BCR-RPT-AMR906BOOSTER

Nemko Test Report: 6L0432RUS9rev1 Applicant: Andrew Corporation 108 Rand Park Drive Garner, NC 27529 USA Equipment Under Test: AMR906 (E.U.T.) In Accordance With: CFR 47 Part 90, Subpart I And CFR 47 Part 24, Subpart D Tested By: Nemko USA Inc. 802 N. Kealy Lewisville, TX 75057-3136 TESTED BY: DATE: 25 September 2006 David Light Wireless Engineer APPROVED BY: DATE: 29 September 2006 Kevin Rose Wireless Engineer Number of Pages: 44 Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 2 of 42 Table of Contents SECTION 1. SUMMARY OF TEST RESULTS 3 SECTION 2. GENERAL EQUIPMENT SPECIFICATION 5 SECTION 3. RF POWER OUTPUT 7 SECTION 4. OCCUPIED BANDWIDTH 8 SECTION 5. SPURIOUS EMISSIONS AT ANTENNA TERMINALS 17 SECTION 6. FIELD STRENGTH OF SPURIOUS EMISSIONS 30 SECTION 7. TEST EQUIPMENT LIST 32 ANNEX A - TEST METHODOLOGIES 33 ANNEX B - TEST DIAGRAMS 41 Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 3 of 42 Section 1. Summary of Test Results Manufacturer: Andrew Corporation Model No.: AMR906 Serial No.: None General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with CFR 47, Part 90, Subpart I and Part 24, Subpart D. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 4 of 42 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. RESULT RF Power Output 90.205 1000 W Complies RF Power Output 24.132 7 W Complies Occupied Bandwidth 90.210 Input/Output Complies Occupied Bandwidth Not specified Input/Output Complies Spurious Emissions at Antenna Terminals 90.210 Plots Complies Spurious Emissions at Antenna Terminals 24.133 -13 dBm Complies Field Strength of Spurious Emissions 90.210 -13 dBm Complies Field Strength of Spurious Emissions 24.133 -13 dBm Complies Frequency Stability 90.213 1 ppm NA Frequency Stability 24.135 1 ppm NA Footnotes For N/A’s: (1) Since the E.U.T. does not contain modulation circuitry modulation testing was not performed. (2) Since the E.U.T. is not a keyed carrier system, Transient Frequency Behavior was not performed. . Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 5 of 42 Section 2. General Equipment Specification Transmitter Supply Voltage Input: 120 Vac Frequency Range: Downlink: 935 to 941 MHz Uplink: 896 to 902 MHz Tunable Bands: Type(s) of Modulation: F3E/F1D (Analog) D7W (QAM) Other Gain: 89 dB Max Output Impedance: 50 ohms RF Power Output (rated): DL: 0.50 W 27 dBm UL: 0.32 W 25 dBm Operator Selection of Operating Frequency: None Power Output Adjustment Capability: ALC Frequency Translation: F1-F1 F1-F2 N/A Band Selection: SoftwareDuplexer Change Fullband Coverag e Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 6 of 42 Description of EUT Bi-directional amplifier used to enhance signals between a mobile and a base station in a wireless network. Typical applications are coverage improvement in small and medium sized environments such as offices, store fronts, underground floors, and small manufacturing facilities. The AMR family will automatically set its gain to maximize performance. However, an alphanumeric interface allows the user to manually set the gain if desired. ALC, Automatic Level Control, is incorporated to prevent overdriving the amplifier. System Diagram Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 7 of 42 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 2.1046 TESTED BY: David Light DATE: 25 August 2006 Test Results: Complies. Measurement Data: Direction Modulation Output per Channel (dBm) Composite Power (dBm) Composite Power (W) Uplink Analog 22.03 25.03 0.32 Downlink Analog 24.01 27.01 0.50 Uplink iDEN 22.05 25.05 0.32 Downlink iDEN 24.02 27.02 0.50 Equipment Used: 1082-1469-1472-1659 Measurement Uncertainty: +/- 1.7 dB Temperature: 22 °C Relative Humidity: 31 % Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 8 of 42 Section 4. Occupied Bandwidth NAME OF TEST: Occupied Bandwidth PARA. NO.: 2.1049 TESTED BY: David Light DATE: 25 August 25 2006 Test Results: Complies. Test Data: See attached plot(s). Equipment Used: 1082-1469-1472-1659-1036 Measurement Uncertainty: 1X10 -7 ppm Temperature: 22 °C Relative Humidity: 31 % Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 9 of 42 Test Data – Occupied Bandwidth OBW – DL Analog 2.5 kHz Tone/3 kHz Deviation Output A Offset 30.6 dB LVL Ref 30 dBmAtt 30 dB FRQ 5 kHz/Center 938 MHzSpan 50 kHz * RBW 300 Hz VBW 1 kHz SWT 560 ms EXT 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 30 Date: 25.AUG.2006 13:44:40 Nemko USA, Inc. CFR 47 PART 90, SUBPART I and PART 24, SUBPART D EQUIPMENT: AMR906 PROJECT NO.:6L0432RUS9rev1 Page 10 of 42 Test Data – Occupied Bandwidth OBW – DL Analog Input Nemko USA, Inc. CFR 47 PART 90, SUB…
