AZ492FT4898Mobile 2-way Radio

APX 7500 User Guide O9 Control Head 68007024014-A English mASTRO ® APX™ 7500 Series Digital Mobile RadiosQuick Reference Card Product Safety and RF Exposure Compliance ATTENTION! This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C98) to ensure compliance with RF energy exposure limits. Radio On/OffAdjusting VolumeSelecting a Zone Selecting a ChannelRadio Controls Receiving and Transmitting Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio. Press the Power On/Off button to toggle the power on or off. Turn the Volume knob clockwise to increase volume or counterclockwise to decrease the volume. 1 > or < to Zone . Press the Menu Select button directly under the Zone . 2 U or D button until the desired zone is displayed. 3 Press the Menu Select button directly below Select to confirm the displayed zone. 4 Press the PTT button to begin transmitting on the displayed zone channel. !  1 > or < to Channel . Press the Menu Select button directly under the Channel . 2 U or D button until the desired channel is displayed. 3 Press the Menu Select button directly below Select to confirm the selected channel. 4 Press the PTT button to begin transmitting on the displayed zone channel. 1 Turn the Mode Knob to scroll to the required channel. 2 Press PTT button to transmit on the selected zone channel. 5 4 1 2 3 6789 11 10 12 13 14 15 16 17 18 Siren Control ButtonsProgrammable Buttons (Top)Response SelectorDirectional ButtonsOrange ButtonPublic Address ButtonKeypadData Feature ButtonMode Knob4-Way Navigation ButtonHome ButtonSatus IconsProgrammable Buttons (Bottom)Menu Select ButtonsVolume KnobDisplay Backlight Control ButtonsLED IndicatorsPower On/Off Button 1 Take the microphone off hook. 2 Select zone/channel. 3 Listen for a transmission.ORTurn the Volume Knob . OR> or < to Monitor then press the Menu Select button directly below Monitor and listen for activity. 4 Adjust volume, if necessary. 5 Press the PTT button to transmit; release to receive. 12 3 456789 10 11 12131415161718 *68007024034* 68007024034-A © 2010 by Motorola, Inc. All Rights Reserved. 05/101301 E. Algonquin Rd., Schaumburg,IL 60196-1078, U.S.A. English Sending an Emergency Alarm To exit emergency at any time, press and hold the Emergency button. Sending an Emergency Call (Trunking Only) To exit emergency at any time, press and hold the Emergency button. Sending a Silent Emergency Alarm If silent emergency alarm is used with emergency call, pressing the PTT button exits the silent mode and initiates the emergency call. Display Status Icons 1 Press the Emergency button. A tone sounds and the display shows EMERGENCY and the current zone or channel. 2 A dispatcher acknowledgment ACK RECEIVED display follows. AND, Trunking Only:A high-pitched tone indicates that the alarm has been received by the trunked system’s central controller. 3 Press and hold the emergency button or the PTT button to return to normal operation. 1 Press the Emergency button. 1 A tone sounds and the display shows EMERGENCY and the current zone or channel. ORA talk prohibited tone sounds when the selected channel does not support emergency. 2 Press and hold the PTT button. Speak clearly into the microphone. 3 Release the PTT to end the transmission. 1 Press the Emergency button to activate the silent alarm feature. 2 The display does not change; the LED does not light up, and there is no tone. Receiving a call or dataTransmitting a call or dataReceived an Individual Call.The more stripes, the stronger the signal strength for the current site (trunking only).Direct radio to radio communication or connected through a repeater.On = Direct Off = Repeater This channel is being monitored.Voice muting the affiliated trunking talkgroup or selected conventional channel.On = Enabled Off = Disabled L = Radio is set at Low power. H = Radio is set at High power. Scanning a scan list.Blinking dot = Detects activity on the Priority-One Channel during scan. Steady dot = Detects activity on the Priority-Two Channel during scan. F O M K H OR . i Radio is in the view or program mode.On steady = View mode. Blinking = Program mode. The vote scan feature is enabled.On = Secure operation. Off = Clear operation. Blinking = Receiving an encrypted voice call. On = AES Secure operation. Off = Clear operation. Blinking = Receiving an encrypted voice call. On = Location feature enabled, and location signal available. Off = Location feature disabled. Blinking = Location feature enabled, but location signal unavailable. On = User is currently associated with the radio. Off = User is currently not associated with the radio. Blinking = Device registration or user registration with the server failed due to an invalid username or pin. Data activity is present.Indicates that the text entry is currently in hexadecimal mode.Alternates between red and blue when the lightbar is on. k m l G no Menu Navigation < or > to Menu Entry. - directly below Menu Entry to select. U or D to scroll through sub-list. - directly below Menu Entry to select. H to exit. Declaration of Conformity English i Declaration of Conformity This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below. DECLARATION OF CONFORMITYPer FCC CFR 47 Part 2 Section 2.1077(a)Responsible Party Name: Motorola, Inc.Address: 1301 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A.Phone Number: 1-800-927-2744Hereby declares that the product: Model Name: APX 7500 conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a) Class B Digital DeviceAs a personal computer peripheral, this device compli…

Text truncated - open the document above for the full version.

English Product Safety and RF Energy Exposure Booklet for Mobile Two-Way Radios Installed in Vehicles or as Fixed Site Control Stations ATTENTION! The information provided in this document supersedes the general safety information contained in user guides published prior to February 2002. BEFORE USING THIS RADIO, READ THIS BOOKLET WHICH CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL INFORMATION FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND INTERNATIONAL STANDARDS. © Motorola, Inc. 2005 8000 W. Sunrise Blvd., Ft. Lauderdale, FL 33322 *6881095C99* 68P81095C99-E 2 English RF Energy Exposure Awareness and Control Information, and Operational Instructions for FCC Occupational Use Requirements NOTICE: This radio is intended for use in occupational/controlled conditions, where users have full knowledge of their exposure and can exercise control over their exposure to meet FCC limits. This radio device is NOT authorized for general population, consumer, or any other use. This 2-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. It uses radio frequency (RF) energy or radio waves to send and receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to, sunlight and x-rays. RF energy, however, should not be confused with these other forms of electromagnetic energy, which when used improperly, can cause biological damage. Very high levels of x-rays, for example, can damage tissues and genetic material. Experts in science, engineering, medicine, health, and industry work with organizations to develop standards for safe exposure to RF energy. These standards provide recommended levels of RF exposure for both workers and the general public. These recommended RF exposure levels include substantial margins of protection. All Motorola 2-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In addition, manufacturers also recommend specific operating instructions to users of 2-way radios. These instructions are important because they inform users about RF energy exposure and provide simple procedures on how to control it. 3 English Please refer to the following Web sites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits. http://www.fcc.gov/oet/rfsafety/rf-faqs.html http://www.osha.gov/SLTC/radiofrequencyradiation/index.html Federal Communication Commission Regulations The FCC rules require manufacturers to comply with the FCC RF energy exposure limits for mobile 2-way radios before they can be marketed in the U.S. When 2-way radios are used as a consequence of employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure awareness can be facilitated by the use of a label directing users to specific user awareness information. Your Motorola 2-way radio has a RF exposure product label. Also, your Motorola user manual, or separate safety booklet, includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Compliance with RF Exposure Standard Your Motorola two-way radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at duty factors of up to 50% talk-50% listen and is authorized by the FCC for occupational use. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio antenna radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. 4 English Your Motorola two-way radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation - Human Exposure) Standard, 2003 • ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001) “additional requirements for SMR, cellular, and PCS product certification.” RF Exposure Compliance and Control Guidelines and Operating Instructions To control exposure to yourself and others and to ensure compliance with the RF exposure limits, always adhere to the following procedures. Guidelines: • User awareness instructions should accompany device when transferred to other users. • Do not use this device if the operational requirements described herein are not met. Instructions: •Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the Push-To-Talk (PTT) button or, for radios equipped with VOX, speak into the microphone. The red LED will illuminate when the radio is 5 English transmitting. To receive calls, release the PTT button, or, for radios equipped with VOX, stop talking. The red LED will extinguish when the radio stops transmitting. Transmitting 50% of the time, or less, is important because this radio generates measurable RF energy exposure only when transmitting (in terms of measuring for standards compliance). •Transmit only when people outside the vehicle are at l…

Text truncated - open the document above for the full version.

MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 2 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The following is a statement of my qualifications: 1) MSEE University of South Florida 2) 11.5 years experience in the development, testing and certification of Land Mobile Communications Products NAME: Anbuselvan Kuppusamy DATE: 09 August 2010 POSITION: Senior Staff Electrical Engineer I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: NAME: Michael Lenzen DATE: 09 August 2010 POSITION: Engineering Manager

FCC ID: AZ492FT4898 EXHIBIT 13A ______________________________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. 17 th August 2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ492FT4898, APX7500. Gentlemen: Motorola Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida, herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a Mobile Transmitter environment with capabilities for clear and coded communications with a variable transmit power of 25-100 Watts in the frequency ranges of 136-174MHz and 380-470 MHz. We are requesting Certification under Part 22, 74, 80 and 90 of the Commission’s Rules to allow operation of this equipment in 136-174 MHz and Part 22, 74, and 90 of the Commission’s Rules to allow operation of this equipment in UHF Range 1 bands. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at (954) 723-5793. Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected]

FCC ID: AZ492FT4898 EXHIBIT 13B ______________________________________________________________________________ Motorola Inc. 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. Date: 17 th August 2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ492FT4898. Dear Sir or Madam: Motorola is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune-up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential”. Please contact me if you require any additional information. Sincerely, /s/ Mike Ramnath (signed) Manager, Regulatory Compliance Tel: (954) 723-5793 E-mail: [email protected]

FCC ID: AZ492FT4898 ______________________________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. 17th August 2010 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification. Gentlemen: The APX7500 Mobile 2-Way radio was designed to operate in the frequency bands 136-174 MHz and 380-470 MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Motorola is requesting that the FCC lists the frequencies 136-174 MHz and 380–470 MHz on the FCC Grant This radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, as indicated in the table below. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC-OET KDB Publication 634817guidance, the grantee acknowledges that devices operating on unauthorized frequencies are a violation of the FCC Rules. Frequency Range (MHz) Part 90 Part 22 Part 74 Part 80 Federal Grant Notes Emission Designator Rule Part 80 & 90 136-150.8 x EF, BE 8K10F1D/F1E/F1W, 11/16K0F3E, 20K0F1E 150.8-161.6250 x x x x EF, BE “”” 161.6250-161.7750* x EF, BE “”” 161.7750-173.4 x x EF, BE “”” 173.4-174 x EF, BE “”” 380-399.9 x EF, BE “”” 406.1-410 x x EF, BE “”” 410-420 x x EF, BE “”” 450-454 x x EF, BE “”” 454-455* x x EF, BE “”” 455-456* x EF, BE “”” 456-460 x x x EF, BE “”” 460-462.5375 x EF, BE “”” 462.7375-470 x EF, BE “”” * Canada FCC ID: AZ492FT4898 ______________________________________________________________________________ 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322. Sincerely, /s/ Mike Ramnath (signed) Mike Ramnath Manager, Regulatory Compliance Email: [email protected] EXHIBIT 13c

8000 West Sunrise Blvd. Plantation. Fl 33322 Page 1 7 th October 2011 Tim Harrington Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Re: Form 731 Confirmation Number: EA697932 with FCC ID: AZ492FT4898 Dear Mr. Harrington; Motorola Inc., 8000 West Sunrise Boulevard, Fort Lauderdale, Florida, herein submits its response to the 22 rd September 2010 for information in Correspondence Number 39169. Q1). op. desc. mentions 2.1061 - that rule section does not exist; please revise/explain this AND ALL FUTURE FILINGS please also ensure ALL rules cites across ALL exhibits are valid and up to date R1). Rule Part 2.1061 removed for Exhibit 12. See attached for amended exhibit. Q2) op. desc. mentions fccids AZ489FT7035, AZ492FT3821 and AZ492FT4897 - unclear why; please revise/explain. R2). FCC ID: AZ489FT7035, AZ492FT3821 and AZ492FT4897 were noted for reference purposes but are now deleted from Exhibit 12. See attached for amended exhibit. Q3). op. desc. mentions 90.539 and 90.543, which are part 90 subpart S 700-band - please revise/explain how applicable this and ALL related exhibits where applicable. R3). Rule Parts 90.539 and 90.543 are deleted. See attached for amended exhibit. Q4). op. desc. has "Part 47 Sec. 2.1033 – 2.1055" - please correct here AND ALL FUTURE FILINGS R4). Part 47 Sec. 2.1033 – 2.1055 is replaced with 47 CFR, Rule Parts 2.1033 – 2.1055. See attached for amended exhibit. Q5). op. desc. states model number "M30TXS9PW1AN" but RFx exhibit at multiple occurrences across two parts (UHF part 1, VHF part 2) states different model numbers "M30QTS9PW1AN", "M30KTS9PW1AN" a) please revise/explain for ALL related exhibits accordingly, for consistency across filing b) please 8000 West Sunrise Blvd. Plantation. Fl 33322 Page 2 explain/demonstrate compliance with 2.908 and 2.931, in case that tested "models" have hardware differences relative to "model" applying for certification R5). Exhibit 12 reflects only the model number tested which is M30TXS9PW1AN. Model numbers, M30KTS9PW1AN & M30QTS9PW1AN, are identical in terms of layout, components and transmitter performances - such as RF Output Power and Impedance. There is negligible difference in RF Exposure performance between M30TXS9PW1AN and the two referenced model numbers. Therefore, the data from the two models were used to supplement the RFx report to show FCC compliance. M30KTS9PW1AN and M30QTS9PW1AN model numbers satisfies the requirements of Rule Part 2.908 and 2.931. Q6). RFx part 2 at page 3 has fccid "AZ492FT3821" - please revise/explain R6). The RFx report was revised and “AZ492FT3821” was removed. Q7). RFx part 1 pg 4 has "Refer to previous MPE reports for additional offered antennas" - please revise/explain to have stand-alone self-contained evaluation report R7). Report was revised. Original wording was replaced with “NA”. Q8). at Appdx A lower figure, please revise/explain two "blue" dots at center of trunk lid (one is expected), i.e. is that two antenna mounting positions and if yes what purposes / uses, or what are those R8). There are two blue dots in the lower figure of appendix A. The blue dot on the right is denoted as #2 to identify the center of the trunk for bystander measurements. The blue dot on the left is denoted as #3 to identify the location of the antenna for the passenger. The antenna location for the passenger is slightly offset from the center of the trunk in the direction of the backseat passenger. The distance between the antenna and backseat passenger (85cm) is illustrated in appendix A and is included in section 6.1.2. Q9). although past applications with similar devices and evaluation methods had considered some text adjustments for disambiguation and self-consistency purposes, please adjust text in 6.1.1 of RFx part 1 as follows or similar for 1st & 3rd para. change from: "MPE measurements for bystander conditions are determined by taking the average of (10) measurements in a 2m vertical line for each of the (3) test locations indicated in appendix A with 20cm increments at the test distance of 90cm from the antenna under test. ... For the current test vehicle, 90cm (directly behind vehicle), 104 cm (45 degree radial) and 110.5 cm (90 degree radial)." to: MPE measurements for bystander conditions are determined by taking the average of (10) measurements in a 2 m vertical line for each of the (3) bystander test locations indicated in Appendix A with 20 cm height increments, with antenna to probe sensor separation distances of 90 cm (directly behind vehicle), 104 cm (45 degree radial) and 110.5 cm (90 degree radial). ... similar remarks may apply for RFx "Part 2" (may have different subclause numbering) 8000 West Sunrise Blvd. Plantation. Fl 33322 Page 3 R9). The RFx report was revised. Referenced paragraph 1 was changed per feedback and therefore paragraph 3 was deleted. Part 2 of 2 of the RFx report was also revised accordingly. Q10). concerning following from 6.1.1 of RFx part 1: "Note: The distance from the trunk-mounted antenna to the edge of the vehicle is 42cm and the distance from the edge of the vehicle’s trunk to the Survey Probe Sensor is 48cm." this is somewhat ambiguous due to Appdx A lower figure appears to show same "breakpoint" (into 42 + 48 dim. lines) of the 90cm distance for what in text seems to be called two different things, i.e. "edge of the vehicle" (unclear whether encompasses bumper protrusion and/or other styling curved structures etc) vs. "edge of the vehicle's trunk" we prefer "edge of the vehicle's trunk" if that will provide tangible identifiable reference point - please confirm distance(s) and/or revise text and figure accordingly R10). The RFx report was revised. The note now states the following; “Note: The distance from the centered trunk-mounted antenna to the edge of the vehicle is 42cm and the distance from the edge of the vehicle to the survey probe sensor is 48cm.” Appendix A was also revi…

Text truncated - open the document above for the full version.

MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-1 EXTERNAL PHOTOGRAPHS The following photographs are attached. 1. Front view (Controls) 2. Back view 3. Top view (FCC label location) 4. FCC label (Close view) 5. RF exposure label (Close view) 6. Bottom View 7. Side view (Left) 8. Side view (Right) 9. Top view with microphone, control head and cables MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-2 FRONT VIEW (CONTROLS) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-3 BACK VIEW MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-4 TOP VIEW (FCC LABEL LOCATION) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-5 FCC LABEL (CLOSE VIEW) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-6 RF EXPOSURE LABEL (CLOSE VIEW) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-7 BOTTOM VIEW MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-8 SIDEVIEW (LEFT) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-9 SIDE VIEW (RIGHT) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 3-10 TOP VIEW WITH MICROPHONE, CONTROL HEAD AND CABLES Note : 1. Cables from the connector are wrapped and placed on the radio. 2. RF exposure label placed at the end of the Microphone cable.

MOTOROLA FCC ID: AZ492FT4898 IDENTIFICATION LABEL LOCATION See the Attached Photograph or Sketch X Bottom of Radio Top of Radio Back of Radio Back of Radio under Belt Clip TYPE X The label is a polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with the minimum peel strength of 32 oz/inch. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3-5 for the actual location of the FCC label on the device. X Label Attached Below. See Attached Drawing. EXHIBIT 1 MOTOROLA FCC ID: AZ492FT4898 RF EXPOSURE LABEL LOCATION See the Attached Photograph or Sketch X On Microphones Cord Back Of Radio under Belt Clip MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3 for the actual location of the RF Exposure Label on Microphones Cord. X Label Attached Below. See Attached Drawing. EXHIBIT 1A

MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 9-1 INTERNAL PHOTOGRAPHS The following photographs are attached. 1. RF board (Top view) 2. RF board (Bottom view) 3. Controller board (Top view) 4. Controller board (Bottom view) 5. RF board, less shields (Top view) 6. RF board, less shield (Bottom view) 7. Controller board, less shield (Bottom view) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 9-2 RF BOARD (TOP VIEW) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 9-3 RF BOARD (BOTTOM VIEW) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 9-4 CONTROLLER BOARD (TOP VIEW) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 9-5 CONTROLLER BOARD (BOTTOM VIEW) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 9-6 RF BOARD, LESS SHIELD (TOP VIEW) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 9-7 RF BOARD, LESS SHIELD (BOTTOM VIEW) MOTOROLA FCC ID: AZ492FT4898 EXHIBIT 9-8 CONTROLLER BOARD, LESS SHIELD (BOTTOM VIEW)

SR 8428 EMS EME Form-SAR-Rpt Ex7B-Rev. 7.00 Page 1 of 2 TESTING CERT # 2518.01 Exhibit 7B: MPE Test Report Photographs Enterprise Mobility Solutions EME Test Laboratory 8000 West Sunrise Blvd. Fort Lauderdale, FL. 33322 Signature on file – Deanna Zakharia Deanna Zakharia EMS EME Lab Senior Resource Manager, Laboratory Director Approval Date: 8/13/2010 SR 8428 EMS EME Form-SAR-Rpt Ex7B-Rev. 7.00 Page 2 of 2 1.0 Antenna Photographs for UHF band: Antenna kit numbers, from left to right; HAE6010A, HAE6011A, HAE4011A, RAE4014ARB, HAE6013A, HAE6031A, HAE6012A & HAE4003A SR 8428 EMS EME Form-SAR-Rpt Ex7B-Rev. 7.00 Page 3 of 2 2.0 Antenna Photographs for VHF band: Antenna kit numbers, from left to right; RAD4010ARB (136MHz), RAD4010ARB (150MHz), RAD4010ARB (174MHz), HAD4016A, HAD4017A, HAD4021A, HAD4006A, HAD4007A, HAD4008A, HAD4009A

SR8428 Form-MPE Vehicle rpt. Rev 6.00 Page 1 of 23 TESTING CERT # 2518.01 DECLARATION OF COMPLIANCE: MPE ASSESSMENT Part 1 of 2 Enterprise Mobility Solutions EME Test Laboratory 8000 West Sunrise Blvd Fort Lauderdale, FL. 33322 Date of Report: August 12, 2010 Report Revision: O Report ID: SR8428_MPE rpt_APX7500_UHFR1_100W and VHF_100W Mobile_Rev O_100812 Responsible Engineer: Stephen C. Whalen (Principal Staff EME Test Engineer) Report author: Kim Uong ((Principal Staff EME Test Engineer) Date/s Tested: 5/26/2010, 6/2/2010 & 6/3/2010; 6/25/2010; 7/14/2010 (UHF); 4/28/08-6/5/08 (VHF) Manufacturer/Location: Motorola, Schaumburg, IL Date submitted for test: 6/02/2010 DUT Description: APX7500 Dual Band UHF R1 100W, 380 - 470 MHz And VHF 100W, 136-174MHz Test TX mode(s): CW Max. Power output: 120 Watts TX Frequency Bands: 380-470MHz & 136-174MHz Signaling type: Analog, APCO 25, and TDMA 1:2 (F2) Model(s) Tested M30QTS9PW1AN (UHF), M30KTS9PW1AN (VHF) Model(s) Certified: M30TXS9PW1AN Serial Number(s): 123ABC4567 ( M30QTS9PW1AN), 83 ( M30KTS9PW1AN) Classification: Occupational/Controlled Environment Regulatory Identifications: FCC ID: AZ492FT4898 – Part 22 & 90 (406.1-470 MHz & 150.8-173.4MHz), MPE results outside of Part 90 are not applicable for FCC compliance demonstration. Approved Accessories: Antenna(s): Antennas for UHF Antennas for VHF HAE4003A (Vehicular Roof Mount, 450-470 MHz, ¼ Wave, 2.15dBi) HAD4006A (Roof Mount 136 - 144 MHz, 1/4 Wave, 2.15dBi) HAE6012A (Vehicular Roof Mount, 380-433 MHz, ¼ Wave, 2.15dBi) HAD4007A (Roof Mount 144-150.8 MHz, 1/4 Wave, 2.15dBi) HAE4011A (Vehicular Mount, 450-470 MHz, ½ Wave, 5.65dBi) HAD4008A (Roof Mount 150.8-162 MHz, 1/4 Wave, 2.15dBi) HAE6010A (Vehicular Mount, 380-433 MHz, ½ Wave, 5.65dBi) HAD4009A (Roof Mount 162 - 174 MHz, 1/4 Wave, 2.15dBi) HAE6013A (Vehicular Mount, 380-470 MHz, ½ Wave, 4.15dBi) RAD4010ARB (Thru-hole Mount 136 - 174 MHz, 1/2 Wave, 5.15dBi) HAE6031A (Vehicular Mount, 380-520 MHz, ½ Wave, 4.15dBi) HAD4016A (Roof Mount 136 - 162 MHz, 1/4 Wave, 2.15dBi) HAE6011A (Vehicular Roof Mount, 380-433 MHz, 5/8 Wave, 7.15dBi) HAD4017A (Roof Mount 146 - 174 MHz, 1/4 Wave, 2.15dBi) RAE4014ARB (Vehicular Mount, 445-470 MHz, 5/8 Wave, 7.15dBi) HAD4021A (Roof Mount 136 - 174 MHz, 1/4 Wave, 2.15dBi) Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 4.0 of this report. This report shall not be reproduced without written approval from an officially designated representative of the Motorola EME Laboratory. I attest to the accuracy of the data and assume full responsibility for the completeness of these measurements. This reporting format is consistent with the suggested guidelines of the TIA TSB-159 April 2006 The results and statements contained in this report pertain only to the device(s) evaluated herein. Signature on file – Deanna Zakharia Deanna Za…

Text truncated - open the document above for the full version.
