AZ492FT4895MOBILE 2-WAY RADIO

m APX7500 03 Mobile User Guide Front_Cover_03Head.fm Page 1 Tuesday, July 8, 2008 1:43 AM Front_Cover_03Head.fm Page 2 Tuesday, July 8, 2008 1:43 AM Declaration of Conformity English i Declaration of Conformity This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below. DECLARATION OF CONFORMITYPer FCC CFR 47 Part 2 Section 2.1077(a)Responsible Party Name: Motorola, Inc.Address: Motorola, Inc. 1301 E. Algonquin Rd.Schaumburg, IL60196-1078, U.S.A.Phone Number: 1-800-927-2744 Hereby declares that the product: Model Name: APX 7500 conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a) Class B Digital DeviceAs a personal computer peripheral, this device complies with Part 15 of the FC C Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Declaration of Conformity English ii Note: This equipment has been tested and found to comply with the li mits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provi de reasonable protection against harmful interference in a residential installation. This equipment generates, us es and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference wi ll not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit differ ent from that to which the receiver is connected. • Consult the dealer or an experienc ed radio/TV technician for help. Contents English iii ContentsThis User Guide contains all the information you need to use the APX ™ 7500 Series Digital Mobile Radios. Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . iImportant Safety Information . . . . . . . . . . . . . . . . . ix Product Safety and RF Exposure Compliance . . .ix Computer Software Copyrights . . . . . . . . . . . . . . . ix Documentation Copyrights . . . . . . . . . . . . . . . . . . . . xDisclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xGetting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 How to Use This User Guide . . . . . . . . . . . . . . . . . . 1Notations Used in This Manual . . . . . . . . . . . . . . . . . 1What Your Dealer/System Administrator Can Tell You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Preparing Your Radio for Use . . . . . . . . . . . . . . . . . . 2 Powering Up the Radio . . . . . . . . . . . . . . . . . . . . . . . 2Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . 3Adjusting the Display Brightness . . . . . . . . . . . . . . . 3 Identifying Radio Controls . . . . . . . . . . . . . . . . . . . . 4 Radio Control You Will Be Using . . . . . . . . . . . . . . . 4 O3 Control Head Display . . . . . . . . . . . . . . . . . . . . 4O3 Control Head . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Programmable Features . . . . . . . . . . . . . . . . . . . . . 6 Assignable Radio Functions . . . . . . . . . . . . . . . . . 6Assignable Settings/Utility Functions . . . . . . . . . . . 7 Accessing the Preprogrammed Functions . . . . . . . . 7 Accessing the Menu Entry Feat ures . . . . . . . . . . . 7 Using the Menu Select Buttons . . . . . . . . . . . . . . . 8Using the Navigation Buttons . . . . . . . . . . . . . . . . 9 Home Button . . . . . . . . . . . . . . . . . . . . . . . . . . 9APP Button (TMS Feature Button) . . . . . . . . . 9Use this button to access the Text Messaging Ser-vice (TMS) feature screen. 4-Way Navigation But-ton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Using the Rockers . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Volume Rocker . . . . . . . . . . . . . . . . . . . . . . . . . 9Mode Rocker . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10Push-To-Talk (PTT) Butto n . . . . . . . . . . . . . . . . . . 11 Identifying Status Indicators . . . . . . . . . . . . . . . . . . 11 Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11Text Messaging Service (TMS) Icons . . . . . . . . . . . 13 Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13TMS Menu Options . . . . . . . . . . . . . . . . . . . . . . . 15 Intelligence Lighting Indicators . . . . . . . . . . . . . . . . 16LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . 18Alert Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Contents English iv General Radio Operation . . . . . . . . . . . . . . . . . . . . 22 Selecting a Zone or Channel . . . . . . . . . . . . . . . . . 22 Selecting or Changing the Zone . . . . . . . . . . . . . 22Selecting or Changing a Mode in the Current Zone 23Selecting or Changing to a Channel Not in the Current Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23Selecting the Home Mode . . . . . . . . . . . . . . . . . . 23 Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Conventional Modes . . . . . . . . . . . . . . . . . . . . . . 23Trunked Modes . . . . . . . . . . . . . . . . . . . . . . . . . . 24Monitoring Conventional Channel Activity . . . . . 24 Receiving and Responding to a Radio Call . . . . . . 24 Receiving and Responding to a TalkGroup Call . 24 Receiving and Responding to an …

Text truncated - open the document above for the full version.

Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 2 SHEET 1 OF 1 Statement of Certification The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The following is a statement of my qualifications: 1) BEng University Technology Mara Malaysia 2) 1.5 years experience in the development, testing and certification of Land Mobile Communications Products NAME: Nur Azlan Abdul Malek SIGNATURE: /s/ Nurazlan (signed) DATE: 30 th June 2010 POSITION: Electrical Engineer I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: NAME: Peter Keh SIGNATURE: /s/ PeterKeh (signed) D DATE: 30 th June 2010 POSITION: Engineering Manager

FCC ID: AZ492FT4895 EXHIBIT 13A ______________________________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. 22 nd July 2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ492FT4895, APX7500. Gentlemen: Motorola Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida, herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a Mobile Transmitter environment with capabilities for clear and coded communications with a variable transmit power of 11-50 Watts in the frequency ranges of 136-174MHz and transmit power of 4-40 Watts in the frequency ranges of 380-470 MHz. We are requesting Certification under Part 22, 74, 80 and 90 of the Commission’s Rules to allow operation of this equipment in 136-174 MHz and Part 22, 74, and 90 of the Commission’s Rules to allow operation of this equipment in UHF Range 1 bands. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at (954) 723-5793. Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected]

FCC ID: AZ492FT4895 EXHIBIT 13B ______________________________________________________________________________ Motorola Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. Date: 12 th July 2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ492FT4895. Dear Sir or Madam: Motorola is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune-up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential”. Please contact me if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Manager, Regulatory Compliance Tel: (954) 723-5793 E-mail: [email protected]

FCC ID: AZ492FT4895 ______________________________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. 22 nd July 2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification. Gentlemen: The APX7500 Mobile 2-Way radio was designed to operate in the frequency bands 136-174 MHz and 380-470 MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Motorola is requesting that the FCC lists the frequencies 136-174 MHz and 380–470 MHz on the FCC Grant This radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, as indicated in the table below. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC-OET KDB Publication 634817guidance, the grantee acknowledges that devices operating on unauthorized frequencies are a violation of the FCC Rules. Frequency Range (MHz) Part 90 Part 22 Part 74 Part 80 Federal Grant Notes Emission Designator Rule Part 80 & 90 136-150.8 x EF, BE 8K10F1D/F1E/F1W, 11/16K0F3E, 20K0F1E 150.8-161.6250 x x x x EF, BE “”” 161.6250-161.7750* x EF, BE “”” 161.7750-173.4 x x EF, BE “”” 173.4-174 x EF, BE “”” 380-399.9 x EF, BE “”” 406.1-410 x x EF, BE “”” 410-420 x x EF, BE “”” 450-454 x x EF, BE “”” 454-455* x x EF, BE “”” 455-456* x EF, BE “”” 456-460 x x x EF, BE “”” 460-462.5375 x EF, BE “”” 462.7375-470 x EF, BE “”” * Canada FCC ID: AZ492FT4895 ______________________________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected] EXHIBIT 13c

Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 3 SHEET 1 OF 5 EXHIBIT 3 EXTERNAL PHOTOGRAPHS - Pursuant to 47 CFR 2.1033(c) 12 The following photographs are attached. 1. Front view (Controls) 2. Back view 3. Top view (FCC label location) 4. FCC label (Close view) 5. RF exposure label (Close view) 6. Bottom View 7. Side view (Left) 8. Side view (Right) 9. Top view with microphone and rear accessory cable Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 3 SHEET 2 OF 5 Front view (Controls) Back View Top View (FCC Label Location) Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 3 SHEET 3 OF 5 FCC Label (Close View) RF Exposure Label (Close View) Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 3 SHEET 4 OF 5 Bottom View Side View (Left) Side View (Right) Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 3 SHEET 5 OF 5 TOP VIEW WITH MICROPHONE AND REAR ACCESSORY CABLE Note : 1. Cables from the connector are wrapped and placed on the radio. 2. RF exposure label placed at the end of the Microphone cable.

Applicant: Motorola FCC ID: AZ492FT4895 Identification Label LOCATION See the Attached Photograph or Sketch X Top of Radio Back of Radio Back of Radio under Belt Clip TYPE X The label is a polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with the minimum peel strength of 32 oz/inch. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3-5 for the actual location of the FCC label on the device. Label Attached Below. See Attached Drawing. Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 1 Applicant: Motorola FCC ID: AZ492FT4895 General Information I. Production Plans -- Pursuant 2.1033 (c) Quantity production is planned. II. Application References -- Pursuant 2.1061 Reference is made to the following Motorola "Application References" 1. Mobile Products and their application. 2. Mobile Products Transmitter Modulations Methods. 3. Plantation, Florida Antenna Range. III. Data Submittal Procedure: Data is supplied in accordance with Part 2, Sub-part J of the Commissions’ rules. Necessary Bandwidth Computation for 8K10F1D, 8K10F1E and 8K10F1W Emission Designators The FCC Rule & Regulations Part 2, §2.202(b) defines Necessary Bandwidth as the minimum value of the occupied bandwidth sufficient to ensure that transmission of information at the rate and with the quality required for the system employed. §2.202(c) lists four methods of determining the necessary bandwidth, including the use of formulas in §2.202(g), and measurement in cases where the other methods of §2.202(c) do not apply. It is felt that while these formulas apply well to voice and many older digital modulation systems, the formulas do not apply to the high performance digital modulation employed in the system submitted for Certification because of difficulties determining representative values for the factors K and M. We have, therefore, used the measurement criteria of §2.202(c) (4). The value cited, 8K10, is the bandwidth that contains 99% of the total transmitted power. The 99% value was chosen because §2.202(b) defines Necessary Bandwidth as the minimum value of the occupied bandwidth. In turn, §2.202(b) defines Occupied Bandwidth as the frequency bandwidth such that, below its lower and above its upper frequency limits, the mean powers radiated are each equal to 0.5% of the total mean power radiated by a given emission, i.e., contains 99% of the total transmitted power. IV. Applicable References: • Reference Certification FCC ID: AZ492FT3824 • TIA-102.CAAA Digital C4FM/CQPSK Transceiver Measurement Methods • TIA/EIA-102.CAAB Land Mobile Radio Transceiver Recommendations, Project 25 – Digital Radio Technology, C4FM/ CQPSK Modulation • EIA/TIA-603A Land Mobile FM or PM Communications Equipment Measurement and Performance Standards • FCC Code of Federal Regulations Rule Part 2 and 90. EXHIBIT 1A

Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 9 SHEET 1 OF 6 Internal Photographs The following photographs are attached. Exhibit 1. RF board with Shields (Top). 9A 2. RF board without Shields (Top). 9B 3. RF board with Shields (Bottom). 9C 4. RF board without Shields (Bottom). 9D 5. Controller board with Shields (Top). 9E 6. Controller board with Shields (Bottom). 9F 7. Controller board without Shields (Bottom). 9G Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 9 SHEET 2 OF 6 EXHIBIT 9A RF board with Shields (Top) EXHIBIT 9B Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 9 SHEET 3 OF 6 RF board without Shields (Top) EXHIBIT 9C Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 9 SHEET 4 OF 6 RF board with Shields (Bottom) Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 9 SHEET 5 OF 6 EXHIBIT 9D RF board with Shields (Bottom) EXHIBIT 9E Controller board with Shields (Top) EXHIBIT 9F Applicant: Motorola FCC ID: AZ492FT4895 EXHIBIT 9 SHEET 6 OF 6 Controller board with Shields (Bottom) EXHIBIT 9E Controller board without Shields (Bottom)

English Product Safety and RF Energy Exposure Booklet for Mobile Two-Way Radios Installed in Vehicles or as Fixed Site Control Stations ATTENTION! The information provided in this document supersedes the general safety information contained in user guides published prior to February 2002. BEFORE USING THIS RADIO, READ THIS BOOKLET WHICH CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL INFORMATION FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND INTERNATIONAL STANDARDS. © Motorola, Inc. 2005 8000 W. Sunrise Blvd., Ft. Lauderdale, FL 33322 *6881095C99* 68P81095C99-E 2 English RF Energy Exposure Awareness and Control Information, and Operational Instructions for FCC Occupational Use Requirements NOTICE: This radio is intended for use in occupational/controlled conditions, where users have full knowledge of their exposure and can exercise control over their exposure to meet FCC limits. This radio device is NOT authorized for general population, consumer, or any other use. This 2-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. It uses radio frequency (RF) energy or radio waves to send and receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to, sunlight and x-rays. RF energy, however, should not be confused with these other forms of electromagnetic energy, which when used improperly, can cause biological damage. Very high levels of x-rays, for example, can damage tissues and genetic material. Experts in science, engineering, medicine, health, and industry work with organizations to develop standards for safe exposure to RF energy. These standards provide recommended levels of RF exposure for both workers and the general public. These recommended RF exposure levels include substantial margins of protection. All Motorola 2-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In addition, manufacturers also recommend specific operating instructions to users of 2-way radios. These instructions are important because they inform users about RF energy exposure and provide simple procedures on how to control it. 3 English Please refer to the following Web sites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits. http://www.fcc.gov/oet/rfsafety/rf-faqs.html http://www.osha.gov/SLTC/radiofrequencyradiation/index.html Federal Communication Commission Regulations The FCC rules require manufacturers to comply with the FCC RF energy exposure limits for mobile 2-way radios before they can be marketed in the U.S. When 2-way radios are used as a consequence of employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure awareness can be facilitated by the use of a label directing users to specific user awareness information. Your Motorola 2-way radio has a RF exposure product label. Also, your Motorola user manual, or separate safety booklet, includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Compliance with RF Exposure Standard Your Motorola two-way radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at duty factors of up to 50% talk-50% listen and is authorized by the FCC for occupational use. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio antenna radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. 4 English Your Motorola two-way radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation - Human Exposure) Standard, 2003 • ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001) “additional requirements for SMR, cellular, and PCS product certification.” RF Exposure Compliance and Control Guidelines and Operating Instructions To control exposure to yourself and others and to ensure compliance with the RF exposure limits, always adhere to the following procedures. Guidelines: • User awareness instructions should accompany device when transferred to other users. • Do not use this device if the operational requirements described herein are not met. Instructions: •Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the Push-To-Talk (PTT) button or, for radios equipped with VOX, speak into the microphone. The red LED will illuminate when the radio is 5 English transmitting. To receive calls, release the PTT button, or, for radios equipped with VOX, stop talking. The red LED will extinguish when the radio stops transmitting. Transmitting 50% of the time, or less, is important because this radio generates measurable RF energy exposure only when transmitting (in terms of measuring for standards compliance). •Transmit only when people outside the vehicle are at l…
