APX MOBILE O2 CONTROL HEAD USER GUIDE APX™ TWO-WAY RADIOS Draft 1 Draft 1 English m ASTRO ® APX™ O2 Control Head Mobile Radio Quick Reference Card Product Safety and RF Exposure Compliance ATTENTION! This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C99) to ensure compliance with RF energy exposure limits. Radio Controls Radio On/Off Adjusting Volume Selecting a Zone Selecting a Channel Receiving and Transmitting Sending an Emergency Alarm Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio. ! C a u t i o n Power Button LED Indicators Emergency Button* Multi-function Knob (MFK)* Home Button Menu Select Buttons* Accessory Port (Microphone) *These controls/buttons are programmable. Dimmer Button Up & Down Buttons* Press the Power button to turn the radio on or off. If volume is set as the primary mode, 1Turn the MFK clockwise to increase volume or counterclockwise to decrease the volume. If volume is not set as the primary mode, press the MFK once and repeat step 1. If zone is set as the primary mode, 1Turn the MFK until the display shows the desired zone and press the PTT button to begin transmitting on the displayed zone. If zone is not set as the primary mode, press the MFK once and repeat step 1. OR 2> or < (on the keypad mic.) to scroll to Zone. 3Press the Menu Select button directly below Zone. 4Rotate the MFK or D or U to the desired zone. 5Press the Menu Select button directly below Sel or the 3 button (on the keypad mic.) to confirm the selected zone number. 6Press the PTT button to begin transmitting on the displayed zone. If channel is set as the primary mode, 1Turn the MFK until the display shows the desired channel and press the PTT button to begin transmitting on the displayed channel. If channel is not set as the primary mode, press the MFK once and repeat step 1. OR 2> or < (on the keypad mic.) to scroll to Chan. 3Press the Menu Select button directly below Chan. 4Rotate the MFK or press D or U to the desired channel. 5Press the Menu Select button directly below Sel or the 3 button (on the keypad mic.) to confirm the channel. 6Press the PTT button to transmit on the displayed channel. 1Take the microphone off the hook. 2Select zone/channel. 3Listen for a transmission. OR > or < (on the keypad mic.) to Mon then press the Menu Select button directly below Mon and listen for activity. 4Adjust volume, if necessary. 5Press the PTT button to transmit; release to receive. 1Press the Emergency button. A tone sounds and the display alternates Emergency and the home display. 2A dispatcher acknowledgment Ack received display follows. AND, Trunking Only: A high-pitched tone indicates that the alarm has been received by the trunked system’s central controller. *PMLN6193A* PMLN6193A MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. © 2012 by Motorola Solutions, Inc. All Rights Reserved. 08/12 1303 East Algonquin Road, Schaumburg, Illinois 60196, U.S.A. Draft 1 English To exit emergency at any time, press and hold the Emergency button. Sending an Emergency Call (Trunking Only) To exit emergency at any time, press and hold the Emergency button. Sending a Silent Emergency Alarm If silent emergency alarm is used with emergency call, pressing the PTT button exits the silent mode and initiates the emergency call. Display Status Icons 3Press and hold the emergency button or the PTT button to return to normal operation. 1Press Emergency button. 2A tone sounds and the display alternates Emergency and the home display. OR A talk prohibited tone sounds when the selected channel does not support emergency. 3Press and hold the PTT button. Speak clearly into the microphone. 4Release the PTT to end the transmission. 1Press the preprogrammed Emergency button to activate the silent alarm feature. 2The display does not change; the LED does not light up, and there is no tone. Receiving a call or data. Transmitting a call or data. Received an Individual Call. u t F The more stripes, the stronger the signal strength for the current site (trunking only). Direct radio-to-radio communication or communication through a repeater. On = Direct Off = Repeater This channel is being monitored. Voice muting the affiliated trunking talkgroup or selected channel. On = Enabled Off = Disabled L = Radio is set at Low power. H = Radio is set at High power. Scanning a scan list. Blinking dot = Detects activity on the Priority-One Channel during scan. Steady dot = Detects activity on the Priority- Two Channel during scan. Radio is in the view or program mode. On steady = View mode. Blinking = Program mode. V O M K HOR . i j The vote scan feature is enabled. On = Secure operation. Off = Clear operation. Blinking = Receiving an encrypted voice call. On = AES Secure operation. Off = Clear operation. Blinking = Receiving an encrypted voice call. On = Location feature enabled, and location signal available. Off = Location feature disabled. Blinking = Location feature enabled, but location signal unavailable. Inverted = User is currently associated with the radio. On = Packet data is activated. Off = Packet data is deactivated. Blinking = Device registration or user registration with the server failed due to an invalid username or pin. Data activity is present. MFK is in Mode Change feature Turn the MFK to change channel. MFK is in Volume Change feature Turn the MFK to adjust the volume. k m l G n o Menu Navigation < or > to Menu Entry (on the keypad mic.). g directly below Menu Entry to select. H to exit.…

Text truncated - open the document above for the full version.

APX™ TWO-WAY RADIOS APX MOBILES O2, O3, O5, O7 & O9 CONTROL HEAD INSTALLATION MANUAL 0 i Foreword This manual covers the O2, O3, O5, O7 and O9 models of the ASTRO ® APX™ mobile radios. It includes all the information necessary to install mid power and high power radios, and configure radio installation inside vehicles. For details on radio operation or component-level troubleshooting, refer to the applicable manuals available separately. A list of related publications is provided in the section “Related Publications,” on page vi. RF Energy Exposure and Product Safety Guide for Mobile Two-way Radios See “Installation Requirements for Compliance with Radio Frequency (RF) Energy Exposure Safety Standards,” on page ii. Manual Revisions Changes which occur after this manual is printed are described in PMRs (Publication Manual Revisions). These PMRs provide complete replacement pages for all added, changed, and deleted items.  To obtain PMRs, go to https://businessonline.motorola.com. Parts Ordering See Appendix A: Replacement Parts Ordering for information on how to obtain replacement parts. For part numbers, refer to the ASTRO APX Mobile Radio Basic Service Manual (Motorola publication part number 6875964M01). Computer Software Copyrights The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs, including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product. Document Copyrights No duplication or distribution of this document or any portion thereof shall take place without the express written permission of Motorola. No part of this manual may be reproduced, distributed, or transmitted in any form or by any means, electronic or mechanical, for any purpose without the express written permission of Motorola. Disclaimer The information in this document is carefully examined, and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies. Furthermore, Motorola reserves the right to make changes to any products herein to improve readability, function, or design. Motorola does not assume any liability arising out of the applications or use of any product or circuit described herein; nor does it cover any license under its patent rights nor the rights of others. Trademarks MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. © 2009 – 2012 by Motorola Solutions, Inc. All rights reserved. ii Installation Requirements for Compliance with Radio Frequency (RF) Energy Exposure Safety Standards ATTENTION! This radio is intended for use in occupational/controlled conditions, where users have full knowledge of their exposure and can exercise control over their exposure to meet FCC limits. This radio device is NOT authorized for general population, consumer, or any other use. To ensure compliance to RF Energy Safety Standards: •Install only Motorola approved antennas and accessories •Be sure that antenna installation is per “Antenna Installation,” on page 2-38 of this manual •Be sure that Product Safety and RF Safety Booklet enclosed with this radio is available to the end user upon completion of the installation of this radio Before using this product, read the guide enclosed with your radio which contains important operating instructions for safe usage and RF energy awareness and control for compliance with applicable standards and regulations. For a list of Motorola-approved antennas and other accessories, visit the following web site which lists approved accessories for your radio model: http://www.motorolasolutions.com. Table of Contents iii 6878215A01 Table of Contents Foreword ..........................................................................................................i RF Energy Exposure and Product Safety Guide for Mobile Two-way Radios..............................................i Manual Revisions .........................................................................................................................................i Parts Ordering ..............................................................................................................................................i Computer Software Copyrights ....................................................................................................................i Document Copyrights ...................................................................................................................................i Disclaimer.....................................................................................................................................................i Trademarks ..................................................................................................................................................i Installation Requirements for Compliance with Radio Frequency (RF) Energy Exposure Safety Standards .......................ii Mobile Radio Model Numbering Scheme..................................................xiii Commercial Warranty ................…

Text truncated - open the document above for the full version.

Appli Th e here 1) 2) I h e of m data icant: Motoro e technical da eby duly certi BEng 7 years exp e Communicat ereby certify th my knowledge a are true and ola Solutions ata supplied w ified. The follo University of erience in the tions Product NAME SIGN A DATE POSIT hat the above e and belief, d correct: NAME SIGN A DATE POSIT s Inc. Stateme n with this app owing is a sta Sheffield Hal developmen s : T e ATURE :___ : Au ION : Se e application w the facts set : Pe ATURE :___ : Au ION : En nt of Certific plication, havi atement of my lam t, testing and eoh Yee Teng ___________ ugust, 16, 201 enior Electrica was prepared t forth in the a eter Keh ___________ ugust, 16, 201 ngineering Ma F ation ng been tak e y qualification certification o g ___________ 12 al Engineer d under my d application an ___________ 12 anager FCC ID: AZ en under my s: of Land Mobi ____ irection and t nd accompan ___ Z492FT382 supervision le that to the bes nying technic EXHIBIT 6 is st al 2

FCC ID: AZ492FT3826 __________________________________________________________ Motorola Solutions Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. CONFIDENTIALITY REQUEST 22 nd August 2012 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ492FT3826 Dear Sir or Madam: Motorola Solutions is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d), 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, Mike Ramnath (signed above) Manager, Regulatory Compliance Tel: (954) 723-5793 E-mail: [email protected] Exhibit 13b

FCC ID: AZ492FT3826 EXHIBIT 13C __________________________________________________________ Motorola Solutions Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 22 nd August 2012 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification. Gentlemen: The APX2500/APX4500 Mobile 2-Way radio was designed to operate in the frequency band 136-174 MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Motorola Solutions is requesting that the FCC lists the frequencies 136-174 MHz on the FCC Grant. For the FCC’s Rule Parts 90 applications, this radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, etc. as indicated in the table below. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC’s KDB634817 guidance, “as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies” Frequency Range (MHz) Part 90 Part 22 Part 74 Part 80 Federal Grant Notes Emission Designator Rule Part 90 136-150.8 x EF, BE 8K10F1D/F1E/F1W, 11K0F3E 150.8-161.6250 x x x x EF, BE “”” 161.6250-161.7750* x EF, BE “”” 161.7750-173.4 x x EF, BE “”” 173.4-174 x EF, BE “”” * Canada Sincerely, Mike Ramnath (signed above) Manager, Regulatory Compliance Email: [email protected]

FCC ID: AZ492FT3826 __________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. September 21 st , 2012 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Att: JC Chen Subject: Response to Correspondence 42591 for Certification of Transmitter with FCC ID: AZ492FT3826, EA596340 Hello Mr. Chen, Please see below for our responses: Q1. Please clarify whether this application is seeking Part 90 certification only or Parts 80 and 90, or Parts 22, 74, 80 and 90? The submitted EMC report also supports Part 90 with all other bands/modes marked not for FCC review. However, the user’s manual suggests the EUT is also Part 80 certified while one of the cover letters states that it is requesting certification for Parts 22, 74, 80 and 90. Please clarify the applicable rule parts and what frequency bands are being authorized and which are extended frequency listings. Keep in mind that FCC policy does not permit equipment for occupational/controlled RF exposure to mix with those for the general population. (It is not practical to claim both categories for the same device anyway.) R1. This application is seeking FCC Rule parts 22, 74, 80, and 90. We will not be mix Occupational and General Population exposure limits. The FCC has approved several products under Rule Parts 22, 74, 80, and 90. Q2. Please review grant notes. BF is used on Form 731 but EF and BE are suggested on the extended frequency justification letter. R2. Please see the attached amended Ex13c. Please note that we had some difficulty to add the second Grant Notes symbol of EF on the FCC website. Could you include “EF” on the approval. Q3. 25 kHz operation is not allowed for Part 90 VHF band. Therefore, 25 kHz modes should not be listed on the grant if this application is for Part 90 only. Please remove the last two listings (with emission designators 16K0F3E and 20K0F1E) on the specification page of Form 731. If you have trouble modifying Form 731, please send in request and specific instruction on what changes you would like me to do on your behalf. FCC ID: AZ492FT3826 __________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. R3. Emission Designators, 16K0F3E and 20K0F1E are not for Rule Part 90. They are for Rule Part 80 and 22, as listed on the Form 731. Q4. Similarly, for data and information associated with 25 kHz operations, the applicant should use the term "Not for FCC" instead of "Not for FCC Part 90" in the operational description (Exhibit 12-1). The latter could be interpreted as being applicable to other FCC rule parts which are not covered in this equipment authorization application. R4. Please note that Emission Designators 16K0F3E and 20K0F1E are applicable to Rule parts 22 and 80. Q5. Please remove the quotation marks around the sentence "as an alternative to listing the exact frequencies..." in the extended frequencies justification letter. The quotation marks make it appear that the applicant is quoting KDB 634817 and not attesting to the effect. R5. We have removed the quotation marks, as request, in Exhibit 13c. Please note that the text was excerpted verbatim from an earlier version of this KDB. Q6. EMC test report test equipment list shows a piece of equipment almost 6 months out of calibration at time of testing. Arine to respond: R6. This was a typo and the actual calibration due date is 2-Mar-2013. See the attached updated file ex 07. Q7. Despite the applicant’s claim that the transmitter is not capable of being programmed by station operators using external controls, user’s manual in Pages 31-33 seem to suggest otherwise. In particular, please clarify the statement on Page 32 "If you select a channel that is not within the preprogrammed band, the radio indicates that it is on an unsupported frequency with both audio and visual warnings." In addition, please describe the default (before programming) radio zone and channel options available to users. R7. The user manual states that “Any reference in this manual to a control that is “preprogrammed” means that the control must be programmed by a dealer or an authorized service personnel using the radio’s programming software, in order to assign a feature to that control.” Since all the channels available for the operator to select are preprogrammed, statement on Page 32 as mentioned in the question will be removed from the user’s manual to avoid confusion. Please note that users must have a valid FCC license to use these radios. The default frequency in the radio is 136.00 MHz. Q8. The measured power levels in the EMC report at high power mode (60/59.8/60 Watts) exceed the number provided on Form 731 (50 Watts). FCC ID: AZ492FT3826 __________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. R8. The power listed on the Form 731 is the Nominal or Rated Power which is 50 Watts. Also, the max power is 60 Watts and is usually listed in the FCC Grant Notes. Also, the Nominal Power meets the FCC’s Rule Part 90.203 (r ) requirement of 20%. Q9. The Emission Mask D shown in the occupied bandwidth plots do not appear to be correct. After 12.5 kHz removed from the center frequency, the mask should be at 50 dB lower than the reference level. R9. Part90.210 (d) (3) ,“On any frequency removed from the center of the authorized bandwidth by a displacement frequency (fd in kHz) of more than 12.5 kHz: At least 50 + 10log (P) dB or 70 dB, whichever is the lesser attenuation.” Attenuation after ±12.5 kHz = 50 + 10 log (P) dB. In this case P = 60 W, therefore attenuation after ±12.5 kHz = 50 + 10log (60) = 67.78 dB down from the reference level. Reference level = 0dB. If you require any additional information, please contact me at (954) 723-5793 (Phone). Sincerely, Mike Ramnath (signed above) Manager, Regulatory Compliance Email: Mik…

Text truncated - open the document above for the full version.

FCC ID: AZ492FT3826 EXHIBIT 13C __________________________________________________________ Motorola Solutions Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 21 st September 2012 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification. Gentlemen: The APX2500/APX4500 Mobile 2-Way radio was designed to operate in the frequency band 136-174 MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Motorola Solutions is requesting that the FCC lists the frequencies 136-174 MHz on the FCC Grant. For the FCC’s Rule Parts 90 applications, this radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, etc. as indicated in the table below. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC’s KDB 634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it is a violation of the FCC Rules if this device operates on unauthorized frequencies. Frequency Range (MHz) Part 90 Part 22 Part 74 Part 80 Federal Grant Notes Emission Designator Rule Part 90 136-150.8 x EF, BF 8K10F1D/F1E/F1W, 11K0F3E 150.8-161.6250 x x x x EF, BF “”” 161.6250-161.7750* x EF, BF “”” 161.7750-173.4 x x EF, BF “”” 173.4-174 x EF, BF “”” * Canada Sincerely, Mike Ramnath (signed above) Manager, Regulatory Compliance Email: [email protected]

FCC ID: AZ492FT3826 __________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. October 24 th , 2012 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Att: JC Chen Subject: Response to second Correspondence 42750 for Certification of Transmitter with FCC ID: AZ492FT3826, EA596340 Hello Mr. Chen, Please see below for our responses: Q1. The EMC report, after removing all data marked "Not for FCC review," can only support Part 90 authorization. Please revise test report or add test report(s) for other applicable rule parts. All rules related to the underlying rule parts, not just the bandwidth, will need to be satisfied by the EUT. A1. We have added the statement at the bottom of the second page of the Test Report, attached, which states “Important Note: The data in this test report meets or exceeds the technical requirements of FCC Rule Parts 22, 74, 80, and 90”. Please note that the technical requirements were reviewed for all the above-mentioned rule parts and the data is compliant. Q2. Form 731 lists all 4 rule parts (22, 74, 80, and 90) for the entire 136-174 MHz. This would require all 4 rule parts to be tested over all possible channels within 136-174 MHz. If the intention is to simply provide 25 kHz mode in non-Part 90 channels, please consider listing only Part 80 for those non-Part 90 channels and use the EF note code to cover the rest of channels. A2. As noted in the above response that the radio complies to the technical requirements, as prescribed, in Rule Parts 22, 74, 80, and 90. We have no issues is the FCC lists the Rule Part Frequencies of 154.0-162.0125 MHz. We cannot correct the Form 731 now that the application was submitted. In addition, the FCC has approved all of our Part 80 applications as 136-174 MHz. See applications, FCC ID: AZ489FT3829, FT3828, etc. Q3. Please review the extended frequency listing request letter, the listed ranges and rules parts should be correct (see Part 2.106) and consistent with Form 731. A3. Per the FCC’s KDB 634817 guidance, “as an alternative to listing the exact frequencies, we acknowledge that it is a violation of the FCC Rules if this device operates on unauthorized frequencies.” However, we did list the frequencies ranges instead of including all the breaks in between, per Part 2.106. The frequencies may not match what is listed on the Form 731 because the input form is not user friendly and we will run out of room to add FCC ID: AZ492FT3826 __________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. the emission designators, power, ppm, etc for each section of the band. The Frequency Justification letter is amended to show the Part 80 frequencies. Q4. Per 90.205(s), instead of 90.203(r), indeed the output power can be as much as 20% higher than the power listed on the authorization. However, note that the power level listed on Form 731, 50 W, will become the rated power on the grant, not those higher numbers in the test report. Please confirm if this is the intent. Revise Form 731 if this is not the intent. A4. You are correct and that is our intent to show 50 Watts on the grant and the maximum power on the grant notes. Q5. Please review Emission Mask D again. The reference level should be the transmit power, not the highest point of the emission spectrum. A5. For Occupied Bandwidth testing, after the unmodulated carrier’s emission spectrum is captured on the spectrum analyzer, the reference plot shall be referenced to 0dB . Hence, the highest point on the plot has been reference to 0dB of the transmit power. Hence, emission Mask D calculation is correct. The test method has been revised in Ex07 test procedure. 6. Please clarify why the default frequency of the radio, 136 MHz, according to your 9/24 reply, is not a channel authorized for this radio (a Part 87 Aviation channel). A5. 136 MHz is also used by the Federal Government and is a default test frequency, which is used for manufacturing purposes only. When an order is placed, only authorized frequencies, based on the customer’s FCC License, will be programmed into the radio. If you require any additional information, please contact me at (954) 723-5793 (Phone). Sincerely, Mike Ramnath (signed above) Manager, Regulatory Compliance Email: [email protected] EXHIBIT 13

FCC ID: AZ492FT3826 __________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. October 30 th , 2012 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Att: JC Chen Subject: Response to second Correspondence 42819 for FCC ID: AZ492FT3826, EA596340 Hello Mr. Chen, Please see below for our responses: Q1. Please indicate which subparts under Part 22 and Part 74 that the EUT is seeking certification. This information would allow me to evaluate the EUT against all applicable rule sections. Alternatively, you may request to remove Part 22 and Part 74 authorization in this application. (AZ4489FT3829 and AZ4489FT3829 are only certified for Part 80 and Part 90.) As pointed out in KDB 634817, it is acceptable to list extended frequency outside each rule part listed. That is, even if you just certify for Part 90 (or Part 80), it is acceptable to list 136-174 MHz if the conditions in KDB 634817 are met. R1. Rule Part 22.561 (Mobile Operations) and 22.725 (Conventional Rural Radio Telephone Stations) are the two Rule Parts applicable to this application. For Rule Part 74 Sub-part H which is for Low Power Auxiliary Stations. The guidance given in KDB 634817 is stated in Exhibit 13c that Motorola Solutions acknowledge that it is a violation of the FCC Rules if this device operates on unauthorized frequencies. Hence, the justification for requesting 136-174 MHz be listed on the FCC Grant. Q2. The test report and extended frequency listing request letter should be consistent with the application. As of now, they both are confusing. The report contains data that are in three categories: 1) not for FCC, 2) not for Part 90, and 3) the rest. What should we be reviewing, for example, for Part 80 compliance? The extended frequency listing request letter has incorrect frequency ranges. Please either correct or remov…
