BCR-RPT-MR803PPBooster

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 800MHz Maximum peak output power at antenna input terminal:34.00 (dBm) Maximum peak output power at antenna input terminal: 2511.886(mW) Antenna gain(typical):5 (dBi) Maximum antenna gain: 3.162278(numeric) Prediction distance:35(cm) Prediction frequency:850 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 0.533333(mW/cm^2) Power density at prediction frequency: 0.516005(mW/cm^2) 2 4R PG S π =

Nemko Test Report: 4L0457RUS1REV1 Applicant: Andrew Corporation Equipment Under Test: MR803P-TR Repeater (E.U.T.) In Accordance With: FCC Part 90, Subpart I Private Land Mobile Repeater Tested By: Nemko USA Inc. 802 N. Kealy Lewisville, TX 75057-3136 Authorized By: Tom Tidwell, Frontline Manager Date: 10/7/04 Total Number of Pages: 85 Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE REPEATER EQUIPMENT: MR803P-TR Repeater PROJECT NO.: 4L0457R Page 2 of 85 Table of Contents Section 1. Summary of Test Results...................................................................................................... 3 Section 2. General Equipment Specification......................................................................................... 5 Section 3. RF Power Output .................................................................................................................. 8 Section 4. Occupied Bandwidth ............................................................................................................9 Section 5. Spurious Emissions at Antenna Terminals......................................................................... 43 Section 6. Field Strength of Spurious Emissions ................................................................................ 68 Section 7. Frequency Stability.............................................................................................................. 74 Section 8. Test Equipment List ...........................................................................................................75 ANNEX A - TEST METHODOLOGIES ................................................................................................. 76 ANNEX B - TEST DIAGRAMS .............................................................................................................. 82 Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE REPEATER EQUIPMENT: MR803P-TR Repeater PROJECT NO.: 4L0457R Page 3 of 85 Section 1. Summary of Test Results Manufacturer: Andrew Corporation Model No.: MR803P-TR Serial No.: 011 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 90, Subpart I. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE REPEATER EQUIPMENT: MR803P-TR Repeater PROJECT NO.: 4L0457R Page 4 of 85 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. MEAS. RESULT RF Power Output 90.205 39.02 Complies Audio Frequency Response TIA EIA-603.3.2.6 N/A N/A N/A Audio Low-Pass Filter Response TIA EIA-603.3.2.6 N/A N/A N/A Modulation Limiting TIA EIA-603.3.2.6 N/A N/A N/A Occupied Bandwidth 90.210 Plots Plots Complies Spurious Emissions at Antenna Terminals 90.210 -13 dBm Plots Complies Field Strength of Spurious Emissions 90.210 -13 dBm E.R.P. E.R.P. Complies Frequency Stability 90.213 Complies Transient Frequency Behavior 90.214 N/A N/A N/A Footnotes For N/A’s: (1) Since the E.U.T. does not contain modulation circuitry modulation testing was not performed. (2) Since the E.U.T. is not a keyed carrier system, Transient Frequency Behavior was not performed. Indoor Temperature: 21°C Humidity: 51% Outdoor Temperature: 19 °C Humidity: 65 % . Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE REPEATER EQUIPMENT: MR803P-TR Repeater PROJECT NO.: 4L0457R Page 5 of 85 Section 2. General Equipment Specification Transmitter Supply Voltage Input: 115V AC Frequency Range: 806-824MHz 851-869MHz Tunable Bands: 806-824MHz 851-869MHz Type(s) of Modulation: F3E (Voice) F1D F2D GXW (iDEN) Other Maximum Input: +0dBm Output Impedance: NA RF Power Output (rated): Single: +34dBm Composite: +24dBm (2-Carrier) Frequency Translation: F1-F1 F1-F2 N/A Band Selection: Software Duplexer Change Fullband Coverage Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE REPEATER EQUIPMENT: MR803P-TR Repeater PROJECT NO.: 4L0457R Page 6 of 85 Modifications Made During Testing No Modifications made during testing Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE REPEATER EQUIPMENT: MR803P-TR Repeater PROJECT NO.: 4L0457R Page 7 of 85 System Diagram Repeater BTS Mobile Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE REPEATER EQUIPMENT: MR803P-TR Repeater PROJECT NO.: 4L0457R Page 8 of 85 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 2.985 TESTED BY: Dustin Oaks DATE: 07/29/2004 Test Results: Complies Measurement Data: iDEN Frequency (MHz) Measured Power (dBm) Rated Power (dBm) UL806 27.02 27 UL824 27.06 27 DL851 27.01 27 DL869 27.16 27 Analog Frequency (MHz) Measured Power (dBm) Rated Power (dBm) UL806 34.00 34 UL821 34.00 34 DL851 34.02 34 DL866 34.09 34 Equipment Used: 1036, 1052, 1053, 1626, 1627, 1964, 1092 Measurement Uncertainty: +/- 1.6dB Temperature: 21 °C Relative Humidity: 51 % Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE REPEATER EQUIPMENT: MR803P-TR Repeater PROJECT NO.: 4L0457R Page 9 of 85 Section 4. Occupied Bandwidth NAME OF TEST: Occupied Bandwidth PARA. NO.: 2.989 TESTED BY: Dustin Oaks DATE: 07/29/2004 Test Results: Complies Test Data: See attached graph(s). Equipment Used: 1036, 1052, 1053, 1626, 1627, 1964, 1092, 1073, 1051, 0973 Measurement Uncertainty: +/- …

Text truncated - open the document above for the full version.

Downlink Uplink

Dallas Headquarters: 802 N. Kealy Lewisville, TX 75057 Tel: (972) 436-9600 Nemko Dallas, Inc.Fax: (972) 436-2667 Page 1 of 1 Job No.:4L0457Date: 10/20/2005 Specification:90.213Temperature(°C): 20 Tested By:David LightRelative Humidity(%) 50 E.U.T.: Configuration: Sample Number:1 Antenna:Directional Coupler: Pre-Amp:Cable #1:1629 Filter:Cable #2: Receiver:1026Environmental Chamber:283 Attenuator #1 Attenuator #2: Measurement Uncertainty: 1x10 -17 ppmStandard Test FrequencyMHz Rho Test FreqeuncyLimitError Voltage Error (Hz)(+/-Hz)(ppm)Comment 20 1200860.00Downlink 20138.00860.00.0 20102.00860.00.0 50 1200860.00.0 40 1200860.00.0 30 1200860.00.0 10120.00860.00.0 0120.00860.00.0 -10120.00860.00.0 -20 1200860.00.0 -30 1200860.00.0 Notes: Measured Frequency (MHz) 860.000000 860.000000 Frequency Stability SMR REPEATER TX CW Test Equipment Used Temp ( O C) 860.000000 There was no frequency drift. 860.000000 860.000000 860.000000 860.000000 860.000000 860.000000 860.000000 860.000000 860.000000 Dallas Headquarters: 802 N. Kealy Lewisville, TX 75057 Tel: (972) 436-9600 Nemko Dallas, Inc.Fax: (972) 436-2667 Page 1 of 1 Job No.:4L0457Date: 10/20/2005 Specification:90.213Temperature(°C): 20 Tested By:#N/ARelative Humidity(%) 50 E.U.T.: Configuration: Sample Number:1 Antenna:Directional Coupler: Pre-Amp:Cable #1:1629 Filter:Cable #2: Receiver:1026Environmental Chamber:283 Attenuator #1 Attenuator #2: Measurement Uncertainty: 1x10 -17 ppmStandard Test FrequencyMHz Rho Test FreqeuncyLimitError Voltage Error (Hz)(+/-Hz)(ppm)Comment 20 1200813.00Uplink 20138.00813.00.0 20102.00813.00.0 50 1200813.00.0 40 1200813.00.0 30 1200813.00.0 10120.00813.00.0 0120.00813.00.0 -10120.00813.00.0 -20 1200813.00.0 -30 1200813.00.0 Notes: 813.000000 There was no frequency drift. 813.000000 813.000000 813.000000 813.000000 813.000000 813.000000 813.000000 813.000000 813.000000 813.000000 813.000000 Temp ( O C) Measured Frequency (MHz) Frequency Stability SMR REPEATER TX CW Test Equipment Used
