AZ492FT7127WAVE Two-Way Mobile Radio

TLK 150 User Guide WAVE ™ TWO-WAY RADIO *MN006371A01* MN006371A01-AA MARCH 2020 © 2020 Motorola Solutions, Inc. All rights reserved Contents Chapter 1: Read Me First............................................................................................5 Chapter 2: Feature and Service Availability.............................................................6 Chapter 3: Software Version......................................................................................7 Chapter 4: Radio Care................................................................................................8 Chapter 5: Radio Overview........................................................................................9 Programmable Buttons ................................................................................................................10 Assignable Radio Functions............................................................................................. 10 Chapter 6: Getting Started........................................................................................11 Turning the Radio On or Off........................................................................................................ 11 Turning the Radio On........................................................................................................11 Turning the Radio Off........................................................................................................11 Resetting the Radio.....................................................................................................................11 Adjusting the Volume ..................................................................................................................11 Chapter 7: Status Indicators....................................................................................12 Display Icons............................................................................................................................... 12 LED Indications ...........................................................................................................................13 Chapter 8: Fast Scroll Talkgroup List.....................................................................14 Chapter 9: Selecting Talkgroup ..............................................................................15 Chapter 10: Radio Calls ...........................................................................................16 Making Calls on the Radio...........................................................................................................16 Receiving and Responding to Calls on the Radio....................................................................... 16 Chapter 11: Supervisory Override...........................................................................17 Chapter 12: Checking Radio Information................................................................18 Chapter 13: Bluetooth...............................................................................................19 Turning the Bluetooth On or Off...................................................................................................19 Turning the Bluetooth On..................................................................................................19 Turning the Bluetooth Off..................................................................................................19 Viewing Bluetooth Connectivity Status........................................................................................19 Clearing Bluetooth Pairing...........................................................................................................20 Chapter 14: Contact List...........................................................................................21 Accessing Contact List................................................................................................................ 21 Chapter 15: Menu......................................................................................................22 Turning the All Alert Tones On or Off..........................................................................................22 Turning the All Alert Tones On..........................................................................................22 MN006371A01-AA Contents 2 Turning the All Alert Tones Off..........................................................................................22 Adjusting Display Brightness.......................................................................................................23 Turning the Voice Announcement On or Off ................................................................................23 Turning the Voice Announcement On...............................................................................23 Turning the Voice Announcement Off...............................................................................23 Turning the DND On or Off..........................................................................................................23 Turning the DND On.........................................................................................................23 Turning the DND Off.........................................................................................................23 Turning the Scan On or Off..........................................................................................................24 Turning the Scan On.........................................................................................................24 Turning the Scan Off.........................................................................................................24 Turning the Location On or Off....................................................................................................24 Turning the Location On...............................................................…

Text truncated - open the document above for the full version.

RF Energy ExposureTraining and Product Safety Information for TLK 150 Devices en-US ja-JP TLK 150 デバイスに関する RF エネルギー被爆トレーニングお よ び製品安全性情報 https://learning.motorolasolutions.com/User_Documentation English Caution Before using this device, read this booklet which contains important operating instructions. For information on product details, brochures, user manuals and approved accessories. Please refer to www.motorolasolutions.com. Compliance with RF Exposure Standards National and international regulations require manufacturers to comply with the RF energy exposure limits for the TLK 150 devices before they can be marketed. Your Motorola Solutions device is designed, manufactured, and tested to comply with all applicable national and international regulations for human exposure to radio frequency electromagnetic energy. RF Energy Exposure Awareness and Control Information and Operational Instructions for General Population and Uncontrolled Environment Use Notice: This device is intended for use in general population conditions where radio-frequency (RF) exposure meets the requirements in national and international regulations. For more information on what RF energy exposure is, consult the following websites: •https://www.fcc.gov/ •https://www.osha.gov/ •https://osha.europa.eu/en •http://www.who.int/peh-emf/project/en/ •http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf11467.html •http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01904.html For additional user training information on exposure requirements, consult the following websites: •https://www.motorolasolutions.com/en_us/about/company-overview/corporate- responsibility/governance-and-policies/wireless-communication-and-health- faqs.html •http://learning.motorolasolutions.com/ RF Exposure Compliance and Control Guidelines To control your exposure, and ensure compliance with the relevant RF exposure limits, always adhere to the following guidelines: English 1 • Do not remove any of the RF Exposure Labels if present from this device or its related accessories. •Attach these instructions to the device when you transfer it to other users. • Do not use this device if the operational requirements described herein are not met. Operating Instructions • The device operates on a vehicle with at least 20 cm distance between antennas and passengers or bystanders. • Transmit only when people (bystanders and/or passengers) are at least at the recommended minimum distance (as shown in Table 1) away from the installed antennas. This separation will ensure that there is sufficient distance from a properly installed (according to the installation instructions) antenna to satisfy the relevant RF exposure limits. • To ensure continued compliance with applicable RF exposure limits, use only Motorola Solutions approved, supplied or replacement antennas and accessories. • For a list of Motorola Solutions approved accessories please refer to your user manual or visit www.motorolasolutions.com Table 1: Rated Power of Vehicle-Installed TLK 150 Device and Recommended Minimum Distance from Antennas TLK 150 Device Rated PowerMinimum Distance of Bystanders from Antennas Less than 7 W8 in. (20 cm) Acoustic Safety To protect your hearing: •Use the lowest volume necessary to do your job. • Turn up the volume only if you are in noisy surroundings. • Turn down the volume before adding headset or earpiece. • Limit the amount of time you use headsets or earpieces at high volume. Mobile Antenna Installation Guidelines • Make sure to follow the antenna installation guidelines that are provided in this TLK 150 device installation manual. • Use only Motorola Solutions approved supplied antenna, or a Motorola Solutions approved replacement antenna. Unauthorized antennas, modifications, or English 2 attachments could damage the device and may result in non-compliance with RF Safety Standards. Vehicles To avoid possible interference between the device transmitter and any vehicle electronic control modules, such as ABS, engine, or transmission control modules, your TLK 150 device should be installed only by an experienced installer, using the following precautions when installing the device: 1 Refer to the manufacturer instructions or other technical bulletins for recommendations on TLK 150 device installation. 2 Before installing the TLK 150 device, determine the location of the vehicle electronic control modules and their harnesses within the vehicle. 3 Route all TLK 150 device wiring, including the antenna cable, as far away as possible from the electronic control units and associated harnesses. Notice to Users (FCC and Industry Canada) This device complies with Part 15 of the FCC rules and Industry Canada's license- exempt RSS's per the following conditions: •This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. • Changes or modifications made to this device, not expressly approved by Motorola Solutions, could void the authority of the user to operate this equipment. Operational Warnings The following explains the operational warnings: For Vehicle With Air Bags Warning: •Refer to vehicle manufacturer’s manual prior to installation of electronic equipment to avoid interference with air bag wiring. • DO NOT mount or place a mission critical device in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a mission critical device is placed in the air bag deployment area and the air bag inflates, the device may be propelled with great force and cause serious injury to occupants of the vehicle. English 3 Potentially Explosive Atmospheres Warning: •Use of a TLK 150 device that is not intrinsically safe in a potentially explosive atmosphere could result in a serious injury or death. You should only use a certified Intrinsically Safe device in potentially explosive atmospheres. • Explosive atmospheres refer to hazard classified locations tha…

Text truncated - open the document above for the full version.

Date: March 13, 2020 Declaration To whom it may concern, This is a WLAN/Bluetooth combination antenna with FCC ID: AZ492FT7127. This WLAN/Bluetooth co-existence mechanism is to ensure that the WLAN and Bluetooth transmitters would not simultaneously operate. Therefore, WLAN and Bluetooth antenna in FCC ID: AZ492FT7127 should not be considered to be able to transmit simultaneously. Though the users can use WLAN and Bluetooth simultaneously, but the real situation is that WLAN and Bluetooth are used by time sharing and no overlap transmission. Should you have any question, please have my best attention. Sincerely yours, Arine Lee FCC/IC Certification Manager E-mail : [email protected]

Date: March 13, 2020 Declaration We, Motorola Solutions, Inc., declare that the device, FCC ID: AZ492FT7127, does not support any non-US channels in all the operational mode(s) in the US market. All non-US frequencies, US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable. Should you have any question or comment regarding this matter, please do not hesitate to contact me. Sincerely yours, Arine Lee FCC/IC Certification Manager E-mail : [email protected]

Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 2 SHEET 1 OF 2 EXHIBIT 2 Statement of Certification (Pursuant to FCC Part 2.907 and 2.909) 2.1 Statement of Certification Transceiver type described herein (AZ492FT7127) is in compliance with all applicable parts of the FCC rules. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Feng Rong Hui SIGNATURE: DATE: 9 th March 2020 TITLE: Engineering Manager Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 2 SHEET 2 OF 2 2.2 Attestation Statement (Equipment Class DTS and DSS – Bluetooth/WiFi) This device contains an embedded Bluetooth device and WiFi device that are compliant with the applicable FCC Part 15C. Part 15.247 (a)(1) • The hopping sequence must be pseudo random. • Each frequency must be used equally on the average by each transmitter • The receivers input bandwidth is approximately equal to the transmit bandwidth • The receiver hops in sequence with the transmitted signal Part 15.247 (g) • The system is designed to comply with all of the regulations in this section when the transmitter is presented with a continuous data (or information) Part 15.247(h) • The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Yap Soon Leng SIGNATURE: DATE: 9 th March 2020 TITLE: Electrical Engineer

FCC ID: AZ492FT7127 ___________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia. EXHIBIT 13A Date: March 13, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: AZ492FT7127 Dear Sir/Madam, Motorola Solutions Malaysia Sdn Bhd herein submits application for Certification of the subject transmitter. This transmitter is intended for use in a Mobile radio application with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: Product Name Model Numbers Frequency Range RF Power FCC Rules Part TLK 150 HK2131A WCDMA B2: 1852.4-1907.6 MHz 418.8 mW (Max) 24E WCDMA B5: 826.4-846.6 MHz 224.4mW (Max) 22H LTE B2: 1860-1900 MHz 378.4 mW (Max) 24E LTE B4: 1720-1745 MHz 325.1 mW (Max) 27 LTE B5: 829-844 MHz 154.9 mW (Max) 22H LTE B7: 2510-2560 MHz 291.7 mW (Max) 27 LTE B13: 782 MHz 121.1 mW (Max) 27 LTE B17: 709-711 MHz 127.1 mW (Max) 27 Bluetooth: 2402-2480 MHz 10.1 mW (Max) 15C Bluetooth Low Energy: 2402-2480 MHz 1.0 mW (Max) 15C WLAN 802.11 b/g/n: 2410-2462MHz 129.1 mW (Max) 15C WLAN 802.11 a/n: 5180-5825 MHz 27.7 mW (Max) 15E A complete Certification application is enclosed. If you require any additional information, please contact me at +604 224 0258 Sincerely, Arine Lee FCC/IC Certification Manager E-mail : [email protected]

FCC ID: AZ492FT7127 ___________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia. EXHIBIT 13B CONFIDENTIALITY REQUEST March 13, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for Transmitter with FCC ID: AZ492FT7127 Dear Sir / Madam, Motorola Solutions Malaysia Sdn Bhd is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions Inc considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d), 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, Arine Lee FCC/IC Certification Manager E-mail : [email protected]

____________________________________________________________________________ Motorola Solutions Inc, 8000 West Sunrise Boulevard, Fort Lauderdale, Florida 33322 Certification Department Date: 13 March 2020 Subject: Application Authorization for FCC filing To Whom It May Concern: I hereby authorize Arine Lee to apply, on my behalf, the application for the following FCC ID: FCC ID: AZ492FT7127 Please contact me if there are any questions or issues. Regards, Deanna Zakharia Regulatory Compliance Manager Tel: (954) 723 4707 Email: [email protected]

Date: March 13, 2020 To whom it may concern, Please be notified that I, Arine Lee, have designated Michael Lin in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Michael Lin in Sporton International Inc. on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. This authorization is limited to the product of as following: FCC ID: AZ492FT7127 If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please don’t hesitate to contact me. Sincerely yours, Arine Lee FCC/IC Certification Manager E-mail : [email protected]

Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 3 SHEET 1 OF 7 EXHIBIT 3 EXTERNAL PHOTOGRAPHS (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) ) The following photographs are attached. Exhibit 1. Front View (Controls) 3A 2. Back View 3B 3. Top View 3C 4. Bottom View (FCC Label Location) 3D 5. Side View (Right) 3E 6. Side View (Left) 3F Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 3 SHEET 2 OF 7 Exhibit 3A – Front View Front View Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 3 SHEET 3 OF 7 Exhibit 3B – Back View Back View Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 3 SHEET 4 OF 7 Exhibit 3C – Top View Top View Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 3 SHEET 5 OF 7 Exhibit 3D – Bottom View (FCC Label Location) Bottom View (FCC Label) Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 3 SHEET 6 OF 7 Exhibit 3E – Side View (Right) Side View (Right) Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 3 SHEET 7 OF 7 Exhibit 3F – Side View (Left) Side View (Left)

Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 1 SHEET 1 OF 2 EXHIBIT 1 IDENTIFICATION LABEL (Pursuant to FCC Part 2.1033(c)(11), 2.1033(b)(7) ) LOCATION See the Attached Photograph or Sketch X Bottom of Radio Top of Radio Back of Radio Back of Radio under Belt Clip In battery compartment TYPE X The label is a polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with the minimum peel strength of 40 oz/inch. MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3 for the actual location of the FCC/IC label on the device. X Label Attached Below. See Attached Drawing. Applicant: Motorola Solutions Inc FCC ID: AZ492FT7127 EXHIBIT 1 SHEET 2 OF 2 Figure 1: FCC Label

Applicant: Motorola Solutions Inc. FCC ID: AZ492FT7127 Exhibit 9 Page | 1 EXHIBIT 9 Internal Photographs (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) ) The following photographs are attached. Exhibit 1. RF board with shields (Top) 9A 2. RF board without shields (Top) 9B 3. RF board with shields (Bottom) 9C 4. RF board without shields (Bottom) 9D 5. RF board with chassis and housing (Top) 9E 6. RF board with chassis and housing (Bottom) 9F 7. Control head board (Bottom) 9G 8. Control head board (Top) 9H 9. Exploded View of radio 9I Applicant: Motorola Solutions Inc. FCC ID: AZ492FT7127 Exhibit 9 Page | 2 Exhibit 9A RF board with shields (Top) Exhibit 9A RF board without shields (Top) Applicant: Motorola Solutions Inc. FCC ID: AZ492FT7127 Exhibit 9 Page | 3 Exhibit 9B RF board with shields (Bottom) Exhibit 9C RF board without shields (Bottom) Applicant: Motorola Solutions Inc. FCC ID: AZ492FT7127 Exhibit 9 Page | 4 Exhibit 9E RF board with chassis and housing (Top) Applicant: Motorola Solutions Inc. FCC ID: AZ492FT7127 Exhibit 9 Page | 5 Exhibit 9F RF board with chassis and housing (Bottom) Applicant: Motorola Solutions Inc. FCC ID: AZ492FT7127 Exhibit 9 Page | 6 Exhibit 9G Control head board (Bottom) Applicant: Motorola Solutions Inc. FCC ID: AZ492FT7127 Exhibit 9 Page | 7 Exhibit 9H Control head board (Top) BT/WIFI Antenna Applicant: Motorola Solutions Inc. FCC ID: AZ492FT7127 Exhibit 9 Page | 8 Exhibit 9I Exploded View of radio

Sporton International (Kunshan) Inc. Page Number : 1 of 10 TEL : 86-512-57900158/ FAX : 86-512-57900958 Report Issued Date : Mar. 10, 2020 FCC ID: AZ492FT7127 Report Version : Rev. 02 RF Exposure Evaluation Report Report No. : FA9N0421 RF Exposure Evaluation Report APPLICANT : Motorola Solutions Inc. EQUIPMENT : WAVE Two-Way Mobile Radio BRAND NAME : Motorola Solutions MODEL NAME : TLK150 MODEL NUMBER : HK2131A FCC ID : AZ492FT7127 STANDARD : 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 We, Sporton International (Kunshan) Inc., would like to declare that the device has been evaluated in accordance with 47 CFR Part 2.1091 and FCC KDB 447498 D01 v06, and pass the limit. Without written approval of Sporton International (Kunshan) Inc., the test report shall not be reproduced except in full. Reviewed by: Rose Wang / Supervisor Approved by: Kat Yin / Manager Sporton International (Kunshan) Inc. No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International (Kunshan) Inc. Page Number : 2 of 10 TEL : 86-512-57900158/ FAX : 86-512-57900958 Report Issued Date : Mar. 10, 2020 FCC ID: AZ492FT7127 Report Version : Rev. 02 RF Exposure Evaluation Report Report No. : FA9N0421 Table of Contents 1. ADMINISTRATION DATA ........................................................................................................................... 4 1.1. Testing Laboratory ............................................................................................................................. 4 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 5 3. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 6 4. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 8 5. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 9 5.1. Standalone Power Density Calculation ............................................................................................. 9 5.2. Collocated Power Density Calculation ............................................................................................. 10 Sporton International (Kunshan) Inc. Page Number : 3 of 10 TEL : 86-512-57900158/ FAX : 86-512-57900958 Report Issued Date : Mar. 10, 2020 FCC ID: AZ492FT7127 Report Version : Rev. 02 RF Exposure Evaluation Report Report No. : FA9N0421 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA9N0421 Rev. 01 Initial issue of report. Jan. 21, 2020 FA9N0421 Rev. 02 Update the equipment name. Mar. 10, 2020 Sporton International (Kunshan) Inc. Page Number : 4 of 10 TEL : 86-512-57900158/ FAX : 86-512-57900958 Report Issued Date : Mar. 10, 2020 FCC ID: AZ492FT7127 Report Version : Rev. 02 RF Exposure Evaluation Report Report No. : FA9N0421 1. Administration Data 1.1. Testing Laboratory Sporton International (Kunshan) Inc. is accredited to ISO/IEC 17025:2017 by American Association for Laboratory Accreditation with Certificate Number 5145.02. Testing Laboratory Test Firm Sporton International (Kunshan) Inc. Test Site Location No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China TEL : +86-512-57900158 FAX : +86-512-57900958 Test Site No. FCC Designation No. FCC Test Firm Registration No. CN1257 314309 Applicant Company Name Motorola Solutions Inc. Address 8000 West Sunrise Boulevard, Fort Lauderdale, Florida Manufacturer Company Name Motorola Solutions Malaysia Sdn. Bhd. Address Plot 2A, Medan Bayan Lepas, Mukim 12, S.W.D. 11900 Bayan Lepas, Penang, Malaysia. Sporton International (Kunshan) Inc. Page Number : 5 of 10 TEL : 86-512-57900158/ FAX : 86-512-57900958 Report Issued Date : Mar. 10, 2020 FCC ID: AZ492FT7127 Report Version : Rev. 02 RF Exposure Evaluation Report Report No. : FA9N0421 2. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type WAVE Two-Way Mobile Radio Brand Name Motorola Solutions Model Name TLK150 Model Number HK2131A FCC ID AZ492FT7127 Wireless Technology and Frequency Range WCDMA Band II: 1852.4 MHz ~ 1907.6 MHz WCDMA Band V: 826.4 MHz ~ 846.6 MHz LTE Band 2: 1850.7 MHz ~ 1909.3 MHz LTE Band 4: 1710.7 MHz ~ 1754.3 MHz LTE Band 5: 824.7 MHz ~ 848.3 MHz LTE Band 7: 2502.5 MHz ~ 2567.5 MHz LTE Band 13: 779.5 MHz ~ 784.5 MHz LTE Band 17: 706.5 MHz ~ 713.5 MHz WLAN 2.4GHz Band: 2412 MHz ~ 2462 MHz WLAN 5.2GHz Band: 5180 MHz ~ 5240 MHz WLAN 5.3GHz Band: 5260 MHz ~ 5320 MHz WLAN 5.5GHz Band: 5500 MHz ~ 5720 MHz WLAN 5.8GHz Band: 5745 MHz ~ 5825 MHz Bluetooth: 2402 MHz ~ 2480 MHz Mode RMC/AMR 12.2Kbps HSDPA HSUPA LTE: QPSK, 16QAM WLAN 2.4GHz 802.11b/g/n HT20/ HT40 WLAN 5GHz 802.11a/n HT20/ HT40 Bluetooth BR/EDR/LE HW Version P2 SW Version TLK150_BASE_ENG_D03.00.32_APPS_D03.00.36 Antenna Type/ Gain For WWAN antenna: External Antenna WCDMA Band V: 1.70 dBi WCDMA Band II: 2.80 dBi LTE Band 2 : 2.80 dBi LTE Band 4 : 2.50 dBi LTE Band 5 : 1.70 dBi LTE Band 7 : 1.10 dBi LTE Band 13 : 0.30 dBi LTE Band 17 : 0.90 dBi WLAN2.4GHz antenna: <2412 MHz ~ 2462 MHz > Chip Antenna with gain -0.1 dBi Bluetooth antenna: <2402 MHz ~ 2480 MHz > Chip Antenna with gain -0.1 dBi WLAN5GHz antenna: <5180 MHz ~ 5240 MHz > Chip Antenna with gain 1.9 dBi <5260 MHz ~ 5320 MHz > Chip Antenna with gain 1.8 dBi <5500 MHz ~ 5720 MHz > Chip Antenna with gain 0.9 dBi <5745 MHz ~ 5825 MHz> Chip Antenna with gain 0.1 dBi EUT Stage Identical Prototype Remark: 1. The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for Sporton International (Kunshan) Inc. Page Number : 6 of 10 TEL : 86-512-57900158/ FAX : 86-512-57900958 Report Issued Date : Mar. 10, 2020 FCC ID: AZ492FT7127 Report Version : Rev. 02 RF Exposure Evaluation Report Report No. : FA9N0421 more detailed description. 3. Maximum RF a…

Text truncated - open the document above for the full version.

Sporton International (Kunshan) Inc. Page Number : 1 of 31 TEL : +86-512-57900158 Report Issued Date : Mar. 10, 2020 FAX : +86-512-57900958 Report Version : Rev. 02 FCC ID: AZ492FT7127 Report Template No.: BU5-FR15CBT4.0 Version 2.0 FCC RF Test Report Report No. : FR9N0421B FCC RF Test Report APPLICANT : Motorola Solutions Inc. EQUIPMENT : WAVE Two-Way Mobile Radio BRAND NAME : Motorola Solutions MODEL NAME : TLK 150 MODEL NUMBER : HK2131A FCC ID : AZ492FT7127 STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DTS) Digital Transmission System The product was received on Nov. 04, 2019 and testing was completed on Jan. 15, 2020. We, Sporton International (Kunshan) Inc., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International (Kunshan) Inc., the test report shall not be reproduced except in full. Reviewed by: Jason Jia / Supervisor Approved by: James Huang / Manager Sporton International (Kunshan) Inc. No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 21…

Text truncated - open the document above for the full version.
