Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Authority to Act as Agent to the Federal Communications Commission On our behalf, I appoint KTL Ottawa to act as agent in the preparation of this application for equipment authorization to the Federal Communications Commission. I certify that submitted Exhibits properly describe the device or system for which equipment authorization is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. Dated this 16 Day of April 1999 Agency agreement expiration date: By: _____________________Sydney J Ludwig Title: Manager Documentation Administration Telephone: 1-804-386-5215 Applicant: Allen Telecom Systems
Master: ktlPT22H Date: February 23, 1999 KTL Test Report:8R01061.2 Applicant:Allen Telecom Group 140 Vista Centre Drive Forest, Virginia 24551 USA Equipment Under Test:TFB 815 Booster Amp (E.U.T.) FCC ID:BCR-BCEL-815BA In Accordance With:FCC Part 22, Subpart H Cellular Band Repeaters Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: T. Tidwell, Laboratory Manager Date: Total Number of Pages:108 KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-BCEL-815BA Page 2 of 95 Table of Contents Section 1. Summary of Test Results General Summary of Test Data Section 2. General Equipment Specification Specifications Description of Modifications for Class II Permissive Change Modifications Made During Testing Theory of Operation System Diagram Section 3. RF Power Output Test Results Measurement Data Power Over Bandwidth Graphs Section 4. Occupied Bandwidth Occupied Bandwidth (Voice + SAT) Test Results Test Data Voice + SAT Input and Ouput Graphs Occupied Bandwidth (WB Data) Test Results Test Data Wideband Data Input and Ouput Graphs Occupied Bandwidth (ST) Test Results Test Data ST Input and Ouput Graphs Occupied Bandwidth (Digital Mod.) Test Results Test Data Digital Mod. Input and Ouput Graphs Section 5. Spurious Emissions at Antenna Terminals Test Results Test Data Graphs KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-BCEL-815BA Page 3 of 95 Table of Contents, continued Section 6. Field Strength of Spurious Test Results Test Data Test Data - Radiated Emissions - Uplink Test Data - Radiated Emissions - Downlink Photographs of Test Setup Pre-Scan Data Section 7. Frequency Stability Test Results Measurement Data Graphs Section 8. Test Equipment List Annex A - Test Methodologies RF Power Output Occupied Bandwidth (Voice & SAT) Occupied Bandwidth (WB Data) Occupied Bandwidth (ST) Occupied Bandwidth (Digital Modulation) Spurious Emission at Antenna Terminals Field Strength of Spurious Radiation Frequency Stability Annex B - Test Diagrams R.F. Power Output Occupied Bandwidth Spurious Emissions at Antenna Terminals Field Strength of Spurious Radiation Frequency Stability KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-BCEL-815BA Page 4 of 95 Section 1.Summary of Test Results Manufacturer:Allen Telecom Group Model No.:TFB 815 Serial No.:Demo 1 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 22, Subpart H. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit AMP Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Kevin Carr, Technologist KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-BCEL-815BA Page 5 of 95 Summary Of Test Data NAME OF TESTPARA. NO.SPEC.MEAS.RESULT RF Power Output22.913(a)500W ERPPlotComplies Occupied Bandwidth (Voice & SAT)22.917(c)Mask CPlotComplies Occupies Bandwidth (Wideband Data)22.917(d)Mask DPlotComplies Occupied Bandwidth (ST)22.917(d)Mask DPlotComplies Occupied Bandwidth (Digital)NoneInput vs. OutputPlotComplies Spurious Emissions at Antenna Terminals 22.917-13 dBmPlotComplies Field Strength of Spurious Emissions22.917-13 dBm E.I.R.P. ChartComplies Frequency Stability22.3551.5 ppmN/AN/A Footnotes For N/A’s: Test Conditions: Indoor Temperature: 22 °C Humidity:21 % Outdoor Temperature: 15 °C Humidity:21 % . KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-BCEL-815BA Page 6 of 95 Section 2.General Equipment Specification Supply Voltage Input: 120 VAC, 60 Hz Frequency Range:Downlink: 869.04 – 893.97 MHz Frequency Range:Uplink: 824.04 – 848.97 MHz 20 dB Bandwidth: Type of Modulation and CDMAGSMNADCCDPDAMPS Designator: (F9W)(GXW)(DXW)(F9W)(F8W, F1D) AGC Threshold: Not Applicable Output Impedance: 50 ohm Gain:Uplink: 2 dB Nominal Downlink: 14.5 dB Nominal Max Input Power: Not Applicable UplinkDownlink (dBm) RF Output (Rated):Single: 8.418.2 Composite: 5.4 / 2 Carrier15.2 / 2 Carrier Frequency Translation: F1-F1F1-F2N/A Band Selection: SoftwareDuplexer Change Fullband Coverage KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-BCEL-815BA Page 7 of 95 Description of Modifications For Class II Permissive Change KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-BCEL-815BA Page 8 of 95 Modifications Made During Testing KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-BCEL-815BA Page 9 of 95 Theory of Operation The RF Booster (TFB 815) is intended to enhance the transmit power capabilities of the BriteCell remote transceivers. System Diagram LNA KTL Ottawa FCC PART 22, SUBPART H CELLULAR BAND REPEATERS PROJECT NO.: 8R01061.2 EQUIPMENT: TFB 815 Booster Amp FCC ID: BCR-…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output | Emission |
|---|---|---|---|---|
| 1 | 22H | 824.04 MHz - 848.97 MHz | 6.90 mW | F1D |
