BEJL177WSBSLCD Monitor

Make sure to read the Important Precautionsbefore using the product. Keep the User's Guide(CD) in an accessible place for future reference. See the label attached on the product and give the information to your dealer when you ask for service. L177WSB User’s Guide A1 This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. On Safety Use only the power cord supplied with the unit. In case you use another power cord, make sure that it is certified by the applicable national standards if not being provided by the supplier. If the power cable is faulty in any way, please contact the manufacturer or the nearest authorized repair service provider for a replacement. The power supply cord is used as the main disconnection device. Ensure that the socket-outlet is easily accessible after installation. Operate the display only from a power source indicated in the specifications of this manual or listed on the display. If you are not sure what type of power supply you have in your home, consult with your dealer. Overloaded AC outlets and extension cords are dangerous. So are frayed power cords and broken plugs. They may result in a shock or fire hazard. Call your service technician for replacement. Do not Open the Display. There are no user serviceable components inside. There are Dangerous High Voltages inside, even when the power is OFF. Contact your dealer if the display is not operating properly. To Avoid Personal Injury : Do not place the display on a sloping shelf unless properly secured. Use only a stand recommended by the manufacturer. Do not drop an object on or apply impact to the product. Do not throw any toys or objects on the product screen. It can cause injury to human, problem to product and damage the display. To Prevent Fire or Hazards: Always turn the display OFF if you leave the room for more than a short period of time. Never leave the display ON when leaving the house. Keep children from dropping or pushing objects into the display's cabinet openings. Some internal parts carry hazardous voltages. Do not add accessories that have not been designed for this display. When the display is to be left unattended for an extended period of time, unplug it from the wall outlet. In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very dangerous. It can cause electric shock. Important Precautions A2 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. Displays are provided with ventilation openings in the cabinet to allow the release of heat generated during operation. If these openings are blocked, built-up heat can cause failures which may result in a fire hazard. Therefore, NEVER: Block the bottom ventilation slots by placing the display on a bed, sofa, rug, etc. Place the display in a built-in enclosure unless proper ventilation is provided. Cover the openings with cloth or other material. Place the display near or over a radiator or heat source. Main power breaker is the power cord and this breaking device must be located at a location where it is easy to operate. Do not rub or strike the Active Matrix LCD with anything hard as this may scratch, mar, or damage the Active Matrix LCD permanently. Do not press the LCD screen with your finger for a long time as this may cause some afterimages. Some dot defects may appear as Red, Green or Blue spots on the screen. However, this will have no impact or effect on the display performance. If possible, use the recommended resolution to obtain the best image quality for your LCD display. If used under any mode except the recommended resolution, some scaled or processed images may appear on the screen. However, this is characteristic of the fixed-resolution LCD panel. On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. On Repacking Do not throw away the carton and packing materials. They make an ideal container in which to transport the unit. When shipping the unit to another location, repack it in its original material. On Disposal The fluorescent lamp used in this product contains a small amount of mercury. Do not dispose of this product with general household waste. Disposal of this product must be carried out in accordance to the regulations of your local authority. Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTRERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY NOTE This epuipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can radiate radio frequency cause harmful interference to radio communications.However,there is no guarantee that interference will not occur in a particular installation.If this which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and the receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. energy and,if not i…

Text truncated - open the document above for the full version.

Block diagram LVDS LVDS LVDS Analog (R/G/B) D-Sub LIPS Filter 5V 12V 5V Regulator Regulator 3.3V 5V-Mod 3.3V Inverter( 2Lamps ) 12V 12V Analog(Vsync/Hsync) KEY 1.8V 1.8V Module SDATA/SCLK EEPROM (System) EEPROM (System) 3.3V 1440*900@60Hz Dual Interface Engine Display Processing Engine LVDS Panel Interface OSD Clock Generator MCU Flash ROM Flash ROM 3.3V Crystal Crystal 14.318MHz interface TSUMU58CWHL Crystal ： HUA LIAN XING; TXC CORPORATION (alternate) Regulation ： 14.31818MHZ 30PPM 20pF INPUT: 120V 60Hz FUNDAMENTAL OPERATION FR EQUENCY IS 0.030-0.083 MHz .

FIGURE 1 LCD MONITOR (M/N: L177WSBS) GENERAL APPEARANCE (FRONT VIEW) FIGURE 2 LCD MONITOR (M/N: L177WSBS) GENERAL APPEARANCE (BACK VIEW) FIGURE 3 LCD MONITOR (M/N: L177WSBS) PORTS FIGURE 4 LCD MONITOR (M/N: L177WSBS) D-SUB CABLE FIGURE 5 LCD MONITOR (M/N: L177WSBS) POWER CORD

Label Location Information Refer to the below red arrow: (For example)

FLATRON L177WSB-BFFLATRON L177WSB-BF

FIGURE 1 LCD MONITOR (M/N: L177WSBS) COVER REMOVED FIGURE 2 LCD MONITOR (M/N: L177WSBS) BOARDS REMOVED FIGURE 3 LCD MONITOR (M/N: L204WS) LED BOARD FRONT FIGURE 4 LCD MONITOR (M/N: L177WSBS) LED BOARD BACK FIGURE 5 LCD MONITOR (M/N: L177WSBS) BUTTON BOARD FRONT FIGURE 6 LCD MONITOR (M/N: L177WSBS) BUTTON BOARD BACK FIGURE 7 LCD MONITOR (M/N: L177WSBS) MAIN BOARD (COMPONENT SIDE) FIGURE 8 LCD MONITOR (M/N: L177WSBS) MAIN BOARD (SOLDERED SIDE) FIGURE 9 LCD MONITOR (M/N: L177WSBS) CHIP ON MAIN BOARD FIGURE 10 LCD MONITOR (M/N: L177WSBS) CRYSTAL ON MAIN BOARD FIGURE 11 LCD MONITOR (M/N: L177WSBS) POWER BOARD (COMPONENT SIDE) FIGURE 12 LCD MONITOR (M/N: L177WSBS) POWER BOARD (SOLDERED SIDE) FIGURE 13 LCD MONITOR (M/N: L177WSBS) LCD PANEL MAIN BOARD SHIELDED SHELL REMOVED FIGURE 14 LCD MONITOR (M/N: L177WSBS) LCD PANEL MAIN BOARD (FRONT VIEW) FIGURE 15 LCD MONITOR (M/N: L177WSBS) LABEL ON LCD PANEL MAIN BOARD FIGURE 16 LCD MONITOR (M/N: L177WSBS) LABEL ON LCD PANEL FIGURE 17 LCD MONITOR (M/N: L177WSBS) CHIP ON LCD PANEL MAIN BOARD FIGURE 18 LCD MONITOR (M/N: L177WSBS) LABEL ON LCD PANEL MAIN BOARD FIGURE 19 LCD MONITOR (M/N: L177WSBS) DEBUG

LG Electronics U.S.A Inc. FCC ID: BEJL177WSBS Page 1 of 24 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F07025 Application for FCC Certificate On Behalf of LG Electronics U.S.A Inc. LCD Monitor Model No.: L177WSBS Serial No.: E07060801 FCC ID : BEJL177WSBS Prepared For : LG Electronics U.S.A Inc. 2000 Millbrook Dr. Lincolnshire, IL 60069 United States Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F07025 Date of Test : Jun 08 - 14, 2007 Date of Report : Jun 16, 2007 LG Electronics U.S.A Inc. FCC ID: BEJL177WSBS Page 2 of 24 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F07025 TABLE OF CONTENTS Page 1 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 4 1.1 Description of Standards and Results......................................................................................... 4 2 GENERAL INFORMATION.......................................................................................................... 5 2.1 Description of Equipment Under Test........................................................................................5 2.2 Supported Simulators ................................................................................................................. 5 2.3 Description of Test Facility ........................................................................................................ 7 2.4 Measurement Uncertainty .......................................................................................................... 7 3 CONDUCTED EMISSION TEST .................................................................................................. 8 3.1 Test Equipment........................................................................................................................... 8 3.2 Block Diagram of Test Setup ..................................................................................................... 8 3.3 Conducted Emission Limit [FCC Part 15 Subpart B 15.107(a)]................................................ 9 3.4 Test Configuration...................................................................................................................... 9 3.5 Operating Condition of EUT .................................................................................................... 10 3.6 Test Procedures ........................................................................................................................ 10 3.7 Test Results .............................................................................................................................. 11 4 RADIATED EMISSION TEST..................................................................................................... 15 4.1 Test Equipment......................................................................................................................... 15 4.2 Block Diagram of Test Setup ................................................................................................... 15 4.3 Radiated Emission Limit [FCC Part 15 Subpart B 15.109(a)]................................................. 16 4.4 Test Configuration.................................................................................................................... 16 4.5 Operating Condition of EUT .................................................................................................... 16 4.6 Test Procedures ........................................................................................................................ 17 4.7 Test Results .............................................................................................................................. 18 5 DEVIATION TO TEST SPECIFICATIONS .............................................................................. 23 6 DEBUG DESCRIPTION ...............................................................................................................24 LG Electronics U.S.A Inc. FCC ID: BEJL177WSBS Page 3 of 24 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F07025 TEST REPORT FOR FCC CERTIFICATE Applicant : LG Electronics U.S.A Inc. Manufacturer : LG Electronics Nanjing Display Co., Ltd.. EUT Description : LCD Monitor (A) Model No. : L177WSBS (B) Serial No. : E07060801 (C) Power Supply : 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART B CLASS B 2006.10 AND ANSI C63.4-2003 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart B (Class B) and ICES-003, Issue 4 February 2004 (CISPR 22:2002) limits both radiated and conducted emissions. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. This report shows that the EUT (M/N: L177WSBS; S/N: E07060801) which was tested in 3m anechoic chamber on Jun 08 - 14, 2007 is technically compliance with the FCC official limits also. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report contains data that are not covered by the NVLAP accreditation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Date of Test : Jun 08 - 14, 2007 Prepared By: ALAN HE / Assistant Reviewer: SAMMY CHEN / Deputy Assistant Manager Approved Signatory: BYRON KWO / Manager LG Electronics U.S.A Inc. FCC ID: BEJL177WSBS Page 4 of 24 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F07025 1 SUMMARY OF STANDARDS AND RESULTS 1.1 Description of Standards and Results …

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test FRONT VIEW SIDE VIEW 2. Radiated Electromagnetic Emission Test FRONT VIEW OF RADIATED EMISSION TEST (LOW FREQUENCY) BACK VIEW OF RADIATED EMISSION TEST (LOW FREQUENCY) FRONT VIEW OF RADIATED EMISSION TEST (HIGH FREQUENCY) BACK VIEW OF RADIATED EMISSION TEST (HIGH FREQUENCY) SETUP WITH MAXIMUM DETECTED EMISSION AT HORIZONTAL POLARIZATION (VGA 1440*900@75HZ, LOW FREQUENCY) SETUP WITH MAXIMUM DETECTED EMISSION AT VERTICAL POLARIZATION (VGA 1440*900@75HZ, LOW FREQUENCY)
