORPress Monitor button and listen for activity. 3 Adjust volume, if necessary. 4 Press the PTT button to transmit; release to receive. 1 Press the Emergency button. 2 The display shows EMERGNCY and the current zone/channel. A short, medium-pitched tone sounds, and the LED rapidly blinks red. 3 When acknowledgment is received, you hear four beeps; alarm ends; and radio exits emergency. *68007024033* 68007024033-A © 2009 by Motorola, Inc. All Rights Reserved. 04/101301 E. Algonquin Rd., Schaumburg,IL 60196-1078, U.S.A. 6875952M01-D_TopD.book Page 3 Wednesday, May 12, 2010 11:35 AM English Sending an Emergency Call To exit emergency at any time, press and hold the Emergency button. Sending a Silent Emergency Call To exit emergency at any time, press and hold the Emergency button. Display Status Icons 1 Press the Emergency button. 2 Press and hold the PTT button. Speak clearly into the microphone. 3 Release the PTT button to end call. 4 Press and hold Emergency button to exit emergency. 1 Press the Emergency button. 2 The display does not change; the LED does not light up, and there is no tone. 3 Silent emergency c ontinues until you: Press and hold the Emergency button to exit emergency state.ORPress and release the PTT button to exit silent emergency mode and enter regular emergency (alarm, call, or alarm with call) mode. Blinks when the battery is low.The more stripes, the stronger the signal strength for the current site (trunking only).Direct radio to radio communication or connected through a repeater.On = Direct Off = Repeater This channel is being monitored.L = Radio is set at Low power. H = Radio is set at High power. Scanning a scan list.Blinking dot = Detects activity on the Priority-One Channel during scan. Steady dot = Detects activity on the Priority-Two Channel during scan. The vote scan feature is enabled. U vV O M H OR L i j k On = Secure operation. Off = Clear operation. Blinking = Receiving an encrypted voice call. On steady = View mode Blinking = Program mode Zone Bank 1A = Radio is in Zone 1. B = Radio is in Zone 2. C = Radio is in Zone 3. Zone Bank 2D = Radio is in Zone 4. E = Radio is in Zone 5. F = Radio is in Zone 6. m A or B or C D or E or F 6875952M01-D_TopD.book Page 4 Wednesday, May 12, 2010 11:35 AM Declaration of Conformity English i Declaration of Conformity This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below. DECLARATION OF CONFORMITYPer FCC CFR 47 Part 2 Section 2.1077(a)Responsible Party Name: Motorola, Inc.Address: 1301 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A.Phone Number: 1-800-927-2744Hereby declares that the product: Model Name: APX 7000 conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a) Class B Digital DeviceAs a personal computer peripheral, this device complies with Part 15 of the FC C Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. 6875952M01-D_TopD.book Page i We dnesday, May 12, 2010 11:35 AM Declaration of Conformity English ii Note: This equipment has been tested and found to comply with the li mits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provi de reasonable protection against harmful interference in a residential installation. This equipment generates, us es and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference wi ll not occur in a particular installation. If this equipment does cause harmful interference to radi o or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit differ ent from that to which the receiver is connected. • Consult the dealer or an experienc ed radio/TV technician for help. 6875952M01-D_TopD.book Page ii We dnesday, May 12, 2010 11:35 AM Contents English iii ContentsThis…

Text truncated - open the document above for the full version.

Users Manual

English Product Safety and RF Energy Exposure Booklet for Portable Two-Way Radios The information provided in this document supersedes the general safety information contained in user guides published prior to February 2002. BEFORE USING THIS RADIO, READ THIS BOOKLET WHICH CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL INFORMATION AND OPERATIONAL INSTRUCTIONS FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND INTERNATIONAL STANDARDS. ALSO READ THE OPERATIONAL INSTRUCTIONS FOR SAFE USAGE. FOR RADIOS THAT HAVE BEEN APPROVED AS INTRINSICALLY SAFE, READ THE INSTRUCTIONS AND INFORMATION ON INTRINSIC SAFETY ON PAGE 10 OF THIS BOOKLET. !  © 2007 by Motorola, Inc. 02/07 1301 E. Algonquin Rd., Schaumburg, IL 60196-1078, U.S.A. *6881095C98* 6881095C98-D *NNTN7223A* NNTN7223A 95C98-D.book Page 1 Tuesday, February 27, 2007 4:36 PM 2 English RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use NOTICE: This radio is intended for use in occupational/controlled conditions where users have full knowledge of their exposure and can exercise control over their exposure to meet the occupational limits in FCC and International standards. This radio device is NOT authorized for general population consumer use. This two-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. It uses radio frequency (RF) energy or radio waves to send and receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to, sunlight and x-rays. RF energy, however, should not be confused with these other forms of electromagnetic energy, which when used improperly, can cause biological damage. Very high levels of x-rays, for example, can damage tissues and genetic material. Experts in science, engineering, medicine, health, and industry work with organizations to develop standards for safe exposure to RF energy. These standards provide recommended levels of RF exposure for both workers and the general public. These recommended RF exposure levels include substantial margins of protection. All Motorola two-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In addition, manufacturers also recommend specific operating instructions to users of two-way radios. These instructions are important because they inform users about RF energy exposure and provide simple procedures on how to control it. 95C98-D.book Page 2 Tuesday, February 27, 2007 4:36 PM 3 English Please refer to the following websites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits: http://www.fcc.gov/oet/rfsafety/rf-faqs.html http://www.osha.gov/SLTC/radiofrequencyradiation/index.html Federal Communication Commission (FCC) Regulations The FCC rules require manufacturers to comply with the FCC RF energy exposure limits for portable two-way radios before they can be marketed in the U.S. When two-way radios are used as a consequence of employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure awareness can be facilitated by the use of a product label directing users to specific user awareness information. Your Motorola two-way radio has a RF Exposure Product Label. Also, your Motorola user manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Compliance with RF Exposure Standards Your Motorola two-way radio is designed and tested to comply with a number of national and International standards and guidelines (listed below) for human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/controlled RF exposure environments at operating duty factors of up to 50% talk-50% listen and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with these exposure guidelines, your radio generates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. NOTE:The approved batteries, supplied with this radio, are rated for a 5-5-90 duty factor (5% talk-5% listen-90% standby) even though this radio complies with FCC occupational exposure limits and may operate at duty factors of up to 50% talk. 95C98-D.book Page 3 Tuesday, February 27, 2007 4:36 PM 4 English Your Motorola two-way radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation – Human Exposure) Standard, 2003 • ANATEL ANNEX to Resolution No. 303 of July 2, 2002 "Regulation of limitation of exposure to electrical, magnetic and electromagnetic fields in the radio frequency range between 9 KHz and 300 GHz" and "Attachment to resolution # 303 from July 2, 2002" RF Exposure Compliance and Control Guidelines and Operating Instructions To control your exposure and ensure compliance with the occupational/controlled environment exposure limits, always adhere to the following procedures. Guidelines: • DO NOT remove the RF Exposure Label from the …

Text truncated - open the document above for the full version.

Attestation Statements

Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 2 SHEET 1 OF 1 EXHIBIT 2 CERTIFICATION OF DATA - Pursuant to 47 CFR 2.907 The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The following is a statement of my qualifications: 1) I received an Electrical Engineering degree from Universiti Technology Malaysia, Malaysia. 2) I have 3 years experience in developing, testing, and certifying Land Mobile Communications Products. NAME: Diong Kah Chen SIGNATURE: /s/ Diong Kah Chen (signed) DATE: 22 nd March, 2010 POSITION: Electrical Engineer 3) I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct. NAME: Ernest Lean SIGNATURE: /s/ Ernest Lean (signed) DATE: 22 nd March 2010 POSITION: Engineering Manager

Cover Letter(s)

EXHIBIT 13A SHEET 1 FCC ID: AZ489FT7042 Date: 7 th June 2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT7042 Dear Sir or Madam: Motorola Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida, herein submits application for Type Acceptance of the subject transmitter. This transmitter is intended for use in a Portable Radio environment with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: 450 -512 MHz, 764-775 MHz, 794-805 MHz, 806- 824 MHz, and 851-869 MHz. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete application for certification is enclosed, contact Mike Ramnath at (954) 723-5793, if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Manager, Regulatory Compliance Tel: (954) 723-5793 E-mail: [email protected]

Cover Letter(s)

EXHIBIT 13B SHEET 1 FCC ID: AZ489FT7042 REQUEST FOR CONFIDENTIALITY Date: March 22 nd ,2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT7042 Dear Sir / Madam, Motorola is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Transmitter Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected]

Cover Letter(s)

EXHIBIT 13c SHEET 1 FCC ID: AZ489FT7042 8 th June 2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification Gentlemen: The APX7000 is a Portable 2-Way radio designed to operate in the frequency bands 450 -512, 764-775 MHz, 794-805 MHz, 806-824 MHz, and 851-869 MHz. To aid equipment authorization in other countries, which accept the United States FCC Grant for Certification, Motorola is requesting that the FCC list the frequencies 450-512 MHz and 764-775 MHz, 794-805 MHz, 806-824 MHz, and 851-869 MHz under FCC Rule Part 90 on the FCC Grant For the FCC’s Rule Parts 90 applications, this radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, etc. as indicated in the table below. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Frequency Range (MHz) Part 90 450-512 x 764-770/794-800 (Canada) 769-775 x 799-805 x 806-824 x 851-869 x Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected]

External Photos

Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 3 SHEET 1 OF 7 EXHIBIT 3 The following photographs are attached. Exhibit 1. Front view. 3A 2. Back view with battery. 3B 3. Front view (FCC label location). 3C 4. Side view (Right). 3D 5. Side view (Left). 3E 6. Top view (Controls). 3F Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 3 SHEET 2 OF 7 Front view Exhibit 3A Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 3 SHEET 3 OF 7 BACK VIEW WITH BATTERY Exhibit 3B Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 3 SHEET 4 OF 7 BACK VIEW (FCC LABELS) Exhibit 3C Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 3 SHEET 5 OF 7 SIDE VIEW (RIGHT) Exhibit 3D Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 3 SHEET 6 OF 7 SIDE VIEW (LEFT) Exhibit 3E Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 3 SHEET 7 OF 7 TOP VIEW Exhibit 3F

ID Label/Location Info

Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 1 SHEET 1 OF 1 Identification Label LOCATION See the Attached Photograph or Sketch X Back of Radio Back of Radio under Belt Clip TYPE X The label is a paper polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with a minimum peel strength of 40 oz/inch. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3C for the actual location of the FCC label on the device. Label Attached Below. See Attached Drawing. Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 1 SHEET 1 OF 1 General Information I. Production Plans -- Pursuant 2.1033 Quantity production is planned. II. Data Submittal Procedure: Data is supplied in accordance with Part 2, Sub-part J of the Commissions’ rules. III. Applicable References: • Reference Certification FCC ID: AZ489FT7042 • EIA/TIA-603 Land Mobile FM or PM Communications Equipment Measurement and Performance Standards • FCC Federal Regulations Part 47 Sec. 2.1046 – 2.1057 • FCC Federal Regulations Part 90 Sec. 90.210 • FCC Federal Regulations Part 15 Sec. 15.107

Internal Photos

Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 9 SHEET 1 OF 7 EXHIBIT 9 Internal Photographs The following photographs are attached. Exhibit 1. RF board with Shields (Top). 9A 2. RF board without Shields (Top). 9B 3. RF board with Shields (Bottom). 9C 4. RF board without Shields (Bottom). 9D 5. Vocon board with Shields (Top). 9E 6. Vocon board without Shields (Top). 9F 7. Vocon board with Shields (Bottom). 9G 8. Vocon board without Shields (Bottom). 9H 9. Expander board with Shields (Top). 9I 10. Expander board without Shields (Top). 9J 11. Expander board with Shields (Bottom). 9K 12. Expander board without Shields (Bottom). 9L Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 9 SHEET 2 OF 7 RF board with Shields (Top) RF board without Shields (Top) Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 9 SHEET 3 OF 7 RF board with Shields (Bottom) RF board without Shields (Bottom) Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 9 SHEET 4 OF 7 Vocon board with Shields (Top) Vocon board without Shields (Top) Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 9 SHEET 5 OF 7 Vocon board with shields board (Bottom) Vocon board without shields board (Bottom) Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 9 SHEET 6 OF 7 Expander board with shields board (Bottom) Expander board without shields board (Bottom) Applicant: Motorola Inc. FCC ID: AZ489FT7042 EXHIBIT 9 SHEET 7 OF 7 Expander board with shields board (Bottom) Expander board without shields board (Bottom)

RF Exposure Info

SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 1 of 63 DECLARATION OF COMPLIANCE SAR ASSESSMENT Part 2 of 4 Enterprise Mobility Solutions EME Test Laboratory 8000 West Sunrise Blvd Fort Lauderdale, FL. 33322. Date of Report: 6/08/10 Report Revision: A Report ID: SAR rpt_APX7000 U2 7-800_Rev A_100608 SR8265 * Refer to section 15.0 for a summary of SAR results. The test results clearly demonstrate compliance with FCC Occupational/Controlled RF Exposure limits of 8 W/kg averaged over 1 gram per the requirements of 47 CFR 2.1093(d). The 10 grams results are not applicable to FCC filing. The test results clearly demonstrate compliance with ICNIRP (1998) Guidelines for limiting exposure in time-varying electric, magnetic, and electromagnetic fields (up to 300 GHz), Health Physics 74, 494-522 RF Exposure limits of 10 W/kg averaged over 10 grams of contiguous tissue. Responsible Engineer: Michael Sailsman (Sr. Staff EME Engineer) Report Author: Michael Sailsman (Sr. Staff EME Engineer) Date/s Tested: 4/9/10-5/11/10 Manufacturer/Location: Motorola, Penang Sector/Group/Div.: G&PS Date submitted for test: 4/14/10 DUT Description: 450-520 1-5W, 764-870 MHz 1-3W, 6.25K/12.5K/25K, Top/Dual Display Models W/GPS. Capable of digital and analog FM transmission. Also capable of TDMA transmission. Test TX mode(s): 50% Max. Power output: 5.6W(UHF R2) & 2.99W (700 MHz), 3.6W (800 MHz) Nominal Power: 5W (UHF R2) & 2.5W (700 MHz), 3W (800 MHz) Tx Frequency Bands: 450-520 MHz(UHF R2) & 764-775 MHz, 794-805 MHz, 806-824 MHz, 851- 870 MHz (7/800 MHz) Signaling type: FM Model(s) Tested: H97TGD9PW1AN/MNUS1000A (QA00572AA & QA00573AA); H97TGD9PW1AN/MNUS1001A (w/Q792 keypad, QA00572AA & QA00573AA) Model(s) Certified: H97TGD9PW1AN/MNUS1000A (QA00572AA & QA00573AA); H97TGD9PW1AN/MNUS1001A (w/Q792 keypad, QA00572AA & QA00573AA) Serial Number(s): Q0BME02S, Q0BME02O, Q05ME0D5 Classification: Occupational/Controlled Environment FCC ID: AZ489FT7042 FCC Rule Part(s): 90; 450-512 MHz (UHF R2); 764-775 MHz, 794-805 MHz, 806-824 MHz, 851-870 MHz IC ID: 109U-89FT7042 IC standard(s): RSS 102 issue 4; Safety Code 6 Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 3.0 of this report. This report shall not be reproduced without written approval from an officially designated representative of the Motorola EME Laboratory. I attest to the accuracy of the data and assume full responsibility for the completeness of these measurements. This reporting format is consistent with the suggested guidelines of the TIA TSB-150 December 2004. The results and statements contained in this report pertain only to the device(s) evaluated. Signature on file Deanna Zakharia EMS EME Lab Senior Resource Manager, Laboratory Director Approval Date: 6/8/10 Certification Date: 6/8/10 Certification No.: L1100611P TESTING CERT # 2518.01 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 2 of 63 APPENDIX B Probe Calibration Certificates SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 3 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 4 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 5 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 6 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 7 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 8 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 9 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 10 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 11 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 12 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 13 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 14 of 63 APPENDIX C Dipole Calibration Certificates SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 15 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 16 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 17 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 18 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 19 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 20 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 21 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 22 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 23 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 24 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 25 of 63 SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 26 of 63 Appendix D SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 27 of 63 Test System Verification Scans The SAR result indicated on the Manufacture’s Calibrated certificate for dipole D450V2 SN 1002 and D835V2/435 were not used due to the following: -- The IEEE1528-2003 and the FCC OET-65 Supplement C, System Verification section indicated that “The measured 1-g SAR should be within 10% of the expected target values specified for the specific phantom and RF source used in the system verification measurement.” -- SPEAG calibration certificates indicate that the allowed tolerance for this dipole is higher than +/- 10% (e.g. 5.03 +/- 18.1% at k=2 for the D450V2 S/N 1002 and 9.51 +/-17.0% at k=2 for the D835V2 S/N 435). -- The allowed tolerance for the probes is also higher than +/- 10% (e.g. 13.3% at k=2 at 450MHz and 11.0% at k=2 at 835MHz for the probe being used to assess this product). Due to probe, dipole and system tolerances noted above, the lab averages dipole results across multiple probes to establish a set of averaged targets for each dipole using the following procedure: • The System Validation was conducted per IEEE1528-2003 and IEC62209-2 Edition 1.0 2010-03 standards using the simulated head tissue and multiple probes that are available and applicable for the dipole under test to verify the System Validation. Results for this dipole are within the measurement system uncertainty of the reference SAR values indicated within IEC62209-2 Edition 1.0 2010-03 when using flat phantom with 2mm thickness is used. These results then are averaged and us…

Text truncated - open the document above for the full version.

RF Exposure Info

SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 1 of 108 TESTING CERT # 2518.01 DECLARATION OF COMPLIANCE SAR ASSESSMENT Part 1 of 4 Enterprise Mobility Solutions EME Test Laboratory 8000 West Sunrise Blvd Fort Lauderdale, FL. 33322. Date of Report: 6/08/10 Report Revision: A Report ID: SAR rpt_APX7000 U2 7-800_Rev A_100608 SR8265 * Refer to section 15 for a summary of SAR results. The test results clearly demonstrate compliance with FCC Occupational/Controlled RF Exposure limits of 8 W/kg averaged over 1 gram per the requirements of 47 CFR 2.1093(d). The 10 grams results are not applicable to FCC filing. The test results clearly demonstrate compliance with ICNIRP (1998) Guidelines for limiting exposure in time-varying electric, magnetic, and electromagnetic fields (up to 300 GHz), Health Physics 74, 494-522 RF Exposure limits of 10 W/kg averaged over 10 grams of contiguous tissue. Responsible Engineer: Michael Sailsman (Sr. Staff EME Engineer) Report Author: Michael Sailsman (Sr. Staff EME Engineer) Date/s Tested: 4/9/10-5/11/10 Manufacturer/Location: Motorola, Penang Sector/Group/Div.: G&PS Date submitted for test: 4/14/10 DUT Description: 450-520 1-5W, 764-870 MHz 1-3W, 6.25K/12.5K/25K, Top/Dual Display Models W/GPS. Capable of digital and analog FM transmission. Also capable of TDMA transmission. Test TX mode(s): 50% Max. Power output: 5.6W(UHF R2) & 2.99W (700 MHz), 3.6W (800 MHz) Nominal Power: 5W (UHF R2) & 2.5W (700 MHz), 3W (800 MHz) Tx Frequency Bands: 450-520 MHz(UHF R2) & 764-775 MHz, 794-805 MHz, 806-824 MHz, 851-870 MHz (7/800 MHz) Signaling type: FM Model(s) Tested: H97TGD9PW1AN/MNUS1000A (QA00572AA & QA00573AA); H97TGD9PW1AN/MNUS1001A (w/Q792 keypad, QA00572AA & QA00573AA) Model(s) Certified: H97TGD9PW1AN/MNUS1000A (QA00572AA & QA00573AA); H97TGD9PW1AN/MNUS1001A (w/Q792 keypad, QA00572AA & QA00573AA) Serial Number(s): Q0BME02S, Q0BME02O, Q05ME0D5 Classification: Occupational/Controlled Environment FCC ID: AZ489FT7042 FCC Rule Part(s): 90; 450-512 MHz (UHF R2); 764-775 MHz, 794-805 MHz, 806-824 MHz, 851-870 MHz IC ID: 109U-89FT7042 IC standard(s): RSS 102 issue 4; Safety Code 6 Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 3.0 of this report. This report shall not be reproduced without written approval from an officially designated representative of the Motorola EME Laboratory. I attest to the accuracy of the data and assume full responsibility for the completeness of these measurements. This reporting format is consistent with the suggested guidelines of the TIA TSB-150 December 2004. The results and statements contained in this report pertain only to the device(s) evaluated. Signature on file Deanna Zakharia EMS EME Lab Senior Resource Manager, Laboratory Director Approval Date: 6/8/10 Certification Date: 6/8/10 Certification No.: L1100611P SR8265 EMS EME Form-SAR-Rpt-Rev. 10.00 Page 2 of 108 Part 1 of 4 1.0 Introduction.........................................................................................4 2.0 Abbreviations / Definitions.................................................................4 3.0 Referenced Standards and Guidelines ................................................4 4.0 SAR Limits .........................................................................................5 5.0 SAR Result Scaling Methodology......................................................5 6.0 Description of Device Under Test (DUT) ..........................................6 7.0 Optional Accessories and Test Criteria ..............................................6 7.1 Antennas ....................................................................................6 7.2 Batteries ...................................................................................10 7.3 Body worn Accessories ...........................................................10 7.4 Audio Accessories ...................................................................10 8.0 Descript…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Deanna Zakharia(Regulatory Compliance Manager)
[email protected]9547234707Fax: --

Test Firm

MotorolaWilliam Elliott
[email protected]954-723-5480Fax: 954-723-6383

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
590,90.21851 MHz - 869 MHz3 WNOTE 11.5 ppm
Confidentiality
Long Term
Grant Notes
Power listed is rated conducted. Maximum conducted output power is 5.6 Watts in the UHF Band; 2.99 Watts in the 700 MHz Band, and 3.6 Watts in the 800 MHz band per 90.205(s). Minimum output setting is 1W in all cases. This device must be restricted to work related operations in an Occupational/Controlled RF exposure Environment, not exceeding a maximum transmitting duty factor of 50%. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration to comply with the Occupational/Controlled SAR limit and requirements. A label, as described in this filing, must be displayed on the device to direct users to specific training information for meeting Occupational Exposure Requirements. Body-worn operating configuration is limited to the specific belt-clip supplied for use with this product that provides at least 2.5 cm separation between the device and the users body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values are - Head: 2.73 W/kg; Body: 6.02 W/kg accounting for a 50% duty cycle. Note 1: 16K0F3E, 11K0F3E, 8K10F1E, 8K10F1D, 8K10F1W, 20K0F1E
