AZ492FT1626Mobile Transmitter

1 English CONTENTS CONTENTS Computer Software Copyrights . . . . . . . . . . 3 Radio Overview . . . . . . . . . . . . . . . . . . . . . 5 Parts of the Radio . . . . . . . . . . . . . . . . . . . . 5 Optional Enhanced DTMF (Keypad) Microphone (RMN4026) . . . . . . . . . . . 6 On/Off/Volume Knob . . . . . . . . . . . . . . . 7 Channel Selector/Menu Navigation Buttons . . . . . . . . . . . . . . . . . . . . . . . . 7 LED Indicators . . . . . . . . . . . . . . . . . . . . 7 Programmable Buttons . . . . . . . . . . . . . 7 Push-to-Talk (PTT) Button . . . . . . . . . . 10 Microphone . . . . . . . . . . . . . . . . . . . . . 10 Menu Keys . . . . . . . . . . . . . . . . . . . . . . 10 Use with Optional Enhanced DTMF Microphone (RMN4026) . . . . . . . . . . 11 LCD Screen . . . . . . . . . . . . . . . . . . . . . 13 Audio Indicators for Programmable Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Getting Started . . . . . . . . . . . . . . . . . . . . 15 Turning the Radio On or Off . . . . . . . . . . . 15 Adjusting the Volume . . . . . . . . . . . . . . . . 15 Selecting a Zone . . . . . . . . . . . . . . . . . . . . 16 Selecting a Radio Channel . . . . . . . . . . . . 16 Sending a Call . . . . . . . . . . . . . . . . . . . . . 17 Receiving a Call . . . . . . . . . . . . . . . . . . . . 17 Radio Calls . . . . . . . . . . . . . . . . . . . . . . . 19 Making a Selective Call . . . . . . . . . . . . . . 19 Receiving a Selective Call . . . . . . . . . . . . 19 Sending a Call Alert™ Page . . . . . . . . . . . 20 Receiving a Call Alert Page . . . . . . . . . . . 20 Radio Check . . . . . . . . . . . . . . . . . . . . . . . 21 Sending a Status . . . . . . . . . . . . . . . . . . . 21 Sending a Message . . . . . . . . . . . . . . . . . 22 Receiving a Message . . . . . . . . . . . . . . . . 23 Sending an Emergency Alert . . . . . . . . . . 23 Receiving Selective Radio Inhibit . . . . . . . 24 Editing a Radio Call List . . . . . . . . . . . . . . 24 Repeater or Talkaround Mode . . . . . . . . . 25 Setting the Power Level . . . . . . . . . . . . . . 25 Name and Call/Message Tone Tagging . . 26 Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Starting or Stopping Scan. . . . . . . . . . . . . 29 Talkback . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Deleting a Nuisance Channel . . . . . . . . . . 30 Restoring a Channel to the Scan List . 30 2 English CONTENTS Editing a Scan List . . . . . . . . . . . . . . . . . . 30 Adding or Deleting Channels in a Scan List . . . . . . . . . . . . . . . . . . . . . 31 Prioritizing a Channel in a Scan List . . 32 Setting Priority Channels . . . . . . . . . . . 32 Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Making a Phone Call . . . . . . . . . . . . . . . . 35 Modifying the Phone List . . . . . . . . . . . . . 36 Adding an Entry (when using the keypad microphone only) . . . . . . 36 Deleting an Entry: . . . . . . . . . . . . . . . . 37 Editing an Entry (when using the keypad microphone only) . . . . . . 38 Editing an Access/Deaccess Code (when using the keypad microphone only) . . . . . . . . . . . . . . . . . . . . . . . . . 39 Audio/Tone Settings. . . . . . . . . . . . . . . . 41 Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Setting the Time . . . . . . . . . . . . . . . . . . . . 45 Displaying the Time . . . . . . . . . . . . . . . . . 46 Selecting the Display Language . . . . . . . . 46 Safety and Warranty . . . . . . . . . . . . . . . 47 Safe and Efficient Operation of Motorola Two-Way Radios . . . . . . . . . . . . . . . . . . 47 Exposure to Radio Frequency Energy. . . . . . . . . . . . . . . . . . . . . . . . . 47 Electromagnetic Interference/ Compatibility . . . . . . . . . . . . . . . . . . . . . 48 Operational Warnings . . . . . . . . . . . . . . . 48 Vehicles with an Air Bag . . . . . . . . . . . 48 Potentially Explosive Atmospheres . . . 48 Blasting Caps and Blasting Areas. . . . 49 Mobile Radio Operation and EME Exposure . . . . . . . . . . . . . . . . . . . . . 49 Mobile Antenna Installation . . . . . . . . . 50 Control Station Operation. . . . . . . . . . . . . 50 Limited Warranty . . . . . . . . . . . . . . . . . . . 50 Accessories . . . . . . . . . . . . . . . . . . . . . . 55 Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . 55 Antennas . . . . . . . . . . . . . . . . . . . . . . . . . 56 Control Station . . . . . . . . . . . . . . . . . . . . . 56 3 English CONTENTS COMPUTER SOFTWARE COPYRIGHTS The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product. 4 English CONTENTS Notes 5 English RADIO OVERVIEW RADIO OVERVIEW PARTS OF THE RADIO Editing Buttons Menu Enter/Select Button (Interchangeable) Programmable Button 2 (P2) (Interchangeable) Programmable Button 4 (P4) (Interchangeable) Programmable Button 3 (P3) LCD Screen Red/Yellow/Green LED Indicators Menu Exit/Escape Button (Interchangeable) Programmable Button 1 (P1) (Left/Right) Microphone Jack Knob On/Off/Volume Channel Selector/ Menu Navigation Buttons (Up/…

Text truncated - open the document above for the full version.

MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 3 SHEET 1 OF 1 CERTIFICATION OF DATA The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The following is a statement of my qualifications: 1) I have received a BSEE degree in Electrical Engineering from Northwestern University, Evanston, Illinois. 2) I have 27 years experience in developing, testing and certifying Land Mobile Communications Products. NAME: James M. Zima SIGNATURE: James M. Zima DATE: July 28, 1999 POSITION: Senior Staff Engineer I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: NAME: Dale Rublaitus SIGNATURE: Dale Rublaitus DATE:July 28, 1999 POSITION: Engineering Manager

MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 12 SHEET 1 OF 1 RF EXPOSURE INFORMATION In accordance with 47 CFR 2.1093 (c), this transmitter has been subject to routine environmental evaluation for RF exposure and found to be compliant with the limits specified 47 CFR 2.1093 (d).

MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 5 SHEET 1 OF 2 CIRCUIT DESCRIPTIONS EXHIBIT 5A – MEANS FOR FREQUENCY STABILIZATION Frequency stability is maintained by a reference oscillator/programmable temperature compensation circuit located in the frequency synthesizer IC U1201. The oscillator is a Colpitts design with an amplifier in the IC. The 16.8 MHz crystal Y1201, varactor CR1201, and feedback capacitors are external circuitry. A control voltage applied to the varactor via the programmable compensation circuit within U1201maintains the frequency stability to within +/-2.5 ppm over the specified operating temperature range. Frequency tuning, also from the programmable compensation circuit, has 128 steps of resolution. Each 16.8 MHz crystal is numerically coded providing its unique characteristic over the operating temperature range. With the crystal temperature characteristic known, a computed compensation characteristic is programmed into the compensation algorithm. EXHIBIT 5B – MEANS FOR LIMITING MODULATION Modulation limiting is accomplished within the custom IC, U0221. The limiting action itself occurs at the rails (i.e., 5V and ground). Using an opamp with feedback, very hard limiting is obtained. The limited modulation signal is then applied to a low-pass splatter filter, and then to an electronic attenuator within U0221 in order to adjust for variations in modulation sensitivities of the frequency synthesizer. The electronic attenuator is controlled by the radio’s microprocessor, U0101. To keep the deviation constant over the RF frequency range & channel bandwidth, the microcomputer adds the proper correction factor to the attenuator. EXHIBIT 5C – MEANS FOR ATTENUATION OF HIGHER AUDIO FREQUENCIES The output of the limiter is applied to a low-pass splatter filter. This filter is a fifth-order switched capacitor filter with the roll-off corner located at 3000 Hz. The output of the low-pass filter is applied to the electronic attenuator before being routed to the modulator. EXHIBIT 5D – MEANS FOR ATTENUATION OF SPURIOUS EMISSIONS The final stage of the RF power amplifier circuit feeds a low-pass filter in order to attenuate harmonics of the carrier frequency as well as any spurious signals. The filter is a seven-pole elliptic design using LC lumped elements. The cast metal chassis forms a compartmentalized shielded enclosure upon which the main circuit board is mounted. A second cast metal compartmentalized shielded enclosure is placed over the main circuit board and secured to the chassis with screws. A conductive elastomeric coating is bonded to the edges of the metal chassis and shield enclosure walls, which come in contact with gold-plated areas of the circuit board when the circuit board and shield are assembled to the chassis. This technique provides very effective and reliable shielding of the various circuits on the main board from each other and from the external environment, minimizing spurious RF radiated emissions. MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 5 SHEET 2 OF 2 EXHIBIT 5E – MEANS FOR LIMITING OUTPUT POWER Output power is regulated through the use of a current sensing ALC loop. The voltage drop across current sensing resistor R1409 provides a feedback signal to the Power Control IC U1503. This signal is then compared to the preprogrammed current reference and the error signal is amplified and used to generate a control voltage to control the bias of the first transmitter stage, U1401. EXHIBIT 5F – MODULATION TECHNIQUES The transmitter is capable of the following types of modulation: i) Modulation of PL (Private Line) - Direct FM tone modulation of 67 Hz to 250.3 Hz at 15% of full system deviation. ii) Modulation of DPL (Digital Private Line) - Direct FM modulation at 134 BPS at 15% of full system deviation. iii) Modulation of DTMF tones at nominally 60% of full system deviation. The Carson’s Rule calculations for necessary bandwidth, Bn = 2M + 2DK, where M = maximum modulating frequency in Hz, D = peak deviation in Hz, and K = 1, are as follows: For 20 kHz Channel Spacing with 5 kHz full system deviation: Bn = 2(3000) + 2 (5000)(1) = 16000 Hz (16K0 designator) Direct FM of PL or DPL is generated by a 6-bit D/A converter contained within U0221. The frequency-determining clock signal is generated by the radio microcomputer. The modulation signal is processed through a five pole switched capacitor filter. The output of the filter is input to the electronic attenuator circuit. The microcomputer adjusts the attenuator to compensate for modulation sensitivity variations of the synthesizer & channel bandwidth ensuring 15% of full system deviation for PL and DPL. DTMF tones are generated by the audio processing IC, U0221. The tones are routed and processed in the same manner as the voice signals. EXHIBIT 5G – MEANS FOR CONTROLLING TRANSIENT FREQUENCY BEHAVIOR The effects of VCO frequency shifts due to transmitter key-up and de-key impedance variations are minimized through the use of a multiple-stage transmitter lineup with resistive isolation pads between various stages, including a pad between the output of the VCO buffer amplifier circuit and the input of the transmitter circuit. Additionally, the value of the DAC which controls output power is gradually raised during transmitter key-up and lowered during de-key, shaping the transmitter attack and decay characteristics by gradually changing the power control voltage. Finally, a pre-bias circuit is used so that the power control circuit does not react to a zero-power condition at transmitter key-up by attempting to increase the power output instantaneously to a high level.

MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 1 LIST OF EXHIBITS DESCRIPTION EXHIBIT REFERENCE I. Cover Letter12.1033 II. Identification Label Information2 General Information2A 1. Production Plans 2. Application References 3. Data Submittal Procedure III.Certification of Data3 IV.External Photographs4 V.Circuit Descriptions5 1. Means for Frequency Stabilization5A 2. Means for Limiting Modulation5B 3. Means for Attenuation of Higher Audio Frequencies5C 4. Means for Attenuation of Spurious Emissions5D 5. Means for Limiting Power Output5E 6. Modulation Techniques5F 7. Means for Controlling Transient Frequency Behavior5G VI. Schematic Diagrams6 1. Transmitter Audio, PL/DPL/DTMF Generation6A 2. Microprocessor/Controller6B 3. Fractional-N Synthesizer, Reference Oscillator6C 4. Voltage-Controlled Oscillators and Buffers6D 5. RF Power Amp, Low-Pass Filter, Antenna Switch6E 6. Transmitter Power Control6F VII. Test Report7 1. Data Index7 2. RF Output Data7A 3. Modulation Characteristics A. Audio Response & Low Pass Filter Response7B, 7C B. Modulation Limiting7D 4. Occupied Bandwidth7E 5. Conducted Spurious Emissions 7F 6. Radiated Spurious Emissions7G 7. Frequency Stability A. Frequency Stability vs. Temperature7H-1 B. Frequency Stability vs. Voltage7H-2 MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 1 LIST OF EXHIBITS (CONTINUED) DESCRIPTION EXHIBIT REFERENCE VIII.Test Set-up Procedures8 IX. Instruction Manual9 X. Internal Photographs10 XI.Parts List and Tune Up Procedures11 1. Function of RF Semiconductors & Active Devices 11A 2. List of Recommended Test Equipment for Servicing11B 3. Tune Up Information11C XII.RF Exposure Information12 XIII.Operational Description13 1. Technical Characteristics 2. Application MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 1 Date:July 30, 1999. Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ492FT1626. Attention: Frank Coperich. Gentlemen: Motorola Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida, herein submits it’s application for Certification of the subject transmitter. This transmitter is primarily intended for use in a mobile radio application with capabilities for communications with a transmit power of 40--72 Watt. The Power is variable 55% of the value listed (40--72 Watt). The subject transmitter complies with Section 90.203 of the rules in that the operator cannot directly program transmit frequencies using only the unit's normally accessible external controls. Enclosed is a complete Certification application. Contact me at (954) 723-5793 if you require any additional information. Sincerely, Mike Ramnath FCC Liaison Email: [email protected] Fax (954) 723-4794

MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 4 SHEET 1 OF 5 GENERAL VIEW, 128 CHANNEL MODEL MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 4 SHEET 2 OF 5 FRONT VIEW, 128 CHANNEL MODEL (TOP) FRONT VIEW, 64 CHANNEL MODEL (MIDDLE) FRONT VIEW, 4 CHANNEL MODEL (BOTTOM) MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 4 SHEET 3 OF 5 FRONT VIEW, 160 CHANNEL MODEL MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 4 SHEET 4 OF 5 BOTTOM VIEW, SHOWING FCC ID LABEL MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 4 SHEET 5 OF 5 FCC Label Shown Above

MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 2 SHEET 1 OF 2 IDENTIFICATION LABEL LOCATION A nameplate of the type presented below will be affixed to every transmitter. It will be placed on the outside of the housing at the bottom back of the transmitter. TYPE The label is a paper polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with a minimum peel strength of 40 oz/inch. MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 2 SHEET 2 OF 2 EXHIBIT 2A - GENERAL INFORMATION 1. Production Plans -- Pursuant 2.981 (c) Quantity production is planned. 2. Application References: EIA/TIA-603 Land Mobile FM or PM Communications Equipment Measurement and Performance Standards Code of Federal Regulations Title 47, Part 2, Sec. 2.983-2.999 and Part 90, Sec.90.210 3. Data Submittal Procedure: Data is supplied in accordance with Part 2, Sub-part J of the Commissions’ rules. The intended use of this transceiver includes applications covered in the Code of Federal Regulations Title 47, Parts 22 and 90. Transmitter power shall not exceed 60 watts for use in applications covered by Part 22, and this power level shall not be adjustable by the user.

MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 10 SHEET 1 OF 3 INTERNAL PHOTOGRAPHS 1. Exhibit 10-1 Top View, with decorative plastic cover removed. 2. Exhibit 10-2Top View, with shield removed. 3.Exhibit 10-3Top View of Chassis, with circuit board removed. MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 10 SHEET 2 OF 3 TOP VIEW, WITH DECORATIVE PLASTIC COVER REMOVED MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 10 SHEET 3 OF 3 TOP VIEW, WITH METAL SHIELD COVER REMOVED (TOP SIDE OF CIRCUIT BOARD VISIBLE) MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 10 SHEET 4 OF 3 TOP VIEW OF CHASSIS, WITH CIRCUIT BOARD REMOVED (BOTTOM SIDE OF CIRCUIT BOARD VISIBLE)

MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 13 SHEET 1 OF 4 OPERATIONAL DESCRIPTION I. Transmitter Technical Characteristics -- Pursuant 2.983 (d) A. Specific Operating Power Levels: RATED: 40 to 72 Watts, variable MEASURED: Refer to Exhibit 7A Maximum Power Rating: 72 Watts Means provided for variation of operating power: Output power is continuously variable over the range of 40 to 72 Watts. The output power isfield programmable to any power level within this range. B. Frequency Range: 42 to 50 MHz C. Frequency Stability: RATED: ± 0.0005% (± 5 ppm) MEASURED: Refer to Exhibits 7H-1 and 7H-2. D. Types of Emissions: 16K0F3E (refer to Exhibit 5F) E. Spurious Emissions: RATED: 2.5 mW (-26 dBm) maximum, which corresponds to -72 dBc at the 40 Watt setting, and –74.6 dBc at the 72 Watt setting. MEASURED: Refer to Exhibits 7F and 7G. F. DC Operating Voltages and Currents of the Final Stage: Refer to Exhibit 7A. II. Transmitter Application The following features, options, accessories, and installations characterize the transmitter. A. Power Supply: Vehicular battery, or AC-DC Converter B. Antenna: Whip, roof top, 1/4 wave, or other external 50-ohm antenna C. Squelch Types: 1. Carrier Squelch (CSQ) 2. Tone Private Line (TPL) 3. Digital Private Line (DPL) MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 13 SHEET 2 OF 4 Description (continued) D. Microphones Available: 1. Hand-held conventional 2. Hand-held conventional with DTMF 3. Base Station Desk Top 4. Telephone Style Handset E. Maximum Transmit Channel Capability: 4 to 160 channels, depending on model. F. Housing Style: The transmitter is enclosed in a metal, shielded chassis as shown in the accompanying photographs. The transmitter circuitry is contained on a single printed circuit board that is mounted to a cast metal chassis that also serves as a heatsink. A cast metal shield cover is placed over the printed circuit board and secured to the chassis with screws. Interior walls in both the chassis and shield cover form compartments that provide isolation between various circuit blocks. The frequency synthesizer, vco/buffers, transmitter stages, and low-pass harmonic filter are each contained in individual, isolated compartments. A conductive elastomeric coating is bonded to the edges of the metal chassis and shield enclosure walls, which come in contact with gold-plated areas of the circuit board when the circuit board and shield are assembled to the chassis. A decorative plastic housing encloses the top and sides of the chassis. The operating controls, indicators and supporting circuitry are contained in a separate plastic housing which is mounted to the front of the chassis. G. Available Accessories: ENKN4000BMAP27 cable RKN4077A3m Remote Mount cable RKN4078A5m Remote Mount cable RKN4079A7m Remote Mount cable RKN4081AMobile Programming RIB Cable RKN4083AMobile Programming RIBless cable RLN4756ATelephone style handset RLN4774A3 point / Lowband RLN4780AHigh profile mounting trunnion RLN4782ADIN mounting kit RLN4801ARemote Mount Control head A RLN4802ARemote Mount Control head B/C RLN4829AConv Control head A Button Kit (no manual) RLN4830AConv Control head BCD Button Kit (no manual) RLN4836AExternal PTT w/Emergency Footswitch RLN4853A10 pin Mic/20 pin DIN Adaptor RMN4025AEnhanced compact mic RMN4026ASmart mic RMN4027AVisor mounted mic RMN4038AHeavy Duty mic MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 13 SHEET 3 OF 4 RMN4041AFootswitch with Remote PTT RMN4042APushbutton with Remote PTT RMN4043AGooseneck PTT RSN4001AExternal speaker 13W 8180384J60Housing Eliminator 45W AARLN4832AModem Option Board (w/NA/LA manual) RLN4832AModem Option Board (w/o Manual) GKN6272AExternal alarm relay GLN7318ADesktop mounting tray w/out speaker GLN7323AExternal PTT/ emergency footswitch GLN7324ALow profile mounting trunnion GLN7326ADesktop mounting tray w/spkr GTF347BMobile Programming Cable RAB4004AMini-U Lowband 42-50MHz HKN9019BEnhanced connector HKN9402A12V Battery Power Cable HKN9557AMini-UHF to PL259 cable HLN3333B RICK with Mounting Bracket HLN3948BRICK with Mounting Tray HLN8097ARemovable slide mount HLN9457AAccessory connector Kit HLN9725BVoice Storage Option Board HLN9742AAdaptor Flashing HMN3000BBlack Desk Microphone HPN4001BDesktop power supply, 25-60W HSN8145AExternal speaker 7.5W L3144AC200 Basic Extended Local Control (Eng Manual) L3145AC200 Basic DC Remote Control (Eng Manual) L3146AC200 Basic Tone Remote Control (Eng Manual) L3147AC200 Advanced Extended Local Control (Eng Manual) L3148AC200 Advanced DC Remote Control (Eng Manual) L3149AC200 Advanced Tone Remote Control (Eng Manual) NTN7373ARUS linecord (3060665A04) packaged NTN7374ARUS linecord (3060665A05) packaged NTN7375ARUS linecord (3002120F02) packaged 0902105F01BNC Connector AAHLN9725BVoice Storage Option Bd (w/NA/LA Manual) HLN9725AVoice Storage Option Bd (w/o Manual) AAHLN9729ADTMF Decode Option Bd (w/NA/LA Manual) HLN9729ADTMF Decode Option Bd (w/o Manual) AAHLN9726ATranscrypt Option Bd (w/NA/LA Manual) HLN9726ATranscrypt Option Bd (w/o Manual) AAHLN9727AScrambler Option Bd (w/NA/LA Manual) HLN9727AScrambler Option Bd (w/o Manual) AAHLN9728ASmartrunk Option Bd (w/NA/LA Manual) MDHLN9728ASmartrunk Option Bd (w/o Manual) MOTOROLA INCFCC ID: AZ492FT1626 EXHIBIT 13 SHEET 4 OF 4 H. Programmability: Programming is accomplished by the use of an IBM PC computer or equivalent, a Radio Interface Box, and Radio Service Software. Adjustment of the transmitter, including programming of the channel frequencies, output power adjustment, frequency adjustment, and deviation adjustment are performed in this manner. NOTE: The transmitter is NOT programmable by the operator.

MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 11 SHEET 1 OF 1 PARTS LIST / TUNE UP INFORMATION This exhibit contains a list of the semiconductor devices used in the transceiver and the test equipment and tuning procedures for maintaining the transceiver. EXHIBIT 11AFunction of RF Semiconductors and Other Active Devices EXHIBIT 11BList of Recommended Test Equipment for Servicing EXHIBIT 11CTune Up Information MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 11A SHEET 1 OF 3 Exhibit 11A - Function of RF Semiconductors & Other Active Devices REFPARTCIRCUITOPERATINGINDUSTRY NO. NUMBER APPLICATION FREQUENCY EQUIVALENT CR12014802245J22REF OSC FREQ CONTROL16.8 MHz1T363 CR12024813825A05VOLTAGE MULTIPLIER1.05 MHzMMBD301 CR13024805649Q14RX VCO FREQ CONTROL 52.7-60.7 MHz HN1V02H CR13064880154K03RX VCO AGC RECTIFIER52.7-60.7 MHzMMBD353 CR13104805649Q14TX VCO FREQ CONTROL42-50 MHzHN1V02H CR13144880154K03TX VCO AGC RECTIFIER42-50 MHzMMBD353 D01014880236E05DATA SWITCH230 kHz MMBD301 D01514813833C02DC SWITCHDC MMBD6100 D01794813833C02CLAMP DC MMBD6100 D03014802245J47DC SWITCHDCRB471E D06214813833C02DC SWITCHDCMMBD6100 D06514813833C02DC SWITCHDCMMBD6100 D06604813833C02DC SWITCHDCMMBD6100 D06614813833C02DC SWITCH DCMMBD6100 D10014880154K03CLIPPER42-50 MHzMMBD353 D11014880154K03CLIPPER10.7 MHz MMBD353 D14014808379X02RF PIN SWITCH42-50 MHzMA4P1450 D14024808379X02RF PIN SWITCH42-50 MHzMA4P1450 D15014880236E05DC SWITCHDCMMBD301 D16014880236E05CLIPPER100 kHzMMBD301 Q01104880048M01DC SWITCHDC DTC144EKA Q01514880048M01DC SWITCHDCDTC144EKA Q01714880048M01DC SWITCHDC DTC144EKA Q01734880052M01DC SWITCH DCRXT-A28 Q01774880048M01DC SWITCHDCDTC144EKA Q01814880048M01DC SWITCHDC DTC144EKA Q01834880048M01DC SWITCHDCDTC144EKA Q01854880048M01DC SWITCHDC DTC144EKA Q02714813824A10DC SWITCHDCMMBT3904 Q03314805921T02DATA SWITCH1 MHzFMC2A Q06414880048M01DC SWITCH DCDTC144EKA Q06614805921T02DC SWITCH DCFMC2A Q06624813824A10DC SWITCHDCMMBT3904 Q06634880048M01DC SWITCHDCDTC144EKA Q06814880052M01DC VOLTAGE SOURCE DCRXT-A28 Q10014880173R01RF AMPLIFIER 42-50 MHzMMBR951 Q10024813824A17RF AMPLIFIER BIAS CONTROLDCMMBT3906 Q10034813824A17DC SWITCHDCMMBT3906 MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 11A SHEET 2 OF 3 REFPARTCIRCUITOPERATINGINDUSTRY NO. NUMBER APPLICATION FREQUENCY EQUIVALENT Q11014813827A07FIRST I-F AMPLIFIER10.7 MHzMMBR941 Q11024813823A05I-F NOISE BLANKER SWITCH10.7 MHzMMBFU310L Q11034813823A05I-F NOISE BLANKER SWITCH10.7 MHzMMBFU310L Q11044813823A05I-F ISOLATION BUFFER10.7 MHzMMBFU310L Q11064813827A07SECOND I-F AMPLIFIER10.7 MHzMMBR941 Q12014813824A17SUPER FILTER PASS DEVICEDCMMBT3906 Q12024880173R01FEEDBACK BUFFER AMPLIFIER42-60.7 MHzMMBR951 Q13034880141L06RX VCO52.7-60.7 MHzMMBFU310 Q13044880173R01RX VCO FIRST BUFFER AMP52.7-60.7 MHzMMBR951 Q13054880173R01RX VCO SECOND BUFFER AMP52.7-60.7 MHzMMBR951 Q13064880141L06TX VCO42-50 MHzMMBFU310 Q13074880173R01TX VCO FIRST BUFFER AMP42-50 MHzMMBR951 Q13084880173R01TX VCO SECOND BUFFER AMP42-50 MHzMMBR951 Q14015105385Y70TX DRIVER STAGE42-50 MHz 85Y70 Q14024886136B01TX FINAL POWER AMPLIFIER42-50 MHz36B01 Q14034886136B01TX FINAL POWER AMPLIFIER42-50 MHz36B01 Q15014880141L03DC SWITCHDCBCW68G Q15024813824A10DC SWITCH DCMMBT3904 Q15034813824A10ERROR AMPLIFIERDCMMBT3904 Q15044813824A10DC AMP/LEVEL SHIFTER DCMMBT3904 Q15054813824A17DC AMP/LEVEL SHIFTER DCMMBT3906 Q15065180159R01VOLTAGE REGULATORDCIMX1 Q16014813824A17DC SWITCHDCMMBT3906 Q16024880048M01DC SWITCH DCDTC144EKA Q16034813824A10IMPULSE NOISE DETECTOR100 kHzMMBT3904 Q16044813824A10PULSE AMPLIFIER 100 kHzMMBT3904 Q16054813824A10PULSE SHAPER100 kHzMMBT3904 Q16064813824A17PULSE AMPLIFIER 100 kHzMMBT3906 Q16074813824A10PULSE RATE AMPLIFIER100 kHz MMBT3904 Q16084813824A10PULSE RATE AMPLIFIER100 kHzMMBT3904 Q16094813824A17PULSE RATE DETECTOR100 kHzMMBT3906 Q16104805585Q17NOISE BLANKER I-F AMPLIFIER10.7 MHzNE25139 U01015102226J56MICROPROCESSOR38.4 kHz-7.4 MHzMC68HC11FL0 U01115102463J64EEPROM 1 MHzX25128_2.7 U01215186137B01FLASH ROM1.85 MHzAT49F040 U01225185963A21SRAM 1.85 MHz63A21 U01415113805A30DECODER/DEMUX5 kHzMC74HC138A U02115183222M49AUDIO AMPLIFIERAUDIOMC3403 U02215185963A53AUDIO FILTER 16.8 MHz63A53 U02515113806A20AUDIO GATE AUDIOMC14053B U02715109699X01AUDIO POWER AMPLIFIER AUDIOTDA1519C MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 11A SHEET 3 OF 3 REFPARTCIRCUITOPERATINGINDUSTRY NO. NUMBER APPLICATION FREQUENCY EQUIVALENT U03015102463J53VOICE STORAGE1 MHzISD33000 U03415180932W01AUDIO AMPLIFIER AUDIOLM2904 U03425105750U28AUDIO GATEAUDIO TC4S66F U03515102463J40VOLTAGE REGULATOR DCLP2951ACMM-3.3 U06115183308X01VOLTAGE REGULATORDCLM2941 U06415183308X01VOLTAGE REGULATORDCLM2941 U06515113816A07VOLTAGE REGULATORDCMC78M05 U06525113815A02RESET MONITOR DCMC33064 U10014802245J50DC SWITCHDCUMC5N U10515108278X01DOUBLE BALANCED MIXER10.7-60.7 MHz78X01 U11035186144B01RECEIVER SYSTEM455 kHz-10.7 MHzSA616 U12015185963A27FREQUENCY SYNTHESIZER 1.05-60.7 MHz63A27 U12505185963A33VOLTAGE REGULATORDCLP2951 U13774802245J50DC SWITCHDCUMC5N U13784802245J50DC SWITCHDCUMC5N U14015105109Z67GAIN CONTROLLED AMPLIFIER42-50 MHz09Z67 U14025113818A03DC AMPLIFIERDCMC33072 U15015185963A15TEMPERATURE SENSOR DCLM50 U15025180932W01DIFFERENTIAL AMPLIFIERDCLM2904 U15035185765B01TX POWER CONTROL1 MHzH99S-4 U16015180929W01GAIN CONTROLLED AMPLIFIER10.7 MHzMC1350 VR01514813830A15DC LEVEL-SENSING SWITCH DCMMBZ5232B VR05014805656W09ESD PROTECTION DCMMQA20VT1 VR05034805656W09ESD PROTECTIONDC MMQA20VT1 VR05044813830A40ESD PROTECTIONDCMMBZ5257B VR05054805656W09ESD PROTECTIONDCMMQA20VT1 VR05094813830A40ESD PROTECTIONDCMMBZ5257B VR05104813830A40ESD PROTECTIONDCMMBZ5257B VR05374813830A15ESD PROTECTIONDCMMBZ5232B VR05414813830A27ESD PROTECTIONDCMMBZ5244B VR06014813832C77TRANSIENT SUPPRESSORDCMR2835S VR06214813830A14VOLTAGE REGULATOR DCMMBZ5231B VR15014813830A27VOLTAGE REGULATOR DCMMBZ5244B COMMENTS: The Motorola designators are special code numbers for active devices used in Motorola radios. These devices are either identical or derived from the device family listed under Industry Equivalent, by …

Text truncated - open the document above for the full version.

MOTOROLA INC.FCC ID: AZ492FT1626 EXHIBIT 6 SCHEMATIC DIAGRAMS This exhibit contains the schematic diagrams of the transmitter circuits. EXHIBIT 6ATransmitter Audio Path, PL/DPL Generation EXHIBIT 6BMicroprocessor/Controller EXHIBIT 6CFractional-N Frequency Synthesizer, Reference Oscillator EXHIBIT 6DVoltage Controlled Oscillators and Buffers EXHIBIT 6ERF Power Amplifier, Harmonic Filter, Antenna Switch EXHIBIT 6FTransmitter Power Control Circuit MOTOROLA INC…
