B5KPKRC1311004-1PCS Broadband GSM Base station



    ! " E RBS 2206 Reference Manual RBS 2206 Reference Manual © Ericsson Radio Systems AB — All Rights Reserved — EN/LZT 720 0008 R1A 2001-06-26 1 (421) © Ericsson Radio Systems AB — All Rights Reserved — RBS 2206 Reference Manual Due to continued progress in methodology, design and manufacturing, the contents of this document are subject to revision without notice. 2 (421) EN/LZT 720 0008 R1A 2001-06-26 © Ericsson Radio Systems AB —All Rights Reserved— RBS 2206 Reference Manual Contents 1 Preface ........................................................................................................... 13 1.1 Objectives ................................................................................................ 13 1.2 Target Groups..........................................................................................13 1.3 RBS 2000 Library Overview.................................................................... 13 1.4 How to Order CPI....................................................................................14 2 Product Safety Requirements RBS 2000....................................................17 2.1 References...............................................................................................17 2.2 Product Safety ......................................................................................... 17 3 Environmental Capabilities..........................................................................19 3.1 Scope.......................................................................................................19 3.2 Terminology ............................................................................................. 19 3.3 References...............................................................................................20 3.4 Transport -40  C - +70  C..........................................................................20 3.5 Storage -25  C - +55  C.............................................................................21 3.6 Handling -40  C - +70  C........................................................................... 23 3.7 Operation Indoor +5  C - +40  C ............................................................... 23 3.8 Operation Outdoor -33  C - +40  C ........................................................... 25 3.9 Operation Outdoor -33  C - +45  C ........................................................... 26 3.10 Operation Outdoor -33  C - +55  C ......................................................... 28 3.11 Operation Mast Mounted Equipment -33  C - +45  C.............................28 3.12 Operation Mast Mounted Equipment -33  C - +55  C............................28 4 Radio Configurations, RBS 2206.................................................................31 4.1 Introduction .............................................................................................. 31 4.2 References...............................................................................................32 4.3 Definitions ................................................................................................ 32 4.4 Frequency Bands.....................................................................................34 4.5 RF Properties...........................................................................................34 4.6 Basic Configurations................................................................................35 4.7 Site Cell Configurations ........................................................................... 67 4.8 Co-Siting with RBS 200 or RBS 2000 Macro Cabinet............................74 EN/LZT 720 0008 R1A 2001-06-26 3 (421) © Ericsson Radio Systems AB — All Rights Reserved — RBS 2206 Reference Manual 5 Product Data..................................................................................................79 5.1 Site Equipment Overview ........................................................................ 79 5.2 Site Power Options..................................................................................80 5.3 Power Connections..................................................................................80 5.4 RBS 2206 Cabinet Hardware Description...............................................84 5.5 External Alarm and Transmission Interface ............................................ 93 5.6 BBS 2000 Rack Description.................................................................... 96 5.7 Antenna System ...................................................................................... 98 6 Unit Description, DXU-21 ............................................................................. 117 6.1 System Environment................................................................................117 6.2 Block Diagram ......................................................................................... 118 6.3 Functions ................................................................................................. 120 6.4 External Interfaces...................................................................................120 6.5 Dimensions and Weight...........................................................................124 7 Unit Description, dTRU.................................................................................125 7.1 Block Diagram ......................................................................................... 125 7.2 Functions ................................................................................................. 126 7.3 External Interfaces...................................................................................127 7.4 Technical Data.........................................................................................128 8 Unit Decription, CDU-G and CDU-F ............................................................ 1…

Text truncated - open the document above for the full version.

Datum/Date Beteckning/Reference Sida/Page 2001-06-26 F115942-24 1 (4) FCC ID: B5KPKRC13111004-1 Exhibit 3 Photos RBS 2206 24 Volt DC system Front view Rear view Open door view Datum/Date Beteckning/Reference Sida/Page 2001-06-26 F115942-24 2 (4) FCC ID: B5KPKRC13111004-1 Exhibit 3 Top shelf view Upper middle shelf view Datum/Date Beteckning/Reference Sida/Page 2001-06-26 F115942-24 3 (4) FCC ID: B5KPKRC13111004-1 Exhibit 3 Lower middle shelf view Bottom shelf view Datum/Date Beteckning/Reference Sida/Page 2001-06-26 F115942-24 4 (4) FCC ID: B5KPKRC13111004-1 Exhibit 3 Transceiver Unit KRC 131 1004/1, R1C Front side Rear side Bottom side

Datum/Date Beteckning/Reference Sida/Page 2001-10-08 1 (1) Exhibit 1 FCC ID:B5KPKRC1311004-1 FCC ID Label FCC ID label placement

Datum/Date Beteckning/Reference Sida/Page 2001-10-08 1 (5) FCC ID: B5KPKRC13111004-1 Exhibit 9 Transceiver Unit KRC 131 1004/1, R1C Front side Rear side Bottom side Datum/Date Beteckning/Reference Sida/Page 2001-10-08 2 (5) FCC ID: B5KPKRC13111004-1 Exhibit 9 ID Label Main board Datum/Date Beteckning/Reference Sida/Page 2001-10-08 3 (5) FCC ID: B5KPKRC13111004-1 Exhibit 9 Main board- PCB component side Main board- PCB rear side Datum/Date Beteckning/Reference Sida/Page 2001-10-08 4 (5) FCC ID: B5KPKRC13111004-1 Exhibit 9 PA1- PCB components side PA1- PCB rear side Datum/Date Beteckning/Reference Sida/Page 2001-10-08 5 (5) FCC ID: B5KPKRC13111004-1 Exhibit 9 PA2- PCB components side PA2- PCB rear side

Open EXHIBIT 12 1 (6) Prepared (also subject responsible if other) No. ERA/RKN/TR Larry Lindström B5KPKRC1311004-1 Approved Checked Date Rev Reference KI/ERA/RKN/TR (L Lindström) 2001-10-04 A Exhibit 12 – Cover Sheet Contents 1 2.1033(c).......................................................................................2 1.1 (2) FCC Identifier: B5KPKRC1311004-1.......................................2 1.2 (4) Type of Emission: 210KGXW...................................................2 1.3 (5) Frequency range: 1930 to 1990 MHz.......................................2 1.4 (6) Range of Operating Power:......................................................2 1.5 (7) Maximum Power Rating:..........................................................2 1.6 (8) Final Amplifier Voltage and Current in normal operation..........2 1.7 (10) Frequency Stabilizing Circuit Description...............................3 1.8 (10) Spurious and Harmonic Suppression.....................................3 1.9 (10) Limiting Power.......................................................................3 1.10 (10) Digital Modulation..................................................................4 Open EXHIBIT 12 2 (6) Prepared (also subject responsible if other) No. ERA/RKN/TR Larry Lindström B5KPKRC1311004-1 Approved Checked Date Rev Reference KI/ERA/RKN/TR (L Lindström) 2001-10-04 A 1 2.1033(c) 1.1 (2) FCC Identifier: B5KPKRC1311004-1 This dTRU (double Tranceiver Radio Unit) consist of two synthesized transmitters (TRX) operating in the frequency band of 1930 to 1990 MHz. There are 299 Channels available with a channel spacing of 200 KHz. This is a constant envelop transmitter using GMSK 0.3 modulation, which is MSK filtered with a Gaussian filter ,having a BT product of 0.3. The transmitter is capable of operation in a TDMA (Time Division Multiple Access) system. For each channel there are 8 time slots available,each containing digital speech or data. The dTRU have a hybrid combiner included which can be used to increase the number of TRX:s per antenna. This combiner is connected before the cavity band pass filter in the combining system. 1.2 (4) Type of Emission: 210KGXW 1.3 (5) Frequency range: 1930 to 1990 MHz 1.4 (6) Range of Operating Power: This transmitter is designed to supply a nominal power level of 44.5 dBm at the antenna connector. The power level can be set at 16 power levels, each with a 2 dB increment. The power levels are labeled P(0) to P(15) where P(0) is the highest power level. 1.5 (7) Maximum Power Rating: The maximum power rating under environmental and supply voltage variations is equal to 44.5 dBm plus a power level tolerance of + 1.3 dB. Therefore the maximum output power is 45.8 dBm equal to 38 W at the antenna connector of the radio base station. 1.6 (8) Final Amplifier Voltage and Current in normal operation P (0) P (15) Collector Voltage 26.0 Volt DC 26.0 Volt DC Collector Current 4.9 Amps DC 0.7 Amps DC Open EXHIBIT 12 3 (6) Prepared (also subject responsible if other) No. ERA/RKN/TR Larry Lindström B5KPKRC1311004-1 Approved Checked Date Rev Reference KI/ERA/RKN/TR (L Lindström) 2001-10-04 A 1.7 (10) Frequency Stabilizing Circuit Description The transmitter in each TRX contains three synthesized oscillators. One PLL gives a 160 MHz signal to the I/Q modulator. The two other generate a 1770 to 1830 MHz signal to the mixer where the modulated signal is converted to the transmit frequency. Two oscillators are needed in frequency hopping mode, one is retuning while the other is active. All three synthesized oscillators have a reference of 13 MHz, which is downmixed by 2, generated in a central synthesized oscillator (PLL) of 26 MHz in the LTU part of the dTRU. This PLL frequency reference is extracted from the 13 MHz signal on the Y-link, which is generated and distributed, by the DXU (Distribution Switch Unit), to all dTRU:s in the basestation. The frequency reference 13 MHz in the DXU is generated in a voltage controlled oscillator placed in an oven together with and phase-locked to a long term stable oven heated oscillator. As an option can the oscillator be phase-locked to the incoming PCM-link frequency or an incoming GPS-link frequency. 1.8 (10) Spurious and Harmonic Suppression Spurious and harmonic suppression is achieved by using two separate bandpass filters of ceramic type in the exciter. A filter module at the output works like a bandpass filter around the carrier. In addition to these filters, the output signal passes a cavity band pass filter in the combining system. 1.9 (10) Limiting Power The TRU measures the output power at its output connector via a RF-detector and the detected value is used by the power loop control block to steer two variable gain amplifiers beteween the modulator and the power amplifier. Open EXHIBIT 12 4 (6) Prepared (also subject responsible if other) No. ERA/RKN/TR Larry Lindström B5KPKRC1311004-1 Approved Checked Date Rev Reference KI/ERA/RKN/TR (L Lindström) 2001-10-04 A 1.10 (10) Digital Modulation The modulation description is given in PN3389 Air Interface: Volume 1 section 4. PN3389 Air Interface: Volume 1 JTC(AIR)/94.10.31-231 R5 4. Modulation This chapter defines the theoretical requirements of the modulator, inclusive of the differential encoder. The modulator receives the bits from the encryption unit and produces an RF modulated signal. The information bits are first differentially encoded and then passed to the modulator. The modulation is GMSK (Gaussian Minimum Shift Keying) with a BT product of 0.3. 4.1 Modulation Format 4.1.1 Modulating Bit Rate The modulating bit rate is 1/T = 1625/6 kb/s (approximately 270.633 kb/s). 4.1.2 Start And Stop Of The Burst The bits contained within a burst are defined in chapter 2. For the purpose of the modulator specification that follows, the bits entering the differential encoder prior to the first bit of the burst and following the last bit of the burst are consecutive logical ones and are denoted by t…

Text truncated - open the document above for the full version.

Open EXHIBIT 101 (21) Prepared (also subject responsible if other)No. ERA/RKN/TR Larry LindströmB5KPKRC1311004-1 ApprovedCheckedDateRevReference KI/ERA/RKN/TR (L Lindström)2001-10-04A Exhibit 10 – Cover Sheet Contents 12.1033 (c) (10) Function of Active Circuit Devices.........................2 1.1Printed Board RSU 1900 MHz GMSK ROA 117 8461/1................2 1.1.1Function Block LTU.......................................................................2 1.1.2Function Block DC/DC..................................................................3 1.1.3Function Block Rx Frontend 1900 MHz.........................................5 1.1.4Function Block RX IF1 GMSK 1900 MHz......................................7 1.1.5Function Block RX IF2 GMSK 1900 MHz......................................8 1.1.6Function Block CPU......................................................................9 1.1.7Function Block SPARC 1 GMSK.................................................10 1.1.8Function Block SPARC 2 GMSK.................................................11 1.1.9Function Block TX1 GMSK 1900 MHz.........................................12 1.1.10Function Block TX2 GMSK 1900 MHz.........................................13 1.2Printed Board PBU1 1900 GMSK Hybrid Combiner ROA 219 5387/114 1.2.1Function Block DC Booster.........................................................14 1.2.2Function Block PA Linearisation GMSK PBU1900.....................16 1.2.3Function Block PA, PBU 1900.....................................................17 1.2.4Function Block Hybrid Combiner, PBU 1900...............................18 1.3Printed Board PBU1 1900 GMSK wo Hybrid Combiner ROA 219 5388/1 ....................................................................................................19 1.3.1Function Block DC Booster.........................................................19 1.3.2Function Block PA Linearisation GMSK PBU1900.....................19 1.3.3Function Block PA, PBU 1900.....................................................19 22.1033(c)(9) Tune-Up Procedure................................................20 32.1033(c)(9,10) Power Tune-Up – Power Limiting.......................21 Open EXHIBIT 102 (21) Prepared (also subject responsible if other)No. ERA/RKN/TR Larry LindströmB5KPKRC1311004-1 ApprovedCheckedDateRevReference KI/ERA/RKN/TR (L Lindström)2001-10-04A 1 2.1033 (c) (10) Function of Active Circuit Devices 1.1 Printed Board RSU 1900 MHz GMSK ROA 117 8461/1 1.1.1 Function Block LTU Product ROZ 104 033/1 Revision D PosProd name/DesProduct number V500DIODE/SCHx2 70V 70mA SOT23 SerialRKZ 323 08/2 Z500MICROCIRCUIT/REG LIN+ ADJ 1.8-20V +/-1% 500RYT 113 6303/1 Z501MICROCIRCUIT/74'74 AC SOP14 2xD FLIP-FLOPRYT 318 0074/C Z503MICROCIRCUIT/MB15E07 PFV-ERRYT 102 6057/1 Z504OSCILLATOR/26.000MHZRTL 202 610/02 Z505MICROCIRCUIT/74'04 LVC SSOP14 6x INVERTERRYT 331 0004/C Z506MICROCIRCUIT/74'04 ACT TSSOP14 6x INVERTER RYT 317 6004/22C Z507MICROCIRCUIT/74'04 ACT TSSOP14 6x INVERTER RYT 317 6004/22C Open EXHIBIT 103 (21) Prepared (also subject responsible if other)No. ERA/RKN/TR Larry LindströmB5KPKRC1311004-1 ApprovedCheckedDateRevReference KI/ERA/RKN/TR (L Lindström)2001-10-04A 1.1.2 Function Block DC/DC Product ROZ 104 032/1 Revision PM5 PosProd name/DesProduct number T700TRANSFORMER/PLANARTRANSFORMER T40REG 735 305/2 T702TRANSFORMER/PLANARTRANSFORMER T25REG 735 304/2 V700RECTIFIER/SCHx2 30V 2x15A D2PAKRKZ 323 6012/3 V702RECTIFIER/SCHx2 30V 2x6A DPAK(TO252AA)RKZ 323 6047/1 V703OVERVOLTAGE PROTECTION/DIODE TS 36V 30A DO-214AB RKZ 223 485/36 V708DIOD/DIODE 200V 1A 35ns SMARKZ 123 05/2 V709DIOD/DIODE 200V 1A 35ns SMARKZ 123 05/2 V710TRANSISTOR/NFET 100V 6A SO8 0.026ohmRYN 123 6032/1 V711TRANSISTOR/NFET 100V 6A SO8 0.026ohmRYN 123 6032/1 V712TRANSISTOR/NFET 100V 6A SO8 0.026ohmRYN 123 6032/1 V714TRANSISTOR/NFET 30V 14A 0.008ohm SO8RYN 123 6012/1 V715TRANSISTOR/NFET 30V 14A 0.008ohm SO8RYN 123 6012/1 V716TRANSISTOR/NFET 30V 14A 0.008ohm SO8RYN 123 6012/1 V717TRANSISTOR/NFET 30V 14A 0.008ohm SO8RYN 123 6012/1 V718TRANSISTOR/NFET 30V 14A 0.008ohm SO8RYN 123 6012/1 V719TRANSISTOR/NFET 30V 14A 0.008ohm SO8RYN 123 6012/1 V720TRANSISTOR/NFET 30V 14A 0.008ohm SO8RYN 123 6012/1 V721TRANSISTOR/NFET 30V 14A 0.008ohm SO8RYN 123 6012/1 V722RECTIFIER/SCH 25V 10A SMBRKZ 323 6038/1 V723RECTIFIER/SCH 25V 10A SMBRKZ 323 6038/1 V724RECTIFIER/SCH 25V 10A SMBRKZ 323 6038/1 V725RECTIFIER/SCH 25V 10A SMBRKZ 323 6038/1 V727TRANSISTOR/N chanl. MOSFETRYN 123 251/C V728TRANSISTOR/N chanl. MOSFETRYN 123 251/C V729DIOD/DIODE 75V 250mA SOT23 BAS16RKZ 123 612 V730DIOD/DIODE 75V 250mA SOT23 BAS16RKZ 123 612 V736REGLERDIOD/REG 12.0V 6% 0.2W SOT-23RKZ 223 01/18 V738ÖVERSPÄNNINGSSKYDD/DIODE TS 36V 30A DO- 214AB RKZ 223 485/36 V746DIOD/DIODE 75V 250mA SOT23 BAS16RKZ 123 612 V747DIOD/DUAL SERIES 70V .2A 6ns SOT-23RKZ 123 03/1 V748DIOD/DUAL SERIES 70V .2A 6ns SOT-23RKZ 123 03/1 V749TRANSISTOR/NFET 100V 6A SO8 0.026ohmRYN 123 6032/1 Z703MICROCIRCUIT/REG SW- ADJ 150kHz 0.5ARYT 113 6320/1 Z705MICROCIRCUIT/LM431 ADJ REGULATORRYT 113 008/3C Z709MICROCIRCUIT/REG SW- 1.26-2.5V +/-1.2% 20ARYT 113 6175/1 Z710MICROCIRCUIT/PWM CURR.-M 5.0V +/-1.5% 1MHzRYT 113 6053/4 Z711MICROCIRCUIT/PWM CURR.-M 5.0V +/-1.5% 1MHzRYT 113 6053/4 Open EXHIBIT 104 (21) Prepared (also subject responsible if other)No. ERA/RKN/TR Larry LindströmB5KPKRC1311004-1 ApprovedCheckedDateRevReference KI/ERA/RKN/TR (L Lindström)2001-10-04A Z712MICROCIRCUIT/VOLTAGE REG, INVERTING, -5VRYT 113 256/C Z851MICROCIRCUIT/COMP x2 36VRYT 101 6169/1 Z853MICROCIRCUIT/COMP x2 36VRYT 101 6169/1 Z854MICROCIRCUIT/COMP x2 36VRYT 101 6169/1 Z855MICROCIRCUIT/COMP x2 36VRYT 101 6169/1 Z856MICROCIRCUIT/SUP.V 2.93V L/NIN RESETRYT 113 6166/2 Z857MICROCIRCUIT/COMP x2 36VRYT 101 6169/1 Z858MICROCIRCUIT/MOSFET DRIV. x2 IN/NONINRYT 109 6204/1 Z859MICROCIRCUIT/MOSFET DRIV. x2 IN/NONINRYT 109 6204/1 Z860MICROCIRCUIT/OPAMP 2.5V/30V R/R 21MHzRYT 101 6339/1 Z861MICROCIRCUIT/OPAMP 2.5V/30V R/R 21MHzRYT 101 6339/1 Open EXHIBIT 105 (21) Prepared…

Text truncated - open the document above for the full version.
