APX ™ N50 User Guide APX ™ Two-Way Radios Model 2 *MN009203A01* MN009203A01-AA JUNE 2022 © 2022 Motorola Solutions, Inc. All rights reserved Contents List of Figures..............................................................................................................8 List of Tables...............................................................................................................9 Legal and Support.....................................................................................................10 Intellectual Property and Regulatory Notices...............................................................................10 Legal and Compliance Statements..............................................................................................11 Declaration of Conformity................................................................................................. 11 Industry Canada WLAN Statement...................................................................................12 Important Safety Information.............................................................................................12 Notice to Users (FCC) ......................................................................................................12 FCC Licensing Information............................................................................................... 13 Applying for Canadian License......................................................................................... 13 Limited Warranty..........................................................................................................................14 MOTOROLA SOLUTIONS COMMUNICATION PRODUCTS.......................................... 14 I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG:...................................... 14 II. GENERAL PROVISIONS:............................................................................................ 15 III. STATE LAW RIGHTS:.................................................................................................15 IV. HOW TO GET WARRANTY SERVICE:......................................................................15 V. WHAT THIS WARRANTY DOES NOT COVER:..........................................................15 VI. PATENT AND SOFTWARE PROVISIONS:................................................................16 VII. GOVERNING LAW:....................................................................................................16 Read Me First.............................................................................................................17 Software Version......................................................................................................................... 17 Chapter 1: Radio Care............................................................................................ 18 1.1 Cleaning Your Radio..............................................................................................................18 1.2 Radio Service and Repair......................................................................................................19 1.3 Battery Recycling and Disposal.............................................................................................19 Chapter 2: Radio Overview.................................................................................... 20 2.1 Keypad Overview...................................................................................................................21 2.2 Programmable Radio Functions............................................................................................ 22 2.3 ViQi........................................................................................................................................25 2.3.1 Activating Basic Voice Control.................................................................................27 2.3.2 Using ViQi Virtual Partner........................................................................................27 Chapter 3: Getting Started......................................................................................28 3.1 Attaching and Removing the Battery..................................................................................... 28 Attaching the Battery.........................................................................................................28 MN009203A01-AA Contents 2 Removing the Battery....................................................................................................... 28 3.2 Attaching and Removing the Antenna................................................................................... 28 Attaching the Antenna.......................................................................................................28 Removing the Antenna..................................................................................................... 28 3.3 Attaching and Removing the Accessory Connector Cover....................................................29 Attaching the Accessory Connector Cover....................................................................... 29 Removing the Accessory Connector Cover......................................................................29 3.4 Attaching the Belt Clip........................................................................................................... 29 3.5 Charging the Radio................................................................................................................29 3.6 Turning the Radio On or Off.................................................................................................. 30 Turning the Radio On........................................................................................................30 Turning the Radio Off........................................................................................................30 3.7 Adjusting the Volume of the Radio...........…

Text truncated - open the document above for the full version.

APX ™ N30 User Guide APX ™ Two-Way Radios Model 2 *MN009363A01* MN009363A01-AA JUNE 2022 © 2022 Motorola Solutions, Inc. All rights reserved Contents List of Figures..............................................................................................................8 List of Tables...............................................................................................................9 Legal and Support.....................................................................................................10 Intellectual Property and Regulatory Notices...............................................................................10 Legal and Compliance Statements..............................................................................................11 Disclaimer......................................................................................................................... 11 Declaration of Conformity................................................................................................. 11 Industry Canada WLAN Statement...................................................................................12 Important Safety Information.............................................................................................12 Notice to Users (FCC) ......................................................................................................13 FCC Licensing Information............................................................................................... 13 Applying for Canadian License......................................................................................... 14 Limited Warranty..........................................................................................................................14 MOTOROLA SOLUTIONS COMMUNICATION PRODUCTS.......................................... 14 I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG:...................................... 14 II. GENERAL PROVISIONS:............................................................................................ 15 III. STATE LAW RIGHTS:.................................................................................................15 IV. HOW TO GET WARRANTY SERVICE:......................................................................15 V. WHAT THIS WARRANTY DOES NOT COVER:..........................................................16 VI. PATENT AND SOFTWARE PROVISIONS:................................................................16 VII. GOVERNING LAW:....................................................................................................17 Read Me First.............................................................................................................18 Software Version......................................................................................................................... 18 Chapter 1: Radio Care............................................................................................ 19 1.1 Cleaning Your Radio..............................................................................................................20 1.2 Radio Service and Repair......................................................................................................20 1.3 Battery Recycling and Disposal.............................................................................................20 Chapter 2: Radio Overview.................................................................................... 21 2.1 Keypad Overview...................................................................................................................22 2.2 Programmable Radio Functions............................................................................................ 23 2.3 ViQi........................................................................................................................................26 2.3.1 Activating Basic Voice Control.................................................................................28 2.3.2 Using ViQi Virtual Partner........................................................................................28 Chapter 3: Getting Started......................................................................................29 3.1 Attaching and Removing the Battery..................................................................................... 29 MN009363A01-AA Contents 2 Attaching the Battery.........................................................................................................29 Removing the Battery....................................................................................................... 29 3.2 Attaching and Removing the Antenna................................................................................... 29 Attaching the Antenna.......................................................................................................29 Removing the Antenna..................................................................................................... 29 3.3 Attaching and Removing the Accessory Connector Cover....................................................30 Attaching the Accessory Connector Cover....................................................................... 30 Removing the Accessory Connector Cover......................................................................30 3.4 Attaching the Belt Clip........................................................................................................... 30 3.5 Charging the Radio................................................................................................................30 3.6 Turning the Radio On or Off.................................................................................................. 31 Turning the Radio On........................................................................................................31 Turning the Radio Off....................…

Text truncated - open the document above for the full version.

en-US es-LA fr-CA pt-BR RF Energy Exposure Training and Product Safety Information for Portable Two-Way Radios Formation sur l’exposition aux RF et information sur la sécurité du produit pour radios bidirectionnelles portatives Capacitación sobre la exposición a energía de radiofrecuencia e información de protección del producto para radios de dos vías portátiles Treinamento sobre a Exposição à Energia de RF e Informações de Segurança do Produto para Rádios Portáteis Bidirecionais https://learning.motorolasolutions.com/User_Documentation Caution Before using this radio, read this booklet which contains important operating instructions. For information on product details, brochures, user manuals and approved accessories. Please refer to www.motorolasolutions.com. Compliance with RF Exposure Standards National and international regulations require manufacturers to comply with the RF energy exposure limits for portable two-way radios before they can be marketed. Your Motorola Solutions two-way radio is designed, manufactured, and tested to comply with all applicable national and international regulations for human exposure to radio frequency electromagnetic energy. When two-way radios are used as a consequence of employment, applicable regulations may require users to be fully aware of and able to control their exposure to meet occupational requirements. RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use Notice: This radio is intended for use in occupational/controlled conditions where users are aware of their exposure and can exercise control over their exposure to meet the requirements in national and international regulations. This radio device is not authorized for general population, consumer use. For more information on what RF energy exposure is, and how to control your exposure to ensure compliance with established RF exposure limits, consult the following websites: •https://www.fcc.gov/ •https://www.osha.gov/ •https://osha.europa.eu/en •http://www.who.int/peh-emf/project/en/ •http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf11467.html •http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01904.html For additional user training information on exposure requirements, consult the following websites: •https://www.motorolasolutions.com/en_us/about/company-overview/ corporate-responsibility/governance-and-policies/wireless- communication-and-health-faqs.html •http://learning.motorolasolutions.com/ RF Exposure Compliance and Control Guidelines To control your exposure, and ensure compliance with the relevant RF exposure limits, always adhere to the following guidelines: • Do not remove any of the RF Exposure Labels if present from this device or its related accessories. • Attach these instructions to the device when you transfer it to other users. • Do not use this device if the operational requirements described herein are not met. Operating Instructions • Transmit no more than 50% of the time. To transmit (talk), press the Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting more than 50% of the time may cause RF exposure compliance requirements to be exceeded. • Hold the radio in a vertical position in front of the face with the microphone (and other parts of the radio including the antenna) at least 1 in. (2.5 cm) away from the nose or lips. Antenna should be kept away from the eye. • When worn on the body, always place the radio in a Motorola Solutions-approved clip, holder, holster, case, or body harness for this product. • DO NOT hold the antenna when the radio is transmitting. • DO NOT use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result. • To ensure continued compliance with applicable RF exposure limits, use only Motorola Solutions approved, supplied or replacement antennas, batteries, and accessories. • For a list of Motorola Solutions approved accessories please refer to your user manual or visit www.motorolasolutions.com English 1 Acoustic Safety Exposure to loud noises from any source for extended periods of time may temporarily or permanently affect your hearing. The louder the volume of the radio, the sooner your hearing will be affected. Hearing damage from loud noise is sometimes undetectable at first, and can have a cumulative effect. To protect your hearing: • Use the lowest volume necessary to do your job. • Turn up the volume only if you are in noisy surroundings. • Turn down the volume before adding headset or earpiece. • Limit the amount of time you use headsets or earpieces at high volume. • When using the radio without a headset or earpiece, do not place the radio's speaker directly against your ear. Medical Devices If you use a personal medical device, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information. Holsters Incorporating Magnets Some Motorola Solutions holsters incorporate strong, neodymium magnets. If you use a personal medical device, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it can be used in close proximity to magnets. Your physician may be able to assist you in obtaining this information. Also be aware that magnets can damage other products, including cell phones, computers, hard drives, and other electronic devices, as well as credit cards and magnetic media. Keep the holster away from any mechanical device that could be affected by a magnetic field. Consult the manufacturer of your product to determine if your device or product can be used in close proximity to magnets. Notice to Users (FCC) This device complies with Part 15 of the FCC rules per the following conditions: • This device may not cause harmful interference. • The device must accept any interference received, including interference that may …

Text truncated - open the document above for the full version.

Applicant: Motorola Solutions Inc FCC ID: AZ489FT7161 / IC: 109U-89FT7161 EXHIBIT 2 SHEET 1 OF 2 EXHIBIT 2 Statement of Certification (Pursuant to FCC Part 2.907, 2.908 and RSP 100 Sec 4) 2.1 Statement of Certification Transceiver type described herein (AZ489FT7161/109U-89FT7161) is in compliance with all applicable parts of the FCC rules and ISED RSS standards. This device is P25 Compliant as well which meets FCC Part 90.548 and RSS 119 Section 5.11 as declared in exhibit 12. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Danesh R Thayaparan SIGNATURE: DATE: 18 April 2022 TITLE: Engineering Manager Applicant: Motorola Solutions Inc FCC ID: AZ489FT7161 / IC: 109U-89FT7161 EXHIBIT 2 SHEET 2 OF 2 2.2 Attestation Statement (Equipment Class DTS and DSS – Bluetooth/WiFi) This device contains an embedded Bluetooth device and WiFi device that are compliant with the applicable FCC Part 15C and ISED RSS 247 regulations. Part 15.247 (a)(1) / RSS 247 Section 5.1 • The hopping sequence must be pseudo random. • Each frequency must be used equally on the average by each transmitter • The receivers input bandwidth is approximately equal to the transmit bandwidth • The receiver hops in sequence with the transmitted signal Part 15.247 (g) / RSS 247 Section 5.1 • The system is designed to comply with all of the regulations in this section when the transmitter is presented with a continuous data (or information) Part 15.247(h) / RSS 247 Section 5.1 • The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Danesh R Thayaparan SIGNATURE: DATE: 18 April 2022 TITLE: Engineering Manager EXHIBIT 2 SHEET 1 OF 1 Date: March 25, 2022 BT and WLAN Declaration To whom it may concern, This is a WLAN/Bluetooth combination antenna with FCC ID: AZ489FT7161/109U- 89FT7161 . This WLAN/Bluetooth co-existence mechanism is to ensure that the WLAN and Bluetooth transmitters would not simultaneously operate. Therefore, WLAN and Bluetooth antennas in FCC ID: AZ489FT7161/109U-89FT7161 should not be considered to be able to transmit simultaneously. Though the users can use WLAN and Bluetooth simultaneously, the real situation is that WLAN and Bluetooth are used by time sharing and no overlap transmission. Should you have any questions, please have my best attention. Sincerely yours, ---------------------------------------------------- Name : Danesh R Thayaparan Title : Engineering Section Manager Te l : +60 (012) 4421676 E- mail: [email protected] EXHIBIT 2 SHEET 1 OF 1 Date: April 13, 2022 WLAN Channels and Mode Declaration We, Motorola Solutions, Inc., declare that the device, FCC ID: AZ489FT7161, does not support any non-US channels in all the operational mode(s) in the US market. All non-US frequencies, US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable. For ISED with IC: 109U-89FT7161, the device operating in 5600-5650 MHz band shall operate as client mode without active scanning function. Should you have any question or comment regarding this matter, please do not hesitate to contact me. Sincerely yours, ---------------------------------------------------- Name : Danesh R Thayaparan Title : Engineering Section Manager Tel : +60124421676 E- mail : [email protected] EXHIBIT 2 SHEET 1 OF 2 June 28, 2022 DTS-UNII Device Declaration Letter To whom it may concern, We have declared below featured for FCC equipment authorization, Device FCC ID: AZ489FT7161 (1) DFS Device -- ☐ Master ☐ Client with Radar detection capability , ☒ Client without radar detection capability ☐ N/A (2) Active / Passive Scanning , ad-hoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode or WIFI Direct capability Access point capability 5150-5250 ☒ Yes , ☐ No ☒ Yes , ☐ No ☐ Yes , ☒ No ☐ Yes , ☒ No 5250-5350 ☐ Yes , ☒ No ☒ Yes , ☐ No ☐ Yes , ☒ No ☐ Yes , ☒ No 5470-5725 ☐ Yes , ☒ No ☒ Yes , ☐ No ☐ Yes , ☒ No ☐ Yes , ☒ No 5725-5850 ☒ Yes , ☐ No ☒ Yes , ☐ No ☐ Yes , ☒ No ☐ Yes , ☒ No (3) Country code selection ability - ☐ Yes , ☒ No If yes, please explain how it was implemented: (please also help to provide detail of options for each country selection) (4) Meet 15.202 requirement - ☒ Yes, ☐ No, ☐ A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices ☒ A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non- DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes cannot be modified by end user or an installer. ☒ Apply, ☐ No Apply, (If apply, please help to provide explanation on it was implement, and how software was controlled) Factory set only. ---------------------------------------------------- Name: Charles Koh EXHIBIT 2 SHEET 2 OF 2 Title: ASTRO Software Section Manager Tel: 0167028479 E-mail: chanloong.koh1@motorolasolu…

Text truncated - open the document above for the full version.

FCC ID: AZ489FT7161 _______________________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13A Date: July 21, 2022 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ489FT7161 Dear Sir/Madam, Motorola Solutions Malaysia Sdn Bhd herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a portable radio application with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: Product Name Model Numbers Frequency Range RF Power FCC Rules Part APX N50 APX N30 H25UCF9PW6AN H15UCF9PW6AN LMR 700 MHz: 762-776 MHz, 792-806 MHz 2.99W (Max declared) 90 LMR 700 MHz: 769-775 MHz, 799-805 MHz (itinerant bands only) 2.99W (Max declared) 90.531 LMR 800 MHz: 806-825 MHz, 851-870 MHz 3.6W (Max declared) 90 BT: 2402-2480 MHz 13.82 mW (max measured conducted peak) 15C BTLE 4.0: 2402-2480MHz 7.06 mW (max measured conducted peak) 15C WLAN 802.11 b/g/n: 2412-2462 MHz 239.88 mW (max measured conducted peak) 15C WLAN 802.11 a/n/ac: 5180-5825 MHz 22.05 mW (max measured conducted average) 15E We are requesting certification under Part(s) of the Commission’s Rules listed above to allow operation of this equipment. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at +604- 2240258 Sincerely, ____________________ Arine Lee FCC/IC Certification Manager E-mail : [email protected]

FCC ID: AZ489FT7161 _______________________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia EXHIBIT 13B CONFIDENTIALITY REQUEST July 21, 2022 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ489FT7161 Dear Sir / Madam, Motorola Solutions Malaysia Sdn Bhd is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d), 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, ____________________ Arine Lee FCC/IC Certification Manager E-mail : [email protected]

____________________________________________________________________________ Motorola Solutions Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 Certification Department Date: 20 July 2022 Subject: Application Authorization for FCC/IC filing To Whom It May Concern: I hereby authorize Arine Lee to apply, on my behalf, the application for the following FCC/IC ID: FCC/IC ID: AZ489FT7161 / 109U-89FT7161 Please contact me if there are any questions or issues. Regards, Deanna Zakharia Regulatory Compliance Manager Tel: (954) 723 4707 Email: [email protected]

Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 1 OF 9 EXHIBIT 3 EXTERNAL PHOTOGRAPHS (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. Front View 3A 2. Back View with battery 3B 3. FCC/IC label location 3C 4. Side view (Right) 3D 5. Side view (Left) 3E 6. Top view with antenna 3F 7. Bottom view 3G Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 2 OF 9 Exhibit 3A: Front View Front view APX N50 / APX N30 Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 3 OF 9 Exhibit 3B: Back View with battery Back View with battery - APX N50 Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 4 OF 9 Back View with battery - APX N30 Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 5 OF 9 Exhibit 3C: FCC/IC Label Location FCC/IC Label Location - APX N50 Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 6 OF 9 FCC/IC Label Location - APX N30 Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 7 OF 9 Exhibit 3D: Side View (Right) Side View (Right) – APX N50 / APX N30 Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 8 OF 9 Exhibit 3E: Side View (Left) Side View (Left) – APX N50 / APX N30 Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7161/ IC: 109U-89FT7161 EXHIBIT 3 SHEET 9 OF 9 Exhibit 3F: Top view with antenna Top view with Antenna – APX N50 / APX N30 Exhibit 3G: Bottom view Bottom view – APX N50 / APX N30 *** END ***
