FCC ID: BBD3-2XG-H 1 Application for Certification For an RF Power Amplifier TPL Communications 3370 San Fernando Rd. #206 Los Angeles, CA 90065 VHF Amplifier: Part # PA3-2EG-HMS FCC ID: BBD3-2XG-H REPORT # RA054894/10078 This report was prepared in accordance with the requirements of the FCC Rules and Regulations Part 2, Subpart J, 2.1031 through 2.1057, Part 90 and other applicable sections of the rules as indicated herein. Prepared By: Fred Gurule DNB Engineering, Inc. 3535 W. Commonwealth Ave. Fullerton, CA 92833 20 JANUARY 2001 FCC ID: BBD3-2XG-H 2 TABLE OF CONTENTS Section Title Sheet # 1.0ADMINISTRATIVE DATA3 1.1Certificatio ns a nd Q ua lificatio ns3 1.2Meas ure me nts a nd Repea tab ility Info rma tio n3 Note: Paragraph numbers in this report follow the application section numbers found in the FEDERAL COMMUNICATIONS COMMISSION Rules and Regulations, Part 2, Subpart J for Certification of electronic equipment. 2.1033 (C) (1)Application for Certification4 2.1033 (C) (2)FCC Identifier4 2.1033 (C) (3)Installation and Operating Instructions4 2.1033 (C) (4)Type of Emissions4 2.1033 (C) (5)Frequency Range5 2.1033 (C) (6)Operating Power5 2.1033 (C) (7)Maximum Power Allowed in Applicable part(s) of the Rules5 2.1033 (C) (8)Final RF Amplifier Input Power C haracteristics5 2.1033 (C) (9)Tune Up Procedure5 2.1033 (C) (10)Schematic Diagram and C ircuit Description6 - 9 2.1033 (C) (11)Equipment Identification Plate10 2.1033 (C) (12) Equipment Photographs11 - 14 2.1033 (C) (13)Digital Modulation Techniques15 2.1033 (C) (14)Test Data16 2.1046Measurement of RF Power Output15 2.1049Measurement of Occupied Bandwidth17 - 19 FIGURE 1 :BLOCK DIAGRAM (Occ up ied Ba nd wid th te sts )18 2.1051Spurious Emissions at Antenna Terminals20 - 24 FIGURE 2: BLOCK DIAGRAM (Spurious Emissions tests)21 2.1053Measurement of Field Strength of Spurious Radiation25 Table 1: Field Strength of Spurious Radiation26 2.1055Measurement of Frequency Stability28 2.1057Frequency Spectrum to be Investigated28 APPENDIX AService/Operating ManualA1 - A18 FCC ID: BBD3-2XG-H 3 1.0ADMINISTRATIVE DATA 1.1Certifications and Qualifications I certify that DNB Engineering, Inc conducted the tests performed in order to obtain the technical data presented in this application. Also, based on the results of the enclosed data, I have concluded that the equipment tested meets or exceeds the requirements of the Rules and Regulations governing this application. 1.2Measurement Repeatability Information The test data presented in this report has been acquired using the guidelines set forth in FCC Part 2.1031 through 2.1057, Part 90. The test results presented in this document are valid only for the equipment identified herein under the test conditions described. Repeatability of these test results will only be achieved with identical measurement conditions. These conditions include: The same test distance, EUT Height, Measurement Site Characteristics, and the same EUT System Components. The system must have the same Interconnecting Cables arranged in identical placement to that in the test set-up, with the system and/or EUT functioning in the identical mode of operation (i.e. software and so on) as on the date of the test. Any deviation from the test conditions and the environment on the date of the test may result in measurement repeatability difficulties. All changes made to the EUT during the course of testing as identified in this test report must be incorporated into the EUT or identical models to ensure compliance with the FCC regulations. Bryan Broaddus (Para. 1.1) Manager, Test Dept. DNB Engineering, Inc. Tel. (714) 870-7781 FAX (714) 870-5081 FCC ID: BBD3-2XG-H 4 2.1033 (C) (1)Application for Certification Name of Applicant:TPL Communications 3370 San Fernando Rd. #206 Los Angeles, CA 90065 Applicant is:XManufacturer Vendor Licensee Prospective Licensee Other Description: VHF Amplifier Part Number: PA3-2EG-HMS Anticipated Production Quantity: Multiple Units 2.1033 (C) (2)FCC Identifier FCC ID: BBD3-2XG-H 2.1033 (C) (3)Installation and Operating Instructions See the Service Manual Included in Appendix A herein for the complete description. 2.1033 (C) (4)Type of Emission F3E FCC ID: BBD3-2XG-H 5 2.1033 (C) (5)Frequency Range 160 MHz 2.1033 (C) (6)Operating Power 500 Watts 2.1033 (C) (7)Maximum Power Allowed in Applicable Part(s) of the Rules RULES PARTMAXIMUM POWER (WATTS) Part 90.205500 Watts (ERP) 2.1033 (C) (8)Final RF Amplifier Input Power Characteristics Input Voltage: 26.4 Vdc Nominal Input Current:33.6 Adc Nominal 2.1033 (C) (9) Tune Up Procedure Refer to Figure in Appendix A. FCC ID: BBD3-2XG-H 6 2.1033 (C) (10) Schematic Diagram and Circuit Description FCC ID: BBD3-2XG-H 7 FCC ID: BBD3-2XG-H 8 FCC ID: BBD3-2XG-H 9 FCC ID: BBD3-2XG-H 10 FCC ID: BBD3-2XG-H 11 FCC ID: BBD3-2XG-H 12 2.1033 (C) (11)Equipment Identification Plate _______________________________________ VHF AMPLIFIER MODEL NO. PA3-2EG-HMS VOLTAGE 110/220 VAC 50-400 Hz PWR OUTPUT: 500W FCC ID: BBD3-2XG-H SERIAL NO.__________ TPL CORPORATION MADE IN USA NOTES: Label will be constructed of 0.02 inch aluminum as shown on the equipment with permanent adhesive. All information on the label will be etched or stamped. Both methods will exceed the expected lifetime of the equipment. The label will be large enough to allow all information to be legible. FCC ID: BBD3-2XG-H 13 2.1033 (C) (11) Equipment Photographs Note: The Main Circuit Board shown in these photos has no components on the reverse side. Photo 1Main Circuit Board (Overall View) Photo 2Main Circuit Board (Detail) Photo 3External Front and Back View FCC ID: BBD3-2XG-H 14 Photo 1Main Circuit Board (Overall View) FCC ID: BBD3-2XG-H 15 Photo 2Main Circuit Board (Detail) FCC ID: BBD3-2XG-H 16 Photo 3External Front and Back View FCC ID: BBD3-2XG-H 17 2.1033 (C) (13) Digital Modulation Techniques _________________________________ __________ Not Applicable 2.1033 (c) (14)Test Data Refer to 2.1046 through 2.1057 2.1046Measurement…
