Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 147.20 mW |
Modular TypeLimited Single Modular ApprovalConfidentialityLong Term Grant NotesLimited Modular Approval. Output power listed is Conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing. When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Compliance of this device in all final host configurations is the responsibility of the Grantee. End-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. Host systems must provide regulated supply voltages to the module. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : PC2201).
The highest reported SAR values are: 0.74 W/kg : Body-worn.
