AZDMTG1RF Memory Tag Transmitter

FCC ID Label FCC ID Label for Host Equipment Size 7.0mm x 55.0mm FCC ID Label for RF Memory TAG1 Size 5.0mm x 45.0mm Contains FCC ID: AZDMTG1 FCC ID: AZDMTG1

FCC Label for Host Equipment Contains FCC ID: AZDMTG1

T E S T R E P O R T REPORT NUMBER:ANKK−103253 APPLICANT:CANON INC. MODEL NUMBER:Memory TAG 1 FCC ID:AZDMTG1 REGULATION:FCC Part15C Section 15.207 Section 15.209 1, Oaza Sunayama, Hasaki−machi, Kashima−gun Ibaraki−ken, 314−0255 Japan Tel.: +81 479 40 1097 Fax.: +81 479 46 1788 Akzo Nobel K. K. EMC Division Kashima Site Akzo Nobel Report No. ANKK−103253FCC ID : AZDMTG1Page 2 of 21 (Version 5.2) TABLE OF CONTENTS Page ABBREVIATIONS ............................................................................................................................ 3 SECTION 1.TEST CERTIFICATION ....................................................................................... 4 SECTION 2.CONCLUSION ...................................................................................................... 5 SECTION 3.EQUIPMENT UNDER TEST................................................................................ 6 SECTION 4.SUPPORT EQUIPMENT USED ........................................................................... 7 SECTION 5.CABLE (S) USED .................................................................................................. 8 SECTION 6.CONSTRUCTION OF EQUIPMENT.................................................................... 9 SECTION 7.OPERATING CONDITIONS............................................................................... 10 SECTION 8.TEST PROCEDURE(S) ....................................................................................... 11 SECTION 9.EVALUATION OF TEST RESULTS .................................................................. 15 SECTION 10. INSTRUMENTS USED FOR FINAL TEST ....................................................... 19 SECTION 11. MEASUREMENT UNCERTAINTY.................................................................... 20 SECTION 12. DESCRIPTION OF TEST LABORATORY ......................................................... 21 Akzo Nobel Report No. ANKK−103253FCC ID : AZDMTG1Page 3 of 21 (Version 5.2) ABBREVIATIONS LISN= Line Impedance Stabilization Network AMN= Artificial Mains Network ISN= Impedance Stabilization Network CDN= Coupling Decoupling Network ANT= Antenna BBA= Broadband Antenna DIP= Dipole Antenna AMP= Amplifier ATT= Attenuator EUT= Equipment Under Test AE= Associated Equipment Q−P= Quasi−peak AVG= Average Akzo Nobel Report No. ANKK−103253FCC ID : AZDMTG1Page 4 of 21 (Version 5.2) SECTION 1. TEST CERTIFICATION APPLICANT INFORMATION Company: CANON INC. Address7-5-1, Hakusan, Toride-shi, Ibaraki-ken, 302-8501 Japan Telephone number: +81 297 77 2111 Fax number: +81 297 74 2454 DESCRIPTION OF TEST ITEM Kind of equipment: RF Memory TAG System Condition of equipment: Pre production Type: Built - in (Copier / Printer) Trademark: Canon FCC IDAZDMTG1 Model number: Memory TAG 1 Serial number: None TEST PERFORMED Location: Kashima No. 3 Test Site EUT received: September 24, 2003 Test started: September 25, 2003 Test completed: November 18, 2003 Regulation: RCC Part15 Subpart C Section 15.207 / 15.209 Intentional Radiators Test setup: ANSI C63.4-2001 Report issue date:November 18, 2003 Test engineer:Naoki Sagawa Report approved by:Takeshi Yamanaka [Site Manager] On the basis of the measurements made, the equipment tested is capable of operation in compliance with the requirements of Part 15 of the FCC Rules under normal use and maintenance. Note a. The test result of this report is effective for equipment under test itself and under the test configuration described on the report. b. This test report does not assure that whether the test result taken in other testing laboratory is compatible or reproducible to the test result on this report or not. c. This test report shall not be reproduced except in full, without issuer’s permission. Akzo Nobel Report No. ANKK−103253 FCC ID : AZDMTG1 Page 5 of 21 (Version 5.2) SECTION 2. CONCLUSION This test report clearly shows that the EUT is in compliance with the FCC Part15C Section15.207 & Section15.209 specification. The minimum margins to the limits are as follows: AC Conducted Emission (AV) 0.6 dB at 0.6892 MHz Spurious Emissions - Radiated Emission Test 15.2 dB at 67.75 MHz Note : See Section 9 for details. Akzo Nobel Report No. ANKK−103253FCC ID : AZDMTG1Page 6 of 21 (Version 5.2) SECTION 3. EQUIPMENT UNDER TEST The equipment under test (EUT) consisted of the following equipment. Indication in the following left side column corresponds to Section 6. Symbol ItemModel No.Serial No. FCC ID / DoC ManufacturerRemarks A) RF Memory TAG System Memory TAG 1 NoneAZDMTG1CanonInterface PCB B) RF Memory TAG System Memory TAG 1 NoneAZDMTG1CanonCoil PCB (RF Antenna) C) RF Memory TAG System Memory TAG 1 NoneAZDMTG1CanonMemory TAG Power ratings of EUT : DC 5V, 24V 3.1 Overview of EUT : Carrier Frequency:13.56 MHz Modulation Method: Transmitting − Amplitude Shift Keying : Receiving − Bi-Phase Shift Keying RF Output Power:31.7 dBuV/m (Measurement Distance : 3.0 m) 3.2 Port(s)/Connector(s) : Port nameConnector typeConnector pinRemarks J041-408Mini CT type 3 pin for Antenna (×8) J400CZ type 14 pinfor Controller in Copier 3.3 RF Operation Frequency : Oscillator Operating Board nameRemarks 13.56 MHz13.56 MHzInterface PCB 13.56 MHz13.56 MHzMomory Tag Akzo Nobel Report No. ANKK−103253FCC ID : AZDMTG1Page 7 of 21 (Version 5.2) SECTION 4. SUPPORT EQUIPMENT USED The EUT was supported by the following equipment during the test. Indication in the following left side column corresponds to Section 6. Symbol ItemModel No.Serial No. FCC ID / DoC ManufacturerRemarks D) Digital CopierF142500NoneN.A.Canon Power ratings of Digital Copier : AC 120V, 60 Hz, 11 A Akzo Nobel Report No. ANKK−103253FCC ID : AZDMTG1Page 8 of 21 (Version 5.2) SECTION 5. CABLE (S) USED The following cable(s) was used for the test. Indication number in the following left side column corresponds to Section 6. Number NameLengthShieldConnectorCore 1) RF Antenna cable0.10 mNonePlastic 2) DC Upper Lead Wires0.61 mNonePlastic 3) Power cable for Digital Copie…

Text truncated - open the document above for the full version.

Annex A Photographs Akzo Nobel Report No. ANKK−103253 FCC ID : AZDMTG1Page 2 of 3 PHOTOGRAPHS OF MAXIMUM DISTURBANCE SET−UP 1. AC Conducted Emission (Section15.207) Test setup in accordance with ANSI C63.4−2001 Front view Side view Akzo Nobel Report No. ANKK−103253 FCC ID : AZDMTG1Page 3 of 3 2. Spurious Emission – Radiated (Section15.209) Test setup in accordance with ANSI C63.4−2001 Front view Rear view
