BEJLX350Tri-Mode Dual-Band Phone (AMPS/CDMA) w/ Bluetooth

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Oct 04, 2005
Application Purpose: Original Equipment
Date of Application: Oct 04, 2005
Equipment Note: Tri-Mode Dual-Band Phone (AMPS/CDMA) w/ Bluetooth
Frequency Range: 1851.25000000 - 1908.75000000
Company: LG Electronics USA, Inc.
Country: United States
