P012346A EN/LZT 720 0090 R1A Ericsson GSM System RBS 2109 User’s Guide Doc nr: 2/001 59-EN/LZT 720 0090 Uen Rev A Ericsson GSM System EN/LZT 720 0090 R1A RBS 2109 User’s Guide BINDER LABEL 1 (1) Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No. KI/EAB/RWB/Z Fredrik Hammar 4/001 59-EN/LZT 720 0090 Uen Dokansv/Godkänd - Doc respons/Approved Kontr - Checked Datum - Date Rev File KI/EAB/RWB/Z Sun ita Patil 20 04-09 -17 A http://sis/documents/word/binderlabel_portrait.doc 98 65 Fontsize 10 Fontsize 10 HEADING XXX LZN xxx xxx R-state 28 38 47 54 RBS 2109 User’s Guide Ericsson GSM System EN/LZT 720 0090 R1A Fontsize 12 Cutting mark Fontsize 14 CAPTION LIST Document No. EN/LZT 720 0090 RBS 2109 User’s Guide Date Rev 2004-09-17 A Introduction 1 Personal Health and Safety Information 2 System Safety Information 3 Tools and Instruments 4 Installation of RBS 2308 and RBS 2309 5 Antenna System Tests 6 Site Installation Tests 7 RBS Site Integration 8 Maintenance 9 Glossary 10 RBS 2109 User’s Guide E Copyright © Ericsson 2004 — All Rights Reserved Disclaimer No part of this document may be reproduced in any form withoutthe written permission of the copyright owner. The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. Ericsson shall have no liability for any error or damage of any kind resulting from the use of this document. Trademark List EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide Contents 1Introduction1 1.1Product Overview2 1.2Target Groups3 1.3Installation and Integration Process Overview4 1.4Radio Site Implementation Process5 1.5RBS Library Overview8 1.6Release History8 2Personal Health and Safety Information9 2.1Introduction9 2.2Hazard Symbols and Admonitions10 2.3General Safety Precautions11 2.4Electric Shock Hazards12 2.5Energy Hazards13 2.6Fire Hazard14 2.7Heat Hazards15 2.8Mechanical Hazards16 2.9Radio Frequency Exposure Hazards17 2.10Laser Hazards18 2.11Chemical Hazards19 2.12Other Hazards21 3System Safety Information25 3.1Introduction25 3.2Admonitions and Safety Symbols26 3.3Batteries27 3.4Electrical Installation28 3.5Electrostatic Discharge29 3.6Equipment Handling30 3.7Ground Connection31 3.8Lightning Protection31 4Tools and Instruments33 4.1Tools for Installation of RBS 210933 EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 4.2Equipment for Antenna System Tests34 4.3Equipment for Site Installation Tests35 4.4Equipment for RBS Site Integration35 4.5Equipment for Maintenance36 4.6Kit Specifications37 5Installation of RBS39 5.1Introduction39 5.2Preconditions39 5.3Torque Settings40 5.4Installation Procedure41 6Antenna System Tests73 6.1Checking the Installation76 6.2Calibrating the Antenna Tester76 6.3Performing DTF Tests79 6.4Naming a DTF Measurement83 6.5Calculating the Feeder Attenuation84 6.6Calculating the Feeder Delay86 6.7Performing SWR Test on Passive Antenna Systems (Without TMA)89 6.8Performing SWR Test on Antenna Systems with ddTMA91 6.9Naming an SWR Measurement95 6.10Performing Concluding Routines95 6.11SWR↔Return Loss Conversion Table98 7Site Installation Tests101 7.1Preconditions101 7.2Inspecting Cable Connections102 7.3Checking AC Mains and DC Power Supply102 7.4Switching on RBS103 7.5Testing Fan Unit105 7.6Setting IDB Parameters106 7.7Reading Fault Status135 7.8Testing External Alarms136 7.9Performing Concluding Routines138 8RBS Site Integration143 8.1Testing Transmission144 EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 8.2Bringing the RBS into Service146 8.3Making Test Calls on the Air Interface147 8.4Performing Concluding Routines151 9Maintenance157 9.1Introduction157 9.2Preconditions157 9.3Fault Localisation Using OMT158 9.4Troubleshooting Using the RBS Indicators175 9.5HW Replacement187 10Glossary221 EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 1Introduction This User’s Guide consists of the chapters listed below. Each chapter is briefly summarised. Introduction This chapter. Personal Health and Safety Information Contains personal health and safety information that applies when working with Ericsson system products. System Safety Information Contains system safety information that applies when working with Ericsson system products. Tools and Instruments Contains lists of all recommended tools and instruments. Installation of the RBS Describes activities for: • Installation of the mounting base • Connection of cables • Connection of external antenna • Mounting the radio cabinet on the mounting base Antenna System Tests Describes the site specific antenna tests that should be performed on site. Site Installation Tests Describes the site specific tests that should be performed on-site. 1EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide RBS Site Integration Describes how to integrate an RBS site into a network. Maintenance Describes first line Maintenance. This means that swap repair is carried out on site and that only replaceable units are handled. Glossary Contains abbreviations and acronyms used in the text. 1.1Product Overview The RBS is a GSM EDGE micro base station for both indoor and outdoor micro cell applications. It is a small yet complete station, with transceivers, switching functions and transmission. The RBS can be mounted on a mast/pole as easily as it can be fitted to a wall. P010530D Figure 1RBS Overview 2E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide IXUInterface and Switching Unit MBUMounting Base Unit RRURemote Radio Unit RXBPRX Bandpass Filter TIMTransmission Interface Mod ule External optional battery backup is possible, as well as theoption of having integrated antennas within the base station. 1.2Target Groups This section describes the target group for this manual, which is all personnel involved in activities relating to the installation and integration of an RBS site. TEMS ON/OFF YES NO 1 2 3 4 5 6 7 8 9…

Text truncated - open the document above for the full version.

RBS 2109 User’s Guide Connecting PCM Twisted Pair 100/120 1 Connect the twisted pairs to P.LINE and N.LINE. P0102010A PORT. A. IN. P. LINEPORT. A. IN. N. LINEPORT. A. IN. GNDPORT. A. OUT. P. LINEPORT. A. OUT. N. LINEPORT. A. OUT. GND PORT A 2 Earth the cables according to the following instruction: Inner and outer shield Connect the inner shield to the terminator block, and the outer shield to the cable gland,see Figure 24 on page 61. Outer shield only Fit the shield to the cable gland,see Figure 25 on page 62. P011352A Figure 24Earthing Inner and Outer Shield 61EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide P011353A Figure 25Earthing Outer Shield Only 5.4.7Installing the RRU This section describes how to install the Remote Radio Unit (RRU). Note:To avoid damage, do not place the RRU on its connectors,see Figure below. P010470A Figure 26Do Not Place the RRU on its Connectors Note:Do not install any equipment on the RRU before mounting it on the MBU. 6 2 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide Caution! The equipment is heavy. Lifting the equipment without the aid of a lifting device can cause injury. 1 Hang the RRU onto the upper hinge. Position the lower hinge and tighten the screw. P010122C 2 Remove the protection cover under the RRU. 63EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 3 Open the left side cover on the RRU, connect the Y link cabl,e and close the cover. Connect the AC/DC cable. P010173B 4 Close the RR U using the clasps. P010125A 5.4.8Connecting Earth Cables This section describes how to connect the earth cables to theRRU and the IXU. 1 Connect the earth cables from the earthing point to both IXU (master) and RRU. P010228A 6 4 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide Note:If an Omni Antenna is to be installed on the RRU, the RRU earthing cable must be connected after the omni antenna bracket has been mounted. 5.4.9Installing the Fan Unit (Optional) This section describes how to install the fan unit. 1 Install the fan on top of the RRU and fasten the three screws. P010496A 2 Connect the power cable to the RRU. P010543A 5.4.10Installing RXBP (Optional) This section describes how to install the Receiver Band Passfilter (RXBP) on the RRU and how to connect the cables. 65EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 1 Install the RXBP on the RRU and tighten the screws. P010175A RXBP RX 2 RX 1 RXBP 2 RXBP 1 2 Connect the fi rst cable from connection po rtRXBP 1on the RXBP to conne ction portRXBP 1on the RRU. C onnect the other cable from connection port RXBP 2on the RXBP toRXBP 2on the RRU. P010172A RXBP 1 RXBP 2 RXBP RX 2 RX 1 RXBP1 RXBP 2 3 Connect the RX antenna cables to connection portRX 1andRX 2on the RXBP, and tighten with the appropriate torque wrench.See Table 9 on page 41. For more information about antenna connections,see: Site Installation Documentation 5.4.11Installing the Integral Omni Antenna (If Applicable) This section describes how to install the integral Omni Antenna on the RRU. 1. Remove the RRU earthing cable if it has been previously installed.See Section 5.4.8 Connecting Earth Cables on page 64 2. Mount the Omni Antenna bracket on top of the RRU, and tighten the captive screws. 6 6 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 3. Install the RRU earthing cable. P011410A Figure 27Mounting the Antenna Bracket 4. Attach the antenna on the bracket. Use the two captive screws on each side of the antenna. 5. Route and fasten the antenna cable with two clamps on the right side of the RRU. 6. Secure the antenna with the sunshield,see Section 5.4.15 on page 69. P011294B Figure 28Installing the Omni Antenna 67EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 5.4.12Installing the Integral Sector Antenna (If Applicable) This section describes how to install a Sector Antenna on theRRU. 1. Attach the Sector Antenna on the front of the RRU. Secure itwith four screws. P011293A Figure 29Installing the Sector Antenna 5.4.13Connecting RBS Antenna Cables This section describes how to connect antenna cables when a MCB or integral antenna is not used. 1 Connect the RBS jumpers to connection portTX(/RX) 1andTX(/RX) 2, and tighten with the appropriate torque wrench.See Table 9 on page 41. P010579B 6 8 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 2 Strap the cables using the appropriate cable tie anchor. P012173A 3 Install the protective cover under the RRU. P010565A 5.4.14Testing the Installation The RBS is now ready for the site installation tests. The site installation tests should be performed directly after the completion of the RBS installation,see Chapter Site Installation Tests. After the installation and integration testing is completed, return toSection 5.4.15 on page 69. 5.4.15Installing the Sunshields This section describes how to install the sunshields. 69EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide Different sunshields are used depending on whether or not components are installed on the front of the RRU. 1. If the fan unit or integral Omni Antenna are not used, install the top sunshield and fasten two screws either to the RRU or the IXU.See Figure below. P010232C 2. If the fan unit is used, install the fan cover on top of the RRU.See Figure below. P010515A 7 0 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 3. Attach the front sunshield to the left sunshield. 4. Close the front sunshield and attach it to the top shield (fan cover) and to the right sunshield. 5. Lock the shield. 5.4.16Performing Concluding Routines This section describes the routines to be completed before leaving the site. Note:Ericsson strongly advises that when cleaning up after installing the RBS, the personnel performing the installation pay particular attention to the environment. Primarily, recycle all waste materialsthat can be recycled and sort waste so that it can be disposed of according to local regulations. Table 11Objects to Be Recycled or Disposed of After RBS Installa…

Text truncated - open the document above for the full version.

RBS 2109 User’s Guide P010476A Figure 66Reading Fault Status 3. In the Available monitors box, select ‘‘MO fault maps’’ and click→to add ‘‘RBS’’ into the Monitors to start box. 4. ClickStart monitor. 5. In the RBS Event Monitor window, check the MO faults box to see if there are any faults. If there are, then correct these before continuing. When an MO fault is selected, corresponding fault description, action and related faults are displayed. See alsoAppendix Fault List. 6. Close the RBS Event Monitor window. 7.8Testing External Alarms This section describes how to use the OMT to test that all external alarms, if used, are recognized and handled correctly. The test is passed when all alarms are recognized. 1 36 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide Note:The alarms must be individually identifiable in the OMT. There must be no doubt which alarm was indicated. The alarm message must be unique for each alarm. 1. On theMaintenancemenu, clickMonitorto open the Monitor window. See figure below. P010475A Figure 67Testing External Alarms 2. In the Available monitors box, select ‘‘External Alarm Status’’ and click→to add ‘‘Alarm Inlets’’ in the Monitors to start box. 3. ClickStart monitor. 4. Trigger the desired alarm by either shorting or breaking it. Note:Test the alarms in numerical order, and always start with alarm 1. 5. Check that the appropriate alarm appears in the RBS Event Monitor window. 137EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 6. Release the trigger on the alarm and check that the alarm disappears from the OMT. 7. Repeat steps 5 to 7 for all defined external alarms. 8. Close the RBS Event Monitor window when finished. 7.9Performing Concluding Routines This section describes the actions to take before leaving the site and provides a site checklist. It also contains a test record. 7.9.1Saving IDB In case it is necessary to re-install the IDB, the IDB parameters must be saved on the PC. 1. On theConfigurationmenu, clickSave IDB. 2. Give the IDB file an RBS-specific name and save the IDB on the PC. 7.9.2Checking RRU and IXU Indicators 1. Ensure that all lids are closed and fastened with screws. 2. Set the RRU and IXU in remote mode by pressing theLocal/Remote button. 3. Check that the RRU and IXU indicators have the status shownin the applicable table below: • Table 43 on page 139 shows the approved status of the RRU and IXU indicators when the RBS is in remote mode but not connected tothe BSC. • Table 44 on page 139 shows the approved status of the RRU and IXU indicators when the RBS is in remote mode, fully operational, and connected to the BSC. 1 38 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide Table 43RRU and IXU Indicators After Site Installation Tests Without BSC Connection RBS in remote mode and no BSC connected RRUIXU FaultOffFaultOff OperationalOffOperationalOff LocalFlashingLocalFlashing RF offOnRBS faultOff AC power onOn (1) External alarmOff DC power onOn (1) AC power onOn (1) DC power onOn (1) IXU temp.Off RRU temp.Off Transmission OKOn/Off (2) (1) Depending on power system configuration. (2) A, B, C, and/or D, depending on transmission configuration. Table 44RRU and IXU Indicators After Site Installation Tests With BSC Connection RBS in remote mode, fully operational and connected to the BSC RRUIXU FaultOffFaultOff OperationalOnOperationalOn LocalOffLocalOff RF offOn/Off (1) RBS faultOff AC power onOn (2) External alarmOff DC power onOn (2) AC power onOn (2) DC power onOn (2) IXU temp.Off RRU temp.Off Transmission OKOn (3) (1) Depending on BSC. (2) Depending on power system configuration. (3) A, B, C, and/or D, depending on transmission configuration. 4. If the Operational indicator on the RRU and/or IXU is flashing, SW is being downloaded from the BSC. Wait until downloading is complete. 5. If the Local indicator on the RRU and/or IXU does not have the correct status, press theLocal/Remotebutton to switch status. 139EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 6. If RBS site integration is not performed immediately after site installation tests, then close the sunshields. 7.9.3Completing Test Record This section contains a test record. It is recommended to fill in the test record during the testing procedure. 1 40 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide P010243C NE Commissioning GSM - Date Site No Te ster's Name Cell RBS type Test Record for Stand-alone Tests Site Notes: NE STAND ALONE TEST Antenna System Te st Record Cable connections inspected Power supply verified Fan Unit Te sted (If Applicable) IDB parameters set Fault status read Remark External Alarms tested Figure 68Test Record for Site Installation Tests 141EN/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 7.9.4Filling in Checklist The following checklist is not mandatory but strongly recommended. Local procedures and safety regulations must be evaluated and included in this checklist. Table 45Checklist Check the following:OK 1 The indicators on the RRU and the IXU are in the approved status. 2 The test equipment has been disconnected from the RBS 3 The RBS cabinet and the mounting base are free from foreign objects. 4 All cabinets and cables are free of damage. 5 All EMC sealants and cable penetrations are intact. 6 Top and bottom of cabinet are free of obstructions (for airflow). 7 The cabinet has been locked, and the screws have been tightened. 8 All tools have been accounted for. 9 All paperwork has been completed. 1 42 E N/LZT 720 0090 Uen R1A 2004-09-17 RBS 2109 User’s Guide 8RBS Site Integration This chapter describes how to integrate the RBS with the BSC into the GSM network, and the tests used to verify the integration. Integration is carried outwith the RBS connected to a PCM link and in close co-operation with a BSC operator. All results must be documented in the test record. Preconditions at the RBS Site This section describes the preconditions for personnel at the RBS site before integrating the RBS. Before startin…

Text truncated - open the document above for the full version.

Limited Internal EXHIBIT 4 Prepared (also subject responsible if other) No. EAB/RTL/I Palle Zetterstrand B5KAKRC161028-4 Approved Checked Date Rev Reference EAB/RTL/I (P. Zetterstrand) 2004-12-08 A 1 EXHIBIT 4 - Cover Sheet Contents EXHIBIT 4 - Cover Sheet 1 Block Diagram RF Parts, RAB 1900 , 1911-ROA 219 5750/1 2 Block Diagram CPU Parts, DRB, 1911-ROA 117 4767/3 3 Sheet 4 5 6 7 8 9 10 11 12 13 14 15 16 A B C D E F G H I J K Prepared (also subject responsible if other) References Doc respons/Approved Date Rev Product name Document no A B C D E F G H 1234567891011 I J K 12 13 14 15 16 123 +5.7V +7V +3.3V +3.3V +7V +7V +5.7V +3.3V +5.7V +5.7V +7V +26V +5.7V +3.3V TXPA0 REF_RANGE_8100 TXPA0ROZ 104 257/1 1(1) RAB-H19 EAB/RTL/R Anders LindahlMGC BS C.2C EMWCOEM EMWHELN 2004-06-07 1911-ROA 219 5750/1 Ux RX1 REF_RANGE_7100 ROZ 104 383/4 RX_FRONTEND REF_RANGE_5100 ROZ 104 348/4 RX FRONTEND TXPA1 REF_RANGE_9100 TXPA1ROZ 104 241/1 RX0 REF_RANGE_6100 ROZ 104 382/4 +5.7V +7V +1.8V +26V RX1_RFIC_13MHZ RX1_TEMP RXIF1_13MHZ PBU1_CTRL_BUS(8:0) TX1_CTRL_BUS(15:0) RX1_J1_BUS(18:0) SPIRA1_BUS(27:0) SPIRA1_TXQ_BUS(11:0) SPIRA1_TXI_BUS(11:0) RX0_ARF RX0_BRF RX1_ARF RX1_BRF RX0_J1_BUS(18:0) PBU0_CTRL_BUS(8:0) SPIRA0_BUS(27:0) SPIRA0_TXI_BUS(11:0) SPIRA0_TXQ_BUS(11:0) TX0_CTRL_BUS(15:0) +26V +3.3V RC0_PA_ON RF_LOOP_0 RX0_TEMP RX0_J3_BUS(8:0) RX0_RFIC_13MHZ RX0_RFIC_13MHZ RXIF0_13MHZ RC1_PA_ON RF_LOOP_1 TX1_RFIC_13MHZ RX1_J3_BUS(8:0) Sheet 4 5 6 7 8 9 10 11 12 13 14 15 16 A B C D E F G H I J K Prepared (also subject responsible if other) References Doc respons/Approved Date Rev Product name Document no A B C D E F G H 1234567891011 I J K 12 13 14 15 16 123 Reviewed and approved according to Check Report 18/17763-592/FCP 103 3486 HEATER_FAULT_EC HEATER_ON_X POWER_GOOD_EC DC_OUT_OVL_EC XTEMP_LED_MMI 1(1) DRB EDGE EAB/RTL/D (P Tammpere)MGC BS C.2A EMWKESE 2003-09-03 1911-ROA 117 4767/3 Ux 5_7V 5_7V_RTN 5V_LEC 5V_LEC_RTN 1_8V_1 1_8V_2 1_2V_1 3_3V 7V -5_5V 1_8V_1_SENSE 1_8V_2_SENSE 1_2V_1_SENSE 3_3V_SENSE DC_OFF_EC AC_MAINS_FAIL DC_OUT_OVL DC_SUPPLY_FAIL FAN_FAULT#1 FAN_ON_EC HEATER_ON_EC HEAT_ON I2CBSDA I2CBSCL AC_MAINS_FAIL_EC AC_POWER_ON_MMI DC_ON_X DC_PA_ON DC_POWER_ON_MMI DC_SUPPLY_FAIL_EC FAN_FAULT_EC FAN_ON_X

2004-12-08 Telecommunication Certification Body Radio Frequency Investigation Ltd. Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ England Subject: Certification Application FCC ID: B5KAKRC161028-4 It is requested that the following information is to be held confidential on behalf of Ericsson AB. FCC Rules Part 0.459 refers. Exhibit 5 CPU Part Schematics 1 19 pages Exhibit 5 RF Part Schematics 1 39 pages Justification of this request is in order to protect the large investment in developing this technology and to facilitate the circuit miniaturization utilized in this design and protect the innovative design as well as proprietary techniques which are implemented. In order to protect Ericsson’s competitive advantage on these proprietary techniques, we request the above listed exhibits be held as confidential and withheld from the Public Information File. Yours sincerely Palle Zetterstrand

Limited Internal EXHIBIT 1 1(1) Prepared (also subject responsible if other) No. EAB/RTL/I Palle Zetterstrand B5KAKRC161028-4 Uen Approved Checked Date Rev Reference EAB/RTL/I (P. Zetterstrand) 2004-12-02 A EXHIBIT 1 - ID Label Placement FCC ID: B5KAKRC161028-4 Remote Radio Unit KRC 161 028/4, R1G ID Label Label Placement

Mounting base. Front view Mounting base PSU. Internal view FCC Identifier Label. IXU-21. Front view IXU-21. Back view RRU-H19 EDGE. Front view RRU-H19 EDGE. Back view RRU-H19 EDGE. Open view Radio Access Board. Front view Radio Access Board. Back view Digital Radio Board. Front view Digital Radio Board. Back view Duplex Filter 1. Front view Duplex Filter 1. Back view Duplex Filter 2. Front view Duplex Filter 2. Back view Heater. Front view Heater. Back view PSU. Front view PSU. Back view PSU. Internal view Radio Interface Board. Front view Radio Interface Board. Back view Ground Plane Extender Board. Front view Ground Plane Extender Board. Back view Y Interface Board. Front view Y Interface Board. Back view. Power Interface Board. Front view Power Interface Board. Back view

Limited Internal EXHIBIT 12 1 (9) Prepared (also subject responsible if other) No. EAB/RTL/I Palle Zetterstrand B5KAKRC161028-4 Approved Checked Date Rev Reference EAB/RTL/I (P. Zetterstrand) 2004-12-08 A Exhibit 12 – Cover Sheet Contents 1 2.1033(c) Circuit Description 2 1.1 (2) FCC Identifier: B5KAKRC161028-4 2 1.2 (4) Type of Emission: 2 1.3 (5) Frequency range: 1930.4 to 1989.6 MHz. 2 1.4 (6) Range of Operating Power: 2 1.5 (7) Maximum Power Rating: 2 1.6 (8) Final Amplifier Voltage and Current in normal operation 2 1.7 (10) Frequency Stabilizing Circuit Description 3 1.8 (10) Spurious and Harmonic Suppression 3 1.9 (10) Limiting Power 3 1.10 (10) Digital Modulation 4 1.10.1 Modulation format for GMSK 4 1.10.2 Modulation format for 8PSK 7 Limited Internal EXHIBIT 12 2 (9) Prepared (also subject responsible if other) No. EAB/RTL/I Palle Zetterstrand B5KAKRC161028-4 Approved Checked Date Rev Reference EAB/RTL/I (P. Zetterstrand) 2004-12-08 A 1 2.1033(c) Circuit Description 1.1 (2) FCC Identifier: B5KAKRC161028-4 This RRU (Remote Radio Unit) consist of two synthesized transceivers (TRX) operating in the frequency band of 1930.4 to 1989.6 MHz. There are 297 Channels available with a channel spacing of 200 KHz. The transceiver is capable of operation in a TDMA (Time Division Multiple Access) system. For each channel there are 8 time slots available, each containing digital speech or data for GMSK and data for 8-PSK. The RRU have a hybrid combiner included which combines two TRX:s per antenna. 1.2 (4) Type of Emission: GMSK: 245KGXW 8-PSK: 245KG7W 1.3 (5) Frequency range: 1930.4 to 1989.6 MHz. 1.4 (6) Range of Operating Power: This transmitter is designed to supply a nominal power level of 41.5 dBm at the antenna connector. The power level can be set at 16 power levels, each with a 2 dB increment. The power levels are labeled P(0) to P(15) where P(0) is the highest power level. 1.5 (7) Maximum Power Rating: The maximum power rating with one TRX under environmental and supply voltage variations is equal to 41.5 dBm plus a power level tolerance of +-2 dB. Therefore the maximum output power is 43.5 dBm equal to 22.4 W at the antenna connector of the radio base station. 1.6 (8) Final Amplifier Voltage and Current in normal operation P (0) P (15) Collector Voltage 29.5 Volt DC 29.5 Volt DC Collector Current 2.2 Amps DC 0.4 Amps DC Limited Internal EXHIBIT 12 3 (9) Prepared (also subject responsible if other) No. EAB/RTL/I Palle Zetterstrand B5KAKRC161028-4 Approved Checked Date Rev Reference EAB/RTL/I (P. Zetterstrand) 2004-12-08 A 1.7 (10) Frequency Stabilizing Circuit Description The transmitter in each TRX contains three synthesized oscillators. One PLL gives a 160 MHz signal to the I/Q modulator. The two other generate a 1770 to 1830 MHz signal to the mixer where the modulated signal is converted to the transmit frequency. Two oscillators are needed in frequency hopping mode, one is retuning while the other is active. All three synthesized oscillators have a reference of 13 MHz generated in a central synthesized oscillator (PLL) of 26 MHz, which is downmixed by 2, in the LTU part of the RRU. This PLL frequency reference is locked to a 3.25 MHz clock which is extracted from the multiplexed Y-interface MY. MY is generated and distributed by the IXU (Interface & Switching Unit) to all RRU:s in the base station. The frequency reference 13 MHz in the IXU is generated in a voltage controlled oscillator phase-locked to the incoming PCM-link frequency or as an option an incoming GPS-link frequency. 1.8 (10) Spurious and Harmonic Suppression Spurious and harmonic suppression is achieved by using two separate bandpass filters of ceramic type in the exciter. A filter module at the output works like a bandpass filter around the carrier. In addition to these filters, the output signal passes a cavity band pass filter in the combining system. 1.9 (10) Limiting Power The TRX measures the output power at its output connector via a RF-detector and the detected value is used by the power loop control block to steer two variable gain attenuators between the modulator and the power amplifier. Limited Internal EXHIBIT 12 4 (9) Prepared (also subject responsible if other) No. EAB/RTL/I Palle Zetterstrand B5KAKRC161028-4 Approved Checked Date Rev Reference EAB/RTL/I (P. Zetterstrand) 2004-12-08 A 1.10 (10) Digital Modulation 1.10.1 Modulation format for GMSK 1.10.1.1 Modulating symbol rate The modulating symbol rate is 1/T = 1 625/6 ksymb/s (i.e. approximately 270.833 ksymb/s), which corresponds to 1 625/6 kbit/s (i.e. 270.833 kbit/s). T is the symbol period. 1.10.1.2 Start and stop of the burst Before the first bit of the bursts as defined in GSM 05.02 [3] enters the modulator, the modulator has an internal state as if a modulating bit stream consisting of consecutive ones (d i = 1) had entered the differential encoder. Also after the last bit of the time slot, the modulator has an internal state as if a modulating bit stream consisting of consecutive ones (d i = 1) had continued to enter the differential encoder. These bits are called dummy bits and define the start and the stop of the active and the useful part of the burst as illustrated in figure 1. Nothing is specified about the actual phase of the modulator output signal outside the useful part of the burst. dummy bits Output phase The useful part The active part 000..............000111111..............111111 3 tail bits3 tail bitsdummy bits 1/2 bit1/2 bit Figure 1: Relation between active part of burst, tail bits and dummy bits. For the normal burst the useful part lasts for 147 modulating bits Limited Internal EXHIBIT 12 5 (9) Prepared (also subject responsible if other) No. EAB/RTL/I Palle Zetterstrand B5KAKRC161028-4 Approved Checked Date Rev Reference EAB/RTL/I (P. Zetterstrand) 2004-12-08 A }) 1.10.1.3 Differential encoding Each data value d i = [0,1] is differentially encoded. The output of the differential encoder is: ∃ ({,dddd iiii =⊕∈ −1 01 where…

Text truncated - open the document above for the full version.

Ericssonwide Internal REPORT 1 (4) Prepared (also subject responsible if other) No. KI/EAB/TFF Nina Lövehagen EAB-04:012844 Uen Approved Checked Date Rev Reference 2004-12-17 PA1 Recommendations of EMF Health and Safety Instructions for Ericsson RBS 2109 This document contains EMF health and safety information for the “Safety Instructions” (A) and provides product specific information for RBS 2109 to be included in the “Technical Product Data” (B). The RBS specific information contains compliance boundaries for typical configurations for RBS 2109 with the integral antennas. The RF exposure compliance boundary assessment for RBS 2109 has been performed according to the process described in [1] and reported in [2]. References [1] EAB/TF-03:035, “Ericsson RF exposure compliance assessment process for radio base stations”, Ericssonwide internal description, revision B, June 2004. [2] EAB/TF-04:012835, “RF exposure compliance boundary for the radio base station RBS 2109”, Ericssonwide internal report, revision A, December 2004. Ericssonwide Internal REPORT 2 (4) Prepared (also subject responsible if other) No. KI/EAB/TFF Nina Lövehagen EAB-04:012844 Uen Approved Checked Date Rev Reference 2004-12-17 PA1 A Safety Instructions The following text should be included in the Safety Instructions. For manuals where just a short text is needed section A1.1 should be used. A1 Radio Frequency Exposure Hazards This section provides instructions and information on potential hazards related to radio frequency (RF) electromagnetic field (EMF) exposure from fixed radio transmitters (as opposed to mobile phones). A1.1 General RF Safety Information Caution! Excessive RF exposure can result in potentially adverse health effects. If it is suspected that RF…
